Search Results (21)

In contrast to traditional hydrogels, which are susceptible to water evaporation and structural degradation, non-hydrogel materials are engineered for superior stability and consistent performance. Here, we report an innovative piezoelectric polyvinyl chloride/multi-walled carbon nanotube polymer gel (PVC/MWCNT polymer gel, PMPG) with exceptional linearity (as low as 1.31%), high sensitivity (50–310.17 mV), rapid response (172–189 ms), and thermal stability. Under strain induction, ordered rearrangement of dipoles in PMPG and the enhancement of MWCNTs generate a potential difference. Increasing MWCNT content enhances output voltage, sensitivity, conductivity, maximum stress, Young’s modulus, and toughness, while reducing nonlinear error. Higher dibutyl adipate (DBA) content increases output voltage and slightly improves sensitivity but decreases mechanical strength. The optimal PMPG (PVC:DBA = 1:5, 1 wt% MWCNTs) exhibited outstanding performance. It exhibits a nonlinear error as low as 1.31%, a conductivity of 25.4 μS/cm, an 80% compressive strain tolerance (273 kPa stress), and dimensional stability for 90 days in air. By integrating PMPG with machine learning algorithms, soft robotic grippers gain advanced contact perception capabilities, enabling applications in medicine, rescue, exploration, and other fields requiring fine manipulation and adaptability. This work highlights PMPG’s potential as a stable, high-performance material for soft robotics and beyond. Full article

This paper proposes a multifunctional soft robotic gripper for a Dobot robot to handle sensitive products. The gripper is based on pneumatic network (PneuNet) bending actuators. In this study, two different models of PneuNet actuators have been studied, designed, simulated, experimentally tested, and validated using two different techniques (3D printing and molding) and three different materials: FilaFlex 60A (3D-printed), Elastosil M4601, and Dragonskin Fast 10 silicones (with molds). A new soft gripper design for the Dobot robot is presented, and a new design/production approach with molds is proposed to obtain the gripper’s PneuNet multifunctional actuators. It also describes a new control approach that is used to control the PneuNet actuators and gripper function, using compressed air generated by a small compressor/air pump, a pressure sensor, a mini valve, etc., and executing on a low-cost controller board—Arduino UNO. This paper presents the main simulation and experimental results of this research study. Full article

Traditional electric robots often rely on heavy gear units or expensive force–torque sensors, whereas pneumatic robots offer a cost-effective and simple alternative. However, their dependence on noisy and bulky pneumatic systems, such as compressed air technology, limits their portability and adaptability. To overcome these challenges, we have developed a reversible electrochemical pneumatic battery (REPB) that is compact, noise-free, energy-efficient, and portable. This innovative REPB, principled by the electrochemical redox reactions of zinc–air batteries, can simultaneously supply both electric and pneumatic power, either positive or negative pressure. Its modular, multi-stack structure allows for the easy customization of power output and capacity to suit various applications. We demonstrate the utility of REPB through its application in jamming robots, such as a novel soft yet robust gripper that merges the strengths of hard and soft grippers, enabling universal robotic gripping. This work presents a groundbreaking approach to powering devices that require pneumatic support. Full article

Real-time multi-axis distributed tactile sensing is a critical capability if robots are to perform stable gripping and dexterous manipulation, as it provides crucial information about the sensor–object interface. In this paper, we present an optical-based six-axis tactile sensor designed in a fingertip shape for robotic dexterous manipulation. The distributed sensor can precisely estimate the local XYZ force and displacement at ten distinct locations and provide the global XYZ force and torque measurements. Its compact size, comparable to that of a human thumb, and minimal thickness allow seamless integration onto existing robotic fingers, eliminating the need for complex modifications to the gripper. The proposed sensor design uses a simple, low-cost fabrication method. Moreover, the optical transduction approach uses light angle and intensity sensing to infer force and displacement from deformations of the individual sensing units that form the overall sensor, providing distributed six-axis sensing. The local force precision at each sensing unit in the X, Y, and Z axes is 20.89 mN, 19.19 mN, and 43.22 mN, respectively, over a local force range of approximately ±1.5 N in X and Y and 0 to −2 N in Z. The local displacement precision in the X, Y, and Z axes is 56.70 μm, 50.18 μm, and 13.83 μm, respectively, over a local displacement range of ±2 mm in the XY directions and 0 to −1.5 mm in Z (i.e., compression). Additionally, the sensor can measure global torques, $T_x$, $T_y$, and $T_z$, with a precision of of 1.90 N-mm, 1.54 N-mm, and 1.26 N-mm, respectively. The fabricated design is showcased by integrating it with an OnRobot RG2 gripper and illustrating real-time measurements during in simple demonstration task, which generated changing global forces and torques. Full article

