In this paper, the pool boiling of ethanol was analyzed. The experiments were carried out at atmospheric pressure. Heat transfer surfaces in the form of deep minichannels were made of copper. The channels with a depth of 0.2 to 0.5 mm were milled in parallel. The width of the minichannels was 0.6–1.2 mm, and the depth was 5.5, 6, and 10 mm. The highest heat transfer coefficient, 52 kW/m²K, was achieved for the minichannels with a depth of 6 mm and a width of 0.8 mm. The maximum heat flux of 953 kW/m² was produced using minichannels 5.5 mm deep and 0.5 mm wide. An over threefold increase in the heat transfer coefficient and over a twofold increase in the maximum heat flux in relation to the plain surface were obtained. In the heat flux range 21.2–1035 kW/m², the influence of channel width and depth on the heat exchange process was determined. The diameters of the detaching vapor bubbles were determined on the experimental setup using a high-speed camera. An analytical model was developed to determine the diameter of the departing bubble for the analyzed enhanced surfaces. The model correctly represented the changes in bubble diameter with increasing heat flux. Full article

The precise design of heat exchangers in automobile air conditioning systems for more sustainable electric vehicles requires an enhanced assessment of CFD mechanistic models for the subcooled boiling flow of pure eco-friendly refrigerant. Computational Multiphase Flow Dynamics (CMFDs) relies on two-phase closure models to accurately depict the complex physical phenomena involved in flow boiling. This paper thoroughly examines two-phase CMFD flow boiling, incorporating sensitivity analyses of critical parameters such as boiling closures, momentum closures, and population balance models. Three datasets from the DEBORA experiment, involving vertical pipes with subcooled boiling flow of refrigerant at three different pressures and varying levels of inlet liquid subcooling, are used for comparison with CFD simulations. This study integrates nucleate site density and bubble departure diameter models to enhance wall boiling model accuracy. It aims to investigate various interfacial forces and examines the S-Gamma and Adaptive Multiple Size-Group (A-MuSiG) size distribution methods for their roles in bubble break up and coalescence. These proposed approaches demonstrate their efficacy, contributing to a deeper understanding of flow boiling phenomena and the development of more accurate models. This investigation offers valuable insights into selecting the most appropriate sub-closure models for both boiling closure and momentum closure in simulating boiling flows. Full article

In this paper, pool boiling of ethanol at atmospheric pressure was analyzed. The enhanced surfaces were made of copper, on which grooves with a depth ranging from 0.2 to 0.5 mm were milled in parallel. The widths of the microchannels and the distances between them were 0.2 mm, 0.3 mm and 0.4 mm, respectively. The highest heat transfer coefficient, 90.3 kW/m²K, was obtained for the surface with a microchannel depth of 0.5 mm and a width of 0.2 mm. The maximum heat flux was 1035 kW/m². For the analyzed surfaces, the maximum heat flux increase of two and a half times was obtained, while the heat transfer coefficient increased three-fold in relation to the smooth surface. In the given range of heat flux 21.2–1035 kW/m², the impact of geometric parameters on the heat transfer process was presented. The diameters of the departing bubbles were determined experimentally with the use of a high-speed camera. A simplified model was proposed to determine the diameter of the departure bubble for the studied surfaces. Full article

Bubble growth behavior significantly influences boiling heat transfer performance, and different microchannel structures and configurations affect bubble growth behavior. To explore the impact of microchannel structures and configurations on the growth behavior of boiling bubbles, two types of microchannel test plates were fabricated on copper substrates using laser machining technology. It was a parallel configuration plate with five different microchannel spacings and a blade vein configuration plate with four different fractal angles. The bubble growth behavior on these two types of surfaces was studied through visual experiments. The results show that smaller microchannel spacing leads to earlier bubble coalescence and departure times under the same degree of superheat. The 3.00 mm microchannel spacing is the critical interfering distance for the parallel configuration plates, while interference behavior occurs for the bubbles on the simulated vein configuration plates at any fractal angle. Furthermore, in different ranges of superheat, the bubble departure diameter increases with increasing superheat, and the frequency of bubble departure initially increases and then decreases with increasing superheat. This study provides experimental data support and design reference for the design of heat transfer plate structures. Full article

