It is well understood that burr size and shape, as well as surface quality attributes like surface roughness in milling parts, vary according to several factors. These include cutting tool orientation, cutting profile, cutting parameters, tool shape and size, coating, and the interaction between the workpiece and the cutting tool. Therefore, burr size cannot be formulated simply as a function of direct parameters. This study proposes an ensemble learning regression model to accurately predict burr size and surface roughness during the slot milling of aluminum alloy (AA) 6061. The model was trained using cutting parameters as inputs and evaluated with performance metrics such as mean absolute error (MAE), mean squared error (MSE), and the coefficient of determination (R²). The model demonstrated strong generalization capability when tested on unseen data. Specifically, it achieved an R² of 0.97 for surface roughness (Ra) and R² values of 0.93 (B5, B8), 0.92 (B2), 0.86 (B1), and 0.65 (B4) for various burr types. These results validate the model’s effectiveness despite the nonlinear and complex nature of burr formation. Additionally, feature importance analysis via the F-test indicated that feed per tooth and depth of cut were the most influential parameters across several burr types and surface roughness outcomes. This work represents a novel and accurate approach for predicting key surface quality indicators, with significant implications for process optimization and cost reduction in precision machining. Full article

SS 316L, a low-carbon 316 Stainless Steel, has been used to manufacture swivel mechanisms for paraplegic patients, but its weight is relatively high compared to a few materials in its range of properties. Aluminum alloy 6061 and Titanium alloy (Ti6Al4V) offer lightweight and incredible strength-to-weight ratio, hence their use for medical, aerospace, and automotive applications. This study, therefore, seeks a replacement for SS 316L. A 3D model of a swivel mechanism was developed to compare the performance of the swivel mechanism made with SS 316L, AA 6061, and Ti6Al4V. The kinematic analysis of the mechanism based on a range of weights: 1kN, 1.1 kN, 1.2 kN, 1.3 kN, 1.4 kN, and 1.5 kN was carried out to generate the inputs for the simulation. The 3D model was made with SolidWorks, and the results of the kinematic analysis were used to define the simulation parameters for the mechanism. Two scenarios generated depicted the full collapse of the mechanism and the full extension. The results showed that AA 6061 and Ti6Al4V outperformed SS 316L with higher yield strength and factor of safety. Therefore, swivel plates made with AA 6061 and Ti6Al4V have higher yield strength than those made with SS 316L, adding to the advantage that they have a higher strength-to-weight ratio. From this analysis and known knowledge of the cost of these materials, the optimal replacement considering cost with yield strength is AA 6061. However, Ti6Al4V is a better alternative for the strength-to-weight ratio for SS 316L. Full article

Solid-state additive friction stir deposition (AFSD) is a thermomechanical-based additive manufacturing technique. For this study, AFSD was utilized to produce aluminum alloy 6061 (AA6061) blocks with varying layer thicknesses (1 mm, 2 mm, and 3 mm). The mechanical properties were assessed through uniaxial tensile tests and Vickers microhardness measurement, and statistical analysis was employed to investigate differences among data groups. The results revealed that the deposition layer thickness influences tensile properties in the building (Z) direction, while the properties in the X and Y directions showed minor differences across the three AFSD blocks. Furthermore, variations in tensile properties were observed depending on the sample orientation in the AFSD blocks and its depth-wise position in the part in the building direction. The microhardness values decreased non-linearly along the building direction, spread across the width of the part’s cross-section, and highlighted that the deposition layer thickness significantly affects this property. The 1 mm block exhibited lower average microhardness values than the 2 mm and 3 mm blocks. The temperature histories and dynamic heat treatment are influenced by the deposition layer thickness and depend on the location of the point being studied in the part, resulting in variations in the microstructure and mechanical properties along the building direction and across the part’s width. Full article

