Search Results (288)

Search Parameters:
Keywords = bottom geometry

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
18 pages, 1900 KiB
Article
Recovery of Optical Transport Coefficients Using Diffusion Approximation in Bilayered Tissues: A Theoretical Analysis
by Suraj Rajasekhar and Karthik Vishwanath
Photonics 2025, 12(7), 698; https://doi.org/10.3390/photonics12070698 - 10 Jul 2025
Viewed by 311
Abstract
Time-domain (TD) diffuse reflectance can be modeled using diffusion theory (DT) to non-invasively estimate optical transport coefficients of biological media, which serve as markers of tissue physiology. We employ an optimized N-layer DT solver in cylindrical geometry to reconstruct optical coefficients of bilayered [...] Read more.
Time-domain (TD) diffuse reflectance can be modeled using diffusion theory (DT) to non-invasively estimate optical transport coefficients of biological media, which serve as markers of tissue physiology. We employ an optimized N-layer DT solver in cylindrical geometry to reconstruct optical coefficients of bilayered media from TD reflectance generated via Monte Carlo (MC) simulations. Optical properties for 384 bilayered tissue models representing human head or limb tissues were obtained from the literature at three near-infrared wavelengths. MC data were fit using the layered DT model to simultaneously recover transport coefficients in both layers. Bottom-layer absorption was recovered with errors under 0.02 cm−1, and top-layer scattering was retrieved within 3 cm−1 of input values. In contrast, recovered bottom-layer scattering had mean errors exceeding 50%. Total hemoglobin concentration and oxygen saturation were reconstructed for the bottom layer to within 10 μM and 5%, respectively. Extracted transport coefficients were significantly more accurate when obtained using layered DT compared to the conventional, semi-infinite DT model. Our results suggest using improved theoretical modeling to analyze TD reflectance analysis significantly improves recovery of deep-layer absorption. Full article
(This article belongs to the Special Issue Optical Technologies for Biomedical Science)
Show Figures

Figure 1

27 pages, 5055 KiB
Article
Physical–Mathematical Modeling and Simulations for a Feasible Oscillating Water Column Plant
by Fabio Caldarola, Manuela Carini, Alessandro Costarella, Gioia De Raffele and Mario Maiolo
Mathematics 2025, 13(14), 2219; https://doi.org/10.3390/math13142219 - 8 Jul 2025
Viewed by 275
Abstract
The focus of this paper is placed on Oscillating Water Column (OWC) systems. The primary aim is to analyze, through both mathematical modeling and numerical simulations, a single module (chamber) of an OWC plant which, in addition to energy production, offers the dual [...] Read more.
The focus of this paper is placed on Oscillating Water Column (OWC) systems. The primary aim is to analyze, through both mathematical modeling and numerical simulations, a single module (chamber) of an OWC plant which, in addition to energy production, offers the dual advantage of large-scale integration into port infrastructures or coastal defense structures such as breakwaters, etc. The core challenge lies in optimizing the geometry of the OWC chamber and its associated ducts. A trapezoidal cross-section is adopted, with various front wall inclinations ranging from 90° to 45°. This geometric parameter significantly affects both the internal compression ratio and the hydrodynamic behavior of incoming and outgoing waves. Certain inclinations revealed increased turbulence and notable interference with waves reflected from the chamber bottom which determined an unexpected drop in efficiency. The optimal performance occurred at an inclination of approximately 55°, yielding an efficiency of around 12.8%, because it represents the most advantageous and balanced compromise between counter-trend phenomena. A detailed analysis is carried out on several key parameters for the different configurations (e.g., internal and external wave elevations, crest phase shifts, pressures, hydraulic loads, efficiency, etc.) to reach the most in-depth analysis possible of the complex phenomena that come into play. Lastly, the study also discusses the additional structural and functional benefits of inclined walls over traditional parallelepiped-shaped chambers, both from a structural and construction point of view, and for the possible use for coastal defense. Full article
Show Figures

