Search Results (28)

To address the adaptability and insufficient imaging quality of conventional in-pipe imaging techniques for irregular pipelines or unstructured scenes, this study proposes a novel radial rotating full-depth-of-field focusing imaging system designed to adapt to the structural complexities of irregular pipelines, which can effectively acquire tiny details with a depth of 300–960 mm inside the pipeline. Firstly, a fast full-depth-of-field imaging method driven by depth features is proposed. Secondly, a full-depth rotating imaging apparatus is developed, incorporating a zoom camera, a miniature servo rotation mechanism, and a control system, enabling 360° multi-view angles and full-depth-of-field focusing imaging. Finally, full-depth-of-field focusing imaging experiments are carried out for pipelines with depth-varying characteristics. The results demonstrate that the imaging device can acquire depth data of the pipeline interior and rapidly obtain high-definition characterization sequence images of the inner pipeline wall. In the depth-of-field segmentation with multiple view angles, the clarity of the fused image is improved by 75.3% relative to a single frame, and the SNR and PSNR reach 6.9 dB and 26.3 dB, respectively. Compared to existing pipeline closed-circuit television (CCTV) and other in-pipeline imaging techniques, the developed rotating imaging system exhibits high integration, faster imaging capabilities, and adaptive capacity. This system provides an adaptive imaging solution for detecting defects on the inner surfaces of irregular pipelines, offering significant potential for practical applications in pipeline inspection and maintenance. Full article

Software-defined radio (SDR) has high flexibility and low cost. It conforms to the miniaturization, lightweight, and digitization trends in through-wall radar systems. Stepped frequency continuous waveform (SFCW) is commonly used in through-wall radar, which has high resolution and strong anti-interference ability. This article develops an SFCW through-wall radar system based on a dual-channel SDR platform. Without changing hardware structure and complicated accessories, a phase compensation method of solving the phase incoherence problem in a low-cost dual-channel SDR platform is proposed. In addition, this article proposes a wall clutter mitigation approach by means of singular value decomposition (SVD) and principal component analysis (PCA) framework for through-wall applications. This approach can process the wall clutter and noise efficiently, and then extract the target subspace to obtain location information. The experimental results indicate that the proposed windowing-based SVD-PCA approach is effective for the developed radar system, which can ensure the accuracy of through-wall detection. It is also superior to the traditional methods in terms of the image quality of range profiles or signal-to-noise ratio (SNR). Full article

The incorporation of reinforcing fillers into natural rubber latex (NR) to achieve superior elasticity and mechanical properties has been widely applied across various fields. However, the tendency of reinforcing fillers to agglomerate within NR limits their potential applications. In this study, multi-walled carbon nanotube (MWCNT)–silica (SiO₂)/NR composites were prepared using a solution blending method, aiming to enhance the performance of NR composites through the synergistic effects of dual-component fillers. The mechanical properties, dispersion behavior, and Payne effect of three types of composites—SiO₂/NR (SNR), MWCNT/NR (MNR), and MWCNT-SiO₂/NR (MSNR)—were investigated. In addition, the mean square displacement (MSD), fractional free volume (FFV), and binding energy of the three composites were simulated using molecular dynamics (MD) models. The results showed that the addition of a two-component filler increased the tensile strength, elongation at break, and Young’s modulus of NR composites by 56.4%, 72.41%, and 34.44%, respectively. The Payne effect of MSNR was reduced by 4.5% compared to MNR and SNR. In addition, the MD simulation results showed that the MSD and FFV of MSNR were reduced by 21% and 17.44%, respectively, and the binding energy was increased by 69 times, which was in agreement with the experimental results. The underlying mechanisms between the dual-component fillers were elucidated through dynamic mechanical analysis (DMA), a rubber process analyzer (RPA), and field emission scanning electron microscopy (SEM). This study provides an effective reference for broadening the application fields of NR. Full article

Time-of-Flight Diffraction (TOFD) is a method of ultrasonic testing (UT) that is widely established as a non-destructive technique (NDT) mainly used for the inspection of welds. In contrast to other established UT techniques, TOFD is capable of identifying discontinuities regardless of their orientation. This paper proposes a redesign of the typical TOFD transducers, featuring an innovative curved sole aimed at enhancing their defect detection capabilities. This design is particularly beneficial for thick-walled samples, as it allows for deeper inspections without compromising the resolution near the surface area. During this research, an evaluation consisting in simulations of the ultrasonic beam distribution and experimental tests on a component with artificially manufactured defects at varying depths has been performed to validate the new design. The results demonstrate a 30 to 50% higher beam distribution area as well as an improvement in the signal-to-noise ratio (SNR) resulting in a 24% enhancement in the capability of defect detection compared to the traditional approach. Full article

