As a core component in renewable energy systems for grid regulation, hydropower units are increasingly exposed to flow conditions that elevate the risk of cavitation and erosion, posing significant challenges to the safe operation of flow-passage components. In this study, model testing and computational fluid dynamics (CFD) simulations are employed to investigate the hydraulic performance and cavitation behavior of a bulb turbine operating under rated head conditions and varying cavitation numbers. The analysis focuses on how changes in cavitation intensity affect flow characteristics and efficiency within the runner region. The results show that as the cavitation number approaches its critical value, the generation, growth, and collapse of vapor cavities increasingly disturb the main flow, causing a marked drop in blade hydraulic performance and overall turbine efficiency. Cavitation predominantly occurs on the blade’s suction side near the trailing edge rim and in the clearance zone near the hub, with bubble coverage expanding as the cavitation number decreases. A periodic inverse correlation between surface pressure and the cavitation area is observed, reflecting the strongly unsteady nature of cavitating flows. Furthermore, lower cavitation numbers lead to intensified pressure pulsations, aggravating flow unsteadiness and raising the risk of vibration. Full article

The cavitation phenomenon significantly impacts the performance of pump turbines, necessitating in-depth research on their cavitation characteristics. This study investigates the performance characteristics of a pump turbine through experimental and numerical simulation methods, with consistent results verifying the accuracy of the numerical simulations. The cavitation flow field is numerically analyzed to compare the cavitation distribution and velocity streamlines at different stages of cavitation development. The Q criterion and entropy production method are employed to identify vortex structures and energy loss regions, respectively, exploring the correlation between vortices and energy losses in the cavitation flow field under low-flow pump conditions. The results demonstrate that intensified cavitation generates more multi-scale vortices in the flow field, leading to increased entropy production and reduced energy efficiency. Proper orthogonal decomposition (POD) and dynamic mode decomposition (DMD) methods were subsequently applied to extract vorticity characteristics from transient cavitation flow fields, revealing primary energy loss regions and elucidating the evolution and distribution patterns of vortices. The POD analysis shows that low-order modes represent dominant vortex structures, while intensified cavitation increases both the quantity of vortices and their complexity in scale, distribution, and evolutionary frequency. The DMD results further indicate distinct evolutionary patterns for vortices of different scales. This research provides insights into the instability characteristics of cavitation flow fields in pump turbines under low-flow pump conditions and offers theoretical support for optimizing the design of pump turbines to expand their high-efficiency operational range. Full article

Operating centrifugal pumps under two-phase flow conditions presents challenges such as phase separation, cavitation, and flow instabilities, compromising reliability and performance. A specialized design is crucial to mitigate these issues. This study utilized computational fluid dynamics (CFDs) to understand two-phase flow behavior and assess the impact of different blade geometries on pump performance under such conditions. For this purpose, the inhomogeneous multiphase model was employed, wherein the momentum and continuity flow equations were individually solved for each phase across three different impellers with varying blade angle distributions. The computational results indicated higher gas concentrations on the pressure side of the blade, with gas pocket size correlating with flow rate and inlet gas concentration. The blade angle distribution’s effect was more pronounced with increased gas concentrations, while a tendency of gas bubbles to coalesce towards the impeller shroud was also observed. The presence of gas promoted flow recirculation and separation, substantially reducing impeller performance. Blade angle distribution critically influenced the flow field, affecting flow separation, stability, efficiency, and overall performance, highlighting the importance of optimized blade design for enhanced centrifugal pump performance in liquid–gas two-phase flow conditions. Full article

Some high-specific-speed centrifugal pumps exhibit instability in terms of hydraulic performance and cavitation characteristics, and there’s a lack of reliable numerical models to guide the optimization of cavitation instability. This paper, by conducting a study on mesh independence, analyzes the cavitation curves and cavitation counters for various mesh combinations in the numerical model, The findings indicate that the boundary layer grid not only influences the location of peak points but also the size of the peak. To achieve a stable NPSH peak position, the y+ at the blade leading edge of high-specific-speed centrifugal pumps needs to be controlled between 20–80. The turbulence model, evaporation coefficient, and condensation coefficient were simulated using the orthogonal experimental design method, analyzing the impact of these parameters on the NPSH peak. A visual high-speed photography test rig was established, and rotating cavitation and sheet cavitation is found at part-load. By comparing the cavitation and pressure counters with high-speed photography images, a numerical model was obtained that closely mirrors the experimental cavitation characteristics. Full article

