This study explores the development of a multifunctional composite material by incorporating carbon black (CB) into an epoxy matrix reinforced with 30 vol.% jute fabric. The objective was to evaluate the impact of CB on the composite’s tensile properties, ballistic performance, and electromagnetic shielding effectiveness (SE) within the X-band frequency range (8.2–12.4 GHz). The epoxy composite with 30 vol.% jute and 5 vol.% CB (EJ30/CB5) exhibited 15% improvements in its tensile strength and elastic modulus compared to the epoxy composite with 30 vol.% jute (EJ30) only. Ballistics tests indicated no significant increases in absorbed energy or limit velocity, which may be attributed to the structural rigidity introduced by the CB. An electromagnetic shielding analysis revealed that the CB addition significantly enhanced the SE from ~2 dB in neat epoxy to 5–8 dB in EJ30/CB5, with absorption emerging as the primary shielding mechanism. The findings highlight the potential of CB- and jute-reinforced epoxy composites for applications requiring both mechanical robustness and electromagnetic interference shielding. Full article

This paper presents the possibility of using additional ballistic shields based on composite materials, which are applied to the body of a passenger car. A ballistic laminate made of Twaron T 750 aramid fabric with 5 mm thick and 2 mm thick magnetic foil was used. In the first stage, the mechanical parameters of the tested ballistic laminate system were determined in tensile tests. In field tests, the considered system was analyzed in terms of impact with a 9 × 19 mm FMJ Parabellum projectile, and then the results were numerically verified. The work was focused on the validation of numerical models. The appropriate correlation level of the numerical results was obtained with the fit, which was estimated at approximately 7%; furthermore, the results prove the correctness of this study’s research methodology. Full article

This article deals with the ballistic impact of the 7.62 mm FMJ M80 rifle projectile into the laminated Twaron/UHMWPE composite armor. The armor composition consisted of composite panels made from Twaron CT 747 para-aramid fabric and ultra-high-molecular-weight Endumax Shield XF33 polyethylene. To analyze the ballistic impact and to verify the resistance of the designed armor according to the NATO AEP 4569 STANAG standard, protection level 1, 7.62 × 51 mm FMJ NATO M80 rifle cartridges with lead projectiles were used in the ballistic experiment. After the projectile impact, the damage failure mechanisms of the composite panels were documented. As part of the evaluation of the experiments, the initial microstructure of the composite panels was documented, and subsequently, the damaged areas of the composite armor after the ballistic experiment were also documented. Optical and scanning electron microscopy were used to document the structures. The important parameter of composite armor is its mechanical properties. The surface hardness of the composite panels was measured by the Shore D method using the hardness tester DIGI-Test II. The results obtained from the ballistic experiment demonstrate that the designed Twaron/Endumax armor was not penetrated. This armor has sustained multiple impacts for all three 7.62 mm FMJ M80 projectiles and is suitable for the construction of armor protection. Full article