The microscopic observation of lung tissue is challenging due to its fragile nature. Xylene and isopropanol are common tissue-clearing reagents used before paraffin embedding, yet no studies have compared these two reagents in lung tissue processing. Due to the well-known health risks xylene could introduce to operators, as well as its environmental hazards, it has long been desired that a less harmful alternative to xylene with the same staining effects be introduced. Thus, we systematically assessed the efficacy of isopropanol as a substitution for xylene. Lung tissue obtained from diseased donors and explanted lungs from recipients were processed simultaneously using either xylene or isopropanol prior to paraffin embedding. Scoring of the overall staining quality after H&E staining, along with the ease of sectioning, was compared systematically. Fluorescent staining was performed to explore alveolar morphology and the overall lectin fluorescence signal between groups. To understand differences in antibody staining, the signal-to-noise ratio (SNR) of smooth muscle actin (SMA) and elastin was examined. No difference was observed with regard to ease of sectioning, staining quality, alveolar circularity, alveolar wall thickness or the SNR between slides processed with xylene or isopropanol. This study demonstrated comparable outcomes of isopropanol and xylene in lung tissue processing, suggesting isopropanol as a more favorable, operator- and environment-friendly substitute for xylene with regards to tissue processing. Full article

Advancements in brain–machine interfaces and neurological treatments urgently require the development of improved brain electrodes applied for long-term implantation, where traditional and polymer options face challenges like size, tissue damage, and signal quality. Carbon nanotubes are emerging as a promising alternative, combining excellent electronic properties and biocompatibility, which ensure better neuron coupling and stable signal acquisition. In this study, a new flexible brain electrode array based on 99.99% purity of single-walled carbon nanotubes (SWCNTs) was developed, which has 30 um × 40 um size, about 5.1 kΩ impedance, and 14.01 dB signal-to-noise ratio (SNR). The long-term implantation experiment in vivo in mice shows the proposed brain electrode can maintain stable LFP signal acquisition over 12 weeks while still achieving an SNR of 3.52 dB. The histological analysis results show that SWCNT-based brain electrodes induced minimal tissue damage and showed significantly reduced glial cell responses compared to platinum wire electrodes. Long-term stability comes from SWCNT’s biocompatibility and chemical inertness, the electrode’s flexible and fine structure. Furthermore, the new brain electrode array can function effectively during 7-Tesla magnetic resonance imaging, enabling the collection of local field potential and even epileptic discharges during the magnetic scan. This study provides a comprehensive study of carbon nanotubes as invasive brain electrodes, providing a new path to address the challenge of long-term brain electrode implantation. Full article

This paper proposes a non-contact continuous respiration monitoring method based on Fringe Projection Profilometry (FPP). This method aims to overcome the limitations of traditional intrusive techniques by providing continuous monitoring without interfering with normal breathing. The FPP sensor captures three-dimensional (3D) respiratory motion from the chest wall and abdomen, and the analysis algorithms extract respiratory parameters. The system achieved a high Signal-to-Noise Ratio (SNR) of 37 dB with an ideal sinusoidal respiration signal. Experimental results demonstrated that a mean correlation of 0.95 and a mean Root-Mean-Square Error (RMSE) of 0.11 breaths per minute (bpm) were achieved when comparing to a reference signal obtained from a spirometer. Full article

In indoor environments, estimating localization using a received signal strength indicator (RSSI) is difficult because of the noise from signals reflected and refracted by walls and obstacles. In this study, we used a denoising autoencoder (DAE) to remove noise in the RSSI of Bluetooth Low Energy (BLE) signals to improve localization performance. In addition, it is known that the signal of an RSSI can be exponentially aggravated when the noise is increased proportionally to the square of the distance increment. Based on the problem, to effectively remove the noise by adapting this characteristic, we proposed adaptive noise generation schemes to train the DAE model to reflect the characteristics in which the signal-to-noise ratio (SNR) considerably increases as the distance between the terminal and beacon increases. We compared the model’s performance with that of Gaussian noise and other localization algorithms. The results showed an accuracy of 72.6%, a 10.2% improvement over the model with Gaussian noise. Furthermore, our model outperformed the Kalman filter in terms of denoising. Full article