In this paper, a unitary method for the solution of transient cavitating flow in viscoelastic pipes is proposed in the framework of the method of characteristics (MOC) and a Z-mirror numerical scheme (MOC-Z model). Assuming a standard form of the continuity equation allows the unified treatment of both viscoelasticity and cavitation. An extension of the MOC-Z is used for Courant numbers less than 1 to overcome a few cases with numerical instabilities. Four viscoelastic models were considered: a Kelvin–Voigt (KV) model without the instantaneous strain, and three generalised Kelvin–Voigt models with one, two, and three KV elements (GKV1, GKV2, and GKV3, respectively). The use of viscoelastic parameters of KV and GKV models calibrated for transient flow tests without cavitation allows good comparisons between experimental and numerical pressure versus time for transient tests with cavitation. Whereas for tests without cavitation, the mean absolute error (MAE) always decreases when the complexity of the model increases (from KV to GKV1, GKV2, and GKV3) for all the considered tests, this does not happen for tests with cavitation, probably because the decreasing capacity of parameter generalization for the increasing complexity of the model. In particular, in the examined cases, the KV model performs better than the GKV1 and the GKV3 models in three cases out of five, and the GKV2 model performs better than the GKV3 model in three cases out of five. Furthermore, the GKV2 model performs better than the KV model only in three cases out of five. Full article

We perform large-eddy simulations to study a cavitating flow over a two-dimensional hydrofoil section—a scaled-down profile (1:13.26) of guide vanes of a Francis turbine—using the Schnerr–Sauer cavitation model with an adaptive mesh refinement in intensive phase transition flow areas. In the test case, the guide vane is tilted at an angle of attack of $9^{°}$ to the direction of the flow, in which the Reynolds number, based on the hydrofoil chord length, equals $1.32\times {10}^6$, thus providing a strong adverse pressure gradient along the surface. The calculated time-averaged turbulence characteristics are compared with those measured by particle image velocimetry to verify that the flow is correctly reproduced in numerical simulations using the procedure of conditional averaging proposed and tested in our previous investigation. A re-entrant jet is identified as the primary source of vapor cloud shedding, and a spectral analysis of the cavitating flow over the profile midsection is conducted. Two characteristic frequencies corresponding to the cases, when an attached cavity detaches completely (as a whole) and two partially from the hydrofoil, are found in the flow. The study reveals that the natural frequency of partial cavity shedding is three times higher than that of full detachments. The examined regime exhibits an oscillatory system with two oscillation zones related to cavitation surge instability and unsteady cloud cavitation resulting from the re-entrant jet. Conditional averaging correlates cavitation structures with pressure distributions, forces, and torque on the guide vane. This modeling approach captures the fine details of quasi-periodic cavitation dynamics, providing insights into unsteady sheet/cloud cavitation and offering a method for developing control strategies. Full article

Cavitation instabilities can induce axial and circumferential vibrations, as well as noise in turbopump inducers. Therefore, the purpose of the present study is to investigate the mechanism of cavitation instability. The flow field near the two-bladed inducer leading edge under alternate blade cavitation was experimentally investigated using particle image velocimetry (PIV). It was found that the tip leakage vortex cavitation draws the flow toward its region of collapse and induces a negative change in the incidence to the adjacent blade. Moreover, this blade-to-blade interaction was identified as the main cause of alternate blade cavitation. Furthermore, it was demonstrated that this blade-to-blade interaction is strongest when the cavity collapse occurs in the inducer throat area, where the leading edge of the following blade is located. Full article

