The performance of a printed square split-ring resonator as a sensor for quantifying nanoparticle concentrations in PVDF-based nanocomposites was evaluated at UHF frequencies. The sensing mechanism was based on the frequency response of parameter S₂₁, observing the shift in the resonant frequency and a variation in S₂₁ level, while samples were placed on the ring split and compared to the sensor without a sample. Experiments with samples of PVDF-based nanocomposites combined with different concentrations of both MoS₂ and MXenes, ranging from 0.01% to 0.2%, were conducted. In general, considering both types of samples studied, it was observed that, as the concentration increases, S₂₁ (dB) increases from-.35 to −6 dB. At the same time, the resonance frequency in the S₂₁ plot went from 500.4 to 498.25 MHz. Although the concentrations and their variations were relatively low, shifts in the resonance frequency of S₂₁ were evident, demonstrating the ability of the sensor to detect low concentrations and variations of MoS₂ and MXenes, being the detection of samples with higher concentrations feasible as future work, and concluding that the sensor had a relatively acceptable performance. In this study, MXenes were the concentrations that produced more noticeable shifts in the resonance frequency of S₂₁. Likewise, characterizations based on SEM and TEM were performed to corroborate the ones at UHF frequencies. Full article

The thermal behavior of 3D-printed polyvinylidene fluoride (PVDF)-based composites enhanced with carbon nanotubes (CNTs), graphene nanoplatelets (GNPs), and their hybrid formulations was investigated under Joule heating at applied voltages of 2, 3, and 4 V. The influence of filler type and weight fraction on both electrical and thermal conductivity was systematically assessed using a Design of Experiments (DoE) approach. Response Surface Methodology (RSM) was employed to derive an analytical relationship linking conductivity values to filler loading, revealing clear trends and interaction effects. Among all tested formulations, the composite containing 6 wt% of GNPs exhibited the highest performance in terms of thermal response and electrical conductivity, reaching a steady-state temperature of 88.1 °C under an applied voltage of just 4 V. This optimal formulation was further analyzed through multiphysics simulations, validated against experimental data and theoretical predictions, to evaluate its effectiveness for potential practical applications—particularly in de-icing systems leveraging Joule heating. The integrated experimental–theoretical–numerical workflow proposed herein offers a robust strategy for guiding the development and optimization of next-generation polymer nanocomposites for thermal management technologies. Full article

In this study, we present a flexible piezoelectric nanogenerator based on a zinc oxide (ZnO)/polyvinylidene fluoride (PVDF) nanocomposite electrospun onto a hemisphere-patterned PDMS substrate. The nanogenerator was fabricated by replicating a silicon mold with inverted hemispheres into PDMS, followed by direct electrospinning of ZnO-dispersed PVDF nanofibers. Varying the ZnO concentration from 0.6 to 1.4 wt% allowed us to evaluate its effect on structural, dielectric, and piezoelectric properties. The nanogenerator containing 0.8 wt% ZnO exhibited the thinnest fibers (371 nm), the highest β-phase fraction (85.6%), and the highest dielectric constant (35.8). As a result, it achieved the maximum output voltage of 7.30 V, with excellent signal consistency under an applied pressure of 5 N. Comparisons with pristine PVDF- and ZnO/PVDF-only devices demonstrated the synergistic effect of ZnO loading and patterned PDMS on the enhancement of piezoelectric output. The hemisphere-patterned PDMS substrate improved the mechanical strain distribution, interfacial contact, and charge collection efficiency. These results highlight the potential of ZnO/PVDF/PDMS hybrid nanogenerators for use in wearable electronics and self-powered sensor systems. Full article

