Search Results (24)

This paper investigates the fundamental workability of 3D printed concrete materials incorporating different fiber types. Fluidity, extrudability, and buildability were proposed as key indicators for assessing printability, evaluated through corresponding test methods, including fluidity tests, filament extrusion tests, and slump tests. The results demonstrate that the optimal ranges for printability are superplasticizer content between 0.35% and 0.45%, accelerator content between 0.60% and 0.85%, and silica fume replacement level between 7.5% and 10%. The incorporation of copper-coated steel fibers led to deteriorated workability, manifested as reduced fluidity, increased fluidity loss over time, poor pumpability, discontinuous extrusion, and low slump, although buildability remained satisfactory. Polypropylene fibers increased the air content in concrete, thereby improving workability; they exhibited good extrusion continuity, appropriate slump and filament width, and favorable buildability. Basalt fibers significantly enhanced air content and workability. However, due to the high stiffness of the fibers, extrusion continuity was only moderate. While the slump and filament width were suitable, the presence of minor voids in the printed filaments resulted in average buildability. Full article

Advanced composite materials and manufacturing technologies are critical to sustain human presence in space. Mechanical testing and analysis are needed to elucidate the effect of processing parameters on composites’ material properties. In this study, test specimens are 3D printed via a fused-filament fabrication (FFF) approach from a basalt moon dust-polylactic acid (BMD-PLA) composite filament and from pure PLA filament. Compression and tensile testing were conducted to determine the yield strength, ultimate strength, and Young’s modulus of specimens fabricated under several processing conditions. The maximum compressive yield strength for the BMD-reinforced samples is 27.68 MPa with print parameters of 100% infill, one shell, and 90° print orientation. The maximum compressive yield strength for the PLA samples is 63.05 MPa with print parameters of 100% infill, three shells, and 0° print orientation. The composite samples exhibit an increase in strength when layer lines are aligned with loading axis, whereas the PLA samples decreased in strength. This indicates a fundamental difference in how the composite behaves in comparison to the pure matrix material. In tension, test specimens have unpredictable failure modes and often broke outside the gauge length. A portion of the tension test data is included to help guide future work. Full article

This study investigates the axial compression behavior of square reinforced concrete (RC) columns confined by a novel type of rectangular closed basalt fiber-reinforced polymer (BFRP) tie fabricated using a continuous filament winding method, and hybrid steel–BFRP configurations. The proposed ties were developed to overcome common limitations of conventional FRP stirrups, such as reduced tensile strength at bent regions and premature rupture. A total of five RC column specimens were tested under monotonic axial loading: one reference specimen with conventional steel ties, two specimens with BFRP ties spaced at 45 mm and 90 mm, and two hybrid specimens combining steel and BFRP ties. Experimental results showed that the steel-confined column achieved the highest peak axial load of 1793.2 kN and an ultimate strain value of 1.12. The specimen with closely spaced BFRP ties (45 mm) reached 94.7% of the peak load of the steel-confined specimen and exhibited over 137% higher axial strain capacity. The hybrid specimen with two interleaved BFRP ties achieved the highest confinement effectiveness ratio of 1.306. The findings demonstrate that the proposed BFRP ties offer a structurally viable and corrosion-resistant alternative to steel ties, particularly when used in hybrid systems. This research contributes to the development of durable, high-performance confinement strategies for RC columns in seismic and aggressive environmental conditions. Full article

Usage of continuous fibers as a reinforcement would definitely increase the mechanical properties of 3D-printed materials. The result is a continuous fiber-reinforced composite obtained by additive manufacturing that is not limited to prototyping or non-structural applications. Among the available continuous reinforcing fibers, basalt has not been extensively studied in 3D printing. This material is attractive due to its natural origin, good mechanical properties, impact strength, and high chemical and thermal resistance. In this work, a continuous basalt fiber co-extruded composite obtained by fused filament fabrication was characterized both thermally and mechanically, concerning the in-plane tensile properties. The degree of anisotropy of the material was also assessed, both qualitatively and quantitatively. The 3D-printed composite showed longitudinal properties, which were 15 times higher than the pure matrix, thus meeting structural requirements. On the other hand, transverse and shear properties were much lower than longitudinal ones, thus leading to a strongly anisotropic material. This was also confirmed by the anisotropy evaluation that was performed numerically and graphically using an innovative approach. This behavior affects the design of 3D-printed parts; thus, an optimized continuous fiber deposition is necessary for structural applications. Full article