Figure 1

24 pages, 3541 KiB
Article
Substructure Optimization for a Semi-Submersible Floating Wind Turbine Under Extreme Environmental Conditions
by Kevin Fletcher, Edem Tetteh, Eric Loth, Chris Qin and Rick Damiani
Designs 2025, 9(3), 68; https://doi.org/10.3390/designs9030068 - 3 Jun 2025
Viewed by 913
Abstract
A barrier to the adoption of floating offshore wind turbines is their high cost relative to conventional fixed-bottom wind turbines. The largest contributor to this cost disparity is generally the floating substructure, due to its large size and complexity. Typically, a primary driver [...] Read more.
A barrier to the adoption of floating offshore wind turbines is their high cost relative to conventional fixed-bottom wind turbines. The largest contributor to this cost disparity is generally the floating substructure, due to its large size and complexity. Typically, a primary driver of the geometry and size of a floating substructure is the extreme environmental load case of Region 4, where platform loads are the greatest due to the impact of extreme wind and waves. To address this cost issue, a new concept for a floating offshore wind turbine’s substructure, its moorings, and anchors was optimized for a reference 10-MW turbine under extreme load conditions using OpenFAST. The levelized cost of energy was minimized by fixing the above-water turbine design and minimizing the equivalent substructure mass, which is based on the mass of all substructure components (stem, legs, buoyancy cans, mooring, and anchoring system) and associated costs of their materials, manufacturing, and installation. A stepped optimization scheme was used to allow an understanding of their influence on both the system cost and system dynamic responses for the extreme parked load case. The design variables investigated include the length and tautness ratio of the mooring lines, length and draft of the cans, and lengths of the legs and the stem. The dynamic responses investigated include the platform pitch, platform roll, nacelle horizontal acceleration, and can submergence. Some constraints were imposed on the dynamic responses of interest, and the metacentric height of the floating system was used to ensure static stability. The results offer insight into the parametric influence on turbine motion and on the potential savings that can be achieved through optimization of individual substructure components. A 36% reduction in substructure costs was achieved while slightly improving the hydrodynamic stability in pitch and yielding a somewhat large surge motion and slight roll increase. Full article
(This article belongs to the Special Issue Design and Analysis of Offshore Wind Turbines)
Show Figures

Figure 1

31 pages, 10078 KiB
Article
Dynamic Response of Bottom-Sitting Steel Shell Structures Subjected to Underwater Shock Waves
by Fantong Lin, Xianxiang Zhou, Lan Xiao, Ziye Liu and Chaojia Liu
Infrastructures 2025, 10(6), 130; https://doi.org/10.3390/infrastructures10060130 - 28 May 2025
Viewed by 308
Abstract
This study examines the dynamic response of bottom-sitting steel shell structures subjected to underwater shock waves. A computational framework integrating the Arbitrary Lagrangian Eulerian (ALE) method was implemented in finite-element analysis to simulate three-dimensional interactions between shock waves and curved shell geometries (hemispherical [...] Read more.
This study examines the dynamic response of bottom-sitting steel shell structures subjected to underwater shock waves. A computational framework integrating the Arbitrary Lagrangian Eulerian (ALE) method was implemented in finite-element analysis to simulate three-dimensional interactions between shock waves and curved shell geometries (hemispherical and cylindrical configurations). An analysis of the impacts of shock-wave propagation media, explosive distance, charge equivalence, hydrostatic pressure, and shell thickness on the dynamic response of these bottom-sitting shell structures is conducted. The findings reveal that the deformation of semi-spherical steel shells subjected to underwater shock waves is significantly greater than that of shells subjected to air shock waves, with effective stress reaching up to 831.4 MPa underwater. The mechanical deformation of curved steel shells exhibits a gradual increase with increasing explosive equivalents. The center displacement of the hemispherical shell at 800 kg equivalent is 6 times that at 50 kg equivalent. Within the range of 0 to 2.0092 MPa, hydrostatic pressure leads to an approximate 26.34% increase in the center vertical displacement of the semi-cylindrical shell compared with 0 MPa, while restricting horizontal convex deformation. Increasing thickness from 0.025 m to 0.05 m results in a reduction of approximately 60% in the center vertical displacement of the semi-cylindrical shell. These quantitative correlations provide critical benchmarks for enhancing the blast resilience of underwater foundation systems. Full article
Show Figures

