Accurate documentation of the geometry of historical buildings presents a considerable challenge, especially when dealing with complex structures like the Metropolitan Cathedral of Valencia. Advanced technologies such as 3D laser scanning has enabled detailed spatial data capture. Still, efficient handling of this data remains challenging due to the volume and complexity of the information. This study explores the application of clustering techniques employing Machine Learning-based algorithms, such as DBSCAN and K-means, to automate the process of point cloud analysis and modelling, focusing on identifying and extracting floor plans. The proposed methodology includes data geo-referencing, culling points to reduce file size, and automated floor plan extraction through filtering and segmentation. This approach aims to streamline the documentation and modelling of historical buildings and enhance the accuracy of historical architectural surveys, significantly contributing to the preservation of cultural heritage by providing a more efficient and accurate method of data analysis. Full article

The Cathedral of Valencia, Spain, has preserved the so-called Holy Chalice of the Last Supper since 1437. It consists of a foot, a gold stem, and an upper cup carved in agate stone. Based on a pious tradition, this cup is supposed to be the one used by Jesus of Nazareth to institute the Eucharist. According to an archeological study published in 1960, this agate bowl was crafted around the 2nd–1st centuries BC, but people visiting this famous relic often wonder about its authenticity and about the evidence supporting it as a Hellenistic–Roman cup. Attempting to clarify this concern, a photographical characterization of the agate cup is presented and discussed. The main conclusions are the following: (i) The typology of the bowl is common to classical tableware, but the wall thickness, shape of the rim, and foot are typical of gemstone cups from the Hellenistic–Roman period. (ii) This cup would have been extremely valuable, which agrees with the location of the Cenacle in the aristocratic neighborhood of Jerusalem. This case study highlights the importance of further investigating the dating of historical objects as a key issue to support their authenticity. Full article

The Cathedral of Valencia has kept an important relic since 1437: the Holy Chalice of the Last Supper. It consists of an agate cup, a gold stem, and a gemstone foot. According to a pious tradition, this cup is the one used by Jesus of Nazareth to institute the Eucharist. Tourists visiting Valencia Cathedral often doubt its authenticity. There are certain queries that pilgrims wonder about, some of which have not been studied in depth. For example: What is known about the family who owned the chalice? Why would Jesus use a gemstone cup instead of one made of glass, silver, or gold? Aimed at clarifying these concerns, the research methodology was essentially centered on a review of the literature. The main conclusions are the following: (i) The Cenacle belonged to a rich disciple of Jesus, who would have lent him a valuable cup of blessing. Quite likely, it was the family of Saint Mark, who had a close link with Saint Peter. (ii) It is unlikely that Jesus used a cup made of glass because this material was relatively affordable. By contrast, gemstone vessels were highly appreciated. This case study highlights the importance of promoting historic and scientific studies about Christian artworks as a pre-requisite to foster heritage tourism. Full article

This paper presents a methodology for using geospatial tools to enact efficient tourism planning and management in streets and other public spaces in historic centres. The study uses 3D laser scanning, GIS, and spatial data processing techniques to analyse the visitor carrying capacity of streets near cultural attractions. The methodology was tested on Miguelete Street in València (Spain), next to the Cathedral. The results show that these digital tools are efficient and accurate for the spatial analysis of visitor carrying capacity studies. Full article

A workflow for the photogrammetric combination of non-invasive multispectral imaging techniques ranging from ultraviolet (UV) and visible (VIS) to near infrared (NIR) for the investigation of wall paintings is presented. Hereby, different methods for image analysis and visualisation techniques are discussed. This includes the combination of spectral bands in hybrid false-colour images and image analysis by applying NDVI/NDPI and PCA. The aim of the research is to generate a high-resolution photogrammetric image set, providing information on underdrawings, material differences, damages, painting techniques and conservation measures. The image data are superimposed with pixel accuracy in a geographic information system (GIS) for further analysis, tracing of observations and findings and the annotation of further information. The research is carried out on the ‘Adoration of the Shepherds’, an early Spanish Renaissance wall painting created in 1472 by Paolo de San Leocadio and Francesco Pagano in the Cathedral of Valencia. The wall painting is preserved in an unfinished condition, and half of it is represented by the initial plaster and preparation layers. This gives the possibility to compare and evaluate the observations of the finished areas as well as carry out an in-depth study of the working techniques. Full article

This work studies the iconography of Vicent Macip’s altarpiece dedicated to Saint Dionysius and Saint Margaret, which is found in the Cathedral of València. The main subject of the altarpiece is the presence of the Virgin Mary in salvation history. Iconographic categories have been described according to their possible relationship to the descriptions that appear in Francesc Eiximenis’s Vida de Jesucrist [Life of Jesus Christ, in Catalan] (Hereafter, this text will be referred to as VCE). or Isabel de Villena’s Vita Christi [Life of Christ, in Latin] (Hereafter, this text will be referred to as VCV), which are important works of 15th-century Valencian literature in the Catalan language that were read during the time the altarpiece was finished. Full article