The low energy density (U_d) of polymeric dielectrics is unfavorable for the integration and miniaturization of electronics, thus limiting their application prospects. Introducing high-ε_r (dielectric constant) ceramic nanofillers to polymer matrices is the most common strategy to enhance their ε_r, and hence their U_d. By comparison, enhancing breakdown strength (E_b) is a more effective strategy to enhance U_d. Herein, 0.6BaTiO₃-0.4Bi(Mg_0.5Ti_0.5)O₃ and 0.85BaTiO₃-0.15Bi(Mg_0.5Zr_0.5)O₃ nanofibers coated with SiO₂ were utilized as fillers in PVDF-based nanocomposites. The combination of experimental and simulation results suggests that the intrinsic properties of nanofillers are the determining factor of the E_b of polymer-based nanocomposites, and SiO₂ coating and film structure design are effective strategies to enhance their E_b, and consequently their U_d. As a result, the sandwich-structured PVDF/6 wt% 0.85BaTiO₃-0.15Bi(Mg_0.5Zr_0.5)O₃@SiO₂ nanofiber within PVDF/PVDF nanocomposite films achieved a maximum U_d of 11.1 J/cm³ at an E_b of 458 MV/m, which are 2.15 and 1.40 times those of pristine PVDF, respectively. Full article

Dielectric capacitors offer immense application potential in advanced electrical and electronic systems with their unique ultrahigh power density. Polymer-based dielectric composites with high energy density are urgently needed to meet the ever-growing demand for the integration and miniaturization of electronic devices. However, the universal contradictory relationship between permittivity and breakdown strength in traditional ceramic/polymer nanocomposite still poses a huge challenge for a breakthrough in energy density. In this work, all-organic carbon quantum dot CDs were synthesized and introduced into a poly(vinylidene fluoride) PVDF polymer matrix to achieve significantly boosted energy storage performance. The ultrasmall and surface functionalized CDs facilitate the polar β-phase transition and crystallinity of PVDF polymer and modulate the energy level and traps of the nanocomposite. Surprisingly, a synergistic dielectric enhancement and loss reduction were achieved in CD/PVDF nanocomposite. For one thing, the improvement in ε_r and high-field D_m originates from the CD-induced polar transition and interface polarization. For another thing, the suppressed dielectric loss and high-field D_r are attributed to the conductive loss depression via the introduction of deep trap levels to capture charges. More importantly, E_b was largely strengthened from 521.9 kV mm⁻¹ to 627.2 kV mm⁻¹ by utilizing the coulomb-blockade effect of CDs to construct energy barriers and impede carrier migration. As a result, compared to the 9.9 J cm⁻³ for pristine PVDF, the highest discharge energy density of 18.3 J cm⁻³ was obtained in a 0.5 wt% CD/PVDF nanocomposite, which is competitive with most analogous PVDF-based nanocomposites. This study demonstrates a new paradigm of organic quantum dot-enhanced ferroelectric polymer-based dielectric energy storage performance and will promote its application for electrostatic film capacitors. Full article

Poly vinylidene fluoride (PVDF) is a versatile polymer that shows polymorphism, and most of its applications are based on its piezoelectric properties given by its polar crystalline phases. Increasing the polymer’s polar β-phase content has been a major pursuit in material science. We present the results on the evolution of induced polymorphic changes of PVDF through thermal treatment and the presence of the nano-ZnO with different morphologies. Three types of samples—a PVDF pure layer, PVDF:ZnO nanoparticles (NPs) and PVDF:ZnO nanorods (NRs)—were subjected to stress by heating at different temperatures from 50 °C close to melting temperature, 170 °C. The changes in PVDF–ZnO composite layers were investigated in situ using an experimental setup consisting of a high-resolution micro-Raman spectrometer and a thermo-electric cell. The ZnO NPs and NRs added in PVDF lead to obtaining a PVDF nanocomposite in which the intensity of the β phase is much higher than that of the α phase: intensities ratio I_{β(840.6 cm⁻¹})/I_{α(798.9 cm⁻¹}) > 5.56. The phase is stable up to 150 °C, and with the increase in temperature to 170 °C, the β phase passes to a lower crystallinity α phase with a large amorphous content highlighted by the 400–700 cm⁻¹ and 800–1000 cm⁻¹ regions without Raman peaks. Full article

