Search Results (21)

THz communication stands as a pivotal technology for 6G networks, designed to address the critical challenge of data demands surpassing current microwave and millimeter-wave (mmWave) capabilities. However, realizing Tbps and kilometer-range transmission confronts the “dual attenuation dilemma” comprising severe free-space path loss (FSPL) (>120 dB/km) and atmospheric absorption. This review comprehensively summarizes our group′s advancements in overcoming fundamental challenges of long-distance THz communication. Through systematic photonic–electronic co-optimization, we report key enabling technologies including photonically assisted THz signal generation, polarization-multiplexed multiple-input multiple-output (MIMO) systems with maximal ratio combining (MRC), high-gain antenna–lens configurations, and InP amplifier systems for complex weather resilience. Critical experimental milestones encompass record-breaking 1.0488 Tbps throughput using probabilistically shaped 64QAM (PS-64QAM) in the 330–500 GHz band; 30.2 km D-band transmission (18 Gbps with 543.6 Gbps·km capacity–distance product); a 3 km fog-penetrating link at 312 GHz; and high-sensitivity SIMO-validated 100 Gbps satellite-terrestrial communication beyond 36,000 km. These findings demonstrate THz communication′s viability for 6G networks requiring extreme-capacity backhaul and ultra-long-haul connectivity. Full article

We propose a probabilistic shaping (PS) scheme based on a single-layer lookup table (LUT) that employs only one LUT for symbol mapping while achieving favorable system performance. This scheme reduces the average power of the signal by adjusting the symbol distribution using a specialized LUT architecture and a flexible shaping proportion. The simulation results indicate that the proposed PS scheme delivers performance comparable to that of the conventional constant-composition distribution-matching-based probabilistic shaping (CCDM-PS) algorithm. Specifically, it reduces the bit error rate (BER) from 1.2376 $\times {10}^{-4}$ to 6.3256 $\times {10}^{-5}$, corresponding to a 48.89% improvement. The radial basis function neural network (RBFNN) effectively compensates for nonlinear distortions and further enhances transmission performance due to its simple architecture and strong capacity for nonlinear learning. In this work, we combine lookup-table-based probabilistic shaping (LUT-PS) with RBFNN-based nonlinear equalization for the first time, completing the transmission of 16-QAM OFDM signals over a photonic terahertz-over-fiber system operating at 400 GHz. Simulation results show that the proposed approach reduces the BER by 81.45% and achieves a maximum Q-factor improvement of up to 23 dB. Full article

Modulation format identification (MFI) is one of the most critical functions embedded in digital coherent receivers in elastic optical networks (EONs). In view of inherent amplitude and phase characteristics of received signals, different modulation formats exhibit a set of notable features in the polar coordinate system, based on which an MFI scheme incorporating the Gaussian weighted k-nearest neighbors (KNN) algorithm was proposed to identify polarization division multiplexed (PDM)-QPSK/-16QAM/-32QAM/-64QAM/-128QAM signals. The performance of the proposed scheme was numerically verified in 28GBaud coherent optical communication systems. The numerical simulation results show that, to achieve 100% correct identification rates for all of the five modulation formats, the required minimum optical signal-to-noise ratios (OSNRs) were less than their relevant thresholds corresponding to the 20% forward error correction (FEC). The tolerable ranges of the residual chromatic dispersion (CD) for QPSK, 16QAM, 32QAM, 64QAM, and 128QAM were −1920 ps/nm~1920 ps/nm, −720 ps/nm~360 ps/nm, −1200 ps/nm~1680 ps/nm, −600 ps/nm~360 ps/nm, and −600 ps/nm~480 ps/nm, respectively. Meanwhile, the results demonstrate the maximum tolerable differential-group delay (DGD) for the QPSK, 16QAM, 32QAM, 64QAM, and 128QAM signals were 34 ps, 16 ps, 20 ps, 6 ps, and 1.2 ps, respectively. In addition, the simulated results also show that the proposed MFI scheme is robust against the fiber nonlinearities, even if the launch power is increased to 4 dBm. Full article

A carrier phase estimation method based on the unscented Kalman filter (UKF) is proposed for probabilistically shaped (PS) quadrature amplitude modulation (QAM) systems. We further integrate a joint decision scheme into the proposed UKF−based algorithm to prevent the correlated erroneous decisions in the phase recovery scheme caused by the impact of PS. The proposed method achieves the performance benefit for PS constellations in optical transmissions by partitioning the constellation symbols suitably and utilizing both the maximum a posterior probability (MAP) and maximum likelihood (ML) detection. The results of numerical simulation and experimental verification reveal that the proposed method performs better than the conventional CPR algorithms in PS systems. Full article