Multi-layer fabrics are commonly used in ballistics shields with a lower bulletproof class to protect against pistol and revolver bullets. In order to additionally limit the dynamic deflection of the samples, layers reinforced with additional materials, including non-Newtonian fluids compacted by shear, are additionally used. Performing a wide range of tests in each case can be very problematic; therefore, there are many calculation methods that allow, with better or worse results, mapping of the behavior of the material in the case of impact loads. The search for simplified methods is very important in order to simplify the complexity of numerical fabric models while maintaining the accuracy of the results obtained. In this article, multi-layer composites were tested. Two samples were included in the elements subjected to shelling. In the first sample, the outer layers consisted of aramid fabrics in a laminate with a thermoplastic polymer matrix. The middle layer contained a non-Newtonian shear-thickening fluid enclosed in hexagonal (honeycomb) cells. The fluid was produced using polypropylene glycol and colloidal silica powder with a diameter of 14 µm in the proportions of 60/40. The backing plate was made using a 12-layer composite made of Twaron^® para-aramid fabrics with a DCPD matrix—not yet used in a wide range of ballistics. Then, numerical simulations were carried out in the Abaqus/Explicit dynamic analysis. The Johnson–Cook constitutive strength model was used to describe the behavior of elastic–plastic materials constituting the elements of the projectiles. For the non-Newtonian fluid, a Up-Us EOS was used. The inner layers of the fabric were treated as an orthotropic material. Complete homogenization of the sample layers was carried out, thanks to which each layer was treated as a homogeneous continuum. As a parameter of fracture mechanics for shield components, the strain criterion was used with the smooth particles hydrodynamics method (SPH). Then, the results of simulations were compared with the results of the ballistic test for both samples placed next to each other, which resulted in the formation of a multi-layer composite in one ballistic test subjected to impact loads during firing with a 9 × 19 mm Parabellum FMJ projectile with an initial velocity of 370 ± 10 m/s. The results of numerical tests are very similar to the ballistic tests, which indicates the correct mapping of the process and the correct conduct of layer homogenization. The applied proportions of the components in the non-Newtonian fluid allowed a reduction in the deflection compared to previous studies. Additionally, the proposal to use a DCPD matrix allowed to obtain a much lower deflection value compared to other materials, which is a novelty in the field of production of ballistic shields. Full article

The ballistic response of armor has been widely used to evaluate its feasibility and advantages as a protective structure. To obtain the ballistic performance and ballistic limitations of composite armor, a type of ultra–high molecular weight polyethylene (UHMWPE) composite armor is designed, which is composed of UHMWPE laminates and steel face sheets of Q235. The total thickness of the armor is 53 mm, with an in–plane dimension of 300 mm × 300 mm. Then, an experimental study of the ballistic impact response of composite armor subject to a typical ogive–nose projectile was carried out. In the velocity range of 501.1 to 1026.1 m/s, the 14.5 mm caliber armor–piercing projectile could penetrate through the composite armor. At the velocity of 433.3 m/s, the A–P projectile was embedded in the armor, leaving a bulge mark on the back sheet. Therefore, 467.2 m/s is taken as the ballistic limit of the armor under the impact of the ogive–nose projectile. In addition, a corresponding numerical simulation model is also established to predict the ballistic limit of the projectile. The numerical predictions are consistent with the experimental results. The ballistic limit obtained from the numerical simulation results is 500 m/s, which is acceptable with a relative error of 7.02%. The failure mechanism of the composite armor is also obtained. Petaling is the main dominant failure mode for both face sheets, while delamination and shear failure dominate the penetration process of UHMWPE laminates. Finally, the perforation mechanism of composite armor under the impact of an A–P projectile is analyzed with theoretical models to predict the residual velocity, the work performed during the perforation, and the resisting stress of σ_s in the cavity–expansion model. The experimental and numerical simulation results can provide necessary data in the analysis of the composite structure’s dynamic response under the impact of sharp head penetrators. The research results present the ballistic performance, failure mechanism, and ballistic limit of the composite armor under the impact of a typical ogive–nose projectile, which can be significant in the design of composite armor in the areas of ship shield, fortifications protection, and bulletproof structures against threats from sharp head penetrators. Full article

Textile ballistic shields are the basis of protection against bullets and fragments with low kinetic energy. They are usually made of para-aramid fabrics or unidirectional structure (UD) sheets of ultra-high molecular weight polyethylene (UHMWPE). The aim of the research presented in the article was to obtain ballistic packages made of embroidered structures and to compare their ballistic properties with those of woven structures in terms of deformation of the standardized ballistic substrate after impact with a 9 mm bullet at a velocity of 380 ± 3 m/s. Using the tailored fiber placement method, embroidered structures were fabricated by embroidering two sets of para-aramid threads at an angle of 90°. As the woven structures, the use of para-aramid fabric made of the same yarn and with a surface weight comparable to that of embroidered structures was adopted. Ballistic packages consisted of 26 layers in five variants, also taking into account the hybrid arrangement of woven and embroidered layers. Ballistic tests have shown that the best ballistic properties have hybrid packages made by folding 13 woven and then 13 embroidered layers, where the maximum deformation of the plasticine substrate is below 23 mm. The conducted research confirmed that embroidered structures in appropriate combination with woven structures can significantly improve the ballistic properties of textile packages. Full article

