Conventional repeatered optical communication systems face inherent limitations in terms of reliability, flexibility in optical fiber configuration, and power supply modes, particularly when applied to large-scale cabled ocean observatories, which have highly variable load demands. To address these challenges, a novel hybrid optimization algorithm (GA + PSO + SA) has been developed to enable simultaneous optimization of multiple critical parameters, including the pump light wavelength, the length of the erbium-doped fiber, and the placement of the remote optical amplifier. This approach represents a significant advancement over conventional single-algorithm methods because it effectively overcomes local optima and achieves global performance optimization. Comprehensive simulations and experimental validation demonstrate that the optimized unrepeatered system achieves transmission distances of 691.8 km using G.654E fibers and over 400 km with standard G.652D fibers, while maintaining excellent signal quality and exceptional stability. This work provides a systematic framework for the design and optimization of ultra-long-haul unrepeatered systems, highlighting their practical applicability in cabled ocean observatories. Full article

The continuous monitoring of radioactivity in a cabled subsea network in the North Sea Observatory was performed to test the performance of a medium-resolution underwater spectrometer, as well as to identify and to assess potential anthropogenic and/or natural hazards. The effectiveness of continuous monitoring was tested together with the operability of the underwater sensor, and quantification methods were optimized to identify the type of radioactivity as well as the activity concentration of radionuclides in the seawater. In the frame of the RADCONNECT project, a medium-resolution underwater radioactivity system named GeoMAREA was integrated into an existing cabled ocean observatory placed on Helgoland Island (COSYNA network). The system could be operated via an online mode controlled by the operational centre (AWI), as well as remotely by the end-user (HCMR). The system provided gamma-ray spectra and activity concentrations of key radionuclides that were enriched in seawater during the monitoring period. As concerns the quantification method of natural radioactivity, the average activity concentrations (in terms of the total monitoring period) of ²¹⁴Bi, ²⁰⁸Tl, ²²⁸Ac and ⁴⁰K were found to be 108 ± 30, 57 ± 14, 40 ± 5 and 9800 ± 500 Bqm⁻³, respectively. As concerns the quantification of ¹³⁷Cs, the average activity concentration in terms of the total monitoring period (although it is uncertain) was found to be 6 ± 4 Bqm⁻³. The data analysis proved that the system had a stable operation in terms of voltage stability, so all acquired spectra could be summed up efficiently in time to produce statistically optimal gamma-ray spectra for further analysis. Full article

The rapid growth of marine industries has emphasized the focus on environmental impacts for all industries, as well as the influence of key environmental parameters on, for instance, offshore wind or aquaculture performance, animal welfare and structural integrity of different constructions. Development of automatized sensors together with efficient communication and information systems will enhance surveillance and monitoring of environmental processes and impact. We have developed a modular Smart Ocean observatory, in this case connected to a large-scale marine aquaculture research facility. The first sensor rigs have been operational since May 2022, transmitting environmental data in near real-time. Key components are Acoustic Doppler Current Profilers (ADCPs) for measuring directional wave and current parameters, and CTDs for redundant measurement of depth, temperature, conductivity and oxygen. Communication is through 4G network or cable. However, a key purpose of the observatory is also to facilitate experiments with acoustic wireless underwater communication, which are ongoing. The aim is to expand the system(s) with demersal independent sensor nodes communicating through an “Internet of Underwater Things (IoUT)”, covering larger areas in the coastal zone, as well as open waters, of benefit to all ocean industries. The observatory also hosts experiments for sensor development, biofouling control and strategies for sensor self-validation and diagnostics. The close interactions between the experiments and the infrastructure development allow a holistic approach towards environmental monitoring across sectors and industries, plus to reduce the carbon footprint of ocean observation. This work is intended to lay a basis for sophisticated use of smart sensors with communication systems in long-term autonomous operation in remote as well as nearshore locations. Full article