We have experimentally implemented a photonics-aided large-capacity fiber-mm-wave wireless communication system employing a simple dual-polarized single-input single-output (SISO) wireless based on polarization multiplexing at the W-band. To compare the performance of different algorithms, 18G-baud, and 35G-baud 16-level quadrature-amplitude-modulation (16QAM), probabilistically shaped 16QAM (PS-16QAM), 64QAM and PS-64QAM signal using different carrier phase recovery (CPR) algorithms are transmitted in the system. Moreover, we compare the Viterbi–Viterbi (VV), improved new algorithm based on VV (NVV), blind phase search (BPS), and two-stage BPS algorithms’ computational complexity to better compare different algorithms. Using the experiment result, we can demonstrate that the BPS algorithm is about half a magnitude better than the NVV algorithm for PS-QAM signals, while the NVV algorithm has the lowest computational complexity. Additionally, we also achieve error-free wireless transmission at a net data rate of 324.1 Gb/s with the bit error ratio (BER) below the forward-error correction (FEC) threshold of 1 × 10⁻² assuming soft-decision forward-error correction (SD-FEC) when using the BPS algorithm. Full article

We experimentally incubate a ground-breaking design, for the first time, of concurrent electro-optical semiconductor optical amplifier Mach–Zehnder interferometer mixing (SOA-MZI) based on a differential transformation methodology. Projecting the simultaneous electro-optical mixing system and improving its efficiency and quality achievement in optical and electrical features is a crucial task due to the characteristics of an optical pulse source (OPS) operating with a repetition rate of $f=$ 58.5 GHz and a pulse width duration of 1 picosecond (ps). The resultant of the contemporaneous electro-optical mixing exhibits exceptional passive power stability, reaching 0.8% RMS over a two-hour period. Furthermore, when the optical bandpass filter is controlled at the data wavelength of 1540 nm, we achieve up to 30 dBm of the overall mean output power with an optical conversion gain of 46 dB and an exceptionally high optical signal-to-noise ratio reaching 80 dB. Using orthogonal frequency division multiplexing (OFDM) signals, each data subcarrier is modulated using 128 quadratic amplitude modulation (128-QAM) at carrier frequencies $f_k$ and simultaneously up-mixed to high aim frequencies $nf\pm f_k$ at the SOA-MZI output. Additionally, the resulting OFDM_128-QAM up-mixed signal is examined using the specifications for the error vector magnitudes (EVMs) and the electrical conversion gains (ECGs). The SOA-MZI mixing experiment can handle high frequencies up to 120 GHz. Positive ECGs are followed by a sharp reduction over the entire band of the aim frequencies. The highest frequency range achieved during the realistic investigation is shown at $2f+f_4=$ 120 GHz, where the EVM reaches 8% with a symbol rate of 15 GSymb/s. Furthermore, the concurrent OFDM_128-QAM up-mixed signal achieves an absolute maximum bit rate of 80.4 Gbit/s. The investigation into the simultaneous electro-optical mixing regime is finally supported by unmatched characterization improvements. Full article

For W-band long-range mm-wave wireless transmission systems, nonlinearity issues resulting from photoelectric devices, optical fibers, and wireless power amplifiers can be handled by deep learning equalization algorithms. In addition, the PS technique is considered an effective measure to further increase the capacity of the modulation-constraint channel. However, since the probabilistic distribution of m-QAM varies with the amplitude, there have been difficulties in learning valuable information from the minority class. This limits the benefit of nonlinear equalization. To overcome the imbalanced machine learning problem, we propose a novel two-lane DNN (TLD) equalizer using the random oversampling (ROS) technique in this paper. The combination of PS at the transmitter and ROS at the receiver improved the overall performance of the W-band wireless transmission system, and our 4.6-km ROF delivery experiment verified its effectiveness for the W-band mm-wave PS-16QAM system. Based on our proposed equalization scheme, we achieved single-channel 10-Gbaud W-band PS-16QAM wireless transmission over a 100 m optical fiber link and a 4.6 km wireless air-free distance. The results show that compared with the typical TLD without ROS, the TLD-ROS can improve the receiver‘s sensitivity by 1 dB. Furthermore, a reduction of 45.6% in complexity was achieved, and we were able to reduce training samples by 15.5%. Considering the actual wireless physical layer and its requirements, there is much to be gained from the joint use of deep learning and balanced data pre-processing techniques. Full article

We design and evaluate two experimental systems for a single and simultaneous electro-optical semiconductor optical amplifier Mach-Zehnder interferometer (SOA-MZI) mixing system based on the differential modulation mode. These systems and the optimization of their optical and electrical performance largely depend on characteristics of an optical pulse source (OPS), operating at a frequency of $f=$ 39 GHz and a pulse width of 1 ps. The passive power stability of the electro-optical mixing output over one hour is better than 0.3% RMS (root mean square), which is excellent. Additionally, we generate up to 22 dBm of the total average output power with an optical conversion gain of 32 dB, while achieving a record output optical signal to noise ratio (OSNR) up to 77 dB. On the other hand, at the SOA–MZI output, the 128 quadratic amplitude modulation (128-QAM) signal at an intermediate frequency (IF), $f_1$, is up-mixed to higher output frequencies $nf \pm f_1$. The advantages of the resulting 128-QAM mixed signal during electrical conversion gains (ECGs) and error vector magnitudes (EVMs) are also evaluated. The performed empirical SOA-MZI mixing can operate up to 118.5 GHz in its high-frequency range. The positive and almost constant conversion gains are achieved. Indeed, the obtained conversion gain values are very close across the entire range of output frequencies. The largest frequency range achieved during experimental work is 118.5 GHz, where the EVM achieves 6% at a symbol rate of 10 GSymb/s. Moreover, the peak data rate of the 128-QAM up mixed signal can reach 70 GBit/s. Finally, the study of the simultaneous electro-optical mixing system is accepted with unmatched performance improvement. Full article