Polymer–metal hybrid structures combine the merits of polymer and metal materials, making them widely applicable in fields such as aerospace and automotive industries. However, the main challenge lies in achieving efficient and strong connections between the metal and polymer components. This paper uses the jet electrochemical machining (Jet-ECM) method to customize the surface morphologies on 6061 aluminum alloy (AA6061) sheets. The connection between AA6061 and carbon fiber-reinforced PA66 (CF/PA66) is then achieved through hot pressure welding (HPW). The effects of aluminum alloy surface morphology, welding force, and welding time on the mechanical properties and microstructure of the joint are investigated. The optimal process parameters are determined by the design of the experiment. The results show that the aluminum alloy surface morphology has the greatest impact on the mechanical property of the welded joint. The optimal process parameters are surface morphology with wider, shallower, and sparsely distributed grooves on the aluminum alloy surface, the welding force is 720 N, the welding time is 12 s, the welding temperature is 360 °C, the cooling time is 16 s, and the optimal peak load of the joint is 6690 N. Under the optimal parameters, the fracture morphology in the AA6061 side is almost entirely covered with CF/PA66. The joint experiences cohesive failure in most areas and fiber-matrix debonding in a small area. Full article

Laser welding, known for its distinctive advantages, has become significantly valuable in the automotive industry. However, in this context, the frequent occurrence of hot cracking necessitates further investigation into this phenomenon. This research aims to understand the hot-cracking mechanism in aluminum alloy (AA) 6061, welded using a laser beam in a lap joint setup. We used an array of material characterization methods to study the effects of processing parameters on the cracking susceptibility and to elucidate the hot-cracking mechanism. A laser power of 2000 W generated large hot cracks crossing the whole weld zone for all welding speed conditions. Our findings suggest that using a heat input of 30 J/mm significantly mitigates the likelihood of hot cracking. Furthermore, we observed that the concentrations of the alloying elements in the cracked region markedly surpassed the tolerable limits of some elements (silicon: 2.3 times, chromium: 8.1 times, and iron: 2.7 times, on average) in AA6061. The hot-cracking mechanism shows that the crack initiates from the weld root at the interface between the two welded plates and then extends along the columnar dendrite growth direction. Once the crack reaches the central region of the fusion zone, it veers upward, following the cooling direction in this area. Our comprehensive investigation indicates that the onset and propagation of hot cracks are influenced by a combination of factors, such as stress, strain, and the concentration of alloying elements within the intergranular region. Full article

The real-time evolution of the deformation and strain field of non-heat-treatable aluminum alloy 5754 and heat-treatable aluminum alloy 6061 resistance spot welding joints during the lap shear test was extracted using the digital image correlation (DIC) technique. The strain competition phenomenon between the nugget and its peripheral metal was quantitatively analyzed by applying 2D and 3D DIC analyses. The quantitative data show the tensile strain concentrated in the peripheral metal of the AA5754-O joint, which fractured in the pull-out mode. In comparison, a significant shear strain appears in the nugget of the AA6061-T6 joint, leading to its fracture in the interfacial failure mode during the lap shear test. The phase evolution of the nugget was analyzed using the thermodynamics database JMatPro, which was further used to calculate the local strength of the joints. The results indicate that the nugget strength of AA5754 is 223 MPa, the nugget strength of AA6061 is 178 MPa, and the heat-affected zone (HAZ) strength of AA6061 is 263 MPa. By inputting the local strength data, the calculated result of the analytical load-bearing competition model is in accordance with the experimental data of the lap shear test. Full article