Figure 1

18 pages, 10795 KiB
Article
Experimental Study on the Hole-Forming Process at the Borehole Bottom During Hot Water Drilling in Ice and Its Influence Mechanisms
by Zhipeng Deng, Youhong Sun, Xiaopeng Fan, Pavel Talalay, Yifan Yang, Ximu Liu, Da Gong, Bing Li, Ting Wang, Wei Wu, Nan Zhang and Xianzhe Wei
J. Mar. Sci. Eng. 2025, 13(4), 817; https://doi.org/10.3390/jmse13040817 - 20 Apr 2025
Viewed by 625
Abstract
Hot water drilling is a drilling method that employs high-temperature and high-pressure hot water jetting to achieve ice melting drilling. Characterized by rapid drilling speed and large hole diameter, it is widely used for drilling observation holes in polar ice sheets and ice [...] Read more.
Hot water drilling is a drilling method that employs high-temperature and high-pressure hot water jetting to achieve ice melting drilling. Characterized by rapid drilling speed and large hole diameter, it is widely used for drilling observation holes in polar ice sheets and ice shelves. Understanding the hole-enlargement process at the bottom of hot water-drilled holes is crucial for rationally designing the structure of hot water drills. However, due to the complexity of heat transfer processes, no suitable theoretical model currently exists to accurately predict this process. To address this, this paper establishes an experimental platform for hot water drilling and conducts 24 sets of experiments under different drilling parameters using visualization techniques. The study reveals the influence mechanisms of drilling speed, hot water flow rate, hot water temperature, downhole drill shape, and nozzle structure on the hole-forming process at the borehole bottom. Experimental results indicate that the primary hole enlargement occurs near the nozzle, achieving 69–81% of the theoretical maximum borehole diameter. The thermal melting efficiency at the borehole bottom is approximately 80%, with about 20% of the input hot water energy heating the surrounding ice. Under identical hot water parameters, jet shapes and drill shapes exhibit minimal impact on borehole geometry. But the improvement of the jet speed and hot water temperature can accelerate the hole-forming process. Full article
(This article belongs to the Section Ocean Engineering)
Show Figures

Figure 1

26 pages, 4299 KiB
Article
Comprehensive Design Optimization Framework for Prestressed Concrete Continuous Beam Bridge Using Genetic Algorithm and Backpropagation Neural Network
by Hao Bai, Yanbo Zhang, Beiyu You and Keyu Chen
Buildings 2025, 15(8), 1344; https://doi.org/10.3390/buildings15081344 - 17 Apr 2025
Viewed by 543
Abstract
Prestressed concrete (PC) continuous beam bridges are widely used in transportation infrastructure. However, their construction involves substantial material consumption, raising sustainability concerns amid increasing environmental pressures. This study aims to address the urgent need for resource-efficient bridge design by developing a comprehensive optimization [...] Read more.
Prestressed concrete (PC) continuous beam bridges are widely used in transportation infrastructure. However, their construction involves substantial material consumption, raising sustainability concerns amid increasing environmental pressures. This study aims to address the urgent need for resource-efficient bridge design by developing a comprehensive optimization framework that minimizes material usage while ensuring structural safety, durability, and compliance with engineering standards. The proposed methodology integrates a Genetic Algorithm (GA) with a Backpropagation (BP) neural network to optimize both the cross-sectional geometry and the overall alignment of PC continuous beam bridges. The GA is utilized to identify optimal cross-sectional parameters within regulatory constraints, while the BP neural network, trained on extensive design data, refines the bridge bottom height profile to enhance structural performance. The integrated GA-BP framework is validated through a case study of a continuous beam bridge, demonstrating a 94% improvement in design efficiency, a 14% reduction in concrete consumption, and a 34% reduction in prestressed steel usage during the preliminary design stage. These results highlight the framework’s significant potential in advancing sustainable and intelligent bridge design, offering a novel approach to combining artificial intelligence with structural optimization for practical engineering applications. Full article
(This article belongs to the Section Building Structures)
Show Figures