This study developed a novel 3D-printable poly(vinylidene fluoride) (PVDF)-based nanocomposite incorporating 6 wt% graphene nanoplatelets (GNPs) with programmable characteristics for resistive heating applications. The results highlighted the significant effect of a controlled printing direction (longitudinal, diagonal, and transverse) on the electrical, thermal, Joule heating, and thermo-resistive properties of the printed structures. The 6 wt% GNP/PVDF nanocomposite exhibited a high electrical conductivity of 112 S·m⁻¹ when printed in a longitudinal direction, which decreased significantly in other directions. The Joule heating tests confirmed the material’s efficiency in resistive heating, with the maximum temperature reaching up to 65 °C under an applied low voltage of 2 V at a raster angle of printing of 0°, while the heating T_max decreased stepwise with 10 °C at the 45° and the 90° printing directions. The repeatability of the Joule heating performance was verified through multiple heating and cooling cycles, demonstrating consistent maximum temperatures across several tests. The effect of sample thickness, controlled by the number of printed layers, was investigated, and the results underscore the advantages of programmable 3D printing orientation in thin layers for enhanced thermal stability, tailored electrical conductivity, and efficient Joule heating capabilities of 6 wt% GNP/PVDF composites, positioning them as promising candidates for next-generation 3D-printed electronic devices and self-heating applications. Full article

Bismuth ferrite (BiFeO₃, BFO) is one of the few single-phase crystalline compounds exhibiting strong multiferroic properties at room temperature, which makes it promising for use in various fields of science and technology. The remarkable characteristics of BFO at the nanoscale position it as a compelling candidate for enhancing the functionalities of polymeric nanocomposite materials. In this study, we explore the fabrication of polyvinylidene fluoride (PVDF) nanocomposites with a variable content of BFO nanopowders (0, 5, 10, 15, 20, and 25 wt%) by solution casting in the form of thin films with the thickness of ~60 µm. Our findings reveal that the presence of BFO nanoparticles slightly facilitates the formation of β- and γ-phases of PVDF, known for their enhanced piezoelectric properties, thereby potentially expanding the utility of PVDF-based materials in sensors, actuators, and energy harvesting devices. On the other hand, the increase in filler concentration leads to enlarged spherulite diameter and porosity of PVDF, as well as an increase in filler content above 20 wt% resulting in a decrease in the degree of crystallinity. The structural changes in the surface were found to increase the hydrophobicity of the nanocomposite surface. Magnetometry indicates that the magnetic properties of nanocomposite are influenced by the BFO nanoparticle content with the saturation magnetization at ~295 K ranging from ~0.08 emu/g to ~0.8 emu/g for samples with the lowest and higher BFO content, respectively. Full article

Mass concrete is widely used in large-scale projects, including metro upper cover structures, water conservancy dams, and heavy equipment foundations, among others, necessitating the process of health monitoring in mass concrete construction. The development of reliable and simple strength-monitoring methods for mass concrete is challenging because the inner temperature of mass concrete is high and changes a lot. This study proposes a strength-monitoring approach for mass concrete using barium titanate–bismuth ferrite/polyvinylidene fluoride (BT–BFO/PVDF) nanocomposite piezoelectric sensors, wherein the new sensors are embedded as actuators and sensors in mass concrete. The stress wave generated by the BT–BFO/PVDF piezoelectric sensors is used to monitor the specimen’s strength for 28 days. The piezoelectric voltage received by the sensors in mass concrete is analyzed. The experimental results indicate that the signal received by the BT–BFO/PVDF sensors is not easily affected by the internal temperature of mass concrete compared with that of the traditional PVDF piezoelectric sensors. The signal parameters sensitive to concrete strength variation and the change trend of concrete strength are closely related to the piezoelectric voltage. Therefore, the proposed approach using BT–BFO/PVDF nanocomposite piezoelectric sensors is efficient (error < 10%) in mass concrete monitoring. Moreover, the monitoring results do not need temperature compensation. The physical meaning of the obtained strength prediction formula is proposed. An experimental system based on PVDF dynamic strain-sensing characteristics is established. Full article