In order to address the requirements of scientific multidisciplinary observation in diverse small-scale regions, we have introduced the Buoy-based Cable Seafloor Observatory System (BCSOS). This system offers a distinct advantage in contexts where the use of shorter cables is feasible, contrasting with the lengthy cables typically necessary for conventional observatories. The BCSOS consists of three primary components: the Real-Time Electric Communication (RTEC) Buoy, the Power Information Transmission System (PITS), and the Seafloor Observation Subsystem (SOS). The RTEC Buoy is equipped with instruments for measuring sea surface parameters and serves as a data and power hub. The PITS, comprising a robust EM cable, connects the buoy to the SOS, which houses instruments for seafloor observations. The system is designed for a maximum water depth of 100 m and has an expected lifespan of about 5 years. The BCSOS prototypes were deployed at the Huangqi Peninsula, Fujian Province, and successfully documented the process during Typhoon Doksuri (international code 2305) at the end of July 2023. The recorded data from the BCSOS revealed a significant increase in wave height and period as the storm approached the Huangqi Peninsula. Additionally, the RTEC buoy exhibited a notable response to the large waves. The data analysis revealed a distinct pattern between the buoy response and the direction of wave propagation across various sea conditions, that the buoy’s angular movement in pitch and roll directions follows a regular elliptical distribution corresponding to different wave propagation directions. Upon thorough evaluation, future enhancements to the system are slated to concentrate on refining its design, with a particular emphasis on bolstering stability and enhancing corrosion resistance. These improvements are aimed at cementing the system’s long-term viability and performance within the challenging marine environment. Full article

Cabled ocean observatories (COOs) have enabled real-time in situ ocean observations for decades, thereby facilitating oceanic understanding and exploration. This review discusses typical COOs worldwide in terms of system configurations and state-of-the-art technology, including network structures, power supply modes, and communication capabilities, and provides a comprehensive analysis of their technical routes. The main characteristics of line, ring, star, and grid networks and their applicability in COOs are elucidated, and the advantages and disadvantages of various power supply modes, as well as the opportunities brought by the development of communication technologies, are described. The insights gained from these discussions can inform the implementation of grid structures, optimization of cable routings, expansion of COO scales, application of dual-conductor submarine cables, and upgrading of communication capacity. On this basis, the challenges and future research directions related to COOs are presented. Full article

Seafloor observatories enable real-time, continuous and long-term observations that promise major breakthroughs in ocean sciences. The effort to dynamically control in situ sensor systems performing individual and cooperative observation tasks is both a challenge and a guarantee for the stable operations of functional observatories. However, current sensor control systems for seafloor observatories are application-oriented and focus on specific engineering requirements rather than general model research. In this paper, a sensor control model was proposed to provide a theoretical specification for designing, developing and deploying a sensor control system for cabled seafloor observatories. The model abstracted the sensor control as a standardized bidirectional information flow process and accordingly structured the control system into the application layer, the service layer, the networking layer, and the sensing layer. The layered functions and interactions between adjacent layers in return realized this information process. A prototype control system was designed and developed, the monitoring architecture of which was derived from one of the deployment scenarios of the sensor control model. The prototype system was tested for its plug-and-play enablement through a series of trials such as tank tests and shallow sea trials. It was put into service for the operational Xiaoqushan Seafloor Observatory and was consistently functioning and presenting satisfactory practical performance in accordance with all the requirements laid for the project. Full article

The taphonomy of carcasses submerged in the ocean is little understood, yet it is extremely important ecologically and forensically. The objectives of this study were to determine the fate of pig carcasses as human proxies in the Strait of Georgia at 170 m in spring and fall. Using Ocean Networks Canada’s Victoria Experimental Network Underseas (VENUS) observatory, two carcasses per season were placed under a cabled platform hosting a webcam and instruments measuring water chemistry. Two minutes of video were recorded every 15 min. In spring, Lyssianassidae amphipods and Pandalus platyceros were immediately attracted and fed on the carcasses, the amphipods removed the bulk of the soft tissue from the inside whilst the shrimp shredded the skin and tissue. The carcasses were skeletonized on Days 8 and 10. In fall, Metacarcinus magister was the major scavenger, removing most of the soft tissue from one carcass. Amphipods did not arrive in large numbers until Day 15, when they skeletonized the scavenged carcass by Day 22 and the less scavenged carcass by Day 24. Amphipods remained for some days after skeletonization. This skeletonization was very different from previous experiments at different depths and habitats. Such data are very valuable for predicting preservation, planning recoveries, and managing family expectations. Full article

