This paper presents a novel Continuous Variable Transmission (CVT) design. CVT is highly beneficial for actuators with rotary output as it can improve the energy efficiency of the actuators by providing an optimum transmission ratio. This property of CVT is highly beneficial for fossil-fuel-based vehicles, electric vehicles, wind turbines, industrial robots, etc. With the exception of Spherical CVT and DH CVT, all known CVTs like push belt CVTs, toroidal CVTs, Milner CVTs, etc., require additional gear sets and clutches for direction reversal and neutral gear ratio. However, Spherical CVT and DH CVT have low torque capacity due to a single traction point constraint. Foregoing in view, a new CVT named CAD CVT has been developed. The paper presents the design conception, the operating principle, the transmission ratio, the torque capacity, frictional losses, and experimental verification of the basic functionality by manufacturing a Proof of Concept (PoC). The proposed CVT is the only CVT capable of independent direction reversal and high torque capacity as it can transmit torque through multiple traction points. The new CVT will significantly impact high-torque applications in different engineering applications, especially land transport consisting of heavy vehicles like trucks, buses, and trailers. Full article

The driving comfort and safety of the automotive powertrain are significantly related to the performance, lifetime, and functionality of the lubricant. The presented study focuses on investigating the performance loss of the lubricant due to water contamination resulting from environmental influences and iron particles originating from the wear of different machine elements. The main purpose is to determine critical factors that contribute to the degradation of the lubricant, and increase the tendency to NVH behavior, leading to adverse comfort losses to the respective user. Therefore, this performance loss is evaluated by test rig-based analysis of the friction behavior of wet clutches. Due to physical adsorption, a significant impact of water and iron contamination on the degradation of the lubricant is found, while the influence of the energy input is secondary. Full article

To improve the driving comfort of continuously variable transmission (CVT) tractors, the shifting quality of hydrostatic power-split transmission with a standard planetary gear set was optimized. Firstly, the powertrain of the CVT and two shift strategies, direct-shift and bridge-shift, were introduced; then, a dynamic model of tractor shifting was constructed, and the models of key components such as wet clutches and proportional pressure valves were experimentally verified. Finally, the control parameters of the above two shifting strategies were optimized, and the acceleration impact and sliding energy loss caused by them were compared. The results showed the following: the minimum peak acceleration of the bridge-shift method was 0.385807 m/s²; the energy consumption of the bridge-shift method was significantly lower than that of the direct-shift method; the sliding friction work of clutches decreased by 14.92% and 75.84%, respectively, while their power loss decreased by 22.82% and 74.48%, respectively. Full article

In order to improve the working quality of wet clutch switching in an agricultural tractor, in this paper, we took a power shift system composed of multiple wet clutches as the research object for full-factorial performance measurement, multi-factor analysis of the degree of influence, establishment of a single evaluation index model, formation of a comprehensive evaluation index, and formulation of adjustable factor control strategies. We studied the simulation test platform of an agricultural tractor power transmission system based on the SimulationX software and obtained 225 sets of sample data under a full-use condition. Partial least squares and range analysis were applied to comprehensively analyze the influence of multiple factors on the working quality of wet clutches. In this paper, we proposed a modeling method for a single evaluation index of the wet clutch (combined with polynomial regression and tentative method, the goal is determined in the form of a model with the maximum coefficient of determination) and two control strategy optimization methods for the wet clutch adjustable factors, i.e., Method 1 (integrated optimization) and Method 2 (step-by-step optimization), both methods were based on an improved genetic algorithm. The results showed that oil pressure, flow rate, and load had significant effects on the dynamic load characteristics (the degrees were 0.38, −0.44, and −0.63, respectively, with a negative sign representing an inverse correlation); rate of flow and load had significant effects on speed drop characteristics (the degrees were −0.56 and 0.73, respectively). A multivariate first-order linear model accurately described the dynamic load characteristics (R² = 0.9371). The accuracy of the dynamic load characteristic model was improved by 5.5037% after adding the second-order term and interaction term of oil pressure. The polynomial model containing the first-order oil pressure, first-order flow rate, second-order flow rate, and interaction terms could explain the speed drop characteristics, with an R² of 0.9927. If agricultural tractors operate under medium and large loads, the oil pressure and flow rate in their definitional domains should be small and large values, respectively; if operating under small loads, both oil pressure and flow rate should be high. When the wet clutch dynamic load and speed drop characteristics were improved, the sliding friction energy loss also decreased synchronously (the reduction could reach 70.19%). Full article

