To ensure the vibration safety of rotor support systems in modern aeroengines, this study develops a dynamic model of the aeroengine gas generator rotor system and analyzes its complex unbalance response characteristics. Subsequently, it investigates vibration reduction strategies based on these response patterns. This study begins by developing individual dynamic models for the disk–blade system, the circular arc end-teeth connection structure and the squeeze film damper (SFD) support system. These models are then integrated using the differential quadrature finite element method (DQFEM) to create a comprehensive dynamic model of the gas generator rotor system. The unbalance response characteristics of the rotor system are calculated and analyzed, revealing the impact of the unbalance mass distribution and the combined support system characteristics on the unbalance response of the rotor system. Drawing on the obtained unbalance response patterns, the vibration reduction procedures for the rotor support system are explored and experimentally verified. The results demonstrate that the vibration response of the modern aeroengine rotor support system can be reduced by adjusting the unbalance mass distribution, decreasing the bearing stiffness and increasing the bearing damping, thereby enhancing the vibration safety of the rotor system. This study introduces a novel integration of DQFEM with detailed component-level modeling of circular arc end-teeth connections, disk–blade interactions and SFD dynamics. This approach uniquely captures the coupled effects of unbalance distribution and support system characteristics, offering a robust framework for enhancing vibration safety in aeroengine rotor systems. The methodology provides both theoretical insights and practical guidelines for optimizing rotor dynamic performance under unbalance-induced excitations. Full article

The residential sector is one of the main sectors responsible for the atmospheric emission of CO₂. Hence, a significant effort is required to develop technological solutions to enable decarbonization. The integration of Organic Rankine Cycle (ORC)-based units with renewable sources at a micro-scale of cogeneration units is commonly believed to be one of the most important technological alternatives. Indeed, an ORC-based unit allows the exploitation of low-temperature heat sources in the production of electricity. The low power scale of this application (1–5 kW) and the severe operating conditions call for the reliable and proper design of components. Particularly critical is the pump, as the experimental analyses available in the literature show its efficiency rarely exceeds values of 0.3. The most suitable technology is volumetric, and among those available, the sliding vane types are interesting candidates. However, low efficiency leads to a significant erosion of the power produced by the expander, limiting the achievement of high-efficiency values. What is more, in the literature, there is a lack of development of optimization strategies to improve the performance of this machine. To fill this knowledge gap, in this present paper an optimized sliding vane rotary pump was designed. Thanks to a comprehensive experimentally validated model, the pump performance was assessed for a wide range of operating conditions. Results confirmed that a disk-shaped configuration also ensures the best efficiency is achieved for small-scale pumps. Moreover, the model allowed for a detailed analysis of efficiency, evaluating the volumetric, fluid dynamic and mechanical behaviors. Results demonstrated that the weakest point was the mechanical efficiency, which was between 0.45 and 0.55. The best configuration was that involving four blades, the adoption of graphite and a clearance gap between the rotor face and casing of 10 μm. These design solutions improved efficiency by up to 25%, with a maximum value equal to 0.50, which is close to double with respect to the usual values. A final remark concerns the operating robustness of the machine, as the efficiency demonstrated weak variations even when wide operating conditions were considered. Full article

Vibroacoustic metamaterials represent an innovative technology developed for broadband vibration reduction. They consist of an array of local resonators and are able to reduce vibrations over a wide frequency range, commonly referred to as a stop band. Vibroacoustic metamaterials may be a promising strategy to reduce out-of-plane vibrations of thin-walled, disk-shaped structures, such as saw blades. However, their behavior in rotating systems has not yet been fully understood. In this study, a vibroacoustic metamaterial integrated into a circular disk for the reduction of out-of-plane vibrations is experimentally investigated in the rotating and non-rotating state. Derived from the predominant frequency range of noise emitted by saw blades, a vibroacoustic metamaterial with a numerically predicted stop band in the frequency range from 2000 Hz to 3000 Hz, suitable for integration into a circular disk, is designed. The resonators of the metamaterial are realized by cutting slots into the disk using a waterjet cutting machine. To experimentally examine the structural dynamic behavior, the disk is excited by an impulse hammer and observed by a stationary optical velocity sensor on a rotor dynamics test stand. The results of the rotating and the non-rotating state are compared. The measurements are carried out at two different radii and at speeds up to 3000 rpm. A distinct stop band characteristic is shown in the desired frequency range from 2000 Hz to 3000 Hz in the rotating and non-rotating state. No significant shift of the stop band frequency range was observed during rotation. However, adjacent modes were observed to propagate into the stop band frequency range. This work contributes to a better understanding of the behavior of vibroacoustic metamaterials in the rotating state and enables future applications of vibroacoustic metamaterials for vibration reduction in rotating, disk-shaped structures such as saw blades, brake disks or gears. Full article