The present study elaborates on the thermal distribution and efficiency of a longitudinal rectangular fin with exponentially varying temperature-dependent thermal conductivity and heat transfer coefficient concerning internal heat generation. Also, the thermal distribution of a fin is comparatively studied for both exponentially varying temperature-dependent thermal conductivity and linearly varying temperature-dependent thermal conductivity. Further, the thermal distribution of a longitudinal fin is examined by using ANSYS software with different fin materials. Many physical mechanisms can be explained by ordinary differential equations (ODEs) with symmetrical behavior, the significance of which varies based on the perspective. The governing equation of the considered problem is reduced to a non-linear ODE with the assistance of dimensionless terms. The resultant equation is solved analytically using the DTM-Pade approximant and is also solved numerically using Runge-Kutta Fehlberg’s fourth-fifth (RKF-45) order method. The features of dimensionless parameters influencing the fin efficiency and temperature profile are discussed through graphical representation for exponentially and linearly varying temperature-dependent thermal conductivity. This study ensures that the temperature field enhances for the higher magnitude of thermal conductivity parameter, whereas it diminishes for diverse values of the thermo-geometric parameter. Also, greater values of heat generation and heat transfer parameters enhance the temperature profile. Highlight: Thermal distribution through a rectangular profiled straight fin is examined. Linear and non-linear thermal properties are considered. The combined impact of conduction, convection, and internal heat generation is taken for modeling the energy equation of the fin. Thermal simulation is performed for Aluminum Alloy 6061 (AA 6061) and Cast Iron using ANSYS. Full article

The high entropy alloy (HEA) filler used during the fabrication method determines the reliability of HEAs for steel-aluminum dissimilar alloy configuration. HEAs have a direct impact on the formation of intermetallic compounds (IMC) formed by the interaction of iron (Fe) and aluminum (Al), and influence the size of the joint’s interaction zone. A novel welding process for Fe-Al alloy joints was developed to prevent the development of a brittle iron-aluminum interface. This research involved investigation of the possibility of using HEA powdered filler. Fe₅Co₂₀Ni₂₀Mn₃₅Cu₂₀ HEAs was used as a filler for the laser joining lap configuration joining hyper-duplex stainless steel UNS S33207 to aluminum alloy 6061. This HEA has unique properties, such as high strength, good ductility, and high resistance to corrosion and wear. A tiny portion of the stainless-steel area was melted by varying the welding parameters. The high-entropy alloy (HEA) with slow kinetic diffusion and large entropy was employed to aid in producing solid solution structures, impeding the blending of iron and aluminum particles and hindering the development of Fe-Al IMCs. The weld seam was created without the use of Fe-Al IMCs,. The specimen broke at the HEAs/Al alloy interface with a tensile-shear strength of 237 MPa. The tensile-shear strength achieved was 12.86% higher than for the base metal AA 6061 and 75.57% lower than for the UNS S33207 hyper-duplex stainless steel. Full article

The precipitation-hardenable aluminum alloy 6061 (AA 6061) is favored for aerospace components and automotive parts. However, the tenacious oxide layer on the surface greatly limits the quality and applicability of joining AA 6061. In this study, the joining method of solid-state diffusion bonding was implemented for AA 6061 plates, and the effects of post-weld heat treatment (PWHT) on the joint interface were investigated. The bonding temperatures were within the range of 500–530 °C, and the time periods varied from 30 to 240 min under a static pressure of 5 MPa in a vacuum. The diffusion bonded specimens were subjected to T4- and T6-PWHT to improve the bonding quality. The interfacial microstructure of the joints was analyzed by scanning electron microscopy, and the mechanical properties were evaluated with shear tests. The experimental results showed that the shear strength of the diffusion bonded joint could reach around 71.2 MPa, which was highly dependent on bonding temperature and holding time, and T6-PWHT further enhanced it to over 100 MPa. The effects of PWHT on the diffusion bonded AA 6061 joint were investigated, and the fractography on the sheared surfaces indicated that PWHT-T6 played an important role in enhancing joint strength, which was consistent with the measured shear strength. The sequential PWHT for AA 6061 after diffusion bonding was proven to be feasible for bonding of AA 6061 parts, and the joint strength was sufficient for industrial needs. Full article