To investigate a hypothesis of the orifice flow-induced instability in rocket engine thrust chambers, a single liquid oxygen (LOX) injector with an optically accessible orifice module was used for experiments, with water as a simulant for LOX. The unsteady pressure downstream of the orifice was measured using high-speed piezoelectric sensors under cavitating and non-cavitating intra-injector flow conditions. The cavitating orifice flows were directly visualized via backlight imaging with a high-speed camera through the optically accessible orifice module. Cavitation initiated at the cavitation number of 2.05, and the downstream bubble cloud formation started below 1.91. The unsteady pressure spectrum arising from cavitation comprises multiple peaks over a broad frequency range, which can cause low- and high-frequency instabilities. The dominant frequencies from cavitation decrease with increasing pressure drop, while the frequencies during non-cavitating flow increase. The non-cavitating orifice flow excites the second longitudinal acoustic mode of the injector tube. The acoustic mode excited by the non-cavitating flow becomes stronger when the pressure peak in the range of whistling phenomenon is close to the first longitudinal acoustic mode. In conclusion, the excitation mechanisms of the orifice-induced instability for the cavitating and non-cavitating flows were well identified, despite the limitations of water as a simulant for LOX. Full article

The integration of intermittent renewable energy resources to the grid system requires that hydro turbines regularly operate at part-load conditions. Reliable operation of hydro turbines at these conditions is typically limited by the formation of a Rotating Vortex Rope (RVR) in the draft tube. In this paper, we investigate the formation of this vortex using the scale-resolving methods SST-SAS, wall-modeled LES (WMLES), and zonal WMLES. The numerical results are first validated against the available experimental data, and then analyzed to explain the effect of using different scale-resolving methods in detail. It is revealed that although all methods can capture the main features of the RVRs, the WMLES method provides the best quantitative agreement between the simulation results and experiment. Furthermore, cavitating simulations are performed using WMLES method to study the effect of cavitation on the flow in the turbine. These effects of cavitation are shown to be highly dependent on the amount of vapor in the RVR. If the amount of vapor is small, cavitation induces broadband high-frequency fluctuations in the pressure and forces exerted on the turbine. As the amount of cavitation increases, these fluctuations tend to have a distinct dominant frequency which is different from the frequency of the RVR. Full article

Cavitation can cause noise in the water-jet pump. If cavitation occurs in the water-jet pump, the hydraulic components in the pump are prone to erosion. The surface erosion reduces energy delivery efficiency and increases maintenance costs. The decline in pump performance will lead to the instability of the entire energy system. In this paper, the cavitation flow structure of the water-jet pump is studied by the method of numerical simulation and experiment, which provides a reference for the prediction and improvement of cavitation. Based on the closed test platform, in order to reveal the physical process of cavitation evolution, high-speed photography is used to capture the complex cavitation flow phenomenon in the pump. After that, the cavitation vortex structure was further explored by numerical simulation. Through the simulation of the impeller blade tip leakage flow and the Tip Leakage Vortex Cavitation (TLVC) characteristics under different cavitation conditions, the flow mechanism of the impeller blade tip leakage flow and the separation vortex induced by the cavitation region under different cavitation conditions were revealed. The main factors affecting the development of the cavitation wake vortex structures were summarized. Full article

A pump-jet, which is generally and widely adopted on underwater vehicles for applications from deep sea exploration to mine clearing, consists of a rotor, stator, and duct, with the properties of high critical speed, high propulsion efficiency, great anti-cavitation performance, and low radiated noise. The complex interaction of the flow field between the various components and the high degree of coupling with the appendage result in the requirements of in-depth research on the hydrodynamic performance and flow field for application and design. Due to the initial application on the military field and complicated structure, there is scant literature in the evaluation of pump-jet performance and optimal design. This paper, in a comprehensive and specialized way, summarizes the pump-jet hydrodynamic performance, noise performance, and flow field characteristics involving cavitation erosion and vortices properties of tip-clearance, the interaction between the rotor and the stator and the wake field, as well as the optimal design of the pump-jet. The merits and applications range of numerical and experimental methods are overviewed as well as the design method. It also concludes the main challenges faced in practical applications and proposes a vision for future research. It was found that the compact structure and complex internal and external flow field make the pump-jet significantly different, also leading to higher performance. As the focus of cavitation research, vortices interact with the complex structure of the pump-jet, leading to instabilities of the flow field, such as vibration, radiated noise, and cavitation erosion. The effective approaches are adopted to reduce radiated pump-jet with minimal influence on the hydrodynamic performance, such as eliminating the tip clearance and installing the sawtooth duct. Advanced optimal technology can achieve high performance, cavitation performance, and acoustic performance, possessing good prospects. Further developments in investigation and the application of pump-jets in the multidisciplinary integration of fluid dynamics, acoustics, materials, chemistry, and bionics should be the main focus in future research. Full article