Three-dimensional subcooled flow boiling of R134a in a threaded tube was numerically simulated at the conditions of 200~400 kW/m² heat flux, 3~20 K inlet subcooling, and 0.2~0.6 m/s inlet velocity. The bubble behavior in the horizontal threaded tube with 0.581 mm thread tooth height was observed. The effect of heat flux, inlet subcooling, and inlet velocity on bubble departure diameter and heat transfer coefficient were explored. The results presented the whole growth process of five kinds of bubbles. It was found that the bubbles either collapsed in cold liquid after leaving the heating wall or grew along the axial direction and contacted the heating wall. And there was no bubble sliding during the growth. In addition, the most important and special characteristic of bubble behavior in threaded tubes was the phenomenon of the bubble passing through the cavity. The coalescence and breakup behavior occurred after the bubble passed through the cavity. According to the discussions of the departure diameter and heat transfer coefficient, it was inferred that the bubble departure diameter increased with the increase of heat flux from 200~400 kW/m² and subcooling from 3~20 K while decreasing with the increase of inlet velocity from 0.2~0.6 m/s. And due to the influence of the threaded tube structure, there are special points in the change of bubble departure diameter. The heat transfer coefficient of the bubbles in the threaded tube was higher than the smooth tube, which was increased by 1.5~12.5%. The heat transfer coefficient increased with the increase of heat flux and subcooling and is closely related to the bubble departure diameter. Full article

The numerical method was used to study bubble sliding characteristics and dynamics of R134a during subcooled flow boiling in a narrow gap. In the numerical method, the volume of fraction (VOF) model, level set method, Lee phase change model and the SST k − ω turbulent model were adopted for the construction of the subcooled flow boiling model. In order to explore bubble sliding dynamics during subcooled flow boiling, the bubble sliding model was introduced. The bubble velocity, bubble departure diameter, sliding distance and bubble sliding dynamics were investigated at 0.2 to 5 m/s inlet velocities. The simulation results showed that the bubble velocity at the flow direction was the most important contribution to bubble velocity. Additionally, the bubble velocity of 12 bubbles mostly oscillated with time during the sliding process at 0.2 to 0.6 m/s inlet velocities, while the bubble velocity increased during the sliding process due to the bubble having had a certain inertia at 2 to 5 m/s inlet velocities. It was also found that the average bubble velocity in flow direction accounted for about 80% of the mainstream velocities at 0.2 to 5 m/s. In the investigation of bubble sliding distance and departure diameter, it was concluded that the ratio of the maximum sliding distance to the minimum sliding distance was close to two at inlet velocities of 0.3 to 5 m/s. Moreover, with increasing inlet velocity, the average sliding distance increased significantly. The average bubble departure diameter obviously increased from 0.2 to 0.5 m/s inlet velocity and greatly reduced after 0.6 m/s. Finally, the investigations of the bubble sliding dynamics showed that the surface tension dominated the bubble sliding process at 0.2 to 0.6 m/s inlet velocities. However, the drag force dominated the bubble sliding process at 2 to 5 m/s inlet velocities. Full article

The current work aims to experimentally evaluate the effect of the size of circular superhydrophobic regions of biphilic surfaces on the bubble dynamics under pool boiling conditions. Biphilic surfaces are structured surfaces with tunable wettability, presenting an array of hydrophobic small spots in a hydrophilic surface or vice versa. The factors that affect the bubble dynamics are of geometric nature such as the diameters of the bubbles, their volume, and the height of the centroid, and of more complex nature such as the departure frequency of the bubbles and the rate of evaporation mass transfer. In this study, the bubble dynamics and boiling performance were evaluated by adjusting the diameter of the single circular superhydrophobic regions. A stainless steel AISI 304 foil was used as the base hydrophilic region, and the superhydrophobic regions were made by spray coating the NeverWet^® superhydrophobic solution over well-defined masks. The main conclusion was that the bubble dynamics are clearly affected by the diameter of the superhydrophobic spots. The smaller spots favored the generation of more uniform and stable bubbles, mainly due to the border surface tension forces’ dominance. With the increase in the diameter of the bubbles, the surface tension acting at the border with the much larger hydrophilic region impacts the process less. Thus, the smaller superhydrophobic regions had higher evaporation mass transfer rates. The region with the best pool boiling performance along with improved bubble dynamics was the superhydrophobic region with an 0.8 mm diameter, corresponding to a superhydrophobic area to total area ratio of 0.11%. Moreover, this experimental work confirmed that the bubble dynamics’ impacting factors such as the diameter at the various stages of development of the bubbles can be modulated according to the final objectives of the design and fabrication of the biphilic surfaces. The research significance and novelty of this work come from the comprehensive study of the geometrical pattern of the heat transfer surface in pool boiling conditions and its impact on the bubble dynamics and heat transfer capability. We also suggest further studies considering nanoscale superhydrophobic spot arrangements and the future usage of different working fluids such as nanofluids. Full article