The Door of the Apostles at the Cathedral of Valencia stands as a treasure of sacred Gothic architecture and sculpture. A modification to its original structure in 1599 removed the mullion and the stone image of the Virgin that is to be found today in the tympanum. However, regardless of her location, Mary Mater Dei presided over everything that was happening in the doorway. She guided those who crossed the temple’s threshold, placed as she was on the mullion so as to appear as a Porta Coeli. In addition, she was the conductor of the characters on the door such as apostles, prophets, patriarchs, virgins and angelic sonadors (sound-makers). The latter appeared playing various instruments from both profane and sacred medieval traditions. Their location in the tympanum, playing a role in the meaning of the message, showed the importance of music as a vehicle for conveying the revelation of the Incarnation of Christ. Full article

The baroque church of Saint Thomas and Saint Philip Neri (Valencia, Spain), which was built between 1727 and 1736, contains valuable paintings by renowned Spanish artists. Due to the considerable height of the central nave, the church can experience vertical temperature gradients. In order to investigate this issue, temperatures were recorded between August 2017 and February 2018 from a wireless monitoring system composed of 21 sensor nodes, which were located at different heights in the church from 2 to 13 m from the floor level. For characterizing the temperature at high, medium and low altitude heights, a novel methodology is proposed based on sparse Partial Least Squares regression (sPLS), Linear Discriminant Analysis (LDA), and the Holt-Winters method, among others, which were applied to a time series of temperature. This approach is helpful to discriminate temperature profiles according to sensor height. Once the vertical thermal gradients for each month were characterized, it was found that temperature reached the maximum correlation with sensor height in the period between August 10th and September 9th. Furthermore, the most important features from the time series that explain this correlation are the mean temperature and the mean of moving range. In the period mentioned, the vertical thermal gradient was estimated to be about 0.043 ${}^{\circ }$C/m, which implies a difference of 0.47 ${}^{\circ }$C on average between sensor nodes at 2 m from the floor with respect to the upper ones located at 13 m from the floor level. The gradient was estimated as the slope from a linear regression model using height and hourly mean temperature as the predictor and response, respectively. This gradient is consistent with similar reported studies. The fact that such gradient was only found in one month suggests that the mechanisms of dust deposition on walls involved in vertical thermal gradients are not important in this case regarding the preventive conservation of artworks. Furthermore, the methodology proposed here was useful to discriminate the time series at high, medium and low altitude levels. This approach can be useful when a set of sensors is installed for microclimate monitoring in churches, cathedrals, and other historical buildings, at different levels and positions. Full article

The famous Renaissance frescoes in Valencia’s Cathedral (Spain) have been kept under confined temperature and relative humidity (RH) conditions for about 300 years, until the removal of the baroque vault covering them in 2006. In the interest of longer-term preservation and in order to maintain these frescoes in good condition, a unique monitoring system was implemented to record both air temperature and RH. Sensors were installed at different points at the vault of the apse during the restoration process. The present study proposes a statistical methodology for analyzing a subset of RH data recorded by the sensors in 2008 and 2010. This methodology is based on fitting different functions and models to the time series, in order to classify the different sensors.The methodology proposed, computes classification variables and applies a discriminant technique to them. The classification variables correspond to estimates of model parameters of and features such as mean and maximum, among others. These features are computed using values of functions such as spectral density, sample autocorrelation (sample ACF), sample partial autocorrelation (sample PACF), and moving range (MR). The classification variables computed were structured as a matrix. Next, sparse partial least squares discriminant analysis (sPLS-DA) was applied in order to discriminate sensors according to their position in the vault. It was found that the classification of sensors derived from Seasonal ARIMA-TGARCH showed the best performance (i.e., lowest classification error rate). Based on these results, the methodology applied here could be useful for characterizing the differences in RH, measured at different positions in a historical building. Full article

