Search Results (14)

This research addresses the challenge of formation control among multiple homogeneous autonomous underwater helicopters (AUHs) in the presence of external disturbances and complex dynamic characteristics. The study introduces a novel approach by integrating both disturbance and state observers within the control law framework to manage external disturbances and the immeasurability of velocity, respectively. Concurrently, localized radial basis function neural networks (RBFNNs) of identical configurations are incorporated into the formation control law to assimilate model uncertainties. Building upon this integration, an experience-based formation control strategy is developed, leveraging accumulated knowledge to diminish computational demands while maintaining stipulated performance criteria. Furthermore, the incorporation of a finite-time prescribed performance control (FTPPC) technique enhances the learning process’s efficiency by expediting convergence. Numerical simulations are presented to validate the efficacy of the proposed methodology. Full article

A new autonomous underwater vehicle (AUV) has high maneuverability near the bottom and a direction turnaround ability, called the autonomous underwater helicopter (AUH). This paper numerically investigates the hydrodynamic performance of the AUH. A Reynolds-Averaged Navier–Stokes (RANS) equation, a computational fluid dynamics (CFD) technique, is applied to analyze the AUH’s behavior. Investigations of the AUH’s hydrodynamic characteristics become more obvious with a service speed in the range of 0.4–1.2 m/s. For the same velocity condition, the resistance of the AUH increases, and the irregular eddy at the rear of the AUH expands with changes in the angles of attack and the length/height ratio. Essential design characteristics including pressure, velocity distribution, and velocity streamlines are shown and analyzed. These insights can be used as a guideline to reduce drag force and optimize the AUH profile for future designs. It has great potential for improving the AUH’s control algorithms. Full article

An Autonomous Underwater Helicopter (AUH) is a disk-shaped, multi-propelled Autonomous Underwater Vehicle (AUV), which is intended to work autonomously in underwater environments. The near-bottom area sweep in unknown environments is a typical application scenario, in which the complete coverage path planning (CCPP) is essential for AUH. A complete coverage path planning approach for AUH with a single beam echo sounder, including the initial path planning and online local collision avoidance strategy, is proposed. First, the initial path is planned using boustrophedon motion. Based on its mobility, a multi-dimensional obstacle sensing method is designed with a single beam range sonar mounted on the AUH. The VFH+ algorithm is configured for the heading decision-making procedure before encountering obstacles, based on their range information at a fixed position. The online local obstacle avoidance procedure is simulated and analyzed with variations of the desired heading direction and corresponding polar histograms. Finally, several simulation cases are set up, simulated and compared by analyzing the heading decision in front of different obstacle situations. The simulation results demonstrate the feasibility of the complete coverage path planning approach proposed, which proves that AUH completing a full coverage area sweep in unknown environments with a single beam sonar is viable. Full article

The observation and detection of the subsea environment urgently require large-scale and long-term observation platforms. The design and development of subsea AUVs involve three key points: the subsea-adapted main body structure, agile motion performance that adapts to complex underwater environments, and underwater acoustic communication and positioning technology. This paper discusses the development and evolution of subsea AUVs before proposing solutions to underwater acoustic communication and positioning navigation schemes. It also studies key technologies for the agile motion of subsea AUVs and finally gives an example of a solution for implementing underwater AUVs, i.e., the disk-shaped autonomous underwater helicopter (AUH). This paper will provide guidance for the design of subsea AUVs and the development of corresponding observation and detection technologies. Full article

To detect a desired underwater target quickly and precisely, a real-time sonar-based target detection system mounted on an autonomous underwater helicopter (AUH) using an improved convolutional neural network (CNN) is proposed in this paper. YOLOv5 is introduced as the basic CNN network because of its strength, lightweight and fast speed. Due to the turbidity and weak illumination of an undesirable underwater environment, some attention mechanisms are added, and the structure of YOLOv5 is optimized to improve the performance of the detector for sonar images with a 1–3% increment of mAP which can be up to 80.2% with an average speed of 0.025 s (40 FPS) in the embedded device. It has been verified both in the school tank and outdoor open water that the whole detection system mounted on AUH performs well and meets the requirements of real time and light weight using limited hardware. Full article

As a new disk-shaped autonomous underwater vehicle (AUV), the autonomous underwater helicopter (AUH) is devoted to subsea operations, usually diving into the seabed and docking with a subsea docking system. Due to the motion control’s performance, the AUH’s stability and steady-state accuracy are affected remarkably while docking. Moreover, considering the difficulties of hydrodynamic modeling of AUHs, the classical model-based control method is unsuitable for AUHs. Moreover, there is a large gap between the hydrodynamic simulation results and real situations. Hence, based on the data-driven principle, the linear active disturbance rejection control with a tracking differentiator (LADRC-TD) algorithm is employed for AUH depths and heading control. As the simulation experiments prove, LADRC and LADRC-TD have better anti-interference performance when compared with PID. According to the pool experiments, overshoots of the LADRC-TD are 20 cm and 3° for the depth control and heading control, respectively, which are superior to PID and LADRC. Meanwhile, the steady-state accuracy of the LADRC-TD is ±21 cm and ±2.5° for the depth and heading control, respectively, which is inferior to PID and the same as LADRC. Full article

