A polarized bidirectional reflectance distribution function (pBRDF) matrix was developed based on the two-scale roughness theory to provide consistent simulations of fully polarized microwave emission and scattering, required for the ocean–atmosphere-coupled radiative transfer model. In this study, the potential of the two-scale pBRDF matrix was explored for simulating ocean full-polarization backscattering and bistatic-scattering normalized radar cross sections (NRCSs). Comprehensive numerical simulations of the two-scale pBRDF matrix across the L-, C-, X-, and Ku-bands were carried out, and the simulations were compared with experimental data, classical electromagnetic, and GMFs. The results show that the two-scale pBRDF matrix demonstrates reasonable dependencies on ocean surface wind speeds, relative wind direction (RWD), geometries, and frequencies and has a reliable accuracy in general. In addition, the two-scale pBRDF matrix simulations were compared with the observations from the advanced scatterometer (ASCAT) onboard MetOP-C satellites, with a correlation coefficient of 0.9634 and a root mean square error (RMSE) of 2.5083 dB. In the bistatic case, the two-scale pBRDF matrix simulations were compared with Cyclone Global Navigation Satellite System (CYGNSS) observations, demonstrating a good correlation coefficient of 0.8480 and an RMSE of 1.2859 dB. In both cases, the two-scale pBRDF matrix produced fairly good simulations at medium-to-high wind speeds. The relatively large differences at low wind speeds (<5 m/s) were due probably to the swell effects. This study proves that the two-scale pBRDF matrix is suitable for the applications of multiple types of active instruments and can consistently simulate the ocean surface passive and active signals. Full article

This study represents the development and analysis of the types of metamaterial structures for terahertz frequency. Recently, investigations about unique coding metamaterial have become well-known among the scientific community since it can manipulate electromagnetic (EM) waves by utilizing various coding sequences. Therefore, several coding and tailored metamaterial designs were compared and numerically analyzed the performances in this research work. The 1-bit coding metamaterial made up of only “0” and “1” elements by adopting two types of unit cells with 0 and π phase responses were analyzed for the coding metamaterial. Moreover, for the numerical simulation analyses, the well-known Computer Simulation Technology (CST) Microwave Studio software was adopted. This investigation focused on the frequency ranges from 0 to 5 THz. On the other hand, the proposed designs were simulated to find their scattering parameter behavior. The comparison of coding and tailored metamaterial revealed slight differences in the RCS values. The coding metamaterial designs manifested RCS values less than −50 dBm², while tailored metamaterial designs exhibited less than −60 dBm². Furthermore, the proposed designs displayed various transmission coefficient result curves for both types of metamaterial. Moreover, the bistatic far-field scattering patterns of both metamaterial designs were presented in this work. In a nutshell, the 1-bit coding metamaterial with a unique sequence can influence the EM waves and realize different functionalities. Full article

The interest in bistatic SAR systems for soil moisture monitoring has grown over recent years, since theoretical studies suggest that the impact of surface roughness on the retrieval of soil moisture decreases when multistatic, i.e., simultaneous mono- and bistatic, radar measurements are used. This paper presents a semi-empirical method to retrieve soil moisture over bare agricultural fields, based on effective roughness modeling, and applies it to a series of L-band fully-polarized SAR backscatter and bistatic scattering observations. The main advantage of using effective roughness parameters is that surface roughness no longer needs to be measured in the field, what is known to be the main source of error in soil moisture retrieval applications. By means of cross-validation, it is shown that the proposed method results in accurate soil moisture retrieval with an RMSE well below 0.05 m³/m³, with the best performance observed for the cross-polarized backscatter signal. In addition, different experimental SAR monostatic and bistatic configurations are evaluated in this study using the proposed retrieval technique. Results illustrate that the soil moisture retrieval performance increases by using backscatter data in multiple polarizations simultaneously, compared to the case where backscatter observations in only one polarization mode are used. Furthermore, the retrieval performance of a multistatic system has been evaluated and compared to that of a traditional monostatic system. The recent BELSAR campaign (in 2018) provides time-series of experimental airborne SAR measurements in two bistatic geometries, i.e., the across-track (XTI) and along-track (ATI) flight configuration. For both configurations, bistatic observations are available in the backward region. The results show that the simultaneous use of backscatter and bistatic scattering data does not result in a profound increase in retrieval performance for the bistatic configuration flown during BELSAR 2018. As theoretical studies demonstrate a strong improvement in retrieval performance when using backscatter and bistatic scattering coefficients in the forward region simultaneously, the introduction of additional bistatic airborne campaigns with more promising multistatic SAR configurations is highly recommended. Full article