In this paper, shields made of 1.3964 stainless steel bonded to a fiber laminate were subjected to ballistic impact response of 7.62 × 51 mm ŁPS (light projectile with a lead core) projectiles. Additionally, between the steel sheet metal and the laminate, a liquid-filled bag was placed, which was a mixture of ethylene glycol (C₂H₆O₂) with 5 wt.% SiO₂ nanopowder. Numerical modeling of the projectile penetrating the samples was carried out using the finite element method in the Abaqus program. The elasto-plastic behavior of the projectile material and the component layers of the shields was taken into account. Projectile penetration through glycol-filled bag has been performed using the smooth particle hydrodynamics technique. The morphology of the penetration channel was also analyzed using a scanning electron microscope. For the shield variant with a glycol-filled bag between the steel and laminate plates, the inlet speed of projectile was 834 m/s on average, and 366 m/s behind the sample. For the variant where there was no glycol-filled bag between the steel and laminate plates, the inlet and outlet average velocities were 836 m/s, after 481 m/s, respectively. Referring to the steel-glycol-laminate and steel-laminate variants, it can be concluded that the laminate-glycol-laminate is more effective. Full article

The effect of two different heat inputs, 1.2 and 0.8 kJ/ mg, on the microstructure associated with a welded high hardness armor (HHA) steel was investigated by ballistic tests. A novel way of comparing the ballistic performance between fusion zone (FZ), heat-affected zone (HAZ), and base metal (BM) of the HHA joint plate was applied by using results of the limit velocity V₅₀. These results of V₅₀ were combined with those of ballistic absorbed impact energy, microhardness, and Charpy and tensile strength revealing that the higher ballistic performance was attained for the lower heat input. Indeed, the lower heat input was associated with a superior performance of the HAZ, by reaching a V₅₀ projectile limit velocity of 668 m/s, as compared to V₅₀ of 622 m/s for higher heat input as well as to both FZ and BM, with 556 and 567 m/s, respectively. Another relevant result, which is for the first time disclosed, refers to the comparative lower microhardness of the HAZ (445 HV) vs. BM (503 HV), in spite of the HAZ superior ballistic performance. This apparent contradiction is attributed to the HAZ bainitic microstructure with a relatively greater toughness, which was found more determinant for the ballistic resistance than the harder microstructure of the BM tempered martensite. Full article

Sandwich panels are widely used in the design of unmanned satellites and, in addition to having a structural function, can often serve as shielding, protecting the satellites’ equipment from hypervelocity impacts (HVI) of orbital debris and micrometeoroids. This paper provides a comprehensive review of experimental studies in the field of HVI on sandwich panels with honeycomb- and open-cell foam cores, as well as an examination of available predictive models for the assessment of the panels’ ballistic limits. The emphasis of the review is placed on: (i) identifying gaps in the existing experimental database and the appropriate directions for its further expansion; and (ii) understanding the limitations of the available predictive models and the potential for their improvement. Full article

In the case of protection of transportation systems, the optimization of the shield is of practical interest to reduce the weight of such components and thus increase the payload or reduce the fuel consumption. As far as metal shields are concerned, some investigations based on numerical simulations showed that a multi-layered configuration made of layers of different metals could be a promising solution to reduce the weight of the shield. However, only a few experimental studies on this subject are available. The aim of this study is therefore to discuss whether or not a monolithic shield can be substituted by a double-layered configuration manufactured from two different metals and if such a configuration can guarantee the same perforation resistance at a lower weight. In order to answer this question, the performance of a ballistic shield constituted of a layer of high-strength steel and a layer of an aluminum alloy impacted by an armor piercing projectile was investigated in experimental tests. Furthermore, an axisymmetric finite element model was developed. The effect of the strain rate hardening parameter C and the thermal softening parameter m of the Johnson–Cook constitutive model was investigated. The numerical model was used to understand the perforation process and the energy dissipation mechanism inside the target. It was found that if the high-strength steel plate is used as a front layer, the specific ballistic energy increases by 54% with respect to the monolithic high-strength steel plate. On the other hand, the specific ballistic energy decreases if the aluminum plate is used as the front layer. Full article