The three volcanoes that are the object of this paper show different types of activity that are representative of the large variety of volcanism present in the Central Mediterranean area. Etna and Stromboli are sub-aerial volcanoes, with significant part of their structure under the sea, while the Marsili Seamount is submerged, and its activity is still open to debate. The study of these volcanoes can benefit from multi-parametric observations from the seafloor. Each volcano was studied with a different kind of observation system. Stromboli seismic recordings are acquired by means of a single Ocean Bottom Seismometer (OBS). From these data, it was possible to identify two different magma chambers at different depths. At Marsili Seamount, gravimetric and seismic signals are recorded by a battery-powered multi-disciplinary observatory (GEOSTAR). Gravimetric variations and seismic Short Duration Events (SDE) confirm the presence of hydrothermal activity. At the Etna observation site, seismic signals, water pressure, magnetic field and acoustic echo intensity are acquired in real-time thanks to a cabled multi-disciplinary observatory (NEMO-SN1 ). This observatory is one of the operative nodes of the European Multidisciplinary Seafloor and water-column Observatory (EMSO; www.emso-eu.org) research infrastructure. Through a multidisciplinary approach, we speculate about deep Etna sources and follow some significant events, such as volcanic ash diffusion in the seawater. Full article

Seafloor observatories enable long term, continuous and multidisciplinary observations, promising major breakthroughs in marine environment research. The effort to remotely control in situ multidisciplinary equipment performing individual and cooperative tasks is both a challenge and a guarantee for the stable operations of functional observatories. With China starting to establish ocean observatory sensor networks, in this study we describe a monitoring system for cabled observatories in the East China Sea (ESOMS) that enables this effort in a plug and play way. An information oriented monitoring architecture for ESOMS was first introduced, derived from a layered control model for ocean observatory sensor network. The architecture contained three components and enabled bidirectional information flow of observation data and commands, based on which architecture components were designed to enable plug-and-play control within related model layers. A control method enabled by general junction box (GJB) and ocean sensor markup language (OSML) was thus proposed as the plug-and-play solution for implementing ESOMS. The GJB-OSML enabled control method (GOE Control Method) mainly actualized two processes, one of which was that the in situ GJB interfaced and represented every attached sensor as a Sensing Endpoint in the cabled observatory network. The other process was that the remote ESOMS utilized the same IP/Port related information modeled by OSML to create/operate a Function Node acted as agent of the in situ sensor. A case study for using ESOMS in the Xiaoqushan Seafloor Observatory was finally presented to prove its performance and applicability. Given this successful engineering trial, the ESOMS design and implementation could be applicable and beneficial for similar efforts in future construction of seafloor observatory network both at home and abroad. Full article

A suitable sampling technology to identify species and to estimate population dynamics based on individual counts at different temporal levels in relation to habitat variations is increasingly important for fishery management and biodiversity studies. In the past two decades, as interest in exploring the oceans for valuable resources and in protecting these resources from overexploitation have grown, the number of cabled (permanent) submarine multiparametric platforms with video stations has increased. Prior to the development of seafloor observatories, the majority of autonomous stations were battery powered and stored data locally. The recently installed low-cost, multiparametric, expandable, cabled coastal Seafloor Observatory (OBSEA), located 4 km off of Vilanova i la Gertrú, Barcelona, at a depth of 20 m, is directly connected to a ground station by a telecommunication cable; thus, it is not affected by the limitations associated with previous observation technologies. OBSEA is part of the European Multidisciplinary Seafloor Observatory (EMSO) infrastructure, and its activities are included among the Network of Excellence of the European Seas Observatory NETwork (ESONET). OBSEA enables remote, long-term, and continuous surveys of the local ecosystem by acquiring synchronous multiparametric habitat data and bio-data with the following sensors: Conductivity-Temperature-Depth (CTD) sensors for salinity, temperature, and pressure; Acoustic Doppler Current Profilers (ADCP) for current speed and direction, including a turbidity meter and a fluorometer (for the determination of chlorophyll concentration); a hydrophone; a seismometer; and finally, a video camera for automated image analysis in relation to species classification and tracking. Images can be monitored in real time, and all data can be stored for future studies. In this article, the various components of OBSEA are described, including its hardware (the sensors and the network of marine and land nodes), software (data acquisition, transmission, processing, and storage), and multiparametric measurement (habitat and bio-data time series) capabilities. A one-month multiparametric survey of habitat parameters was conducted during 2009 and 2010 to demonstrate these functions. An automated video image analysis protocol was also developed for fish counting in the water column, a method that can be used with cabled coastal observatories working with still images. Finally, bio-data time series were coupled with data from other oceanographic sensors to demonstrate the utility of OBSEA in studies of ecosystem dynamics. Full article