The anomalous propagation conditions, particularly the tropospheric ducts, severely impact the regular operation and performance evaluation of radio devices in the atmospheric boundary layer. Therefore, it is necessary to provide the regional distribution of tropospheric ducts for utilizing or avoiding these abnormal propagation phenomena. As significant uncooperative signal sources, the global navigation satellite systems (GNSS) have been widely applied in the remote sensing of the ocean and atmosphere due to the greater convenience and lower cost. With the completed deployment of the BeiDou Navigation Satellite System (BDS) in 2020, an additional source can be chosen in the relevant studies. Taking the BDS as an example, since the scattered signals from the ocean surface at low satellite elevation angles can be effectively trapped by tropospheric ducts, we propose a method to invert for the regional distribution of tropospheric ducts using the received power of ocean-scattered signals in this paper. Firstly, the propagation model was built to calculate the received power, and a suite of simulations was made in various atmospheric environments. The results suggested that the received power is more sensitive to the surface duct without a base layer. Then, we made a preliminary estimation of the tropospheric ducts on the ocean nearby Qingdao utilizing the Weather Research and Forecasting (WRF) model as well as the echo data measured by a Doppler weather radar. Before the inversion, the actual satellite azimuth and elevation angles should be obtained to evaluate the bistatic scattering coefficients and the received powers of the selected satellite signals. Finally, we presented an inversion example using the proposed method. In absence of the actual measurements, the received powers pre-estimated at different SNRs served as the inputs of the inversion process and the estimated duct parameters were used to verify the validity of the proposed inversion method. For both the received power and modified refractivity profile, the fitness between the values pre-estimated using the estimated duct parameters and calculated by the inverted duct parameters gets better as the elevation angle decreases and the SNR increases. The variation of the fitness between the estimated and inverted values is slightly different for each duct parameter. Moreover, the calculation of inversion errors further explained the above behaviors, including the mean absolute error (MAE) and the root mean square error (RMSE). Despite some certain errors, the inversion results maintain the overall tendencies and most characteristics of the estimated values, thus proving the validity of the inversion method. Full article

Soil moisture is one of the vital environmental variables in the land–atmosphere cycle. A study of the sensitivity analysis of bistatic scattering coefficients from bare soil at the Ku-band is presented, with the aim of deepening our understanding of the bistatic scattering features and exploring its potential in soil moisture retrieval. First, a well-established advanced integral method was adopted for simulating the bistatic scattering response of bare soil. Secondly, a sensitivity index and a normalized weight quality index were proposed to evaluate the effect of soil moisture on the bistatic scattering coefficient in terms of polarization and angular diversity, and the combinations thereof. The results of single-polarized VV data show that the regions with the maximum sensitivity and high quality index, simultaneously, to soil moisture are in the forward off-specular direction. However, due to the effect of surface roughness and surface autocorrelation function (ACF), the single-polarized data have some limitations for soil moisture inversion. By contrast, the results of two different polarization combinations, as well as a dual-angular simulation of one transmitter and two receivers, show significant estimation benefits. It can be seen that they all provide better ACF suppression capabilities, larger high-sensitivity area, and higher quality indices compared to single-polarized estimation. In addition, dual polarization or dual angular combined measurement provides the possibility of retrieving soil moisture in backward regions. These results are expected to contribute to the design of future bistatic observation systems. Full article