Figure 1

18 pages, 8040 KiB
Article
Tailorable Energy Absorption During Quasi-Static Crush via Additively Manufactured Honeycomb
by Colleen M. Murray, Grace N. Johnson, Min Mao and Norman M. Wereley
Polymers 2025, 17(8), 1050; https://doi.org/10.3390/polym17081050 - 12 Apr 2025
Cited by 2 | Viewed by 471
Abstract
Honeycomb materials are being used for energy absorption applications in aerospace and automotive industries due to their high strength-to-weight ratio. In this work, additively manufactured honeycombs with different inscribed diameters were tested in quasi-static compression on a servo-hydraulic material test system to determine [...] Read more.
Honeycomb materials are being used for energy absorption applications in aerospace and automotive industries due to their high strength-to-weight ratio. In this work, additively manufactured honeycombs with different inscribed diameters were tested in quasi-static compression on a servo-hydraulic material test system to determine how the geometry affects the energy absorption properties. Samples were made from acrylonitrile butadiene styrene in order to study the performance of brittle honeycomb structures in energy absorption applications. Samples were manufactured with buckling initiators, or small triangle cutouts, located at varying distances from the bottom of the sample, while others had no modifications. These buckling initiators create preferential stress concentrations, thus encouraging a controlled folding of the structure. As this study shows, the crush efficiency and energy absorbed efficiency increase as the inscribed diameter decreases. When the inscribed diameter is 20 mm, the crush efficiency is 20.29%, while it is three times larger when the inscribed diameter decreases to 10 mm (62%). The energy absorbed efficiency is 45% for the 10 mm sample while it decreases to 16.70% when the diameter is 20 mm (a 36% decrease). Similarly, the presence of buckling initiators increases crush efficiency and energy absorbed efficiency when compared to samples of similar geometry but no buckling initiators, regardless of the size of the honeycomb. Full article
Show Figures

Figure 1

23 pages, 5906 KiB
Article
Design and Performance Assessment of Biocompatible Capacitive Pressure Sensors with Circular and Square Geometries Using ANSYS Workbench
by Md Shams Tabraiz Alam, Shabana Urooj, Abdul Quaiyum Ansari and Areiba Arif
Sensors 2025, 25(8), 2423; https://doi.org/10.3390/s25082423 - 11 Apr 2025
Viewed by 2431
Abstract
This research outlines the design of capacitive pressure sensors fabricated from three biocompatible materials, featuring both circular and square geometries. The sensors were structured with a dielectric layer positioned between gold-plated electrodes at the top and bottom. Their performance was assessed through simulations [...] Read more.
This research outlines the design of capacitive pressure sensors fabricated from three biocompatible materials, featuring both circular and square geometries. The sensors were structured with a dielectric layer positioned between gold-plated electrodes at the top and bottom. Their performance was assessed through simulations conducted with ANSYS Workbench. Of the various sensor configurations tested, the circular design that included two crescent-shaped slots and a 20 µm thick PDMS dielectric material demonstrated the highest sensitivity of 10.68 fF/mmHg. This study further investigated the relationship between resonant frequency shifts and arterial blood pressure, revealing an exceptionally linear response, as evidenced by a Pearson’s correlation coefficient of −0.99986 and an R-squared value of 0.99972. This confirmed the sensor’s applicability for obtaining precise blood pressure measurements. Additionally, a 3 × 30 mm cobalt–chromium (Co-Cr) stent was obtained, and its inductance was measured using an impedance analyzer. Full article
(This article belongs to the Special Issue Advances in E-health, Biomedical Sensing, Biosensing Applications)
Show Figures

Figure 1

14 pages, 2349 KiB
Article
Numerical Study on Free Convection in an Inclined Wavy Porous Cavity with Localized Heating
by Sivasankaran Sivanandam, Huey Tyng Cheong and Aasaithambi Thangaraj
Modelling 2025, 6(2), 30; https://doi.org/10.3390/modelling6020030 - 5 Apr 2025
Viewed by 946
Abstract
The goal of the present investigation is to explore the heater position and tilting angle of geometry on a buoyant convective stream and energy transport in a tilted, curved porous cavity. This work can be utilized in the field of solar panel construction [...] Read more.
The goal of the present investigation is to explore the heater position and tilting angle of geometry on a buoyant convective stream and energy transport in a tilted, curved porous cavity. This work can be utilized in the field of solar panel construction and electrical equipment cooling. Since no study has explored the impact of the heater location in an inclined wavy porous chamber, three locations of the heater of finite length on the left sidewall, viz., the top, middle, and bottom, are explored. The stream through the porous material is explained by the Darcy model. The upper and lower walls, as well as the remaining area in the left wall, are covered with thermal insulation, while the curved right sidewall maintains the lower temperature. The governing equations and related boundary conditions are discretized by the finite difference approximations. The equations are then iteratively solved for different heater positions, inclinations, Darcy–Rayleigh number (RaD), and corrugation of the right walls. It is witnessed that the heater locations and cavity inclinations alter the stream and thermal fields within the curved porous domain. Furthermore, all heating zones benefit from improved heat conduction due to the right sidewall’s waviness and the tilted porous domain. Full article
Show Figures

