The mutual influences of the electric field, rotation, and heat transmission find applications in controlled drug delivery systems, precise microfluidic manipulation, and advanced materials’ processing techniques due to their ability to tailor fluid behavior and surface morphology with enhanced precision and efficiency. Capillary instability has widespread relevance in various natural and industrial processes, ranging from the breakup of liquid jets and the formation of droplets in inkjet printing to the dynamics of thin liquid films and the behavior of liquid bridges in microgravity environments. This study examines the swirling impact on the instability arising from the capillary effects at the boundary of Rivlin–Ericksen and viscous liquids, influenced by an axial electric field, heat, and mass transmission. Capillary instability arises when the cohesive forces at the interface between two fluids are disrupted by perturbations, leading to the formation of characteristic patterns such as waves or droplets. The influence of gravity and fluid flow velocity is disregarded in the context of capillary instability analyses. The annular region is formed by two cylinders: one containing a viscous fluid and the other a Rivlin–Ericksen viscoelastic fluid. The Rivlin–Ericksen model is pivotal for comprehending the characteristics of viscoelastic fluids, widely utilized in industrial and biological contexts. It precisely characterizes their rheological complexities, encompassing elasticity and viscosity, critical for forecasting flow dynamics in polymer processing, food production, and drug delivery. Moreover, its applications extend to biomedical engineering, offering insights crucial for medical device design and understanding biological phenomena like blood flow. The inside cylinder remains stationary, and the outside cylinder rotates at a steady pace. A numerically analyzed quadratic growth rate is obtained from perturbed equations using potential flow theory and the Rivlin–Ericksen fluid model. The findings demonstrate enhanced stability due to the heat and mass transfer and increased stability from swirling. Notably, the heat transfer stabilizes the interface, while the density ratio and centrifuge number also impact stability. An axial electric field exhibits a dual effect, with certain permittivity and conductivity ratios causing perturbation growth decay or expansion. Full article

Pressure nozzles are widely used in spray drying and other industries. In order to improve the atomization characteristics of pressure cyclone nozzles, a new type of annular jet gas impingement atomization device is developed. We use high-speed imaging and digital image processing and other methods to analyze the spray characteristics of the different annular device configurations (using four, six, and eight tubes) and under different gas–liquid mass flow rates. It is shown that with an increase in the Air–Liquid mass Ratio (ALR), the liquid film breakup process changes from undulating sheet breakup to perforated sheet breakup and the breakup length decreases. The breakup length decreases the most under the condition of six-tube airflow with the range of 31–55%, while the Sauter mean diameter (SMD) basically does not change. With the increase in ALR and the Weber number of liquid (We_l), the droplet size distribution becomes more uniform. The spray characteristics of the atomizer assisted by gas jets reaches the best state when We_l = 4596.3 and $\dot{m}$_g = 1.97 g/s. The experimental conclusions have some guiding significance for the design and optimization of the atomization devices in spray drying towers. Full article

The use of gas energy includes a wide range of applications to directly accelerate the liquid in a pipeline without the aid of mechanical equipment, such as marine gas-liquid jet propulsion. To clarify the characteristics of energy transfer by interphase forces for gas-liquid flows in variable cross-section tubes, two-fluid models of annular flow, bubbly flow and homogeneous flow were adopted, respectively, along with four newly elaborated coefficients, which are the work factor of gas $f_g$, reflecting the relative ability of gas to power liquid, the interface work transfer coefficient $k_g$ (representing the relative magnitude of mechanical work received by liquid from gas), the interphase work-to-energy conversion coefficient $k_l$ (denoting the capability of energy transfer through work performed by interphase forces) and the interphase mechanical efficiency ${\eta }_w$. The results reveal the interphase work transfer is strongly influenced by the structural parameters of the tubes (or nozzles), and an optimized design is necessary to improve the performance. The higher the degree of gas dispersion in the liquid, the more advantageous the conversion of gas work into the liquid’s mechanical energy. Of these three flow patterns, annular flow has the lowest $k_l$ and ${\eta }_w$ ($k_l$ = 0.0797, ${\eta }_w$ = 0.9885 in present example), while homogeneous flow displays the limit of interphase mechanical energy conversion because the gas-liquid momentum coupling reaches the maximum ($k_l$ = 0.9979, ${\eta }_w$ = 1). Full article