In recent years, conductive polymer nanocomposites have gained significant attention due to their promising thermoresistive and Joule heating properties across a range of versatile applications, such as heating elements, smart materials, and thermistors. This paper presents an investigation of semi-crystalline polyvinylidene fluoride (PVDF) nanocomposites with 6 wt.% carbon-based nanofillers, namely graphene nanoplatelets (GNPs), multi-walled carbon nanotubes (MWCNTs), and a combination of GNPs and MWCNTs (hybrid). The influence of the mono- and hybrid fillers on the crystalline structure was analyzed by X-ray diffraction (XRD) and differential scanning calorimetry (DSC). It was found that the nanocomposites had increased amorphous fraction compared to the neat PVDF. Furthermore, nanocomposites enhanced the β phase of the PVDF by up to 12% mainly due to the presence of MWCNTs. The resistive properties of the nanocompositions were weakly affected by the temperature in the analyzed temperature range of 25–100 °C; nevertheless, the hybrid filler composites were proven to be more sensitive than the monofiller ones. The Joule heating effect was observed when 8 and 10 V were applied, and the compositions reached a self-regulating effect at around 100–150 s. In general, the inclusion in PVDF of nanofillers such as GNPs and MWCNTs, and especially their hybrid combinations, may be successfully used for tuning the self-regulated Joule heating properties of the nanocomposites. Full article

Additive manufacturing (AM) technology has recently seen increased utilization due to its versatility in using functional materials, offering a new pathway for next-generation conformal electronics in the smart sensor field. However, the limited availability of polymer-based ultraviolet (UV)-curable materials with enhanced piezoelectric properties necessitates the development of a tailorable process suitable for 3D printing. This paper investigates the structural, thermal, rheological, mechanical, and piezoelectric properties of a newly developed sensor resin material. The polymer resin is based on polyvinylidene fluoride (PVDF) as a matrix, mixed with constituents enabling UV curability, and boron nitride nanotubes (BNNTs) are added to form a nanocomposite resin. The results demonstrate the successful micro-scale printability of the developed polymer and nanocomposite resins using a liquid crystal display (LCD)-based 3D printer. Additionally, incorporating BNNTs into the polymer matrix enhanced the piezoelectric properties, with an increase in the voltage response by up to 50.13%. This work provides new insights for the development of 3D printable flexible sensor devices and energy harvesting systems. Full article

In this study, flexible nanocomposites made from PVDF-HFP reinforced with carbon nanotubes (CNTs) and graphene nanoplatelets (GNPs) are manufactured using a sonication and solvent casting method for monitoring purposes. More specifically, the effect of the volume batch under the sonication process is explored. For CNT-based composites, the electrical conductivity decreases as the batch volume increases due to less effective dispersion of the CNTs during the 30-min sonication. The maximum electrical conductivity achieved in this type of sensor is 1.44 ± 0.17 S/m. For the GNP-based nanocomposites, the lower the batch volume is, the more breakage of nanoplatelets is induced by sonication, and the electrical response decreases. This is also validated by AC analysis, where the characteristic frequencies are extracted. Here, the maximum electrical conductivity measured is 8.66 ± 1.76 S/m. The electromechanical results also show dependency on the batch volume. In the CNT-based nanocomposites, the higher gauge factor achieved corresponds to the batch size, where the sonication may be more effective because it leads to a dispersed pathway formed by aggregates connected by tunneling mechanisms. In contrast, in the CNT-based nanocomposites, the GF depends on the lateral size of the GNPs. The biggest GF of all sensors is achieved with the PVDF-HFP/GNP sensors, having a value of 69.36 × 10⁴ at 35% of strain, while the highest GF achieved with a PVDF-HFP/CNT sensor is 79.70 × 10³ at 70%. In addition, cycling tests show robust electromechanical response with cycling for two different strain percentages for each type of nanocomposite. The sensor with the highest sensitivity is selected for monitoring two joint movements as proof of the applicability of the sensors manufactured. Full article