Figure 1

14 pages, 6999 KiB
Article
Aluminium/Steel Joints with Dissimilar Thicknesses: Enhancement of UTS and Ductility Through Making an S-Shaped Interface and a Mixed-Mode Fracture
by Tiago Oliveira Gonçalves Teixeira, Reza Beygi, Ricardo João Camilo Carbas, Eduardo Andre Sousa Marques, Masih Bolhasani Hesari, Mohammad Mehdi Kasaei and Lucas Filipe Martins da Silva
J. Manuf. Mater. Process. 2025, 9(4), 120; https://doi.org/10.3390/jmmp9040120 - 5 Apr 2025
Viewed by 519
Abstract
This study presents a simple and innovative design to join a 2 mm thick steel sheet to a 5 mm thick aluminium sheet in a butt configuration. Thickness differences were addressed using support plates, while an aluminium run-on plate was employed to prevent [...] Read more.
This study presents a simple and innovative design to join a 2 mm thick steel sheet to a 5 mm thick aluminium sheet in a butt configuration. Thickness differences were addressed using support plates, while an aluminium run-on plate was employed to prevent the FSW tool from plunging into the steel. The process produced a unique S-shaped Al/St interface, the formation mechanism of which is analysed in this study. Scanning electron microscopy (SEM) observations revealed a gradient in the thickness of intermetallic compounds (IMCs) along the joint interface, decreasing from the top to the bottom. This S-shaped interface led to a 150% increase in the ultimate tensile strength (UTS) of the joint. The mechanism underlying this enhancement, attributed to the curved geometry of the interface and its alignment with the loading direction, is discussed in detail. These findings highlight the potential of this approach for improving the performance of dissimilar material joints in lightweight structural applications. Full article
(This article belongs to the Special Issue Advances in Dissimilar Metal Joining and Welding)
Show Figures

Figure 1

16 pages, 4912 KiB
Article
Characterization of Laser-Ablated Bound Metal Deposition (laBMD)
by Alexander Watson, Masoud Rais-Rohani, John Belding, Jasper McGill and Brett D. Ellis
J. Manuf. Mater. Process. 2025, 9(4), 119; https://doi.org/10.3390/jmmp9040119 - 4 Apr 2025
Viewed by 623
Abstract
Additive manufacturing of metals is limited by a fundamental tradeoff between deposition rates and manufacturability of fine-scale features. To overcome this problem, a laser-ablated bound metal deposition (laBMD) process is demonstrated in which 3D-printed green-state bound metal deposition (BMD) parts are post-processed via [...] Read more.
Additive manufacturing of metals is limited by a fundamental tradeoff between deposition rates and manufacturability of fine-scale features. To overcome this problem, a laser-ablated bound metal deposition (laBMD) process is demonstrated in which 3D-printed green-state bound metal deposition (BMD) parts are post-processed via laser ablation prior to conventional BMD debinding and sintering. The laBMD process is experimentally characterized via a full-factorial design of experiments to determine the effect of five factors—number of laser passes (one pass, three passes), laser power (25%, 75%), scanning speed (50%, 100%), direction of laser travel (perpendicular, parallel), and laser resolution (600 dpi, 1200 dpi)—on as-sintered ablated depth, surface roughness, width, and angle between ablated and non-ablated regions. The as-sintered ablation depth/pass ranged from 3 to 122 µm/pass, the ablated surface roughness ranged from 3 to 79 µm, the angle between ablated and non-ablated regions ranged from 1° to 68°, and ablated bottom widths ranged from 729 to 1254 µm. This study provides novel insights into as-manufactured ablated geometries and surface finishes produced via laser ablation of polymer–metallic composites. The ability to inexpensively and accurately manufacture fine-scale features with tailorable geometric tolerances and surface finishes is important to a variety of applications, such as manufacturing molds for microfluidic devices. Full article
Show Figures