Autonomous underwater helicopter, referred to as AUH, has high maneuverability in the horizontal plane and stable movement in the vertical direction due to its disc shape. Thus, the AUH demonstrates great advantages when working in scenarios that require high accuracy of horizontal movement, fixed height and depth, operation near the seafloor, and so on. In this paper, we propose a new design for an autonomous underwater helicopter with three thrusters in the vertical direction (three-vertical-thrusters), so it is equipped with fewer thrusters while maintaining maneuverability and motion stability. The three-vertical-thruster AUH not only achieves stable attitude control, but also reduces the number of thrusters, enabling the AUH to save space, reduce drag, and decrease power consumption. The three-vertical-thruster structure is designed first and compared with the existing four-vertical-thrusters type to verify its advantages through dynamic analysis and hydrodynamic simulation. The three-vertical-thruster AUH is then modelled, and a compensation method is proposed for its more complex control. The three-vertical-thruster AUH’s controllability and stability are also verified by experiments on the basis of the experimental prototypes. Full article

Real-time status monitoring is an important prerequisite for coral reef ecological protection. Existing equipment does not provide an ocean observation platform with adequate mobility and efficiency. This paper describes the design considerations of a proposed autonomous underwater helicopter (AUH) dedicated for ecological observation of coral reefs, including the system architecture, electronic devices, sensors and actuators, and explains the path control algorithm and controller to follow a specific path for ocean exploration. The structure and dynamic model of the AUH are first introduced, and then the corresponding simplification is made for motion analysis. Furthermore, computational fluid dynamics (CFD) simulation is carried out to evaluate the dynamic performance of the AUH. Fuzzy-PID control algorithm is utilized to achieve a good antidisturbance effect. In order to validate the performance of the proposed underwater vehicle, a field test was performed, and results confirmed the feasibility of the proposed prototype. Full article

The autonomous underwater helicopter, shortly referred to as AUH, is a newly developed underwater platform with a unique disc shape. An autonomous underwater helicopter with a suboptimal disc shape is presented in this paper. It adopts a multirotor configuration and stable fins to overcome the shape shortcoming for motion stabilization. Its motion analysis and mathematical model have been introduced accordingly. Computational Fluid Dynamics (CFD) simulation is carried out to evaluate fins’ hydrodynamic performance. Proportional integral derivative (PID) and sliding mode fuzzy (SMF) control are adopted for controller design. Finally, the controller is applied on this AUH and extensively tested in various simulations and experiments, and the results illustrate the high stabilization and robustness of the controller and the hovering stability and manoeuvrability of AUH. Full article

The hydrodynamic performance of a novel hovering autonomous underwater vehicle, the autonomous underwater helicopter (AUH), with an original disk-shaped hull (HG1) and an improved fore–aft asymmetric hull (HG3), is investigated by means of computational fluid dynamics with the adoption of overlapping mesh method. The hydrodynamic performance of the two hull shapes in surge motion with variation of the angle of attack is compared. The results show that HG3 has less resistance and higher motion stability compared to HG1. With the angle of attack reaching 10 degrees, both HG1 and HG3 achieve the maximum lift-to-drag ratio, which is higher for HG3 compared to HG1. Furthermore, based on the numerical simulation of the plane motion mechanism test (PMM) and according to Routh’s stability criterion, the horizontal movement and vertical movement stability indexes of HG1 and HG3 (${\mathrm{G}}_{\mathrm{H}}^{\mathrm{HG}1}=1.0$, ${\mathrm{G}}_{\mathrm{V}}^{\mathrm{HG}1}=49.7$, ${\mathrm{G}}_{\mathrm{H}}^{\mathrm{HG}2}=1.0$,${\mathrm{G}}_{\mathrm{V}}^{\mathrm{HG}3}=2.1$) are obtained, which further show that the AUH has better vertical movement stability than the torpedo-shaped AUV. Furthermore, the scale model tail velocity experiment indirectly shows that HG3 has better hydrodynamic performance than HG1. Full article

