Onboard hydrogen storage tanks are currently fitted with thermally activated pressure relief devices (TPRDs), enabling hydrogen to blowdown in the event of fire. For release diameters below the critical diameter, the flame from the TPRD may blow-out during a pressure drop. Flame blow-outs pose a safety concern for an indoor or covered environment, e.g., a garage or carpark, where hydrogen can accumulate and deflagrate. This study describes the application of a validated computational fluid dynamics (CFD) model to simulate the dynamic flame behaviour from a TPRD designed to exclude its blow-out. The dynamic behaviour replicates a real scenario. Flame behaviour during tank blowdown through two TPRDs with different nozzle geometries is presented. Simulations confirm flame blow-out for a single-diameter TPRD of 0.5 mm during tank blowdown, while the double-diameter nozzle successfully excludes flame blow-out. The pressure at which the flame blow-out process is initiated during blowdown through a single-diameter nozzle was predicted. Full article

The widespread use of fossil fuels in automobiles has become a concern, particularly in light of recent frequent natural disasters, prompting a shift towards eco-friendly vehicles to mitigate greenhouse gas emissions. This shift is evident in the rapidly increasing registration rates of hydrogen vehicles. However, with the growing presence of hydrogen vehicles on roads, a corresponding rise in related accidents is anticipated, posing new challenges for first responders. In this study, computational fluid dynamics analysis was performed to develop effective response strategies for first responders dealing with high-pressure hydrogen gas leaks in vehicle accidents. The analysis revealed that in the absence of blower intervention, a vapor cloud explosion from leaked hydrogen gas could generate overpressure exceeding 13.8 kPa, potentially causing direct harm to first responders. In the event of a hydrogen vehicle accident requiring urgent rescue activities, the appropriate response strategy must be selected. The use of blowers can aid in developing a variety of strategies by reducing the risk of a vapor cloud explosion. Consequently, this study offers a tailored response strategy for first responders in hydrogen vehicle leak scenarios, emphasizing the importance of situational assessment at the incident site. Full article

Accidental release from a hydrogen car tank in a confined space like a tunnel poses safety concerns. This Computational Fluid Dynamics (CFD) study focuses on the first seconds of such a release, which are the most critical. Hydrogen leaks through a Thermal Pressure Relief Device (TPRD), forms a high-speed jet that impinges on the street, spreads horizontally, recirculates under the chassis and fills the area below it in about one second. The “fresh-air entrainment effect” at the back of the car changes the concentrations under the chassis and results in the creation of two “tongues” of hydrogen at the rear corners of the car. Two other tongues are formed near the front sides of the vehicle. In general, after a few seconds, hydrogen starts moving upwards around the car mainly in the form of buoyant blister-like structures. The average hydrogen volume concentrations below the car have a maximum of 71%, which occurs at 2 s. The largest “equivalent stoichiometric flammable gas cloud size Q9” is 20.2 m³ at 2.7 s. Smaller TPRDs result in smaller hydrogen flow rates and smaller buoyant structures that are closer to the car. The investigation of the hydrogen dispersion during the initial stages of the leak and the identification of the physical phenomena that occur can be useful for the design of experiments, for the determination of the TPRD characteristics, for potential safety measures and for understanding the further distribution of the hydrogen cloud in the tunnel. Full article

With an increase in the use of eco-friendly vehicles such as hybrid, electric, and hydrogen vehicles in response to the global climate crisis, accidents related to these vehicles have also increased. Numerical analysis was performed to optimize the safety of first responders responding to hydrogen vehicle accidents wherein hydrogen jet flames occur. The influence range of the jet flame generated through a 1.8-mm-diameter nozzle was analyzed based on five discharge angles (90, 75, 60, 45, and 30°) between the road surface and the downward vertical. As the discharge angle decreases toward the road surface, the risk area that could cause damage moves from the center of the vehicle to the rear; at a discharge angle of 90°, the range above 9.5 kW/m² was 1.59 m and 4.09 m to the front and rear of the vehicle, respectively. However, at a discharge angle of 30°, it was not generated at the front but was 10.39 m to the rear. In response to a hydrogen vehicle accident, first responders should perform rescue activities approaching from a diagonal direction to the vehicle front to minimize injury risk. This study can be used in future hydrogen vehicle design to develop the response strategy of the first responders. Full article

This study presents a methodology of a quantitative risk assessment for the scenario of an onboard hydrogen storage tank rupture and tunnel fire incident. The application of the methodology is demonstrated on a road tunnel. The consequence analysis is carried out for the rupture of a 70 MPa, 62.4-litre hydrogen storage tank in a fire, that has a thermally activated pressure relief device (TPRD) failed or blocked during an incident. Scenarios with two states of charge (SoC) of the tank, i.e., SoC = 99% and SoC = 59%, are investigated. The risks in terms of fatalities per vehicle per year and the cost per incident are assessed. It is found that for the reduction in the risk with the hydrogen-powered vehicle in a road tunnel fire incident to the acceptable level of 10⁻⁵ fatality/vehicle/year, the fire-resistance rating (FRR) of the hydrogen storage tank should exceed 84 min. The FRR increase to this level reduces the societal risk to an acceptable level. The increase in the FRR to 91 min reduces the risk in terms of the cost of the incident to GBP 300, following the threshold cost of minor injury published by the UK Health and Safety Executive. The Frequency–Number (F–N) of the fatalities curve is developed to demonstrate the effect of mitigation measures on the risk reduction to socially acceptable levels. The performed sensitivity study confirms that with the broad range of input parameters, including the fire brigade response time, the risk of rupture of standard hydrogen tank-TPRD systems inside the road tunnel is unacceptable. One of the solutions enabling an inherently safer use of hydrogen-powered vehicles in tunnels is the implementation of breakthrough safety technology—the explosion free in a fire self-venting (TPRD-less) tanks. Full article

