L-shaped steel-reinforced concrete (SRC) columns are commonly used as edge and corner members in bridge piers and high-rise buildings. However, systematic experimental evidence on their dynamic behavior and detailing effects under lateral impact remains limited. This study presents a parametric drop-weight impact program on seven SRC columns with built-in L-shaped steel sections. The effects of impact velocity (v), axial compression ratio (n = 0–0.2), and stirrup spacing in the non-densified region (s = 100–200 mm) were examined in terms of damage evolution, impact-response indices (Fmax, Fave, Δmax, Δres, T), and energy absorption efficiency (η = E_ab/E). The results show that impact velocity was the dominant parameter governing both response amplitude and damage severity. Increasing v from 7.67 to 9.90 m/s increased Δmax and Δres by 92.6% and 144.3%, respectively, while η increased from 60.7% to 74.6%. Within the investigated range, axial compression improved resistance and suppressed residual deformation. As n increased from 0 to 0.2, Fmax and Fave increased by 17.5% and 30.4%, respectively, whereas Δres decreased by 32.1%. The effect of stirrup spacing on η was non-monotonic. The intermediate spacing (s = 150 mm) yielded the highest energy absorption ratio (60.7%) and the most balanced overall response among the tested cases, rather than representing a definitive optimum. No global buckling of the embedded steel section was observed, and all specimens maintained overall structural integrity under high-energy impact. These results provide experimental evidence for the response assessment and preliminary transverse detailing of asymmetric SRC columns under lateral impact. Full article

Reinforced Concrete (RC) barriers are used for different purposes in the highway inventory. An important purpose is the use of concrete barriers to act as railing that protects bridge piers against vehicular collision force (VCF). Therefore, these barriers are designed to absorb the collision energy and/or redirect the vehicle away from the parts being protected. Accurate estimation of the capacity of RC barriers during crash events is an important consideration in their design and placement. The American Association of State Highway and Transportation Officials (AASHTO) considers yield line analysis (YLA) with the V-shape failure pattern to predict the barrier capacity. AASHTO’s analysis method involves some assumptions that are intended to simplify the analysis process. Some of these assumptions have been shown to underestimate the actual barrier capacity and might disqualify many existing RC barriers from acting as intervening structures due to structural inadequacy. Many researchers have proposed alternative failure patterns and methodologies in an attempt to better predict the capacity of RC barriers. This research shows that AASHTO’s YLA, with the current V-shape failure pattern, can be improved and still predict the barrier capacity when some of the simplifying assumptions are eliminated. Also, the research presents an alternative innovative truss analogy model to predict the capacity of RC barriers. The results of the improved YLA and the proposed truss model are validated by finite element analysis (FEA) using Abaqus. The results of this research will help structural engineers in the highway industry to initially design new barriers for the intended capacity as well as estimate the capacity of existing ones. Full article

Steel–concrete composite girder rigid frame bridges with V-shaped piers are a new type of bridge structure. Based on the traditional composite continuous beam bridge, part or all of the vertical piers are changed into V-shaped piers. This special structure makes them have the mechanical characteristics of both composite continuous beams and V-shaped piers. In this paper, the finite element model of the first steel–concrete composite continuous beam V-pier rigid frame bridge in China is established by simulation software, the construction process of the bridge is simulated, and the stress and deflection of the bridge in each construction stage are studied. At the same time, the stress of the completed bridge model considering the construction stage is compared with that of the completed bridge model without considering the construction stage. It is found that the stress difference between the two concrete slabs is as high as 2.7 MPa. The results show that the stress state of the bridge is greatly affected by the construction process. This study can provide guidance for the design and construction of such bridges, which is of great significance. Full article

The concrete piers in steep mountain areas are highly susceptible to damage disasters due to the impact of debris avalanches, which pose a serious threat to the safe operation of bridge structures. In order to investigate the impact load characteristics of debris avalanches on bridge pier structures in V-shaped valley mountain areas, Particle Flow Code 3D (PFC^3D) models based on a discrete element method were applied in this study to establish a full-scale three-dimensional model of a debris avalanche in a V-shaped valley. By installing double-column piers in the influence zone of the debris avalanche, the impact force, accumulation morphology, motion characteristics of debris particles, internal force response of the double-column piers, and impact energy indicators were investigated. In addition, parameters such as the layout position of the piers and the impact angle of the debris were studied. The results showed that the particles at the front edge of the debris avalanche have a significant impact on the magnitude and distribution of the impact force on the piers. It is important to consider the layout position of the piers and the impact angle of the debris when designing bridge pier structures in high, steep mountain areas. There was a significant difference in the movement patterns between the particles at the front and rear edges of the landslide. The particles at the front edge had a higher velocity and stronger impact, while the particles at the rear edge had a slower velocity and were more likely to be obstructed by bridge piers, leading to accumulation. The obstruction effect of the piers on the debris particles was closely related to their positioning and the impact angle. Piers that were closer to the center of the valley and had a larger impact angle have a more significant obstruction effect, and the topography of the valley had a significant focusing effect on the debris avalanche, resulting in a greater impact force and energy on the piers located closer to the center of the valley. The impact force amplitude and duration of landslide debris on bridge piers showed a significant difference between the bottom and upper piers, as well as between the piers on the upstream and downstream sides. These research findings can provide valuable references for the design and disaster assessment of bridge piers for impact prevention in steep slopes and mountainous areas with deep ravines. Full article

