To overcome the inherent drawbacks of cast-in-place reinforced concrete bracing—such as long construction periods and difficult demolition—as well as the relatively high construction cost of steel structure bracing, while fully incorporating the respective technical advantages of these two traditional support systems, this paper proposes a novel hybrid prefabricated reinforced concrete (RC)–steel structure foundation pit bracing system. In order to investigate the overall bearing capacity variation in the standard components of this structure under complex external forces in foundation pits, a numerical model was established using the finite element software ABAQUS. The study examines the trend of the axial compressive bearing capacity of a single standard beam segment as the steel thickness of its external stiffening sleeve varies, as well as the effects of eccentric loading, oblique loading, and the presence or absence of auxiliary supports on the structural bearing capacity of multi-segment beam assemblies. The numerical analysis results show that the bearing capacity of a single beam segment exhibits a strong correlation with the variation in sleeve thickness, and a fitting curve of compressive strength as a function of thickness was derived. For the multi-segment assembly, an increase of 1 mm in the load eccentricity in the Y and Z directions reduces the ultimate peak load by approximately 20.95 kN and 23.94 kN, respectively; in the XY and XZ planes, an increase of 1° in the eccentric angle of the oblique load reduces the peak ultimate bearing capacity by about 6.02 kN and 9.67 kN, respectively. Auxiliary supports have a relatively minor influence on the structural bearing capacity. This research thoroughly explores the bearing capacity of the prefabricated steel–concrete composite and steel structure foundation pit bracing under complex working loads, providing strong support for engineering design and demonstrating broad application prospects. Full article

The use of high-strength reinforcing steel is an effective way to improve the flexural efficiency of reinforced concrete beams. However, the flexural behaviour of beams reinforced with 630 MPa grade longitudinal rebars in combination with normal-strength concrete is still not fully understood, especially with regard to serviceability performance. In this study, the flexural performance of simply supported RC beams reinforced with HRB500, HRB600 and HRB630 longitudinal rebars and cast with C60 steel-fibre-reinforced concrete was investigated through a combined experimental and numerical approach. Six beams were tested under four-point bending to examine cracking patterns, deflection development and ultimate flexural capacity. A three-dimensional nonlinear finite element model based on the Concrete Damage Plasticity model in ABAQUS was then established and calibrated against the test data. Using the validated numerical model, a parametric study was carried out to investigate the influence of steel grade, tensile reinforcement ratio on flexural stiffness and ductility. Test results indicate that, for the same reinforcement ratio, the ultimate moment capacity of HRB630 beams is about 8% higher than that of HRB600 beams and about 25% higher than that of HRB500 beams, while a ductile flexural failure mode governed by yielding of tension reinforcement is still maintained. The study also shows that for HRB630 beams, deflection predictions need to account for the higher steel stress level and the deterioration of tension stiffening effects. In general, the results demonstrate that HRB630 high-strength rebars can be safely and efficiently used in flexural members when the tensile reinforcement ratio is kept within the under-reinforced range and steel-fibre-reinforced concrete is adopted to improve cracking and deflection performance. Full article

This study investigates two novel prefabricated frame joints: prestressed steel sleeve-connected prefabricated reinforced concrete joints (PSFRC) and non-prestressed steel sleeve-connected prefabricated reinforced concrete joints (SSFRC). A total of three PSFRC specimens, four SSFRC specimens, and one cast-in-place joint were designed and fabricated. Seismic performance tests were conducted using different end-plate thicknesses, grout strengths, stiffener configurations, and prestressing tendon configurations. The experimental results showed that all specimens experienced beam end failures, and three failure modes occurred: (1) failure of the end plate of the beam sleeve, (2) failure of the variable cross-section of the prefabricated beam, and (3) failure of prefabricated beams at the connection with the steel sleeves. The load-bearing capacity and initial stiffness of the structure are increased by 35.41% and 32.64%, respectively, by increasing the thickness of the end plate. Specimens utilizing C80 grout exhibited a 39.05% higher load capacity than those with lower-grade materials. Adding stiffening ribs improved the initial stiffness substantially. Specimen XF2 had 219.08% higher initial stiffness than XF1, confirming the efficacy of stiffeners in enhancing joint rigidity. The configuration of the prestressed tendons significantly influenced the load-bearing capacity. Specimen YL2 with symmetrical double tendon bundles demonstrated a 27.27% higher ultimate load capacity than specimen YL1 with single centrally placed tendon bundles. An analytical model to calculate the moment–rotation relationship was established following the evaluation criteria specified in Eurocode 3. The results demonstrated a good agreement, providing empirical references for practical engineering applications. Full article