An under-expanded hydrogen jet from high-pressure equipment or storage tank is a potential incident scenario. Experiments demonstrated that the delayed ignition of a highly turbulent under-expanded hydrogen jet generates a blast wave able to harm people and damage property. There is a need for engineering tools to predict the pressure effects during such incidents to define hazard distances. The similitude analysis is applied to build a correlation using available experimental data. The dimensionless blast wave overpressure generated by delayed ignition and the follow-up deflagration or detonation of hydrogen jets at an any location from the jet, $∆P_{exp}/P_0$, is correlated to the original dimensionless parameter composed of the product of the dimensionless ratio of storage pressure to atmospheric pressure, $P_s/P_0$, and the ratio of the jet release nozzle diameter to the distance from the centre of location of the fast-burning near-stoichiometric mixture on the jet axis (30% of hydrogen in the air by volume) to the location of a target (personnel or property), $d/R_w$. The correlation is built using the analysis of 78 experiments regarding this phenomenon in the wide range of hydrogen storage pressure of 0.5–65.0 MPa and release diameter of 0.5–52.5 mm. The correlation is applicable to hydrogen free jets at ambient and cryogenic temperatures. It is found that the generated blast wave decays inversely proportional to the square of the distance from the fast-burning portion of the jet. The correlation is used to calculate the hazard distances by harm thresholds for five typical hydrogen applications. It is observed that in the case of a vehicle with onboard storage tank at pressure 70 MPa, the “no-harm” distance for humans reduces from 10.5 m to 2.6 m when a thermally activated pressure relief device (TPRD) diameter decreases from 2 mm to a diameter of 0.5 mm. Full article

Hydrogen jet fires from a thermally activated pressure relief device (TPRD) on onboard storage are considered for a vehicle in a naturally ventilated covered car park. Computational Fluid Dynamics was used to predict behaviour of ignited releases from a 70 MPa tank into a naturally ventilated covered car park. Releases through TPRD diameters 3.34, 2 and 0.5 mm were studied to understand effect on hazard distances from the vehicle. A vertical release, and downward releases at 0°, 30° and 45° for TPRD diameters 2 and 0.5 mm were considered, accounting for tank blowdown. direction of a downward release was found to significantly contribute to decrease of temperature in a hot cloud under the ceiling. Whilst the ceiling is reached by a jet exceeding 300 °C for a release through a TPRD of 2 mm for inclinations of either 0°, 30° or 45°, an ignited release through a TPRD of 0.5 mm and angle of 45° did not produce a cloud with a temperature above 300 °C at the ceiling during blowdown. The research findings, specifically regarding the extent of the cloud of hot gasses, have implications for the design of mechanical ventilation systems. Full article

It is significant to assess the hydrogen safety of fuel cell vehicles (FCVs) in parking garages with a rapidly increased number of FCVs. In the present work, a Flame Acceleration Simulator (FLACS), a computational fluid dynamics (CFD) module using finite element calculation, was utilized to predict the dispersion process of flammable hydrogen clouds, which was performed by hydrogen leakage from a fuel cell vehicle in an outdoor parking garage. The effect of leakage diameter (2 mm, 3 mm, and 4 mm) and parking configurations (vertical and parallel parking) on the formation of flammable clouds with a range of 4–75% by volume was considered. The emission was assumed to be directed downwards from a Thermally Activated Pressure Relief Device (TPRD) of a 70 MPa storage tank. The results show that the 0.7 m parking space stipulated by the current regulations is less than the safety space of fuel cell vehicles. Compared with a vertical parking configuration, it is safer to park FCVs in parallel. It was also shown that release through a large TPRD orifice should be avoided, as the proportion of the larger hydrogen concentration in the whole flammable domain is prone to more accidental severe consequences, such as overpressure. Full article

This paper presents a series of experiments on the effectiveness of existing mechanical ventilation systems during accidental hydrogen releases in confined spaces, such as underground garages. The purpose was to find the mass flow rate limit, hence the TPRD diameter limit, that will not require a change in the ventilation system. The experiments were performed in a 40 ft ISO container in Norway, and hydrogen gas was used in all experiments. The forced ventilation system was installed with a standard 315 mm diameter outlet. The ventilation parameters during the investigation were British Standard with 10 ACH and British Standard with 6 ACH. The hydrogen releases were obtained through 0.5 mm and 1 mm nozzles from different hydrogen reservoir pressures. Both types of mass flow, constant and blowdown, were included in the experimental matrix. The analysis of the hydrogen concentration of the created hydrogen cloud in the container shows the influence of the forced ventilation on hydrogen releases, together with TPRD diameter and reservoir pressure. The generated experimental data will be used to validate a CFD model in the next step. Full article