As a new processing method, water jet processing technology has risen rapidly due to its wide range of applications, no pollution, and zero discharge. In this paper, the flow characteristics and failure characteristics of ultra-high-pressure gas-liquid jet in the range of 300 MPa are analyzed by numerical calculation. The research conclusion shows that the jet atomization diffusion is caused by the friction between the liquid medium and the surrounding gas, the mixed flow of broken water droplets and cavitation. The jet diffusion process is essentially the energy exchange process between the jet in the core area and the turbulent flow in the atomization area. The distribution of the turbulent kinetic energy in the atomization area can determine the degree of jet diffusion and the rate of energy decay. The water jet impacted the surface of the target to form a crater-like annular erosion pit. With the increase of the impact pressure, the deformation showed an overall increasing trend, and the increasing trend increased significantly. The central depression of the erosion area is caused by the damage of the material by the stagnation pressure in the core area. The flow characteristics of gas-liquid flow in the process of formation and diffusion in the high-pressure water jet nozzle are explored from the microscopic point of view, and it also provides a theoretical basis for equipment optimization in engineering. Full article

The introduction of air into a submerged annular jet will result in dispersion of the jet, which will affect the degree of enclosure of the gas–water mixing zone in the annular jet nozzle, and then have a significant impact on air suction and the formation of the foam system in the floatation process. A numerical simulation method is used to analyze the characteristics of the distribution of the axial flow velocity of annular jets, gas–phase volume, and turbulence intensity in the gas–water mixing zone in the nozzle with different air–liquid ratios, and thereby reveal the mechanism whereby gas–containing in annular jets affects the degree of enclosure of the gas–water mixing zone. The results show that as the air–liquid ratio increases, the degree of air–liquid mixing will increase and the radial flow velocity will decrease gradually, resulting in the effective enclosure of the gas–water mixing zone. Meanwhile, the dissipation of jet energy, the range of turbulent flow and the vorticity intensity will increase, but the turbulence intensity will decrease. When the gas–water mixing zone is fully enclosed, as gas–containing continues to increase, the degree of dispersion of the annular jet will further increase. Consequently, the area of the gas–water mixing zone with bounced–back water will become larger, resulting in a higher axial flow velocity, larger local turbulence intensity and larger vorticity intensity. This will lead to the dissipation of jet energy, which is not favorable for air suction. Full article

The linear instability of an annular liquid jet with a radial temperature gradient in an inviscid gas steam is investigated theoretically. A physical model of an annular liquid jet with a radial temperature gradient is established, dimensionless governing equations and boundary conditions are given, and numerical solutions are obtained using the spectral collocation method. The correctness of the results is verified to a certain extent. The liquid surface tension coefficient is assumed to be a linear function of temperature. The effects of various dimensionless parameters (including the Marangoni number/Prandtl number, Reynolds number, temperature gradient, Weber number, gas-to-liquid density ratio and velocity ratio) on the instability of the annular liquid jet are discussed. A decreasing Weber number destabilizes the annular liquid jet when the Weber number is lower than a critical value. It is found that the effects of the Marangoni effect are related to the Weber number. The Marangoni effect enhances instability when the Weber number is small, while the Marangoni effect weakens instability when the Weber number is large. In addition, because the thermal effect is considered, a decreasing Reynolds number enhances the instability when the Weber number is lower than a critical value, which is similar to the results of a viscous liquid sheet with a temperature difference between two planar surfaces. Furthermore, the effects of other dimensionless parameters are also investigated. Full article

The present study compares two twin-fluid atomizer concepts based on the airflow (shock waves) pattern obtained through shadowgraph imaging for atomization of water with a low air/water pressure supply. The research work was conducted using the backlight imaging technique for converging (sonic) and converging–diverging (supersonic) air-assist atomizers with a 3.0 mm (throat) diameter. An annular sheet of thicknesses 70 µm and 280 µm with a high-speed air-core was employed to study the breakup dynamics for different water mass flow rates (100–350 kg/h) and air mass flow rates (5–35 kg/h). Different sheet breakup patterns were identified as the function of the ALR ratio (air-to-liquid mass flow), liquid Weber number (_WeL), and Reynolds number (Reg). Different breakup modes extend from canonical Rayleigh bubble breakup, ligament-type breakup, to the pure pulsating breakup via annular sheet disintegration. The sheet breakup dynamics were studied in terms of spray angle and breakup length. With higher ALR values, breakup length showed a decreasing trend, while spray angle showed an increasing trend in the converging and converging–diverging (CD) air-assist atomizers, respectively, owing to the drastic difference in the jet flow dynamics. Full article