Aluminum is a material widely used in aeronautical and transport industries due to its excellent mechanical and corrosion resistance properties. Unfortunately, aluminum alloys are susceptible to corrosion, which limits their use in some corrosive environments. The aim of this work is to characterize hard coat film fabricated by anodizing in a citric–sulfuric acid system using electrochemical techniques. The anodization process was carried out using an aluminum alloy AA 6061 anodization bath: a mix of citric and sulfuric acid solutions were used. For the anodizing process, two current densities were used, 1 and 7.2 A·cm⁻². Anodized specimens obtained under different conditions were exposed to a 3.5 wt.% NaCl solution, and their electrochemical behavior was studied by electrochemical impedance spectroscopy (EIS) and cyclic potentiodynamic polarization (CPP) according to ASTM G106-15 and ASTM G5-13, respectively. Scanning electron microscopy (SEM) was employed to determinate the morphology and thickness of coatings. The results showed improved corrosion resistance in 6061 aluminum anodized in citric–sulfuric acid electrolyte compared to those anodized in sulfuric acid solution. Full article

In the present work, aluminum alloy 6061 (AA6061) device chips were subjected to cold compaction monitored by an extrusion procedure at an extrusion ratio of 5:2 and elevated temperatures of 350, 425, and 500 °C, respectively. The influence of changing temperature on the corrosion of the extruded alloys after 1 h and 24 h in 3.5% NaCl solutions was studied. The polarization (cyclic potentiodynamic polarization, CPP) results indicated that the corrosion decreases with the increase of extrusion temperature of AA6061 from 350 to 500 °C. Impedance (electrochemical impedance spectroscopy, EIS) experiments provided a remarkable increase in the corrosion resistance with rising the extrusion temperature. Potentiostatic current-time (PCT) curves indicated that the current initially increased then decreased for all alloys after 1 h measurements. Prolonging the exposure time to 24 h was observed to decrease the rate of corrosion for all AA6061 alloys as proved by CPP and EIS data. This effect was found to increase the pitting corrosion as indicated by the measured PCT curves and by the scanning electron microscopy (SEM) images for the surface of the alloys. The surface layers formed on AA6061 alloys were mostly composed of aluminum oxide as presented by the spectra of the energy dispersive X-ray analyzer (EDX). All results indicated that the increase of the temperature of extrusion increased the corrosion resistance via decreasing the corrosion current and corrosion rate, and that this effect was found remarkably increased when the immersion time increased from 1 to 24 h exposure to the chloride test solution. Full article

Aluminum Alloy 6061 components are frequently manufactured for various industries—aeronautics, yachting, and optical instruments—due to their excellent physical and mechanical properties, including corrosion resistance. There is little research on the mechanical tooling of AA6061 and none on its structure and properties and their effects on surface roughness after finish turning. The objective of this comprehensive study is, therefore, to ascertain the effects of both the modern method of hardening AA6061 shafts and the finish turning conditions on surface roughness, Ra, and the minimum machining time for unit-volume removal, T_m, while also establishing the cost price of processing one part, C. The hardening methods improved both the physical and the mechanical material properties processed with 2, 4, and 6 passes of equal channel angular pressing (ECAP) at room temperature, using an ECAP-matrix with a channel angle of 90°. The reference workpiece sample was a hot extruded chip under an extrusion ratio (ER) of 5.2 at an extrusion temperature of 500 °С (ET = 500 °C). The following results were obtained: grain size in ECAP-6 decreased from 15.9 to 2.46 μm, increasing both microhardness from 41 Vickers hardness value (HV) to 110 HV and ultimate tensile strength from 132.4 to 403 MPa. The largest decrease in surface roughness, Ra—70%, was obtained turning a workpiece treated with ECAP-6. The multicriteria optimization was computed in a multilayer perceptron-based artificial neural network that yielded the following optimum values: the minimal length of the three-dimensional estimates vector with the coordinates Ra = 0.800 μm, T_m = 0.341 min/cm³, and С = 6.955 $ corresponded to the optimal finish turning conditions: cutting speed v_c = 200 m/min, depth of cut a_p = 0.2 mm, and feed per revolution f_r = 0.103 mm/rev (ET-500 extrusion without hardening). Full article
