A hybrid fiber sensor for the simultaneous measurement of pressure and temperature is proposed. The sensor is constituted of a section of silica capillary tube (SCT) whereat access channels are created with two different methods: instilling a bubble on the fiber by employing successive arc discharges on the SCT whilst under pressure and splicing the SCT with another section of SCT with a smaller inner diameter. The reflection-based sensor enhances Fabry–Perot interference (FPI) and antiresonant (AR) guidance, simultaneously, in a single sensing element of a few millimeters. A comparison study between the access channel methods reveals higher spectral visibility for the bubble method and similar pressure and temperature resolutions. For a 2.58 mm long sensor with a bubble, the sensitivity to pressure is 4.09 ± 0.01 nm/MPa and −3.7 ± 0.1 nm/MPa for the FPI and AR, respectively, while its sensitivity to temperature is −0.20 ± 0.02 pm/°C and 24.0 ± 0.5 pm/°C, respectively, for the FPI and AR, which are within the numerically calculated sensitivities. The sensor is robust and has a convenient reflective probe with easy and low-cost fabrication, granting high competitiveness in actual applications. Full article

A highly birefringent and low-loss hollow-core anti-resonant fiber (HC-ARF) based on a hybrid guidance mechanism is proposed and investigated by using a finite element method. The hybrid guidance mechanism is caused by the anti-resonance effect and the total internal reflection effect. The proposed HC-ARF is obtained by employing twin symmetrical and mutually tangential elliptical arc anti-resonance layers (EA-ARLs) in a conventional 8-tube HC-ARF. Because of the anti-resonance mechanism and the total internal reflection mechanism in the EA-ARL, mode coupling appears between the core mode and the cladding mode. Simulation results indicate that the proposed HC-ARF can achieve birefringence as high as 10⁻² in a near-infrared range of 1400 nm to 1600 nm and a low confinement loss (CL) of 7.74 × 10⁻⁴ dB/m (9.26 × 10⁻⁴ dB/m) for x- and y-polarization components of the fundamental mode (FM) at 1550 nm. In addition, the existence of the 8-tube anti-resonance structure in the cladding significantly suppresses the CL of the x-polarization component of the FM significantly, but the impact on the CL of the y-polarization FM can be ignored, which is determined mainly by the twin EA-ARLs. Furthermore, the performance of the birefringence and CL are also investigated by changing the values of other fiber structure parameters. Our proposed structure successfully shows the ability of the hybrid guidance mechanism in the application of CL manipulation of orthogonal polarization components. Full article

In this paper, a hollow core fiber was spliced with standard single-mode fibers to form a fiber optic gas pressure sensor, and its sensing characteristics with single hole or multi-holes punched on the hollow core fiber with femtosecond laser pulses were investigated. The experiments demonstrate that the air pressure sensitivity of the single hole sensor was −3.548 nm/MPa, with a linearity of 99.45%, while its response times for air pressure’s rise and fall were 4.25 s and 2.52 s, respectively. The air pressure sensitivity of the ten-hole sensor was up to −3.786 nm/MPa, with a linearity of 99.47%, while its response times for air pressure’s rise and fall were 2.17 s and 1.30 s, respectively. Theoretical analysis and experimental results indicate that the pressure sensitivity of the sensor with an anti-resonant reflecting guidance mechanism mainly comes from the refractive index change of the air inside the hollow core fiber. The proposed device with multi-holes drilled by a femtosecond laser has the advantages of fabrication simplicity, low cost, fast response time, good structural robustness, high repeatability, high sensitivity to air pressure, and insensitivity to temperature (only 10.3 pm/°C), which makes it attractive for high pressure sensing applications in harsh environments. Full article

In this paper, we propose and experimentally demonstrate a simple technique to enhance the curvature sensitivity of a bending fiber optic sensor based on anti-resonant reflecting optical waveguide (ARROW) guidance. The sensing structure is assembled by splicing a segment of capillary hollow-core fiber (CHCF) between two single-mode fibers (SMF), and the device is set on a steel sheet for measuring different curvatures. Without any surface treatment, the ARROW sensor exhibits a curvature sensitivity of 1.6 dB/m⁻¹ in a curvature range from 0 to 2.14 m⁻¹. By carefully coating half of the CHCF length with polydimethylsiloxane (PDMS), the curvature sensitivity of the ARROW sensor is enhanced to −5.62 dB/m⁻¹, as well as an increment in the curvature range (from 0 to 2.68 m⁻¹). Moreover, the covered device exhibits a low-temperature sensitivity (0.038 dB/°C), meaning that temperature fluctuations do not compromise the bending fiber optic sensor operation. The ARROW sensor fabricated with this technique has high sensitivity and a wide range for curvature measurements, with the advantage that the technique is cost-effective and easy to implement. All these features make this technique appealing for real sensing applications, such as structural health monitoring. Full article

We propose and demonstrate a cascaded hollow-core fiber (HCF) device for multi-parameter sensing based on the combination of antiresonant reflecting guidance (ARRG) and Mach-Zender interference (MZI). The device was fabricated by splicing two sections of HCF together. Two sets of fringes, which have different free spectral ranges, were generated from ARRG and MZI, respectively, and were aliasing in the transmission spectrum. The two sets of fringes were then separated using a band pass filter and a Gaussian fitting technique. The wavelengths at two transmission loss dips formed by ARRG and MZI exhibit a temperature sensitivity of 14.1 and 28.5 pm/°C, and a strain sensitivity of 0.4 and −0.8 pm/με, respectively. By using a crossing matrix with differences sensitivities, the cross-sensitivity between temperature and strain can be solved. The gas pressure response of the cascaded HCF device was also tested up to 300 °C, and linear relationships between the gas pressure sensitivities and temperature were found, which can be used in gas pressure application in various temperatures. Moreover, the proposed cascaded HCF sensor is compact, low cost, and simple for fabrication, and hence offers a promising way for the simultaneous measurement of multiple parameters, such as temperature, strain, and gas pressure. Full article

In this paper, a simplified hollow-core photonic crystal fiber surface-enhanced Raman scattering (SERS) probe is presented. Silver nanoprisms are grown with a photoreduction method and account for the SERS, which have better electromagnetic enhancement than spherical silver nanoparticles at 785 nm. Due to the antiresonant reflecting guidance mechanism, the excited laser and SERS signal are effectively guided in such a fully filled hollow-core photonic crystal fiber SERS probe and complicated selective filling with target sample is avoided. Rhodamine 6G molecules are used as probe molecules and the simplified hollow-core photonic crystal fiber SERS probe is test. Detection of low concentration Rhodamine 6G down to 10⁻⁸ M is achieved with a short integration time of 300 ms. Full article