In recent times, the soft robotics field has been attracting significant research focus owing to its high level of manipulation capabilities unlike traditional rigid robots, which gives room for increasing use in other areas. However, compared to traditional rigid gripper robots, being capable of controlling/obtaining overall body stiffness when required is yet to be further explored since soft gripper robots have inherently less-rigid properties. Unlike previous designs with very complex variable-stiffness systems, this paper demonstrates a soft gripper design with minimum system complexity while being capable of varying the stiffness of a continuum soft robotic actuator and proves to have potential applications in gripping objects of various shapes, weights, and sizes. The soft gripper actuator comprises two separate mechanisms: the pneumatic mechanism for bending control and the mechanical structure for stiffness variation by pulling tendons using stepper motors which compresses the actuator, thereby changing the overall stiffness. The pneumatic mechanism was first fabricated and then embedded into another silicon layer during which it was also merged with the mechanical structure for stiffness control. By first pneumatically actuating the actuator which causes bending and then pulling the tendons, we found out that the actuator stiffness value can be increased up to 145% its initial value, and the gripper can grasp and lift a weight of up to 2.075 kg. Full article

This research presents a comprehensive study on the design and implementation of a flexible robotic gripper. Conventional grippers utilized in articulated robotic arms are often limited in their capabilities, being restricted to specific tasks or fixed object sizes. While soft grippers are a viable option, they have limitations in terms of grasping objects across a wide range and providing complete coverage. In this study, a novel compressible gripper is developed to enable safe and secure grasping of objects with varying sizes and shapes within a wide range. The gripper features a grasping area measuring 14 cm × 6 cm, allowing complete coverage of objects within this surface area. The current prototype with 7 cm of compressibility demonstrates the ability to grasp objects with a width difference of 7 cm with a maximum thickness of 15 cm, enabling manipulation of objects with varying widths, as defined by user-programmable parameters. The functionality of the gripper is based on the compressibility of the 3D-printed thermoplastic polyurethane (TPU) material. The flexible part of the gripper can be easily interchanged, offering versatility by accommodating different thicknesses without the need to replace the entire gripper mechanism. The gripper system operates using an open-loop control system, enhancing user-friendliness. Experimental evaluation of the gripper involved the creation and analysis of a CAD model followed by the fabrication of a prototype. The prototype exhibited exceptional performance in grasping objects of diverse sizes, shapes, and textures, demonstrating the effectiveness of the developed soft gripper system. The scalability of the soft gripper enables seamless integration with various types of articulated robotic arms, while the maximum weight limit for objects will be defined based on the robotic arms’ limitations. The research findings highlight the promising capabilities of the compressible gripper in enhancing the versatility and efficiency of robotic grasping systems, offering a significant contribution to the field of robotics. Full article

This paper introduces a new gripper mechanism that is capable of grasping objects of various sizes and shapes without the need for a closed-loop control system. Industries such as the food and beverage industry are seeking innovative soft grippers with a simplified control system. The proposed design utilizes a rotary mechanism with springs to achieve both force-closure and form-closure grasping. The design sets itself apart from most soft grippers with its ability to offer grasping forces in all lateral directions. The gripper is designed in a cylindrical shape and is actuated by a stepper motor with a gearbox to enhance the torque. Three stacked curvilinear and linear rails convert the motor’s rotational motion into linear motion. The grasping component consists of three curved parts, each incorporating numerous compression springs. Currently, the gripper can effectively grasp objects ranging from five to nine centimeters in diameter, with a maximum height of ten centimeters. However, the design is scalable based on specific application requirements. A comprehensive CAD model of the mechanism was developed, and multiple analyses were conducted, including motion, topology, and stress analyses. Finally, a functional prototype of the gripper was constructed and successfully tested for grasping fruits and vegetables of different sizes and shapes. This research can be further expanded to explore the application of the gripper in space exploration with its novel and completely electro-mechanical foundation. Full article