Autonomous Underwater Helicopter (AUH) is a disk-shaped Autonomous Underwater Vehicle (AUV), and it has comparative advantage of near-bottom hovering and whole-direction turn-around ability over the traditional slender AUV. An optimization design of its irregular geometric profile is essential to improve its hydrodynamic performance. A parametric representation of its profile is proposed in this paper using Non-Uniform Rational B-spline (NURBS) curve. The parametric representation of AUH profile is described with two decision variables and several data points. Based on this parametric curve, Computational Fluid Dynamics (CFD) simulation is carried out to evaluate its hydrodynamic performance with various parameters. A predication model is established over variables’ design space using Kriging surrogate model with CFD simulation results and a Genetic Algorithm (GA) procedure is conducted to find optimal design variables, which can produce an optimum lift-drag ratio. CFD verification results confirm that AUH profile with optimized design variables can increase its lift-drag ratio by 2.11 times compared with that of non-optimized ones. It demonstrates that the parametric representation and optimization procedure of AUH profile proposed in this paper is feasible, and it has a great potential in improving AUH’s performance. Full article

Autonomous Underwater Vehicles (AUVs) are the mainstream equipment for underwater scientific research and engineering. However, it remains a great challenge for AUVs to carry out near-seabed operations because of their poor maneuverability. In this paper, a new design for a high-maneuverability disc-shaped AUV is proposed, namely, the Autonomous Underwater Helicopter (AUH). We designed the AUH’s propulsion system through dynamic analysis based on the unique disc shape. The experimental prototype was built by mechatronics technology, after which several motion experiments were carried out to demonstrate the high maneuverability. We find that the prototype has high maneuverability: it can cruise at 0.8 m/s (about 1.5 knots), at least; its turning radius is zero and its turning speed is at least 20 deg/s; and the motion of specific curves in a small range was completed. It is demonstrated that over-actuation is not necessary for the high-maneuverability AUH because of its unique disc shape. A propulsion system consisting of four propellers and a buoyancy adjustment system is used for the highly maneuverable AUH. In addition, the AUH may be a solution for near-seafloor operations. Full article

An autonomous underwater hovering vehicle (AUH) is a novel, dish-shaped, axisymmetric, multi-functional, ultra-mobile submersible in the autonomous underwater vehicle (AUV) family. Numerical studies of nonlinear, asymmetric water entry impact forces on symmetrical, airborne-launched AUVs from conventional single-arm cranes on a research vessel, or helicopters or planes, is significant for the fast and safe launching of low-speed AUVs into the target sea area in the overall design. Moreover, a single-arm crane is one of the important ways to launch AUVs with high expertise and security. However, AUVs are still subject to a huge load upon impact during water entry, causing damage to the body, malfunction of electronic components, and other serious accidents. This paper analyses the water entry impact forces of an airborne-launched AUH as a feasibility study for flight- or helicopter-launched AUHs in the future. The computational fluid dynamics (CFD) analysis software STAR-CCM+ solver was adopted to simulate AUH motions with different water entry speeds and immersion angles using overlapping grid technology and user-defined functions (UDFs). In the computational domain for a steady, incompressible, two-dimensional flow of water with identified boundary conditions, two components (two-phase flow) were modeled in the flow field: Liquid water and free surface air. The variations of stress and velocity versus time of the AUH and fluid structure deformation in the whole water entry process were obtained, which provides a reference for future structural designs of an AUH and appropriate working conditions for an airborne-launched AUH. This research will be conducive to smoothly carrying out the complex tasks of AUHs on the seabed. Full article

In this paper, the Magnus force induced by a disk-type, spinnable autonomous underwater vehicle (AUV), i.e., autonomous underwater helicopter (AUH), was predicted to promote the spinning AUH moving away from a deep-sea region with temporary and shockable ocean current. The simulation technique of the ANSYS-CFX solver based on viscous computational fluid dynamics (CFD) was employed to analyze the hydrodynamic performance of the spinning AUH and its high-speed propellers in uniform flow conditions. The behavior of the spinning AUH in currents can obviously alter the pressure distribution on both sides of the disk-shaped hull form, resulting in a differential pressure force in the horizontal plane, i.e., Magnus force. The simulation results show that this induced force can enable an AUH at 1 knot service speed to successfully move away from a sudden, transient, and/or steady, uniform ocean current region with inflow velocities of 1–2 knots in deep-sea conditions. The Magnus force induced by symmetrically configurated propeller couple force can be more efficient and effective at driving the AUH’s escape from the current spoiler zone than driving the AUH using the two high-revolution propellers directly. A suitable mechanical power energy-saving matching point integrating the AUH and symmetric propulsion was determined to compare the proposed method and two conventional methods for AUH escape from currents. The comparison results prove that the proposed method is effective and efficient. This study provides a significant reference for the interdependent relationship between the effective spinning speed of an AUH, subject to couple force, controlled propeller revolution, AUH speed, and battery capacity, and the range of ocean currents. Full article