Agate veins and nodules occur in the Lece Volcanic Complex (Oligocene-Miocene) situated in the south of Serbia and occupying an area of 700 km². This volcanic complex is composed predominantly of andesites, with sporadic occurrences of andesite-basalts, dacites and latites, and features agate formations that have been very little investigated. This study focuses on five selected agate occurrences within the Lece Volcanic Complex, employing optical microscopy, scanning electron microscopy (SEM), X-ray powder diffraction analysis, inductively coupled plasma mass spectrometry (ICP-MS), and Fourier transform infrared spectroscopy (FTIR). In three localities (Rasovača, Mehane, and Ždraljevići), agate mineralization is directly related to distinct fault zones with strong local brecciation. In the other two localities (Vlasovo and Sokolov Vis), the agate is found in nodular form and does not show any connection with fracture zones. The silica phases of the Lece volcanic agates consist of cristobalite and tridymite, length-fast chalcedony, quartzine (length-slow chalcedony), and macrocrystalline quartz. Vein agates show a frequent alternation between length-fast chalcedony and quartz bands. Nodular agates consist primarily of length-fast chalcedony, occasionally containing notable quantities of opal-CT, absent in vein agates. Microtextures present in vein agates include crustiform, colloform, comb, mosaic, flamboyant, and pseudo-bladed. Jigsaw puzzle quartz microtexture supports the recrystallization of previously deposited silica in the form of opal or chalcedony from hydrothermal fluids. Growth lines in euhedral quartz (Bambauer quartz) point to agate formations in varying physicochemical conditions. These features indicate epithermal conditions during the formation of hydrothermal vein agates. Due to intense hydrothermal activity, vein agate host rocks are intensively silicified. Vein agates are also enriched with typical ore metallic elements (especially Pb, Co, As, Sb, and W), indicating genetic relation with the formation of polymetallic ore deposits of the Lece Volcanic Complex. In contrast, nodular agates have a higher content of major elements of host rocks (Al₂O₃, MgO, CaO, Na₂O, and K₂O), most probably mobilized from volcanic host rocks. Organic matter, present in both vein and nodular agate with filamentous forms found only in nodular agate, suggests formation in near-surface conditions. Full article

This paper presents the results of experimental investigation of the mechanical characteristics of 3D-printed acrylonitrile butadiene styrene (ABS) and its modifications reinforced with different types of short-fiber fillers: carbon, glass, and basalt. Elastic modulus, tensile and bending strength, as well as fracture toughness were determined in series of mechanical tests for samples produced with different manufacturing parameters, such as nozzle diameter and infill angle. It was found that the use of ABS filament reinforced with the short fibers can significantly improve the mechanical properties of 3D-printed devices when the infill angle is oriented along the vector of the applied load. In such a case, the elastic modulus and tensile strength can be increased by more than 1.7 and 1.5 times, respectively. The use of a larger nozzle diameter led to the growth of tensile strength by an average of 12.5%. When the macroscopic load is applied along the normal to the printed layers, the addition of short fibers does not give much gain in mechanical properties compared to pure ABS, which was confirmed by both standard tensile and fracture toughness tests. The surface of the fractured samples was examined using scanning electronic microscopy, which allowed us to make conclusions on the type of defects as well as on the level of adhesion between the polymeric matrix and different types of short fibers. Full article

A basalt fiber asphalt mixture could improve the road performance of pavements and prolong the service life. The oil/asphalt absorption capacity of basalt fiber affects the road performance of asphalt mixtures to a certain extent. However, using kerosene as the medium to measure the oil absorption rate of bundle fibers by the vibration method, as the Chinese specifications recommends, is unreasonable. Therefore, the aim of this paper is to study the effect of the basalt fiber morphology on the oil absorption rate and the oil/asphalt absorption test methods suitable for asphalt mixtures with different structures (dense-graded and gap-graded), and to also explore the appropriate method to determine the oil/asphalt absorption rate of fiber to kerosene and asphalt. The results showed that the filamentous basalt fiber (FBF) was easier to disperse uniformly in asphalt than the bundled basalt fiber (BBF), and the oil absorption capacity of the FBF could more accurately characterize the actual working state of the fiber in the asphalt mixture. For the gap-graded asphalt mixture, the appropriate method to measure the fiber oil absorption rate is the combination of the vibration and centrifugation methods, while the fiber asphalt absorption rate is measured by the vibration method. For the dense-graded asphalt mixture, the combination of the extrusion and centrifugation methods are more reasonable to determine the fiber oil absorption rate, while the extrusion method is suitable for determining the fiber asphalt absorption rate. The concept of an effective fiber oil absorption rate is proposed to characterize the ability of fiber to adsorb kerosene in asphalt mixtures with different structures. A temperature of 160 °C is recommended as the test temperature to determine the fiber asphalt absorption rate. Kerosene as the asphalt absorption test medium could not directly reflect the ability of fiber to adsorb asphalt. Full article