Coefficient of friction values, wear and surface roughness differences are revealed using pin-on-disc test apparatus examinations under three pv loads, where samples are cut from a reference, unused, and several differently aged and dimensioned, used, dry friction fiber-reinforced hybrid composite clutch facings. Tests are characterized by surface activation energy and separated into Trend 1, ‘clutch killer’, and 2, ‘moderate’, groups from our previous study. The results reveal that acceptable, 0.41–0.58, coefficient of friction values among Trend 1 specimens cannot be reached during high pv tests, though the −0.19–−0.11 difference of minimum and maximum pv results disappears when activation energy reaches 179 MJ. The maximum pv friction coefficient can decrease by up to 30% at working diameter due to clutch killer test circumstances, as 179 MJ surface activation energy is applied, while by moderate tests such losses can only be detected close to 2000 MJ energy values among small-sized facings. Besides that, Trend 2 specific wear values are the third of trend 1 results at inner diameter specimens. Compared to reference facing values, specific wear results at working diameter under maximum pv decrease by 47–100%, while increasing specific wear during lifetime can only be detected at the inner diameter of facings enduring clutch killer tests or that are small-sized facings. Among Trend 1 radial and tangential Ra delta results, inner diameter samples provide more decreasing surface roughness data, while by Trend 2 values, the opposite relation is detected. Apart from the effects of activation energy, mileage and driver profile, facing size and friction diameter influence is also revealed. Full article

Wear and surface microgeometry aspects of fiber-reinforced hybrid composite dry friction clutch facings are revealed in a novel way: after different, real life automotive tests during their lifetime. This study examines and reveals the tribological response of friction material surfaces to real life application conditions with two different facing diameters and in two directions. Along the increasing activation energy scale, wear values increased according to two different trends, sorting tests into two main groups, namely ‘clutch killer’ and ‘moderate’. Wear results also highlighted the influence of mileage and test conditions, with clutch killer tests also creating considerable wear-more than 0.1 mm-at inner diameters: 1% higher wear was generated by 90% higher mileage; another 1% increment could be caused by insufficient cooling time or test bench-specific conditions. Surface roughness values trends varied accordingly with exceptions revealing effects of facing size, friction diameter and directions and test conditions: small (S) facings produced significantly decreased Rmax roughness, while large (L) and medium (M) size facings had increased roughness values; Rmax results showed the highest deviations among roughness values in radial direction; tests run with trailer and among city conditions resulted in more than 2% thickness loss and a 40–50% roughness decrease. Full article

The objective of this study is the simulation of the most affected design factors and variables of the clutch pack for the power-shift transmission (PST) of a tractor based measured data. The simulation model, the mathematical model of sliding velocity, a moment of inertia, and clutch engagement pressure of clutch pack were developed using the powertrain and configurations of the real PST tractor. In this study, the sensor fusion method was used to precisely measure the proportional valve pressure by test bench, which was applied to the simulation model. The clutch engagement times were found 1.20 s at all temperatures for determined factors. The engagement pressures have a significant difference at various temperatures (25 to 100 °C) of the hydraulic oils after the 1.20 s but the most affected factors were satisfied with the simulation conditions that ensure the clutch engagement on time. Finally, this sensor fusion method is believed to be helpful in realizing precision agriculture through minimization of power loss and maximum energy efficiency of tractors. Full article

In order to improve fuel economy, the number of gears in the hydraulic automatic transmission of heavy-duty mining trucks is continuously increasing. Compared with single-transition shifts, double-transition shifts can optimize the structure of multi-speed transmissions, but the difficulty of control will also increase. In this paper, a dynamic model of a 6 + 2 speed automatic transmission and vehicle powertrain system are built based on the Lagrange method, and the dynamic analysis of the two sets of clutches that make up the double-transition shift are carried out. Since a simulation model of the double-transition shift process is built-in MATLAB/Simulink, the shift jerk and clutch energy loss are used as multi-objective, and the genetic algorithm is used to optimize the simulation. Five strategies for the overlapping time of the clutches are proposed, and simulation experiments and Pareto optimal analysis are carried out, respectively. The simulation results show that the non-overlapping of the two sets of clutch inertia phases in the double-transition shift can effectively reduce the shift jerk. The overlapping of the torque phase and the inertia phase of the other clutch set can control the clutch energy loss at a low level due to using less shift time. Full article