Figure 1

26 pages, 9353 KiB
Review
The Review of Selected Non-Pneumatic Tires Properties—Load Carrying Mechanism, Structure of Non-Pneumatic Tires
by Marcin Żmuda and Jerzy Jackowski
Materials 2025, 18(7), 1566; https://doi.org/10.3390/ma18071566 - 30 Mar 2025
Viewed by 868
Abstract
In recent years, non-pneumatic tires have been gaining popularity, which can be seen in the increase in research results and proposals from world-class tire manufacturers (mainly as technology demonstrators). The possibility of eliminating the need to maintain compressed air is a major factor [...] Read more.
In recent years, non-pneumatic tires have been gaining popularity, which can be seen in the increase in research results and proposals from world-class tire manufacturers (mainly as technology demonstrators). The possibility of eliminating the need to maintain compressed air is a major factor in the development of non-pneumatic tires and their usage in vehicles. Articles and patents were reviewed in relation to the load transfer mechanism, the design of non-pneumatic tire components, and recommendations for materials. Non-pneumatic tire top loaders are a desirable type of this type of wheel compared to bottom loaders, because they transfer loads over a larger part of the wheel, which increases their load capacity. Most non-pneumatic tires consist of a rim, an elastic structure, and a shear beam/band with a tread. The rim is used to secure the elastic structure and can be fitted with vibration dampers in the form of circumferential rubber rings. The gradient elastic structure, in comparison with the homogeneous structure (same thickness or dimensions of the elements), allows the range of axle displacements to be adjusted to the desired level without the need to increase the size of the wheel, and also influences the change in the location of the maximum stresses. The shear beam/ band mimics the properties of compressed air used in pneumatic tires. The shear beam/ band made as a webbing geometry ensures uniform pressure in the contact patch. The reinforced composite shear beam/ band ensures adequate bending strength with low energy losses and a small thickness of the beam/ band. Materials commonly used in the tire industry are used as reinforcement for the shear beam/ band, which was illustrated by the results of our own research. Full article
Show Figures

Graphical abstract

15 pages, 3576 KiB
Article
Effect of Solidification Direction on the Freckle Formation in Single-Crystal Superalloy Castings
by Dexin Ma, Hongyuan Sun, Yunxing Zhao, Weitai Xu, Zaiwang Huang, Bowen Cheng, Yang Liu, Fu Wang, Qiang Yang, Lv Li, Yangpi Deng, Fuze Xu, Haijie Zhang and Menghuai Wu
Materials 2025, 18(7), 1534; https://doi.org/10.3390/ma18071534 - 28 Mar 2025
Cited by 1 | Viewed by 637
Abstract
Solidification experiments in two opposite directions were conducted to investigate the buoyancy effect on freckle formation during directional solidification in single-crystal superalloy castings. During conventional upward solidification with the superalloy CMSX-4, severe freckles were observed in castings of various geometries. By reversing the [...] Read more.
Solidification experiments in two opposite directions were conducted to investigate the buoyancy effect on freckle formation during directional solidification in single-crystal superalloy castings. During conventional upward solidification with the superalloy CMSX-4, severe freckles were observed in castings of various geometries. By reversing the solidification direction from upward to downward, freckle-free castings could be obtained. To visually verify the effect of the solidification direction, an in situ observation experiment by varying the solidification direction was performed using a Ga-In alloy. In the upward solidification process, strong solutal convection was visually observed due to the decrease in the density of the interdendritic liquid. Conversely, a stable condition without visible flow was established during downward solidification, due to the stable state of the top-light, bottom-heavy liquid system. A new Rayleigh-number model was successfully applied to characterize the freckle features in superalloy cluster castings. When the solidification direction was reversed from upward to downward, the driving force for solutal convection was suppressed, leading to the complete elimination of freckle formation in single-crystal superalloy castings. Full article
(This article belongs to the Special Issue Achievements in Foundry Materials and Technologies)
Show Figures