This paper focuses on sea surface wind speed estimation based on cyclone global navigation satellite system reflectometry (GNSS-R) data. In order to extract useful information from delay-Doppler map (DDM) data, three delay waveforms are presented for wind speed estimation. The delay waveform without Doppler shift is defined as central delay waveform (CDW), and the integral of the delay waveforms with different Doppler shift values is defined as integral delay waveform (IDW), while the difference between normalized IDW (NIDW) and normalized CDW (NCDW) is defined as differential delay waveform (DDW). We first propose a data filtering method based on threshold setting for data quality control. This method can select good-quality DDM data by adjusting the root mean square (RMS) threshold of cleaned DDW. Then, the normalized bistatic radar scattering cross section (NBRCS) and the leading edge slope (LES) of IDW are calculated using clean DDM data. Wind speed estimation models based on NBRCS and LES observations are then developed, respectively, and on this basis, a combination wind speed estimation model based on determination coefficient is further proposed. The CYGNSS data and ECMWF reanalysis data collected from 12 May 2020 to 12 August 2020 are used, excluding data collected on land, to evaluate the proposed models. The evaluation results show that the wind speed estimation accuracy of the piecewise function model based on NBRCS is 2.3 m/s in terms of root mean square error (RMSE), while that of the double-parameter and triple-parameter models is 2.6 and 2.7 m/s, respectively. The wind speed estimation accuracy of the double-parameter and triple-parameter models based on LES is 3.3 and 2.5 m/s. The results also demonstrate that the RMSE of the combination method is 2.1 m/s, and the coefficient of determination is 0.906, achieving a considerable performance gain compared with the individual NBRCS- and LES-based methods. Full article

To extend the scope of high frequency (HF) radio oceanography, a new HF radar model, named shore-to-air bistatic HF radar, has been proposed for ocean observations. To explore this model, the first-order scattering coefficient and the second-order electromagnetic scattering coefficient for shore-to-air bistatic HF radar are derived using the perturbation method. In conjunction with the contribution of the hydrodynamic component, the second-order scattering coefficient is derived. Based on the derived scattering coefficients, we analyzed the simulated echo Doppler spectra for various scattering angles and azimuthal angles, operation frequencies, wind speeds, and directions of wind, which may provide the guideline on the extraction of sea state information for shore-to-air bistatic HF radar. The singularities in the simulated echo Doppler spectra are discussed using the normalized constant Doppler frequency contours. In addition, the scattering coefficients of shore-to-air bistatic HF radar are compared with that of monostatic HF radar and land-based bistatic HF radar. The results verify the correctness of the proposed scattering coefficients. The model of shore-to-air bistatic HF radar is effective for ocean observations. Full article

The linear geometry distortion caused by time variant bistatic angles induces the sheared shape of the bistatic inverse synthetic aperture radar (bistatic-ISAR) image. A linear geometry distortion alleviation algorithm for space targets in bistatic-ISAR systems is presented by exploiting prior information. First, we analyze formation mathematics of linear geometry distortions in the Range Doppler (RD) domain. Second, we estimate coefficients of first-order polynomial of bistatic angles by least square error (LSE) method through exploiting the imaging geometry and orbital information of space targets. Third, we compensate the linear spatial-variant terms to restore the linear geometry distortions. Consequently, the restored bistatic-ISAR image with real shape is obtained. Simulated results of the ideal point scatterers dataset and electromagnetic numerical dataset verify the performance of the proposed algorithm. Full article