Cardiovascular pathology is the leading cause of death and disability in the Western world, and current diagnostic testing usually evaluates the anatomy of the vessel to determine if the vessel contains blockages and plaques. However, there is a growing school of thought that other measures, such as wall shear stress, provide more useful information for earlier diagnosis and prediction of atherosclerotic related disease compared to pulsed-wave Doppler ultrasound, magnetic resonance angiography, or computed tomography angiography. A novel algorithm for quantifying wall shear stress (WSS) in atherosclerotic plaque using diagnostic ultrasound imaging, called Multifrequency ultrafast Doppler spectral analysis (MFUDSA), is presented. The development of this algorithm is presented, in addition to its optimisation using simulation studies and in-vitro experiments with flow phantoms approximating the early stages of cardiovascular disease. The presented algorithm is compared with commonly used WSS assessment methods, such as standard PW Doppler, Ultrafast Doppler, and Parabolic Doppler, as well as plane-wave Doppler. Compared to an equivalent processing architecture with one-dimensional Fourier analysis, the MFUDSA algorithm provided an increase in signal-to-noise ratio (SNR) by a factor of 4–8 and an increase in velocity resolution by a factor of 1.10–1.35. The results indicated that MFUDSA outperformed the others, with significant differences detected between the typical WSS values of moderate disease progression (p = 0.003) and severe disease progression (p = 0.001). The algorithm demonstrated an improved performance for the assessment of WSS and has potential to provide an earlier diagnosis of cardiovascular disease than current techniques allow. Full article

Day by day, the demand for wireless systems is increasing while the available spectrum resources are not sufficient. To fulfil the demand for wireless systems, the spectrum hole (spectrum vacant) should be found and utilised very effectively. Cognitive radio (CR) is a device which intelligently senses the spectrum through various spectrum-sensing detectors. Based on the complexity and licensed user’s information present with CR, the appropriate detector should be utilised for spectrum sensing. In this paper, a hybrid detector (HD) is proposed to determine the spectrum hole from the available spectrum resources. HD is designed based on an energy detector (ED) and matched detector (MD). Unlike a single detector such as ED or MD, HD can sense the signal more precisely. Here, HD can work on both conditions whether the primary user (PU) information is available or not. HD is analysed under heterogeneous environments with and without cooperative spectrum sensing (CSS). For CSS, four users were used to implement OR, AND, and majority schemes under low SNR walls. To design the HD, specifications were chosen based on the IEEE Wireless Regional Area Network (WRAN) 802.22 standard for accessing TV spectrum holes. For the HD model, we achieved the best results through OR rule. Under the low SNR circumstances at −20 dB SNR, the probability of detection (P_D) is maximised to 1 and the probability of a false alarm (P_FA) is reduced to 0 through the CSS environment. Full article

Despite all the expectations for photoacoustic endoscopy (PAE), there are still several technical issues that must be resolved before the technique can be successfully translated into clinics. Among these, electromagnetic interference (EMI) noise, in addition to the limited signal-to-noise ratio (SNR), have hindered the rapid development of related technologies. Unlike endoscopic ultrasound, in which the SNR can be increased by simply applying a higher pulsing voltage, there is a fundamental limitation in leveraging the SNR of PAE signals because they are mostly determined by the optical pulse energy applied, which must be within the safety limits. Moreover, a typical PAE hardware situation requires a wide separation between the ultrasonic sensor and the amplifier, meaning that it is not easy to build an ideal PAE system that would be unaffected by EMI noise. With the intention of expediting the progress of related research, in this study, we investigated the feasibility of deep-learning-based EMI noise removal involved in PAE image processing. In particular, we selected four fully convolutional neural network architectures, U-Net, Segnet, FCN-16s, and FCN-8s, and observed that a modified U-Net architecture outperformed the other architectures in the EMI noise removal. Classical filter methods were also compared to confirm the superiority of the deep-learning-based approach. Still, it was by the U-Net architecture that we were able to successfully produce a denoised 3D vasculature map that could even depict the mesh-like capillary networks distributed in the wall of a rat colorectum. As the development of a low-cost laser diode or LED-based photoacoustic tomography (PAT) system is now emerging as one of the important topics in PAT, we expect that the presented AI strategy for the removal of EMI noise could be broadly applicable to many areas of PAT, in which the ability to apply a hardware-based prevention method is limited and thus EMI noise appears more prominently due to poor SNR. Full article