Cable-stiffened steel columns (CSSC) have a high load-carrying capacity and strong stability compared to ordinary steel columns. In practical engineering, the connection between the crossarm and main column of a CSSC is usually welded. However, the welding-residual stress adversely affects the steel column. In this study, pre-cast CSSCs, with a pinned connection between the crossarm and main column, are presented. The new type of pre-cast CSSCs avoid the welding-residual and are easy to disassemble. A model test and numerical analysis of its global stability behavior under eccentric compression is conducted. Based on the analysis, the buckling modes of these columns are defined and a method for determining the governing imperfection in a nonlinear buckling analysis is proposed. The effects of slenderness ratio, cross-arm length, cable diameter, and other parameters on the load-carrying capacities of the columns are investigated using the proposed method. The results of this study can be used as a reference for the engineering designs and specifications of pre-cast CSSCs. Full article

This study investigates the structural performance of assembled rib-plate bridge abutments (ARBAs) with two different connection methods: bull leg bolt and flange connections. In addition, we explored the bending and shear performance of the connection parts and related areas to assess the damage characteristics and modes of these ARBAs. Utilizing model testing, a numerical analysis was conducted to define the force performance of the ARBA, with reference to a cast-in-place rib-plate abutment. The research results indicate that the bearing capacity and deformation capacity of the cap part of the assembled ribbed slab abutment model with cow leg connections are lower than those of the cast-in-place structure. When the structure fails, a 45° diagonal crack develops from the cross-section at the mid-span joint to the connection between the rib slab and the cap, until the concrete protective layer at the joint is crushed, exhibiting a shear failure mode. The bearing capacity of the assembly rib plate type abutment cap connected by the flange plate is basically the same as that of the cast-in-place structure, and the deformation capacity is weaker than that of the cast-in-place rib plate type abutment. The expansion of structural cracks is consistent with that of the rib plate type abutment connected by the cow leg. When the flange plate at the mid span is damaged, the contact surface between the flange plate and the concrete is pried off, resulting in the inability of the structure to continue bearing, exhibiting a shear failure mode. Through numerical simulation, taking the stress performance of the integral cast-in-place ribbed slab abutment as a reference, the assembled ribbed slab abutment connected by the flange plate is basically consistent with the integral cast-in-place ribbed slab abutment in terms of ultimate load, concrete damage, and steel reinforcement skeleton stress, and the connection device has not yet reached the yield state. The ultimate displacement is slightly weaker than that of the integral cast-in-place ribbed slab abutment. By comparison, it can be seen that the ultimate bearing capacity of the assembled ribbed slab abutment connected by the flange is basically the same as that of the cast-in-place ribbed slab abutment, and the stress performance can reach an “equivalent cast-in-place”, making it the preferred solution for the assembled abutment structure. The finite element parameter analysis of the flanged ARBA revealed that the thickness of the stiffening ribs, the number of bolts, and length of the flange plate anchoring steel plate were proportional to the ultimate load-bearing capacity of the prefabricated ARBA. In the case of no change in the structural damage mode, considering the economic benefits and load-bearing capacity of the structure, the following parameter combinations of the flanged ARBA are recommended: a thickness of 30 mm of the stiffening ribs, the number of bolts is 12, and a length of 50 cm of the length of flange plate anchoring steel plate. Full article