In the flotation process, gas-liquid properties and the bubble system greatly influence bubble mineralization. In order to clarify how the mechanism applies to the closure characteristics of an annular jet mixed flow zone on the inspiratory performance and the bubble system, different degrees of closure on the velocity field and gas-liquid ratio in the mixed flow zone were investigated using numerical simulation. The variations in the characteristics of bubble size distribution, rising velocity, and gas content under different closure levels were measured with a high-speed dynamic camera technology. The results confirmed that when the closure degrees of the mixed flow zone improved, the inlet jet could gradually overcome the static pressure outside the nozzle effectively. It formed a gas-liquid mixing zone with high turbulence first, and a large pressure difference at the gas-liquid junction second. This helped to increase the inspiratory capacity. At the same time, the gas-liquid ratio rose gradually under conditions of constant flow. When the nozzle outlet was completely closed, the gas-liquid ratio gradually stabilized. For the bubble distribution system, an enhancement in the closure degrees can effectively reduce the bubble size, and subsequently, the bubble size distribution became more uniform. Due to the improved gas-liquid shear mixing, the aspect ratio of the bubbles can be effectively changed, consequently reducing the bubble rising speed and increasing the gas content and bubble surface area flux of the liquid. Full article

In this study, a compressible three-phase homogeneous model was established using ABAQUS/Explicit. These models can numerically simulate the pulsation process of cavitation bubbles in the free field, near the flat plate target, and near the curved boundary target. At the same time, these models can numerically simulate the strong nonlinear interaction between the cavitation bubble and its nearby wall boundaries. The mutual flow of liquid and gas and fluid solid coupling were solved by the Euler domain in simulation. The results of the numerical simulation were verified by comparing them with the experimental results. In this study, we used electric spark bubbles to represent cavitation bubbles. A high-speed camera was used to record the pulsation process of cavitation bubbles. This study first verified the pulsation process of cavitation bubbles in the free field, because it was the simplest case. Then we verified the interaction process between cavitation bubbles and different wall boundaries. In order to further confirm the credibility of the numerical simulation results, for each wall surface, this study used two burst distances (10 mm and 25 mm) for simulation verification. The numerical model established in this study could effectively simulate the pulsation characteristics of cavitation bubbles, such as the formation of jets and annular bubbles. After verification, the simulated cavitation bubble was almost the same as the cavitation bubble captured by the high-speed camera in the experiment in terms of time, volume, and shape. In this study, a detailed velocity field of the cavitation bubble collapse stage was obtained, which laid down the foundation for the study of the strong nonlinear interaction between the cavitation bubble and the target plates of different shapes. Compared with the experimental results, we found that the numerical model established by the simulation could accurately simulate the bubble pulsation and jet formation processes. In the experiment, the interval time for the bubble pictures taken by the high-speed camera was 41.66 μs per frame. Using a numerical model, the bubble pulsation process can be simulated at an interval of 1 µs per frame. Therefore, the numerical model established by the simulation could show the movement characteristics of the cavitation bubble pulsation process in more detail. Full article

Liquid impinging jet at the bottom of the annular cavity is a typical case in the process industry. The jet could have an impact at the bottom center or its peripheral section. The profiled annular cylindrical cavity with the installed electricity heater source is investigated in this paper. Thermal contact irreversibility and liquid drag irreversibility are generated within the profiled cavity. Through analytical modeling and experimental verification, a valid model of the entropy generation is established for both states. The results show that the total entropy between the liquid and the bottom is many times greater for the case of the central jet impingement. Within the annular vertical walls are the locations of the maximum or minimum of the entropy. The effectiveness of the liquid heating is greater in the peripheral impact of the liquid. The method and the results are the basis for optimizing the profiled cavity in various optimization geometry parameters. The optimal geometry of the annular cavity exists in such a way that the balance between thermal irreversibility and liquid drag irreversibility leads to the total minimum rate of the entropy generation for the annular cavity. Full article