Underground Mining (UM) is a hostile industry that generally requires a wireless communication system as a cross-cutting axis for its optimal operation. Therefore, in the last five years, it has been shown that, in addition to radio-frequency-based communication links, wireless optical communications, such as Visible Light Communication (VLC), can be applied to UM environments. The application of VLC systems in underground mines, known as UM-VLC, must take into account the unique physical features of underground mines. Among the physical phenomena found in underground mines, the most important ones are the positioning of optical transmitters and receivers, irregular walls, shadowing, and a typical phenomenon found in tunnels known as scattering, which is caused by the atmosphere and dust particles. Consequently, it is necessary to use proper dust particle distribution models consistent with these scenarios to describe the scattering phenomenon in a coherent way in order to design realistic UM-VLC systems with better performance. Therefore, in this article, we present an in-depth study of the interaction of optical links with dust particles suspended in the UM environment and the atmosphere. In addition, we analytically derived a hemispherical 3D dust particle distribution model, along with its main statistical parameters. This analysis allows to develop a more realistic scattering channel component and presents an enhanced UM-VLC channel model. The performance of the proposed UM-VLC system is evaluated using computational numerical simulations following the IEEE 802.1.5.7 standard in terms of Channel Impulse Response (CIR), received power, Signal-to-Noise-Ratio (SNR), Root Mean Square (RMS) delay spread, and Bit Error Rate (BER). The results demonstrate that the hemispherical dust particle distribution model is more accurate and realistic in terms of the metrics evaluated compared to other models found in the literature. Furthermore, the performance of the UM-VLC system is negatively affected when the number of dust particles suspended in the environment increases. Full article

Radar-based non-contact vital signs monitoring has great value in through-wall detection applications. This paper presents the theoretical and experimental study of through-wall respiration and heartbeat pattern extraction from multiple subjects. To detect the vital signs of multiple subjects, we employ a low-frequency ultra-wideband (UWB) multiple-input multiple-output (MIMO) imaging radar and derive the relationship between radar images and vibrations caused by human cardiopulmonary movements. The derivation indicates that MIMO radar imaging with the stepped-frequency continuous-wave (SFCW) improves the signal-to-noise ratio (SNR) critically by the factor of radar channel number times frequency number compared with continuous-wave (CW) Doppler radars. We also apply the three-dimensional (3-D) higher-order cumulant (HOC) to locate multiple subjects and extract the phase sequence of the radar images as the vital signs signal. To monitor the cardiopulmonary activities, we further exploit the VMD algorithm with a proposed grouping criterion to adaptively separate the respiration and heartbeat patterns. A series of experiments have validated the localization and detection of multiple subjects behind a wall. The VMD algorithm is suitable for separating the weaker heartbeat pattern from the stronger respiration pattern by the grouping criterion. Moreover, the continuous monitoring of heart rate (HR) by the MIMO radar in real scenarios shows a strong consistency with the reference electrocardiogram (ECG). Full article

In actual life-detection radar applications, a quasi-static person with weak respiration is difficult to find when relying on the echoes from a single fixed observation point. To effectively sense the weak respiration of a quasi-static person in complex through-wall and through-floor conditions, this paper proposes a novel multi-observation point detection system composed of multiple Golay complementary coded radars in which communication and synchronization are carried out wirelessly. The collaboration structure and Golay complementary coded transmitter improve the signal to noise ratio (SNR). Proof-of-principle experiments are carried out with our designed radar prototype and prove that the radar system can detect a respiring target 21 m behind a brick wall or a respiring target behind two levels of reinforced concrete floors, validating the effectiveness of a multi-observation point working mode for the efficient detection of weak human respiration. Full article

This study performed an experimental investigation on pulsed thermography to detect internal defects, the major degradation phenomena in several structures of the secondary systems in nuclear power plants as well as industrial pipelines. The material losses due to wall thinning were simulated by drilling flat-bottomed holes (FBH) on the steel plate. FBH of different sizes in varying depths were considered to evaluate the detection capability of the proposed technique. A short and high energy light pulse was deposited on a sample surface, and an infrared camera was used to analyze the effect of the applied heat flux. The three most established signal processing techniques of thermography, namely thermal signal reconstruction (TSR), pulsed phase thermography (PPT), and principal component thermography (PCT), have been applied to raw thermal images. Then, the performance of each technique was evaluated concerning enhanced defect detectability and signal to noise ratio (SNR). The results revealed that TSR enhanced the defect detectability, detecting the maximum number of defects, PPT provided the highest SNR, especially for the deeper defects, and PCT provided the highest SNR for the shallower defects. Full article