Alkali-activated concrete is an eco-friendly construction material that is used to preserve natural resources and promote sustainability in the construction industry. This emerging concrete consists of fine and coarse aggregates and fly ash that constitute the binder when mixed with alkaline activators, such as sodium hydroxide (NaOH) and sodium silicate (Na₂SiO₃). However, understanding its tension stiffening and crack spacing and width is of critical importance in fulfilling serviceability requirements. Therefore, this research aims to evaluate the tension stiffening and cracking performance of alkali-activated (AA) concrete. The variables considered in this study were compressive strength (f_c) and concrete cover-to-bar diameter (C_c/d_b) ratios. After casting the specimen, they were cured before testing at ambient curing conditions for 180 days to reduce the effects of concrete shrinkage and obtain more realistic cracking results. The results showed that both AA and OPC concrete prisms develop slightly similar axial cracking force and corresponding cracking strain, but OPC concrete prisms exhibited a brittle behavior, resulting in a sudden drop in the load–strain curves at the crack location. In contrast, AA concrete prisms developed more than one crack simultaneously, suggesting a more uniform tensile strength compared to OPC specimens. The tension-stiffening factor (β) of AA concrete exhibited better ductile behavior than OPC concrete due to the strain compatibility between concrete and steel even after crack ignition. It was also observed that increasing the confinement (C_c/d_b ratio) around the steel bar delays internal crack formation and enhances tension stiffening in AAC. Comparing the experimental crack spacing and width with the values predicted using OPC codes of practice, such as EC2 and ACI 224R, revealed that EC2 tends to underestimate the maximum crack width, while ACI 224R provided better predictions. Thus, models to predict crack spacing and width have been proposed accordingly. Full article

In this paper, the system response, stress redistribution, failure mode, and catenary effect of steel frames with circular tube columns and cast steel stiffener (CSS) joints under a sudden column removal scenario were revealed. Based on this force transfer mechanism analysis, a practical and computationally efficient component-based model considering catenary effects and CSS joint details with a series of springs was established and validated by a detailed solid-element method. By using this component-based model, the proper dynamic response increase factor of the CSS joint frames was investigated. The results show that the great overall stiffness and strength of the CSS limit the deformation of the column front shell. Therefore, the CSS joint frames have superior performance for progressive collapse prevention than the frames using welded joints without stiffeners. In addition, the component-based model is validated to be effective and the dynamic response increase factor of the frames with circular tube columns and CSS joints is smaller than 2.0. Full article

Beam-column joint with cast steel stiffeners (CSS) is a new type of joint with a large degree of design freedom. The joint stress distribution can be improved by designing a reasonable cross-sectional shape of the CSS with high rigidity, high integrity, and good seismic performance. Due to the construction specificity, the exact theoretical formula for the moment bearing capacity of the CSS joint is hard to deduce. Some researchers have proposed empirical or simplified theoretical formulas for the prediction of moment bearing capacity. However, the formulas are biased and cannot capture uncertainties in the data measurement and modeling process. In addition, current formulas cannot be updated efficiently over time, and no work has been conducted regarding the reliability of the CSS joints subject to different loading conditions. In this paper, a new approach to address the above issues is proposed. A probabilistic model for the joint capacity is established to capture the uncertainties and correct the bias. A Bayesian method is proposed for model training, which allows the model to be updated efficiently whenever new experiment or simulation data are available. A fragility analysis is conducted using the proposed capacity model to quantify the failure probability of joints under different loading conditions. The advantages of the proposed approach are validated by analyzing joints in a database obtained from experiments and numerical simulations. Results show that the proposed capacity model provides unbiased and more accurate estimates of the bending moment than the currently available ones. New factors such as column thickness and concrete filling are found to significantly impact the moment capacity. The bending fragility of CSS joints can be lowered at different degrees by increasing concrete strength, steel strength, column thickness, etc. Guidance on CSS joint design and retrofitting based on the capacity model and fragility analysis is also presented at the end of this paper. Full article