Increased cooling requirements of many compact systems involving high heat fluxes demand the development of high-performance cooling techniques including immersion cooling utilizing pool boiling. This study presents the functionalization of copper surfaces to create interfaces for enhanced pool boiling heat transfer. Three types of surface structures including a crosshatch pattern, shallow channels and deep channels were developed using nanosecond laser texturing to modify the surface micro- and nanomorphology. Each type of surface structure was tested in the as-prepared superhydrophilic state and superhydrophobic state following hydrophobization, achieved through the application of a nanoscale self-assembled monolayer of a fluorinated silane. Boiling performance evaluation was conducted through three consecutive runs under saturated conditions at atmospheric pressure utilizing water as the coolant. All functionalized surfaces exhibited enhanced boiling heat transfer performance in comparison with an untreated reference. The highest critical heat flux of 1697 kW m⁻² was achieved on the hydrophobized surface with shallow channels. The highest heat transfer coefficient of 291.4 kW m⁻² K⁻¹ was recorded on the hydrophobized surface with deep channels at CHF incipience, which represents a 775% enhancement over the highest values recorded on the untreated reference. Surface microstructure was identified as the key reason for enhanced heat transfer parameters. Despite large differences in surface wettability, hydrophobized surfaces exhibited comparable (or even higher) CHF values in comparison with their hydrophilic counterparts, which are traditionally considered as more favorable for achieving high CHF values. A significant reduction in bubble departure diameter was observed on the hydrophobized surface with deep channels and is attributed to effective vapor entrapment, which is pointed out as a major contributing reason behind the observed extreme boiling heat transfer performance. Full article

To study the processes of boiling on a smooth surface with contrast wettability, a hybrid model was developed based on Lattice Boltzmann method and heat transfer equation. The model makes it possible to describe the phenomena of natural convection, nucleate boiling, and transition to film boiling, and, thus, to study heat transfer and the development of crisis phenomena in a wide range of surface superheats and surface wetting characteristics. To find the optimal configuration of the biphilic surface, at the first stage a numerical simulation was carried out for a single lyophobic zone on a lyophilic surface. The dependences of the bubble departure frequency and the departure diameter of the bubble on the width of the lyophobic zone were obtained, and its optimal size was determined. At the next stage, the boiling process on an extended surface was studied in the presence of several lyophobic zones of a given size with different distances between them. It is shown that in the region of moderate surface superheat, the intensity of heat transfer on biphilic surfaces can be several times (more than 4) higher compared to surfaces with homogeneous wettability. Based on numerical calculations, an optimal configuration of the biphilic surface with the ratios of the lyophobic zones’ width of the order of 0.16 and the distance between the lyophobic zones in the range of 0.9–1.3 to the bubble departure diameter was found. Full article

Three-dimensional subcooled flow boiling of R134a in a horizontal tube was simulated by a VOF (volume of fluid) model combined with the level set method. Bubble characteristics were explored at heat flux of 0.3 MW/m², inlet subcooling of 3 K, and inlet velocity of 0.4 m/s. It was observed that five representative bubbles occurred in subcooled flow boiling, including sliding bubble, coalescing bubble, non-departed bubble, bouncing bubble, and continuous-boiling bubble. The results showed that the bubble radial velocity was an important factor of bubble departure after a sliding process. Moreover, the effect of heat flux, inlet velocity, and inlet subcooling on bubble departure diameter were investigated. The departure diameter increased with increasing inlet velocity from 0.2 to 0.4 m/s and heat flux from 0.2 to 0.4 MW/m², while diameter decreased with inlet subcooling from 3 to 10 K. Finally, based on the influence of heat flux, inlet velocity, and inlet subcooling on average departure diameter of the bubble except the coalescing bubble, a model was proposed to predict the average departure diameter. The deviation of the model was within 5%. Full article

The pool-boiling performance of water on thin metal foils with graphene-oxide deposition was studied. The boiling performance was evaluated both on fully coated surfaces, achieved by spin-coating, and surfaces with a laser-textured nucleation site, into which graphene oxide was added via drop-casting. During the experiments, a high-speed IR camera was used to obtain the transient temperature and heat-flux distribution. At the same time, a high-speed video camera was used to acquire synchronized bubble-growth recordings. In addition, a surface-wettability analysis was conducted for all the samples. In the case of fully coated samples, graphene-oxide deposition resulted in an increased number of active nucleation sites and an increase in the nucleation temperature, leading to a lowered nucleation frequency. Meanwhile, samples with a single laser-textured nucleation site enabled the analysis of isolated vapor bubbles, confirming that graphene-oxide deposition leads to a higher nucleation temperature, consequently resulting in a larger bubble-departure diameter and longer growth time. Two explanations for the results are proposed: the wettability of graphene-oxide deposition and the filling of surface microcavities with graphene-oxide nanoflakes. Full article

