Today, various systems are used to reduce vibrations in civil engineering structures. Among these systems, tuned liquid dampers are the preferred passive systems due to their ability to be designed in different geometries, their low cost, their ease of installation, and their low maintenance costs. This study examines the effectiveness of tuned liquid dampers (TLD) and tuned liquid column dampers (TLCD) under identical geometric conditions and harmonic ground motion to assess which is more efficient in controlling the behavior of a three-storey steel shear frame model equipped with these systems. A small-scale, three-storey shear frame model placed on a uniaxial shaking table was subjected to harmonic motion with a 5 mm amplitude, 1.4 Hz frequency, and 10 cycles. The chosen frequency aligns with the resonance frequency of the undamped building model’s first mode. Both TLD and TLCD tanks, positioned atop the structure, share a geometry of 30 cm in length and 10 cm in width, with variable liquid heights of 5, 10, 15, and 20 cm. Mounting TLD and TLCD models with four different liquid heights on the undamped model resulted in nine distinct setups. In this designed scenario, the TLDs and TLCDs on the undamped shear frame were compared according to liquid heights at rest. To identify the best-performing system based on liquid height, response displacement–frequency graphs were generated for all models within a frequency range of 0.5–2.5 Hz, and damping ratios were calculated using the half-power bandwidth method. Additionally, harmonic ground motion experiments at the resonance frequency compared both acceleration and displacement values over time for damped and undamped models. Peak acceleration and displacement values on each floor were also analyzed. The results highlight which system proves more effective based on damping ratio, acceleration, and displacement values under equivalent conditions. Full article

As buildings become taller and slenderer, managing their vibrational response and mitigating it pose significant challenges in design. Tuned liquid dampers (TLDs) are liquid (usually water)-filled tanks that can mitigate structural vibrations by leveraging the sloshing motion of the contained fluid. However, the dynamic behavior of TLDs and their interaction with structures is complex. While most research on TLDs has focused on mitigating wind-induced vibrations, less attention has been paid to their seismic control of structural responses. Moreover, existing literature on the experimental research involving TLDs mostly pertains to small-scale models. This study aims to experimentally explore the effectiveness of large-scale TLDs in mitigating vibrations in both linear and nonlinear structures under seismic loads. A real-time hybrid simulation is employed as the experimental method, where only the TLD is physically constructed and tested, while the rest of the system is simulated numerically in a coupled manner, allowing for obtaining the dynamic response of the structure equipped with the TLD in real time. This approach offers the flexibility to significantly scale up the TLD size for physical testing while exploring various TLD-structure scenarios by numerically adjusting the structural properties within the simulation. Full article

This research aims to develop an efficient and accurate model for simulating tuned liquid dampers (TLDs) with sloped beds. The model, based on nonlinear shallow water equations, is enhanced by introducing new terms tailored to each specific case. It employs the central upwind method and Minmod limiter functions for flux and interface variable assessment, ensuring both high accuracy and reasonable computational cost. While acceleration, slope, and dissipation are treated as explicit sources, an implicit scheme is utilized for dispersion discretization to enhance the model’s stability, resulting in matrix equations. Time discretization uses the fourth-order Runge–Kutta scheme for precision. The performance of the model has been evaluated using several test cases including dam-breaks on flat and inclined beds and run-up and run-down simulations over parabolic beds, which are relevant to sloshing in tanks with sloped beds. It accurately predicts phenomena such as asymmetric sloshing waves, especially in sloped beds, where pronounced waves occur. Dispersion and dissipation terms are crucial for capturing these effects and maintaining stable wave patterns. An initial perturbation method assesses the tank’s natural period and numerical diffusion. Furthermore, the model integrates with a single-degree-of-freedom (SDOF) system to create a TLD model, demonstrating enhanced damping effects with sloped beds. Full article