Figure 1

31 pages, 18317 KiB
Article
Computational Model and Constructal Design Applied to Thin Stiffened Plates Subjected to Elastoplastic Buckling Due to Combined Loading Conditions
by Raí Lima Vieira, Guilherme Ribeiro Baumgardt, Elizaldo Domingues dos Santos, Luiz Alberto Oliveira Rocha, Thiago da Silveira, João Paulo Silva Lima and Liércio André Isoldi
Appl. Sci. 2025, 15(6), 3354; https://doi.org/10.3390/app15063354 - 19 Mar 2025
Cited by 1 | Viewed by 384
Abstract
The size of ships has increased considerably in recent decades. This growth impacts the stress magnitude in the bottom hull plates, which constantly suffer from biaxial compression and lateral water pressure, potentially leading to buckling. Adding stiffeners is an effective alternative to increase [...] Read more.
The size of ships has increased considerably in recent decades. This growth impacts the stress magnitude in the bottom hull plates, which constantly suffer from biaxial compression and lateral water pressure, potentially leading to buckling. Adding stiffeners is an effective alternative to increase mechanical buckling resistance if placed in a proper way. Several researchers have investigated the influence of stiffeners on plates under different loading conditions. However, the behavior under combined biaxial compression and lateral pressure has not yet been widely explored. This work aims to verify and validate a computational model to analyze the elastoplastic buckling of plates under biaxial compression and lateral pressure, applying it in a case study to define the ideal geometric configuration to increase ultimate buckling resistance, using the constructal design method and exhaustive search technique. In this study, a portion of the volume from a reference plate without stiffeners was converted into stiffeners to determine the optimal geometry for maximizing ultimate buckling resistance. The numerical model was verified and validated, and the case study identified the optimal plate configuration with five longitudinal and four transverse stiffeners, with a height-to-thickness ratio of 8.70, achieving a 284% increase in ultimate buckling resistance compared to the reference plate. These results highlight the importance of geometric evaluation in structural engineering problems. Full article
(This article belongs to the Special Issue Structural Mechanics in Materials and Construction)
Show Figures

Figure 1

23 pages, 8962 KiB
Article
A Parametric Design Method for Unstepped Planing Hulls Using Longitudinal Functions and Shape Coefficients
by Junjie Chen, Yongpeng Ou, Guo Xiang, Qing Ye and Wei Wang
Appl. Sci. 2025, 15(5), 2667; https://doi.org/10.3390/app15052667 - 1 Mar 2025
Viewed by 865
Abstract
This paper proposes a specifically parametric design method for planing hulls using longitudinal functions and shape coefficients in order to meet the requirements for optimizing the hydrodynamic performance of planing hulls. To fully define the geometry of the planing hull, a series of [...] Read more.
This paper proposes a specifically parametric design method for planing hulls using longitudinal functions and shape coefficients in order to meet the requirements for optimizing the hydrodynamic performance of planing hulls. To fully define the geometry of the planing hull, a series of design parameters and a set of longitudinal functions and shape coefficients are introduced to define key geometric features. The main frame curves of the hull are designed from bottom to top to ensure the priority and independence of parameters related to the planing surface. The mathematical equations of the control points of the keel curve, chine curve, sheer curve, and surface station curve of the hull framework are established and solved based on B-spline theory. This configures the basis for generating a continuous smooth surface of the hull. Finally, based on the frame curves, the hull surface was generated by using NURBS surface interpolation. The design parameters, especially the longitudinal functions and shape coefficients, can intuitively and independently control the key features of the hull form, which allow control over key geometric features that are highly relevant to the hydrodynamics of the planing hull. By utilizing this approach, rapid production of deep-V and radial planing hulls is achievable, resulting in closed and smooth hull surfaces. Case studies have provided evidence that the modeling of monohull unstepped planing hulls with diverse characteristics can be effectively accomplished through the definition of these parameters. Full article
(This article belongs to the Section Marine Science and Engineering)
Show Figures

Figure 1