Fused Deposition Modeling (FDM) enables many advantages compared to traditional manufacturing techniques, but the lower mechanical performance due to the higher porosity still hinders its industrial spread in key sectors like the automotive industry. PP and PA12 filaments filled with low amounts of basalt fibers were produced in the present work to improve the poor mechanical properties inherited from the additive manufacturing technique. For both matrices, the introduction of 5 wt.% of basalt fibers allows us to achieve stiffness values comparable to injection molding ones without modifying the final weight of the manufactured components. The increased filament density compared with the neat polymers, upon the introduction of basalt fibers, is counterbalanced by the intrinsic porosity of the manufacturing technique. In particular, the final components are characterized by a 0.88 g/cm³ density for PP and 1.01 g/cm³ for PA12 basalt-filled composites, which are comparable to the 0.91 g/cm³ and 1.01 g/cm³, respectively, of the related neat matrix used in injection molding. Some efforts are still needed to fill the gap of 15–28% for PP and of 26.5% for PA12 in tensile strength compared to injection-molded counterparts, but the improvement of the fiber/matrix interface by fiber surface modification or coupling agent employment could be a feasible solution. Full article

This work reports calcium oxalate film formation on basaltic stone surfaces of the 17th-century western India Raigad Hill Fort. Nine stone samples extracted from the exterior surfaces of different historical structures of the fort were investigated under FTIR, optical microscopy, XRD, and SEM-EDX. The FTIR spectroscopy revealed intense peaks for Ca-oxalate patinas on basaltic stone surfaces. Observation under optical microscopy clearly showed milky white oxalate films, and peaks for crystalline calcium oxalate, including rock silicates, were prominently observed through XRD investigations. The surface morphology, the origin of the oxalate film, and the state of conservation of the basalt rock were investigated through SEM-EDX. The massive structures at Raigad, at a height of about 800 m, have hardly been chemically cleaned or coated with preservatives in the past. The presence of organic filaments in SEM photomicrographs indicated the biological origin of the oxalate patina due to the thick growth of microbiota on the monument stone during very heavy monsoons. The oxalic acid secreted by microbes dislodged the Ca-rich plagioclase of the stone, ensuring Ca-ions’ availability for film formation. The optical and mineralogical analyses suggest that the film is not the result of simple deposition but of the surface transformation of basaltic stone. Full article

To improve their interfacial properties, 3D orthogonal woven fabrics with basalt filament yarns were modified with functionalized carboxylated carbon nanotubes (KH570-MWCNTs) and polydopamine (PDA). Fourier infrared spectroscopy (FT-IR) analysis and scanning electron microscopy (SEM) testing were used. It was demonstrated that both methods could successfully modify basalt fiber (BF) 3D woven fabrics. The 3D orthogonal woven composites (3DOWC) were produced with epoxy resin and 3D orthogonal woven fabrics as raw material by the VARTM molding process. The bending properties of the 3DOWC were tested and analyzed by experimental and finite element analysis methods. The results showed that the bending properties of the 3DOWC modified by KH570-MWCNTs and PDA were significantly improved, and the maximum bending loads were increased by 31.5% and 31.0%. The findings of the finite element simulation and the experiment results were in good agreement, and the simulation error value was 3.37%. The correctness of the finite element simulation results and the model’s validity further reveal the material’s damage situation and damage mechanism in the bending process. Full article

Basalt/epoxy composite pipes in a [±55]₄ winding configuration were produced on CNC filament winding machines (10 N fiber tension and ~11 mm bandwidth). In the experiments, a 34 m/s impact velocity was set using the double-disc method, and five different particle impingement angles (30, 45, 60, 75, and 90°) were used to determine the erosive effect on the outer surfaces of filament wound composite pipes under the influence of 600 μm erodent particles with angular geometry in the test set, complying with the ASTM G76-95 standard. The winding patterns in the lamina (±55 angle-ply laminate region) and zigzag (±55 zigzag region) regions of BFR/EP pipes were determined to have significant effects on solid particle erosion resistance, as evidenced by the SEM images. Full article

Fused filament fabrication (FFF) is gaining attention as an efficient way to create parts and replacements on demand using thermoplastics. This technology requires the development of new materials with a reliable printability that satisfies the requirement of final parts. In this context, a series of composites based on acrylonitrile styrene acrylate (ASA) reinforced with basalt fiber (BF) are reported in this work. First, several surface modification treatments are applied onto the BF to increase their compatibility with the ASA matrix. Then, once the best treatment is identified, the mechanical properties, coefficient of thermal expansion (CTE) and warping distortion of the different specimens designed and prepared by FFF are studied. It was found that the silanized BF is appropriate for an adequate printing, obtaining composites with higher stiffness, tensile strength, low CTE and a significant reduction in part distortion. These composites are of potential interest in the design and manufacturing of final products by FFF, as they show much lower CTE values than pure ASA, which is essential to successfully fabricate large objects using this technique. Full article