This study proposes a novel variable air pressure supply structure based on the electromagnetic effect. This structure can be implemented in various soft robots driven by air pressure, including pneumatic artificial muscles, pneumatic soft grippers, and other soft robots. The structure’s main body comprises a hollow circular tube, a magnetic piston arranged in the tube, and an electromagnetic solenoid nested outside the tube. The electromagnetic solenoid is designed with special winding and power supply access modes, generating either an attractive force or a repulsive force on the magnetic piston. This solenoid conforms with the magnetic piston expectation in the tube by changing the polarity direction. The interior of the whole structure is a closed space. The gas is conveyed to the soft robot by the gas guide hoses at the two ends of the structure, and the expansion energy of the compressed gas is fully utilized. Then, the gas supply pressure is controlled to drive the robot. The mathematical model of the structure is established based on the analysis of the electromagnetic force and gas pressure on the piston. The simulation results show that the structure’s inherent vibration characteristics under various parameters align with expectations. The real-time automatic optimization of the controller parameters is realized by optimizing the incremental proportional-integral-derivative (PID) controller based on a neural network. The simulation results show that the structure can meet the application requirements. The experimental results show that the proposed gas supply structure can provide a continuous pressure supply curve with any frequency in a specific amplitude range and has an excellent tracking effect on the sinusoidal-like pressure curve. Full article

In this study, a comprehensive approach for sensing object stiffness through the pincer grasping of soft pneumatic grippers (SPGs) is presented. This study was inspired by the haptic sensing of human hands that allows us to perceive object properties through grasping. Many researchers have tried to imitate this capability in robotic grippers. The association between gripper performance and object reaction must be determined for this purpose. However, soft pneumatic actuators (SPA), the main components of SPGs, are extremely compliant. SPA compliance makes the determination of the association challenging. Methodologically, the connection between the behaviors of grasped objects and those of SPAs was clarified. A new concept of SPA modeling was then introduced. A method for stiffness sensing through SPG pincer grasping was developed based on this connection, and demonstrated on four samples. This method was validated through compression testing on the same samples. The results indicate that the proposed method yielded similar stiffness trends with slight deviations in compression testing. A main limitation in this study was the occlusion effect, which leads to dramatic deviations when grasped objects greatly deform. This is the first study to enable stiffness sensing and SPG grasping to be carried out in the same attempt. This study makes a major contribution to research on soft robotics by progressing the role of sensing for SPG grasping and object classification by offering an efficient method for acquiring another effective class of classification input. Ultimately, the proposed framework shows promise for future applications in inspecting and classifying visually indistinguishable objects. Full article

About 8% of the Ecuadorian population suffers some type of amputation of upper or lower limbs. Due to the high cost of a prosthesis and the fact that the salary of an average worker in the country reached 248 USD in August 2021, they experience a great labor disadvantage and only 17% of them are employed. Thanks to advances in 3D printing and the accessibility of bioelectric sensors, it is now possible to create economically accessible proposals. This work proposes the design of a hand prosthesis that uses electromyography (EMG) signals and neural networks for real-time control. The integrated system has a mechanical and electronic design, and the latter integrates artificial intelligence for control. To train the algorithm, an experimental methodology was developed to record muscle activity in upper extremities associated with specific tasks, using three EMG surface sensors. These data were used to train a five-layer neural network. the trained model was compressed and exported using TensorflowLite. The prosthesis consisted of a gripper and a pivot base, which were designed in Fusion 360 considering the movement restrictions and the maximum loads. It was actuated in real time thanks to the design of an electronic circuit that used an ESP32 development board, which was responsible for recording, processing and classifying the EMG signals associated with a motor intention, and to actuate the hand prosthesis. As a result of this work, a database with 60 electromyographic activity records from three tasks was released. The classification algorithm was able to detect the three muscle tasks with an accuracy of 78.67% and a response time of 80 ms. Finally, the 3D printed prosthesis was able to support a weight of 500 g with a safety factor equal to 15. Full article

We present a high-performance flexible bending strain sensor for directional motion detection of human hands and soft robotic grippers. The sensor was fabricated using a printable porous conductive composite composed of polydimethylsiloxane (PDMS) and carbon black (CB). The utilization of a deep eutectic solvent (DES) in the ink formulation induced a phase segregation between the CB and PDMS and led to a porous structure inside the printed films after being vapored. This simple and spontaneously formed conductive architecture provided superior directional bend-sensing characteristics compared to conventional random composites. The resulting flexible bending sensors displayed high bidirectional sensitivity (gauge factor of 45.6 under compressive bending and 35.2 under tensile bending), negligible hysteresis, good linearity (>0.99), and excellent bending durability (over 10,000 cycles). The multifunctional applications of these sensors, including human motion detection, object-shape monitoring, and robotic perceptions, are demonstrated as a proof-of-concept. Full article