Non-metallic oxide nanofluids have recently attracted interest in pool boiling heat transfer (PBHT) studies. Research work on carbon and silica-based nanofluids is now being reported frequently by scholars. The majority of these research studies showed improvement in PBHT performance. The present study reports an investigation on the PBHT characteristics and performance of water-based silica nanofluids in the nucleate boiling region. Sonication-aided stable silica nanofluids with 0.0001, 0.001, 0.01, and 0.1 particle concentrations were prepared. The stability of nanofluids was detected and confirmed via visible light absorbance and zeta potential analyses. The PBHT performance of nanofluids was examined in a customized boiling pool with a flat heating surface. The boiling characteristics, pool boiling heat transfer coefficient (PBHTC), and critical heat flux (CHF) were analyzed. The effects of surface wettability, contact angle, and surface roughness on heat transfer performance were investigated. Bubble diameter and bubble departure frequency were estimated using experimental results. PBHTC and CHF of water have shown an increase due to the nanoparticle inclusion, where they have reached a maximum improvement of ≈1.33 times over that of the base fluid. The surface wettability of nanofluids was also enhanced due to a decrease in boiling surface contact angle from 74.1° to 48.5°. The roughness of the boiling surface was reduced up to 1.5 times compared to the base fluid, which was due to the nanoparticle deposition on the boiling surface. Such deposition reduces the active nucleation sites and increases the thermal resistance between the boiling surface and bulk fluid layer. The presence of the dispersed nanoparticles caused a lower bubble departure frequency by 2.17% and an increase in bubble diameter by 4.48%, which vigorously affects the pool boiling performance. Full article

In this paper experiments have been conducted to investigate the flow boiling and heat transfer characteristics in microchannels with three different surface wettability. Three types of microchannels with a super-hydrophilic surface (θ ≈ 0°), a hydrophilic surface (θ = 43°) and an untreated surface (θ = 70°) were prepared. The results show that the average heat transfer coefficient of a super-hydrophilic surface microchannel is significantly higher than that of an untreated surface microchannel, especially when the mass flux is high. The visualization of the flow patterns states that the number of bubble nucleation generated in the super-hydrophilic microchannel at the beginning of the flow boiling is significantly more than that in the untreated microchannel. Through detailed analysis of the experimental data, flow patterns and microchannel surface SEM images, it can be inferred that the super-hydrophilic surface microchannel has more active nucleation cavities, a high nucleation rate and a large nucleation number, a small bubble departure diameter and a fast departure frequency, thereby promoting the flow and heat transfer in the microchannel. In addition, through the force analysis of the vapor-liquid interface, the mechanism that the super-hydrophilic microchannel without dryout under high heat flux conditions is clarified. Full article

Boiling, as the most efficient type of convective heat transfer, is an area of interest in many fields of industry and science. Many works have focused on improving the heat transfer efficiency of boiling by altering the physical and chemical properties of surfaces by using different technological processes in their fabrication. This paper presents experimental investigations into pool boiling on enhanced surfaces with open microchannels. The material of the fabricated surface was copper. Parallel microchannels made by machining were about 0.2, 0.3, and 0.4 mm wide, 0.2 to 0.5 mm deep, and spaced with a pitch equal to twice the width of the microchannel. The experiments were carried out in water at atmospheric pressure. The experimental results obtained showed an increase in the heat flux and the heat transfer coefficient for surfaces with microchannels. The maximum (critical) heat flux was 2188 kW/m², and the heat transfer coefficient was 392 kW/m²K. An improvement in the maximum heat flux of more than 245% and 2.5–4.9 times higher heat transfer coefficient was obtained for the heat flux range of 992–2188 kW/m² compared to the smooth surface. Bubble formation and growth cycle in the microchannel were presented. Two static computational models were proposed to determine the bubble departure diameter. Full article

The pseudopotential Lattice Boltzmann Method has attracted much attention in the recent years for the simulation of boiling heat transfer. Many studies have been published recently for the simulation of the bubble cycle (nucleation, growth and departure from a heated surface). This paper puts forward two-dimensional simulations of bubble nucleation, growth and departure using an improved pseudopotential Lattice Boltzmann Model from the literature at different reduced temperatures, $T_r=0.76$ and $T_r=0.86$. Two different models using the Bhatnagar–Gross–Krook (BGK) and the Multiple-Relaxation-Time (MRT) collision operators with appropriate forcing schemes are used. The results for pool boiling show that the bubbles exhibit axial symmetry during growth and departure. Numerical results of departure diameter and release period for pool boiling are compared against empirical correlations from the literature by varying the gravitational acceleration. Reasonable agreement is observed. Nucleate boiling trends with heat flux are also captured by the simulations. Numerical results of flow boiling simulations are compared by varying the Reynolds number for both reduced temperatures with the MRT model. It was found that the departure diamenter and release period decreases with the increase of the Reynolds number. These results are a direct effect of the drag force. Proper conclusions are commented at the end of the paper. Full article