In order to solve defects such as poor integrity, delamination failure, and narrow absorption bandwidth, three-dimensional (3D) gradient honeycomb woven composites (GHWCs) with triangular sections were designed and prepared. Three-dimensional gradient honeycomb woven fabric was crafted with carbon fiber (CF) filaments and basalt fiber (BF) filaments as raw materials on an ordinary loom. Then, the 3D honeycomb woven fabric filled with rigid polyurethane foam was used as the reinforcement, and epoxy resin (EP) doped with carbon black (CB) and carbonyl iron powder (CIP) was conducted as the matrix. The 3D GHWC with triangular sections, which had both EM-absorbing and load-bearing functions, was prepared by the VARTM process. Through the macro test and micro characterization of 3D GHWCs with triangular sections, the overall absorbing properties and mechanical properties of the materials were analyzed. Moreover, the EM-absorbing mechanism and failure mode of the materials were clarified in this work. The results indicated that the CF filament reflective layer effectively improved the EM-absorbing and mechanical properties. Adding a CB/CIP-absorbing agent enhanced the overall EM-absorbing property but reduced the mechanical properties. The increasing number of gradient layers increased the maximum bending load, but the EM-absorbing performance first increased and then decreased. When the thickness was 15 mm, the maximum bending load was 3530 N, and the minimum reflection loss (RL_min) was −21.6 dB. The synergistic effects of EM-absorbing and mechanical properties were the best right now. In addition, this work provided a feasible strategy that adjusting the type of absorber and gradient aperture size ratio could meet the unique requirements of absorbing frequency and intensity, which has excellent application prospects in civil and military fields. Full article

This study demonstrated the physical–chemical and technical feasibility of recycling EAF slag granulated by rapid cooling with gas to produce continuous glass fibers with a basalt-like composition. To adjust the chemical composition, a silica fume-based secondary raw material was used, together with other additives. Different compositions were tested: 50% EAF slag and 50% silica fume (sample C1); 40% EAF slag, 50% silica fume and 10% Na₂O (sample C2); 40% EAF slag, 50% silica fume, 5% Na₂O and 5% K₂O (sample C3); 20% EAF slag, 57% silica fume, 10% Na₂O and 13% alkali earth oxides (sample C4); 26% EAF slag, 35% silica fume, 7% CaO and 12% Na₂O (sample C5); 26% EAF slag, 35% silica fume, 4% CaO and 15% Na₂O (sample C6). The last composition allowed obtaining fibers up to 5–6 m long, with a diameter between 60 and 180 µm. The process involved using a refractory material crucible with a calibrated bottom orifice as a single nozzle bushing. The optimal temperature range for fiber forming was between 1115 and 1125 °C, with a linear drawing speed of about 2 m/s. Preliminary mechanical tests were performed. Based on these results, potential further recycling applications of granulated EAF slag in the production of basalt-like glass for noncontinuous fiber production for mechanical reinforcement or for thermal–acoustic insulation can also be foreseen. Full article

Multiaxis three-dimensional (3D) continuous basalt fiber/cementitious concretes were manufactured. The novelty of the study was that the non-interlace preform structures were multiaxially created by placing all continious filamentary bundles in the in-plane direction of the preform via developed flat winding-molding method to improve the fracture toughness of the concrete composite. Principle and off-axis flexural properties of multiaxis three-dimensional (3D) continuous basalt fiber/cementitious concretes were experimentally studied. It was identified that the principle and off-axis flexural load-bearing, flexural strength and the toughness properties of the multiaxis 3D basalt concrete were extraordinarily affected by the continuous basalt filament bundle orientations and placement in the pristine concrete. The principle and off-axis flexural strength and energy absorption performance of the uniaxial (B-1D-(0°)), biaxial ((B-2D-(0°), B-2D-(90°) and B-2D-(+45°)), and multiaxial (B-4D-(0°), B-4D-(+45°) and B-4D-(−45°)) concrete composites were considerably greater compared to those of pristine concrete. Fractured four directional basalt concretes had regional breakages of the brittle cementitious matrix and broom-like damage features on the filaments, fiber-matrix debonding, intrafilament bundle splitting, and minor filament entanglement. Multiaxis 3D basalt concrete, particularly in the B-4D structure, controlled the crack phenomena and it was recognized as a more damage-tolerant material than the neat concrete. Full article