In this paper, unsteady and time-averaged turbulence characteristics in a submerged cavitating jet with a high Reynolds number are studied using large eddy simulation. The simulation is validated by comparing the vapor distribution using CFD and a high-speed photography experiment. The results indicate that the currently used numerical method can predict the evolution of the cavitation cloud in the jet accurately. The instantaneous and time-averaged flow fields of the submerged jet with three different cavitation numbers are studied. Comparing the frequency spectral of jets with different cavitation numbers, it is found that, for a fixed location, the frequency increases with the decrease in the cavitation number. Comparing the vorticity distribution at different streamwise locations, the instability process of the ring-shapes vortexes is revealed. Comparing the shape of the cavitation cloud and the vortexes in the jet finds that their spatial distribution and the temporal evolution are similar, indicating that the dynamic characteristics of the vortex and the cavitation affect each other. For the currently investigated cavitating jets, the Reynolds number increases with the decrease in the cavitation number. However, the spreading rate is lower for the jet with higher Reynolds numbers here. This is means that the momentum exchange between the jet and submerging water is reduced by the cavitation phenomenon. Full article

Rotating cavitation (RC) in inducers mainly degrades performance with unstable radial force. In this paper, the influence of step casings on cavitation performance and the instabilities of inducers were numerically investigated. Firstly, a numerical scheme was validated by means of a comparison with experimental measurements taken for an original inducer (Model O). We then performed simulations with five different step casing models (Models A–E), in which the starting locations and enlargement sizes of the step casings were altered. The interaction between tip leakage flow and main flow in the inter-blade passages was found to highly affected by cavity structure and blade loading. Considering both cavitation performance and radial force, our results suggest that Model E is an alternative improvement. In short, this study provides a standard workflow for the effective suppression of rotating cavitation in inducers by the simple adoption of the step casing configuration presented here in engineering practice. Full article

To study instability in the unsteady cavitating flow in a liquid rocket engine inducer, visualization experiments of non-cavitating and cavitating flows inside a model inducer were carried out at different flow conditions. Visual experiments were carried out to capture the evolution of non-cavitating and cavitating flows in a three-bladed inducer by using a high-speed camera. The external characteristic performance, cavitation performance, and pressure pulsation were analyzed based on the observation of non-cavitation and cavitation development and their instabilities. Under non-cavitation conditions, the change of flow rate has a significant impact on the pressure pulsation characteristics in the inducer. The occurrence of cavitation aggravated the instability of the flow and caused the intensity of pressure pulsation at each measuring point to increase. This cavitation structure has strong instability, and the tail region is often accompanied by shedding cavitation clouds perpendicular to the blade surface. Full article

This study aimed to investigate the Cavitation dynamics of Hydrodynamic-acoustic cavitation by employing experimental methods. The spatial distribution of cavitation clouds, the temporal and spatial distribution achieved by cavitation clouds, and the main flow structure in the flow field were extracted and analyzed by complying with the cavitating flow image captured with the high-speed camera. As indicated from the results, the widened cavitation region and the strength of cavitation under the synergy of ultrasound were reported. When the inlet pressure is 2 MPa, the average value of the volume-averaging cavitation intensity variable is 0.029, 0.058, and 0.092, respectively, and the corresponding growth rate is 95% and 58.5%. By adopting the Proper Orthogonal Decomposition method (POD), the ultrasound was revealed to primarily enhance the cavitation intensity by downregulating the cavitation threshold other than altering the large-scale vortex structure in the flow field. The high-frequency pressure pulsation of ultrasound strengthened the instability exhibited by the shear layer and induced small-scale vortex structures at the shear layer, which was suggested to be the more violently shed and collapse. Full article