The use of tuned liquid dampers (TLDs) as an alternative to reduce the response of flexible structures with a low amount of structural damping is a viable option. The correct characterization of the dynamic properties of the TLD plays an important role in the performance of the TLD-main structure system. This work presents the results of an experimental study to evaluate the dynamic properties of a scaled rectangular TLD using high-speed videos. For the experimental investigation, a scaled rectangular TLD is subjected to lateral displacement of the sinusoidal type with amplitudes that range from 5 to 40 mm and frequency equal to 0.625 Hz. The dynamic properties of the TLD system are identified with the use of high-speed videos with a duration of 28.96 s and recorded at 500 frames per second (fps). The recorded videos are analyzed with the software Tracker to extract time histories of wave elevation at predefined locations. The frequency and damping of the TLD system are identified from the time histories of wave elevation through Fourier analysis and free-vibration decay. The findings of this study revealed that the identified dynamic properties of the TLD by using high-speed videos presented small differences with respect to the target values, with errors that range from 0.93 to 2.9% for frequency and from 1.6 to 8.8% for damping, indicating that the use of high-speed videos can be an alternative to evaluate the dynamic properties of TLD systems. Full article

Integrating existing liquid storage and supply tanks in buildings with tuned liquid dampers (TLDs) are significant for reducing the effective cost of TLDs. However, existing water supplement devices for fire-suppression liquid tanks may overfill with water, which leads to TLD mistuning. To overcome this problem, a passive liquid control system named TLD with a stable replenishment sub-tank system (TLD-SRS) is proposed. The system, which consists of an additional sub-tank connected to the main tank and a floating ball, replenishes liquid in the TLD automatically. The system can avoid vibration interference and maintain the normal operation of the passive replenishment system under usual wind loads. According to the studies of tuned liquid column dampers (TLCD), the proposed TLD with a stable replenishment sub-tank system (TLD-SRS) uses simple devices to ensure that the liquid level in the TLD is steady at the target liquid level with a floating ball. The TLD-SRS is verified on a large-scale TLD shaking table experiment. The overshoot, which is the percentage of liquid that exceeds the target volume of TLD is calculated during sloshing with wind loads. Compared with TLD installed with a regular liquid replenishment device, the proposed TLD-SRS significantly reduces the overshoot of liquid and acceleration on the roof of the building. Full article

The slender structure is prone to be affected by horizontal force; therefore, the seismic performance needs to be considered carefully. Meanwhile, due to the low cost and good performance on the seismic resistance of the Tuned liquid dampers (TLDs) system, it has been widely used for vibration control. Regarding the abovementioned background, in this study, we conduct the experiment to investigate the seismic performance of the slender structure with the integral water tank, and two designed parameters (the placement location and the water level of the water tank) are studied. The experimental phenomenon and the structural accelerations are recorded to be analyzed further and discussed, then a useful design guide for an integral water tank is summarized. Finally, some practical and helpful advice and conclusions are put forward for the design of the water tank that is used for the purpose of seismic resistance in the slender structure. Our research can fill the blank in the research on the integral water tank of TLDs system, which also has good potential to achieve the enhancement of slender structure seismic performance. Full article

In order to make full use of the advantages of PD (particle damper) and TLD (tuned liquid damper) technologies, a new kind of damping system combining these two already-existing dampers is proposed and was named as PDAL (tuned particle damper with additional liquid). A shaking table test of a steel frame structure with a PDAL system is conducted here for the purpose of vibration control analysis. The results of the test demonstrate well the reliability and effectiveness of the PDAL system under various seismic waves. Seismic responses (mainly acceleration value) are investigated thoroughly for parameter analysis based on the experimental data, and some suggestions are proposed for future designs, including the necessity for parameter optimization and awareness of the dynamic characteristic changes that might occur in actual structures if attached with a PDAL system. This paper constitutes a preliminary study for the PDAL system, and it can serve as a baseline and conceptual reference for future investigations. Full article

Liquid dampers, such as tuned liquid dampers (TLDs), are employed to improve serviceability by reducing wind-affected building vibrations. In order to maximize the vibration suppression efficiency of the liquid damper, the tuning frequency of the liquid damper should match the natural frequency of the building. Experimental evaluation of the tuning frequency of a liquid damper performed in a factory prior to installation in a building is a critical task to ensure correct performance, and for this, multipoint measurement of the TLD is required. In this study, a novel liquid level measurement system combining Laser Doppler Vibrometer (LDV) and a stepwise rotating galvanometer scanner was developed to observe liquid sloshing in TLD. The proposed system can measure the liquid level at multiple points simultaneously with a single laser point. In the experimental phase, the liquid damper’s natural frequency and mode shape are experimentally evaluated utilizing the developed system. The performance of the proposed system was verified by comparison with the video sensing system. Full article