Tidal stream turbines (TST) are a promising option for electricity generation to meet the ever-increasing demand for energy. The actuator disk (AD) method is often employed to represent a TST, to evaluate the TST operating in a tidal flow. While this method can effectively reduce the computational cost and provide accurate prediction of far-wake flow conditions, it falls short of fully characterising critical hydrodynamics elements. To address this limitation, a hybrid method is implemented by coupling AD with the blade element momentum (BEM) theory, using detailed performance data, such as thrust, to enhance the prediction of the wake effects. This work focuses on the development of a hybrid BEM–AD method using Reynolds-Averaged Navier–Stokes (RANS) turbulence models within computational fluid dynamics (CFD). Two variations and a hybrid modification of an AD model are presented in this paper. The first modified variation is a velocity variation that takes into account velocity profile inflow into the disk’s configuration. The second modified variation is a radial variation that integrates the blade element theory into the disk’s configuration. The hybrid modified model combines both the velocity profiles influenced and blade element theory in the design and analysis of the actuator disk. Several key investigations on some of the pre-solver parameters are also investigated in this research such as the effect of changing velocity and radial distance on the porosity and loss coefficient of the actuator disk performance. Importantly, this work provides an improved method to evaluate the key wake effects from a TST array which is crucial to determine the power performance of the TST array. Full article

Interfacial stress between layers of thermal barrier coatings near free edges is a critical factor that may cause turbine blades to fail. This paper uses simulation methods to reveal the effects of variations in geometric and material parameters on the stress of thermal barrier coatings. The stress distributions of a disk-shaped coating–substrate system undergoing thermal mismatch are calculated by an analytical method and the finite element method. The analytical solution reveals that the coefficient of thermal expansion, elasticity modulus, Poisson’s ratio, and thickness of each layer affect interfacial stress between coatings and substrate. The simulation results exhibit significant concentrations of the normal and shear stresses, which make the coating system prone to cracking and spalling from the free edge. The parametric analysis highlights that the thermal mismatch strain affects the stress magnitude. The region affected by free edges becomes larger with increasing thickness, elasticity modulus, and Poisson’s ratio of the topcoat. Finally, two integral parameters are proposed to represent the stress state near the free edge related to mode I and II fracture, respectively. The parameters, not sensitive to the grid density, are validated by experiments. Full article

The paper describes a numerical method based on a modal work approach to evaluate the forced response of bladed disks and its validation against numerical results obtained by a commercial FEM code. Forcing functions caused by rotor–stator interactions are extracted from CFD unsteady solutions properly decomposed in time and space to separate the spinning perturbation acting on the bladed disk in a cyclic environment. The method was firstly applied on a dummy test case with cyclic symmetry where the forcing function distributions were arbitrarily selected: comparisons for resonance and out of resonance conditions revealed an excellent agreement between the two numerical methods. Finally, the validation was extended to a more realistic test case representative of a low-pressure turbine bladed rotor subjected to the wakes of two upstream rows: an IGV with low blade count and a stator row. The results show a good agreement and suggest computing the forced response problem on the finer CFD blade surface grid to achieve a better accuracy. The successful validation of the method, closely linked to the CFD environment, creates the opportunity to include the tool in an integrated multi-objective procedure able to account for aeromechanical aspects. Full article

This paper presents the microstructural characteristics and mechanical properties of linear friction-welded (LFWed) Ti-6Al-2Sn-4Zr-2Mo-0.1Si (Ti-6242) in as-welded (AWed) and stress relief-annealed (SRAed) conditions. The weld center (WC) of the AWed Ti-6242 consisted of recrystallized prior-β grains with α’ martensite that were tempered during SRA at 800 °C for 2 h and transformed into an acicular α + β microstructure. The peak hardness values, obtained in the AWed joints at the WC, sharply decreased through the thermomechanically affected zones (TMAZs) to the heat-affected zone (HAZ) of the Ti-6242 parent metal (PM). The SRA lowered the peak hardness values at the WC slightly and fully recovered the observed softening in the HAZ. The tensile mechanical properties of the welds in the AWed and SRAed conditions surpassed the minimum requirements in the AMS specifications for the Ti-6242 alloy. Fatigue tests, performed on the SRAed welds, indicated a fatigue limit of 468 MPa at 10⁷ cycles, just slightly higher than that of the Ti-6242 PM (434 MPa). During tensile and fatigue testing, the welds failed in the PM region, which confirms the high mechanical integrity of the joints. Both the tensile and fatigue fracture surfaces exhibited characteristic features of ductile Ti-6242 PM. Full article

To improve the reliability and safety of the mistuned blisk (integrally bladed disk), a novel strategy for passive vibration reduction by the hard coating was developed, and the vibration and damping characteristics of the HCM (hard-coating mistuned) blisk were investigated in this work. Firstly, by the proposed criterion called FDSD (frequency difference and its standard deviation), a classical reduced-order model established by the component mode synthesis method was modified to carry out modal analysis for high computational efficiency. Then, forced vibration responses of the HCM blisk were achieved by the Rayleigh damping model. Next, a specific benchmark of a mistuned blisk deposited NiCoCrAlY + YSZ hard coating was chosen to conduct numerical calculations, and the results were compared with those obtained from the FOM (full-order model) and experimental test, respectively. Finally, the influence of the hard coating and coating thickness on the mistuned blisk were investigated, in particular. Full article