The three-dimensional (3D) force sensor has become essential in industrial and medical applications. The existing conventional 3D force sensors quantify the three-direction force components at a point of interest or extended contact area. However, they are typically made of rigid, complex structures and expensive materials, making them hard to implement in different soft or fixable industrial and medical applications. In this work, a new flexible 3D force sensor based on polymer nanocomposite (PNC) sensing elements was proposed and tested for its sensitivity to forces in the 3D space. Multi-walled carbon nanotube/polyvinylidene fluoride (MWCNT/PVDF) sensing element films were fabricated using the spray coating technique. The MWCNTs play an essential role in strain sensitivity in the sensing elements. They have been utilized for internal strain measurements of the fixable 3D force sensor’s structure in response to 3D forces. The MWCNT/PVDF was selected for its high sensitivity and capability to measure high and low-frequency forces. Four sensing elements were distributed into a cross-beam structure configuration, the most typically used solid 3D force sensor. Then, the sensing elements were inserted between two silicone rubber layers to enhance the sensor’s flexibility. The developed sensor was tested under different static and dynamic loading scenarios and exhibited excellent sensitivity and ability to distinguish between tension and compression force directions. The proposed sensor can be implemented in vast applications, including soft robotics and prostheses’ internal forces of patients with limb amputations. Full article

Among the various water purification techniques, advancements in membrane technology, with better fabrication and analysis, are receiving the most research attention. The piezo-catalytic degradation of water pollutants is an emerging area of research in water purification technology. This review article focuses on piezoelectric polyvinylidene difluoride (PVDF) polymer-based membranes and their nanocomposites for textile wastewater remediation. At the beginning of this article, the classification of piezoelectric materials is discussed. Among the various membrane-forming polymers, PVDF is a piezoelectric polymer discussed in detail due to its exceptional piezoelectric properties. Polyvinylidene difluoride can show excellent piezoelectric properties in the beta phase. Therefore, various methods of β-phase enhancement within the PVDF polymer and various factors that have a critical impact on its piezo-catalytic activity are briefly explained. This review article also highlights the major aspects of piezoelectric membranes in the context of dye degradation and a net-zero approach. The β-phase of the PVDF piezoelectric material generates an electron–hole pair through external vibrations. The possibility of piezo-catalytic dye degradation via mechanical vibrations and the subsequent capture of the resulting CO₂ and H₂ gases open up the possibility of achieving the net-zero goal. Full article

The composites with multiple types of nano-carbon fillers have better electrical conductivity and piezoresistive properties as compared with composites with a single type of nano-carbon fillers. As previously reported, the nano-carbon fillers with various aspect ratios, such as carbon nanotube (CNT) and carbon black (CB), have synergistic enhanced effects on the piezoresistive performance of composite sensors. However, most of the works that have been reported are experimental investigations. The efficient and usable numerical simulation investigation needs to be further developed. In this study, based on an integrated 3D statistical resistor network model, a numerical simulation model was created to calculate the piezoresistive behavior of the CNT/CB/ Polyvinylidene Fluoride (PVDF) composite. This model also takes into account the tunneling effect between nearby nano-fillers. It is found from numerical simulation results that the piezoresistive sensitivity of composite simulation cells can be influenced by the fraction of CNT and CB. In the case that the CNT content is 0.073 wt.%, the best force-electrical piezoresistive sensitivity can be achieved when the CB loading is up to 0.2 wt.%. To verify the validity of the simulation model, the previous experimental investigation results are also compared. The experimental results confirm the validity of the model. The investigation is valuable and can be utilized to design a strain sensor for this nano-composite with increased sensitivity. Full article