As the standards of bridge design and construction continue to improve, more and more combination bridges are being put into use. The public’s demand for aesthetically pleasing bridges is also increasing, making it necessary to use the special structure of steel–concrete combinations, continuous V-shaped piers, and continuously stiffened bridges. This structure has the structural and mechanical characteristics of both a continuous girder and a V-shaped pier bridge. The span can be reduced to a certain extent because the support of the V-shaped piers can be applied directly to the main girder. The spanning capacity of the bridge is generally greater than that of a combined steel–concrete girder bridge with vertical piers. The whole bridge is continuous, without expansion joints, making it more stable and safe for traffic. At present, research on this structural bridge type is not yet complete. In this paper, the structural system and dynamic characteristics of this bridge are investigated in the context of real-life engineering. Firstly, the self-vibration characteristics of the three structures were analyzed, and their effects on the self-vibration characteristics were studied by varying the height of the crossbeam at the V-shaped piers’ support, the main beam stiffness, and the V-shaped piers’ stiffness in the three structures. The results show that the increase in main beam stiffness can effectively improve the vertical stiffness of the three structures, with the most obvious effect on structure one and the least effect on structure two; the increase in V-shaped pier stiffness causes a huge improvement in the transverse stiffness of the three structures. Subsequently, a two-unit rod system model of the background bridge was established using the finite element method, and the original model was improved by calculating the equivalent shear stiffness of the shear nail group so that it could simulate the shear joints more accurately. The effects of the shear connectors on the self-vibration characteristics of the steel–concrete combined continuous beam–V-shaped piers and continuous rigid-frame bridge were investigated through theoretical analysis and finite element simulation. It was found that due to the existence of flexible shear connectors, the interface between the steel beam and concrete slab in the combined beam has a slippage effect which causes the deformation to become unsynchronized, and there is a certain difference between vibration patterns. The stiffness of the shear connectors has a certain effect on the self-vibration frequency of the bridge. The damage to the local shear connectors does not have a large effect on the self-vibration frequency of the overall structure, but the damage to the shear connectors at the beginning of the connection between the V-shaped piers and the main beam is greater than that of the other areas. Damage to shear joints should be given special consideration in comparison to other areas. Full article

The load-carrying capacity assessment of existing road bridges, is a growing challenge for civil engineers worldwide due to the age and condition of these critical parts of the infrastructure network. The critical loading event for road bridges is the live load; however, in earthquake-prone areas bridges generally require an additional seismic evaluation and often retrofitting in order to meet more stringent design codes. This paper provides a review of state-of-the-art methods for the seismic assessment and retrofitting of existing road bridges which are not covered by current design codes (Eurocode). The implementation of these methods is presented through two case studies in Croatia. The first case study is an example of how seismic assessment and retrofitting proposals should be conducted during a regular inspection. On the other hand, the second case study bridge is an example of an urgent assessment and temporary retrofit after a catastrophic earthquake. Both bridges were built in the 1960s and are located on state highways; the first one is a reinforced concrete bridge constructed monolithically on V-shaped piers, while the second is an older composite girder bridge located in Sisak-Moslavina County. The bridge was severely damaged during recent earthquakes in the county, requiring urgent assessment and subsequent strengthening of the substructure to prevent its collapse. Full article

The article investigates the causes of the Morandi viaduct collapse in Genoa. This three-span viaduct was a part of the A10 motorway leading to Savona. The structure design of the viaduct supports and diagonal stay cables was unique. The viaduct included three cable-stayed system, each supported a three-span continuous beam by two sets of prestressed concrete cables on the two sides of the pylon across the width. The pair of V shapes piers supported upside-down V pylons that supported the top ends of two pairs of diagonal stay cables. The stays were constructed from steel cables with prestressed concrete shells poured on. This article provides information on the technical condition of the viaduct and the way of strengthening the cables in the early 1990s. At that time, the author of the article visited the structure. In August 2018, the viaduct collapse occurred, and one of the structure supports collapsed. In June 2019, during the demolition process, the other two supports were destroyed. Since in Venezuela and Libya there are still two more bridges with a structure similar to that in Italy, the concept of strengthening the structure, as proposed by the author of the article 25 years ago, may still be useful. Full article