This work focuses on the combination of two complementary non-destructive techniques to analyse the final deformation and internal damage induced in aramid composite plates subjected to ballistic impact. The first analysis device, a 3D scanner, allows digitalising the surface of the tested specimen. Comparing with the initial geometry, the permanent residual deformation (PBFD) can be obtained according to the impact characteristics. This is a significant parameter in armours and shielding design. The second inspection technique is based on computed tomography (CT). It allows analysing the internal state of the impacted sample, being able to detect possible delamination and fibre failure through the specimen thickness. The proposed methodology has been validated with two projectile geometries at different impact velocities, being the reaction force history on the specimen determined with piezoelectric sensors. Different loading states and induced damages were observed according to the projectile type and impact velocity. In order to validate the use of the 3D scanner, a correlation between impact velocity and damage induced in terms of permanent back face deformation has been realised for both projectiles studied. In addition, a comparison of the results obtained through this measurement method and those obtained in similar works, has been performed in the same range of impact energy. The results showed that CT is needed to analyse the internal damage of the aramid sample; however, this is a highly expensive and time-consuming method. The use of 3D scanner and piezoelectric sensors is perfectly complementary with CT and could be relevant to develop numerical models or design armours. Full article

Among all the forensic applications in which it has become an important exploration tool, ground penetrating radar (GPR) methodology is being increasingly adopted for buried landmine localisation, a framework in which it is expected to improve the operations efficiency, given the high resolution imaging capability and the possibility of detecting both metallic and non-metallic landmines. In this context, this study presents landmine detection equipment based on multi-polarisation: a ground coupled GPR platform, which ensures suitable penetration/resolution performance without affecting the safety of surveys, thanks to the inclusion of a flexible ballistic shielding for supporting eventual blasts. The experimental results have shown that not only can the blanket absorb blast-induced flying fragments impacts, but that it also allows for the acquisition of data with the accuracy required to generate a correct 3D reconstruction of the subsurface. The produced GPR volume is then processed through an automated learning scheme based on a Convolutional Neural Network (CNN) capable of detecting buried objects with a high degree of accuracy. Full article

We describe a systematic approach for the design of long, ballistic cold, and thermal neutron guides for the European Spallation Source (ESS). The guides investigated in this work are 170 m long and are required to have a narrowing point with room for a pulse shaping chopper placed 6 m from the moderator. In addition, most guides avoid line-of-sight from the moderator to the sample. The guides are optimized in order to find a reasonable trade-off between neutronics performance and construction price. The geometries simulated are closely related to the thermal-neutron multi-length-scale diffractometer HEIMDAL and the cold-neutron multi-analyser spectrometer BIFROST. For the cold-neutron guide an inexpensive solution was found that maintains good transport properties, while avoiding line-of-sight. However, for the thermal-neutron guide the losses when avoiding line-of-sight are large and it seems a good choice to stay in line-of-sight, even though this will increase both the shielding costs and fast-neutron background. The results are of general relevance for the understanding of the relation between transport, background, and price of long neutron guides. Full article

The aim of the article is to present a new technique providing an increase in the reliability of standard destructive tests of light ballistic shields. During the ballistic impact (i.e., of projectiles or fragments) on the material and its penetration by these incoming items, the absorbed kinetic energy is transformed into heat. In particular, the material regions that are damaged generate heat, and around and above the damage, on particular areas of the surface of the sample, the temperature signal increases. While registering, thermal cameras can process the impact and penetration of a material by a projectile and can accurately determine the area of the material (around the point of impact and the area of penetration) that has been damaged. Two infrared cameras were used for our testing work. One recorded the changes to the temperature field on the surface with the ballistic impact and the second one on the opposite surface. These results were compared with those obtained by optical active thermography performed by the reflection approach. Selected results from all the tests are presented in this paper. Full article