This study investigates the potential of improving the energy efficiency and reducing the lifecycle costs of electric city buses with multispeed gearboxes. A two-speed dual clutch gearbox and a continuously variable transmission were studied and compared to a reference fixed gear ratio powertrain. A novel two-level optimization model was introduced. The top level involves an exhaustive search algorithm and quasi-static vehicle dynamic model for optimizing the two-speed gearbox gear ratios, utilizing efficiency maps for the electric motor and the inverter. The second level is an integer programming model, which finds an optimal gear shifting policy subject to constraints on hysteresis and gear shifting induced losses. The model was applied with a standard driving cycle and additionally with three measured cycles acquired from a prototype battery electric city bus operating on a daily schedule on a suburban route in Espoo, Finland. The results showed that a two-speed gearbox reduced energy consumption by 2–3.2%, depending on the driving cycle characteristics. On the other hand, the continuously variable transmission was found to increase consumption by 1.9–4.0% due to large losses of the belt mechanism. It was concluded that the two-speed gearbox is a cost-effective investment for electric city buses characterized by operation profiles with frequent acceleration and braking events. Full article

The main benefits of dual clutch transmissions (DCTs) are: (i) a higher energy efficiency than automatic transmission systems with torque converters; and (ii) the capability to fill the torque gap during gear shifts to allow seamless longitudinal acceleration profiles. Therefore, DCTs are viable alternatives to automated manual transmissions (AMTs). For vehicles equipped with engines that can generate considerable torque, large clutch-slip energy losses occur during power-on gear shifts and, as a result, DCTs need wet clutches for effective heat dissipation. This requirement substantially reduces DCT efficiency because of the churning and ancillary power dissipations associated with the wet clutch pack. To the knowledge of the authors, this study is the first to analyse the detailed power loss contributions of a DCT with wet clutches, and their relative significance along a set of driving cycles. Based on these results, a novel hybridised AMT (HAMT) with a single dry clutch and an electric motor is proposed for the same vehicle. The HAMT architecture combines the high mechanical efficiency typical of AMTs with a single dry clutch, with the torque-fill capability and operational flexibility allowed by the electric motor. The measured efficiency maps of a case study DCT and HAMT are compared. This is then complemented by the analysis of the respective fuel consumption along the driving cycles, which is simulated with an experimentally validated vehicle model. In its internal combustion engine mode, the HAMT reduces fuel consumption by >9% with respect to the DCT. Full article

This paper examines the benefits of a drivetrain that is able to disengage its propulsion motor from the driveline in an electric vehicle. The drivetrain was developed for an ultra-efficient eco vehicle competing in the Shell 2013 Eco Marathon. Various clutch mechanisms were examined. In spite of the complexity and losses associated with additional bearings and release surfaces, an actuated dog clutch was chosen as it offers superior performance due to the dual capability of freewheeling and regenerative braking that results. Track data from the event is presented along with experimental work that indicates that the clutch mechanism reduces power consumption by more than 35% for a ferrous permanent magnet propulsion motor. Savings were reduced to 5% for a coreless permanent magnet motor coupled to the driveline via an 11:1 straight cut spur gear arrangement. This reduced saving was due to the removal of hysteresis and eddy current losses from the stator. The paper also demonstrates during a competition in which the driver was aware of the energy consumption, the driving style changed when the technological option to free wheel was available. Finally the study was inferred onto a real world application with further experimental and simulation work on the Delta E4 Coupe, a high performance electric sports car. The vehicle uses a ferrous permanent magnet direct drive arrangement, indicated a reduction in power consumption of 10 to 14%. It is hoped that these insights are relevant when considering the development of electric vehicle drivetrains where machine topology and drive cycle will determine the value of a clutch mechanism. Full article

This paper presents the design and validation of a novel multi-mode transmission (MMT) for a hybrid electric vehicle (HEV) using a single electric machine (EM), which implies compact and low cost. The topology of the MMT planetary gearset is the same as that of conventional four speed automatic transmissions. The MMT uses two planetary gearsets and four clutches to combine an engine and an EM with the vehicle, and the EM is operated as a motor or a generator. The MMT realizes five power flow modes, which are developed into sixteen operating modes, including one motor-only mode, four engine-only modes, four compound driving modes, six braking modes, and one charging while parking mode. The single EM HEV solution avoids losses from another EM and extra power electronics which are employed in many existing HEVs. The properly arranged clutches transmit power flow more flexibly, allow direct mechanical power transmission from the engine to the drive shaft, and avoid spin loss for the engine and energy conversion loss for the electric components. The fuel consumption of the proposed hybrid vehicle system is compared with a benchmark vehicle which uses a planetary gearset, two EMs and no clutch. Simulation results under New European Driving Cycle show that the fuel consumption of the proposed HEV is comparable to the benchmark vehicle. Reasons for comparable results are explored, which indicates the fuel economy potential of the new concept. Full article