We investigated the effect of partial dehydration under mechanical stress in the properties of alginate hydrogels. For this aim, we characterized the mechanical properties of the hydrogels under tensile and shear stress, as well as their swelling behavior, macroscopic appearance, and microscopic structure. We found that the processes of dehydration under a mechanical stress were irreversible with fully rehydration being impossible. What is more, these processes gave rise to an enhancement of the mechanical robustness of the hydrogels beyond the effect due to the increase in polymer concentration caused by dehydration. Finally, we analyzed the applicability of these results to alginate-based magnetic hydrogel grippers that bended in response to an applied magnetic field. Remarkably, our study demonstrated that the dehydration of the magnetic hydrogels under compression facilitated their bending response. Full article

The soft gripper has received extensive attention, due to its good adaptability and flexibility. The dielectric elastomer (DE) actuator as a flexible electroactive polymer that provides a new approach for soft grippers. However, they have the disadvantage of having a poor rigidity. Therefore, the optimization design method of a rigid-flexible soft finger is presented to improve the rigidity of the soft finger. We analyzed the interaction of the rigid and soft materials, using the finite element method (FEM), and researched the influence of the parameters (compression of the spring and pre-stretching ratio of the DE) on the bending angle. The optimal parameters were obtained using the FEM. We experimentally verified the accuracy of the proposed method. The maximum bending angle is 19.66°. Compared with the theoretical result, the maximum error is 3.84%. Simultaneously, the soft gripper with three fingers can grasp various objects and the maximum grasping quality is 11.21 g. Full article

Forceps, clamps, and haemostats are essential surgical tools required for all surgical interventions. While they are widely used to grasp, hold, and manipulate soft tissue, their metallic rigid structure may cause tissue damage due to the potential risk of applying excessive gripping forces. Soft pneumatic surgical grippers fabricated by silicone elastomeric materials with low Young’s modulus may offer a promising solution to minimize this unintentional damage due to their inherent excellent compliance and compressibility. The goal of this work is to evaluate and compare the grip-induced nerve damage caused by the soft pneumatic elastomeric gripper and conventional haemostats during surgical manipulation. Twenty-four Wistar rats (male, seven weeks) are subjected to sciatic nerve compression (right hind limb) using the soft pneumatic elastomer gripper and haemostats. A histopathological analysis is conducted at different time-points (Day 0, Day 3, Day 7 and Day 13) after the nerve compression to examine the morphological tissue changes between the rats in the ‘soft gripper’ group and the ‘haemostats’ group. A free walking analysis is also performed to examine the walking function of the rats after recovery from different time points. Comparing the rigid haemostats and soft gripper groups, there is a visible difference in the degree of axonal vacuolar degeneration between the groups, which could suggest the presence of substantial nerve damage in the ‘haemostats’ group. The rats in the haemostats group exhibited reduced right hind paw pressure and paw size after the nerve compression. It shows that the rats tend not to exert more force on the affected right hind limb in the haemostats group compared to the soft gripper group. In addition, the stance duration was reduced in the injured right hind limb compared to the normal left hind limb in the haemostats group. These observations show that the soft pneumatic surgical gripper made of silicone elastomeric materials might reduce the severity of grip-induced damage by providing a safe compliant grip compared to the conventional haemostats. The soft pneumatic elastomer gripper could complement the current surgical gripping tool in delicate tissue manipulation. Full article

Electroadhesion is a suitable technology for developing grippers for applications where fragile, compliant or variable shape objects need to be grabbed and where a retention action is typically preferred to a compression force. This article presents a self-sensing technique for electroadhesive devices (EAD) based on the capacitance measure. Specifically, we demonstrate that measuring the variation of the capacitance between electrodes of an EAD during the adhesion can provide useful information to automatically detect the successful grip of an object and the possible loss of adhesion during manipulation. To this aim, a dedicated electronic circuit is developed that is able to measure capacitance variations while the high voltage required for the adhesion is activated. A test bench characterization is presented to evaluate the self-sensing of capacitance during different states: (1) the EAD is far away from the object to be grasped; (2) the EAD is in contact with the object, but the voltage is not active (i.e., no adhesion); and (3) the EAD is activated and attached to the object. Correlation between the applied voltage, object material and shape and capacitance is made. The self-sensing EAD is then demonstrated in a closed-loop robotic application that employs a robot manipulator arm to pick and place objects of different kinds. Full article