We have developed a method for evaluating the fidelity of the Aerosol Robotic Network (AERONET) retrieval algorithms by mimicking atmospheric extinction and radiance measurements in a laboratory experiment. This enables radiometric retrievals that use the same sampling volumes, relative humidities, and particle size ranges as observed by other in situ instrumentation in the experiment. We use three Cavity Attenuated Phase Shift (CAPS) monitors for extinction and University of Maryland Baltimore County’s (UMBC) three-wavelength Polarized Imaging Nephelometer (PI-Neph) for angular scattering measurements. We subsample the PI-Neph radiance measurements to angles that correspond to AERONET almucantar scans, with simulated solar zenith angles ranging from 50 ${}^{\circ }$ to 77 ${}^{\circ }$ . These measurements are then used as input to the Generalized Retrieval of Aerosol and Surface Properties (GRASP) algorithm, which retrieves size distributions, complex refractive indices, single-scatter albedos, and bistatic LiDAR ratios for the in situ samples. We obtained retrievals with residuals less than 8% for about 90 samples. Samples were alternately dried or humidified, and size distributions were limited to diameters of less than 1.0 or 2.5 $\mathsf{\mu }$ m by using a cyclone. The single-scatter albedo at 532 nm for these samples ranged from 0.59 to 1.00 when computed with CAPS extinction and Particle Soot Absorption Photometer (PSAP) absorption measurements. The GRASP retrieval provided single-scatter albedos that are highly correlated with the in situ single-scatter albedos, and the correlation coefficients ranged from 0.916 to 0.976, depending upon the simulated solar zenith angle. The GRASP single-scatter albedos exhibited an average absolute bias of +0.023–0.026 with respect to the extinction and absorption measurements for the entire dataset. We also compared the GRASP size distributions to aerodynamic particle size measurements, using densities and aerodynamic shape factors that produce extinctions consistent with our CAPS measurements. The GRASP effective radii are highly correlated (R = 0.80) and biased under the corrected aerodynamic effective radii by 1.3% (for a simulated solar zenith angle of ${\theta }_{\circ }={50}^{\circ }$ ); the effective variance indicated a correlation of R = 0.51 and a relative bias of 280%. Finally, our apparatus was not capable of measuring backscatter LiDAR ratios, so we measured bistatic LiDAR ratios at a scattering angle of 173 degrees. The GRASP bistatic LiDAR ratios had correlations of 0.71 to 0.86 (depending upon simulated ${\theta }_{\circ }$ ) with respect to in situ measurements, positive relative biases of 2–10%, and average absolute biases of 1.8–7.9 sr. Full article

The Earth’s surface bistatic reflectivity ${\mathsf{\Gamma }}_{\mathrm{L}\mathrm{H}\mathrm{C}\mathrm{P},\mathrm{C}\mathrm{y}\mathrm{G}\mathrm{N}\mathrm{S}\mathrm{S}}$ is experimentally characterized using the novel Global Navigation Satellite Systems Reflectometry (GNSS-R) L-band passive multistatic radar technique from the Cyclone Global Navigation Satellite Systems (CyGNSS) eight-microsatellite constellation. The focus of this study is to evaluate the influence of the GNSS satellites’ elevation angle ${\mathsf{\theta }}_{\mathrm{e}}$ on ${\mathsf{\Gamma }}_{\mathrm{L}\mathrm{H}\mathrm{C}\mathrm{P},\mathrm{C}\mathrm{y}\mathrm{G}\mathrm{N}\mathrm{S}\mathrm{S}}$ , as a function of soil moisture content (SMC) and effective surface roughness parameter $\mathrm{h}$ . As the average response, the change of the scattering regime at a global scale and considering also vegetated surfaces appears at ${\mathsf{\theta }}_{\mathrm{e}}$ ≈ 55°. This empirical observation is understood as a change on the dominant scattering term, from incoherent to coherent. Then, the correlation of ${\mathsf{\Gamma }}_{\mathrm{L}\mathrm{H}\mathrm{C}\mathrm{P},\mathrm{C}\mathrm{y}\mathrm{G}\mathrm{N}\mathrm{S}\mathrm{S}}$ and SMC is evaluated as a function of ${\mathsf{\theta }}_{\mathrm{e}}$ over specific sparsely vegetated target areas. The smoother the surface, the higher the angular variability of the Pearson correlation coefficients. Over croplands (e.g., Argentinian Pampas), an improved correlation coefficient is achieved over angular ranges where the coherent scattering regime becomes the dominant one. As such, this function depends on the surface roughness. The maximum correlation coefficients are found at different ${\mathsf{\theta }}_{\mathrm{e}}$ for increasing mean roughness levels: ${\mathrm{r}}_{\mathrm{P}\mathrm{a}\mathrm{m}\mathrm{p}\mathrm{a}\mathrm{s}}$ ≈ 0.78 at ${\mathsf{\theta }}_{\mathrm{e}}$ ≈ [60,70]°, ${\mathrm{r}}_{\mathrm{I}\mathrm{n}\mathrm{d}\mathrm{i}\mathrm{a}}$ ≈ 0.72 at ${\mathsf{\theta }}_{\mathrm{e}}$ ≈ [50,60]°, and ${\mathrm{r}}_{\mathrm{S}\mathrm{u}\mathrm{d}\mathrm{a}\mathrm{n}}$ ≈ 0.74 at ${\mathsf{\theta }}_{\mathrm{e}}$ ≈ [30,40]°. SMC retrieval algorithms based on GNSS-R multi-angular information could benefit from these findings, so as to improve the accuracy using single-polarized signals. Full article