The present publication collects the communications presented in the IV Workshop of the Spanish National Network on Mycotoxins and Toxigenic Fungi and their Decontamination Processes (MICOFOOD), held in the School of Pharmacy and Nutrition of the Universidad de Navarra (Pamplona, Spain) from the 29 to the 31 May 2019. More than 70 professionals from academia, the industry and public services have participated. The scientific program included: five sessions: sponsors (presentation and services), toxigenic fungi, toxicology, analysis and control, and reduction and prevention strategies. In total, 18 oral communications and 24 posters were presented. It is worth mentioning the high participation and quality of the communications from PhD students. The invited conference, entitled: “Mycotoxins within the framework of exposure assessment: past present and future”, was given by Dr. Barbara de Santis (Istituto Superiore di Sanità, Rome, Italy). The meeting ended with the roundtable: “From feed to fork: safe food without mycotoxins”, where representatives of feed and agrofood companies and public administrations discussed about the current situation and problems related with mycotoxins. Different prizes were awarded for the best oral presentation (Effect of Staphylococcus xylosus on the growth of toxigenic moulds in meat substrates, by E. Cebrian et al., University of Extremadura), and the best posters (Combined toxicity of aflatoxins and ochratoxin A: A systematic review by M. Alonso-Jaúregui et al., Universidad de Navarra; and Application of natamycin in products affected by toxigenic fungi by Torrijos et al., Universitat de València). The participants had the opportunity to learn about the history and gastronomy of Pamplona. Situated in the north of Spain, Pamplona is a city of Roman origin featuring a large gothic cathedral complex and a Vauban citadel of the 16th century. Full article

Studies on the effect of occupational noise have been widely performed for occupations such as construction workers, workers of factories or even musicians and workers of nightclubs. However, studies on the acoustics of church bells are very scarce and usually reported in languages other than English. In Spain, although the tradition of bell ringers is progressively getting lost, some bell ringers that continue transmitting the tradition remain. Church bells create sound with a large sound pressure level that can be heard from a great distance. However, despite the characteristics of the sound of church bells, bell ringers do not present symptoms of occupational hearing loss unlike musicians and construction workers. To determine the effects of the sound of the church bells on bell ringers, in this paper, an acoustic study of the church bells and a physiological study of the hearing abilities of bell ringers. Results show sound pressure levels reaching 120 dB inside the bell tower. The resulting hearing loss in bell ringers is small considering the great intensity of the sound produced by the bells. This is likely due to the short amount of time that bell ringers are exposed to the sound even if it reaches high sound pressure levels. Full article

A typo has been found in our paper [1]. It is stated on page 8698 that the range of acceptable temperature for the conservation of frescoes is 6–25 °C while in the case of RH, this range is 45%–60%, according to the Italian Standard UNI 10829 (1999). These recommended ranges of temperature (6–25 °C) and RH (45%–60%) correspond to the Standard DM 10/2001 [2], not to UNI 10829. The authors would like to apologize for any inconvenience this may have caused to the readers of this journal. [...] Full article

Cultural Heritage preventive conservation requires the monitoring of the parameters involved in the process of deterioration of artworks. Thus, both long-term monitoring of the environmental parameters as well as further analysis of the recorded data are necessary. The long-term monitoring at frequencies higher than 1 data point/day generates large volumes of data that are difficult to store, manage and analyze. This paper presents software which uses a free open source database engine that allows managing and interacting with huge amounts of data from environmental monitoring of cultural heritage sites. It is of simple operation and offers multiple capabilities, such as detection of anomalous data, inquiries, graph plotting and mean trajectories. It is also possible to export the data to a spreadsheet for analyses with more advanced statistical methods (principal component analysis, ANOVA, linear regression, etc.). This paper also deals with a practical application developed for the Renaissance frescoes of the Cathedral of Valencia. The results suggest infiltration of rainwater in the vault and weekly relative humidity changes related with the religious service schedules. Full article

Non-destructive methods are of great interest for the analysis of cultural heritage. Among the different possible techniques, this paper presents a low cost prototype based on the emission and reception of airborne ultrasound without direct contact with the test specimen. We successfully performed a method test for the detection of brick joints under a XVth century Renaissance fresco of the Metropolitan Cathedral of the city of Valencia (Spain). Both laboratory and in situ results are in agreement. Using this prototype system, an early moisture detection system has been installed in the dome that supports the fresco. The result is encouraging and opens interesting prospects for future research. Full article

We describe the performance of a microclimate monitoring system that was implemented for the preventive conservation of the Renaissance frescoes in the apse vault of the Cathedral of Valencia, that were restored in 2006. This system comprises 29 relative humidity (RH) and temperature sensors: 10 of them inserted into the plaster layer supporting the fresco paintings, 10 sensors in the walls close to the frescoes and nine sensors measuring the indoor microclimate at different points of the vault. Principal component analysis was applied to RH data recorded in 2007. The analysis was repeated with data collected in 2008 and 2010. The resulting loading plots revealed that the similarities and dissimilarities among sensors were approximately maintained along the three years. A physical interpretation was provided for the first and second principal components. Interestingly, sensors recording the highest RH values correspond to zones where humidity problems are causing formation of efflorescence. Recorded data of RH and temperature are discussed according to Italian Standard UNI 10829 (1999). Full article