The Blade-Element Momentum (BEM) model for Horizontal-Axis Wind Turbines (HAWTs), although extremely useful, is known to be approximate due to model formulation insufficiencies, for which add-ons and corrections have been formulated over the past many decades. Scrutiny of the axial and azimuthal momentum conservation properties reveals momentum simplifications and absence of momentum sources not included in momentum theory underlying the standard BEM. One aspect relates to azimuthal momentum conservation, the wake swirl. This correction can be expressed analytically. Another aspect relates to axial momentum conservation, the wake expansion. This correction is not analytically quantifiable. The latter correction term is therefore quantified from postprocessing a large number of axisymmetric Actuator Disk (AD) Navier-Stokes computations with systematic variation of disk loading and tip-speed ratio. The new momentum correction terms are then included in the BEM model, and results benchmarked against references. The corrected BEM is derived by re-visiting the governing equations. For a disk represented by a constant-circulation set of blades, the corrected BEM contains no approximation to the underlying conservation laws. The study contributes by bridging the gap between BEM and the axisymmetric AD method for all disk load levels and tip speed ratios relevant for a wind turbine. The wake swirl correction leads to higher power efficiency at lower tip-speed ratios. The wake expansion correction causes a redistribution of the potential for power extraction, which increases on the inner part of the rotor and decreases on the outer part of the rotor. The overall rotor-averaged value of Betz limit is unaffected by the new corrections, but exceeding Betz locally on the inner- and mid-section of the rotor is shown to be possible. The two corrections significantly improve the axi-symmetric static BEM modelling accuracy for the radial distributions as well as for the rotor-integrated quantities, by reducing errors, approximately one order of magnitude. The relevance of these corrections for modern multi-MW rotors is quantified and discussed. Full article

The decreasing performance of jet engines during operation is a major concern for airlines and maintenance companies. Among other effects, the erosion of high-pressure compressor (HPC) blades is a critical one and leads to a changed aerodynamic behavior, and therefore to a change in performance. The maintenance of BLISKs (blade-integrated-disks) is especially challenging because the blade arrangement cannot be changed and individual blades cannot be replaced. Thus, coupled deteriorated blades have a complex aerodynamic behavior which can have a stronger influence on compressor performance than a conventional HPC. To ensure effective maintenance for BLISKs, the impact of coupled misshaped blades are the key factor. The present study addresses these effects on the aerodynamic performance of a first-stage BLISK of a high-pressure compressor. Therefore, a design of experiments (DoE) is done to identify the geometric properties which lead to a reduction in performance. It is shown that the effect of coupled variances is dependent on the operating point. Based on the DoE analysis, the thickness-related parameters, the stagger angle, and the max. profile camber as coupled parameters are identified as the most important parameters for all operating points. Full article

For the purpose of improving the working reliability of the blisk (integrally-bladed disk) under severe environment, a passive vibration reduction method by depositing a hard coating on both sides of blades is developed and then investigated systematically. Firstly, an analytical model of the blisk-deposited hard coating is taken into account. Secondly, by using the Oberst beam theory and axial symmetry property, the composite hard-coated blade is equivalent to a special homogeneous blade possessing the equivalent material parameters. Then, energy equations of the blisk with hard-coated blades are derived by using the complex-valued modulus, and then substituted into the Lagrange equations. Additionally, eigenvalue equations of the blisk with hard-coated blades are acquired by taking advantage of Rayleigh-Ritz method, and its natural characteristics are obtained subsequently. Further, the frequency response functions of the blisk with hard-coated blades are formulated by using proportional damping to achieve its damping matrix. Finally, a stainless-steel blisk with deposited NiCoCrAlY + YSZ hard coating on both sides of the blades is chosen as the study case to conduct numerical calculations, and the results are compared with those obtained by experimental tests in terms of natural frequencies and mode shapes. The variation of natural frequencies, modal loss factors and frequency response functions of the blisk generated by hard coating are studied, respectively, and the influence of the coating thickness on the damping capacity are further discussed. Full article

As one of fracture critical components of an aircraft engine, accurate life prediction of a turbine blade to disk attachment is significant for ensuring the engine structural integrity and reliability. Fatigue failure of a turbine blade is often caused under multiaxial cyclic loadings at high temperatures. In this paper, considering different failure types, a new energy-critical plane damage parameter is proposed for multiaxial fatigue life prediction, and no extra fitted material constants will be needed for practical applications. Moreover, three multiaxial models with maximum damage parameters on the critical plane are evaluated under tension-compression and tension-torsion loadings. Experimental data of GH4169 under proportional and non-proportional fatigue loadings and a case study of a turbine disk-blade contact system are introduced for model validation. Results show that model predictions by Wang-Brown (WB) and Fatemi-Socie (FS) models with maximum damage parameters are conservative and acceptable. For the turbine disk-blade contact system, both of the proposed damage parameters and Smith-Watson-Topper (SWT) model show reasonably acceptable correlations with its field number of flight cycles. However, life estimations of the turbine blade reveal that the definition of the maximum damage parameter is not reasonable for the WB model but effective for both the FS and SWT models. Full article