The microwave scatterometer is one of the most effective instruments in ocean remote sensing, which urges the need for some theoretical models to accurately estimate the scattering coefficient of the sea surface. For the simulation of the scattering from an ocean surface, the sea spectrum, or its inverse Fourier transform, autocorrelation function is essential. Currently, many sea spectral models have been proposed for describing sea waves. However, which spectrum should be adopted during electromagnetic (EM) computations? A systematic comparison of these models is needed to evaluate their accuracies. In this paper, we focus on numerical simulations of scattering from a rough sea surface in monostatic and bistatic configurations by using six different sea spectral models and the first-order small slope approximation (SSA-1). First, sea spectral models proposed by Elfouhaily et al., Hwang et al., Romeiser et al., Apel et al., Fung et al., and Pierson et al., are compared with each other from different points of view, e.g., the omnidirectional parts, the angular spreading functions, the autocorrelation functions, and the slope variances. We find that the spectra given by Elfouhaily and Hwang could reflect realistic wind sea waves more accurately. Then, the scattering coefficients are simulated in fully monostatic and bistatic configurations. Regarding the monostatic scattering, the results simulated using EM scattering models are compared with those obtained from the measured UAVSAR data in the L band and the empirical model CMOD5 in the C band. Comparisons are made for various incident angles, wind speeds, and wind directions. Meanwhile, special attention is paid to low to moderate incident angles. The comparisons show that, it is difficult to find one certain spectral model to simulate scattering coefficient accurately under all wind speeds or wind directions. Accurate estimations will be obtained using different methods according to different situations. Full article

This paper presents a theoretical study of microwave remote sensing of vegetated surfaces. The purpose of this study is to find out if satellite bistatic radar systems can provide a performance, in terms of sensitivity to vegetation geophysical parameters, equal to or greater than the performance of monostatic systems. Up to now, no suitable bistatic data collected over land surfaces are available from satellite, so that the electromagnetic model developed at Tor Vergata University has been used to perform simulations of the scattering coefficient of corn, over a wide range of observation angles at L- and C-band. According to the electromagnetic model, the most promising configuration is the one which measures the VV or HH bistatic scattering coefficient on the plane that lies at the azimuth angle orthogonal with respect to the incidence plane. At this scattering angle, the soil contribution is minimized, and the effects of vegetation growth are highlighted. Full article

Accurate models are used today for infrared and microwave satellite radiance simulations of the first two Stokes elements in the physical retrieval, data assimilation etc. of surface and atmospheric parameters. Although in the past a number of theoretical and experimental works have studied the polarimetric emission of some natural surfaces, specially the sea surface roughened by the wind (Windsat mission), very limited studies have been conducted on the polarimetric emission of rain cells or other natural surfaces. In this work, the polarimetric emission (four Stokes elements) of a rain cell is computed using the polarimetric radiative transfer equation assuming that raindrops are described by Pruppacher-Pitter shapes and that their size distribution follows the Laws-Parsons law. The Boundary Element Method (BEM) is used to compute the exact bistatic scattering coefficients for each raindrop shape and different canting angles. Numerical results are compared to the Rayleigh or Mie scattering coefficients, and to Oguchi’s ones, showing that above 1-2 mm raindrop size the exact formulation is required to model properly the scattering. Simulation results using BEM are then compared to the experimental data gathered with a X-band polarimetric radiometer. It is found that the depolarization of the radiation caused by the scattering of non-spherical raindrops induces a non-zero third Stokes parameter, and the differential phase of the scattering coefficients induces a non-zero fourth Stokes parameter. Full article