D-band (110–170 GHz) is a promising direction for the future of 6th generation mobile networks (6G) for high-speed mobile communication since it has a large available bandwidth, and it can provide a peak rate of hundreds of Gbit/s. Compared with the traditional electrical approach, photonics millimeter wave (mm-wave) generation in D-band is more practical and effectively overcomes the bottleneck of electrical devices. However, long-distance D-band wireless transmission is still limited by some key factors such as large absorption loss and nonlinear noises. Deep neural network algorithms are regarded as an important technique to model the nonlinear wireless behavior, among which the study on complex-value equalization is critical, especially in coherent detection systems. Moreover, probabilistic shaping is useful to improve the transmission capacity but also causes an imbalanced machine learning issue. In this paper, we propose a novel complex-valued neural network equalizer coupled with balanced random oversampling (ROS). Thanks to the adaptive deep learning method for probabilistic shaping-quadrature amplitude modulation (PS-QAM), we successfully realize a 135 GHz 4Gbaud PS-16QAM with a shaping entropy of 3.56 bit/symbol wireless transmission over 4.6 km. The bit error ratio (BER) of 4Gbaud PS-16QAM can be decreased to a soft-decision forward error correction (SD-FEC) with a 25% overhead of 2 × 10⁻². Therefore, we can achieve a net rate of an 11.4 Gbit/s D-band radio-over-fiber (ROF) delivery over 4.6 km air free wireless distance. Full article

This gazette focuses on simulation and experimental studies for all-optical three-input “AND” gate schemes. The proposed gate exploits the semiconductor optical amplifier Mach-Zehnder Interferometer (SOA-MZI) nonlinearities, particularly the cross-phase modulation (XPM) corollary in addition to the cross-gain modulation (XGM) corollary, which originates from a SOA-MZI differential modulation concept. Further, the system performance is analyzed and examined through actual and simulated results to evaluate the obtained “AND” gate signal. Dependent on the nonlinearity of SOAs, the all-optical “AND” gate can operate with three signals driven by a 2 picoseconds (ps) optical pulse source (OPS). We noticed that our experimental results are perfectly matched to the simulated results. The output “AND” signal is acquired at higher common harmonics up to 200 GHz in the simulation study and the optical “AND”, which can vastly be used in optical networking, is evaluated through many parameters, such as error vector magnitude (EVM), extinction ratio (ER), and gain. As a result, the pinnacle bit rate for the 16-QAM (Quadrature Amplitude Modulation) and 256-QAM “AND” signal reaches 100 and 200 Gbit/s, respectively, at the 100 GHz common harmonic frequency. Full article

By combining the nonlinear impairment features derived from the first-order perturbation theory, we propose a nonlinear impairment compensation (NLC) scheme based on the transfer learning-assisted convolutional bidirectional long short-term Memory (CNN-BiLSTM) neural network structure. When considering the correlation of nonlinear impairment between preceding and succeeding consecutive adjacent symbols on the current moment symbol and integrating the multidimensional feature extraction and time memory characteristics of CNN-BiLSTM, the nonlinear impairment information contained in the input feature can be fully utilized to accurately predict the nonlinear impairment showing significant compensation effect. Meanwhile, transfer learning (TL) is introduced to greatly reduce the complexity of the scheme on the basis of high compensation performance. To verify the effectiveness of the proposed scheme, we construct single-channel (SC) and 5-channel 28 GBaud polarization division multiplexing 16 quadrature amplitude modulation (PDM-16QAM)/85 GBaud PDM-64QAM simulation systems, and SC and 3-channel 28 GBaud PDM-16QAM experimental systems. The experimental results show that when compared with simple recurrent neural network (SRNN) NLC and DBP 20 steps per span (DBP20StPs), the Q-factor gain of our scheme is about 1 dB and 1.7 dB in the SC system, and about 1.1 dB and 1.5 dB in the 3-channel system at the optimal launch power, respectively. It is interesting to highlight that, by applying TL to the simulation and experimental systems, our scheme based on only 5% of the training samples can achieve compensation performance comparable to or higher quality than retraining at various launch powers. Full article

In this paper, a novel, nonbinary (NB) LDPC-coded probabilistic shaping (PS) scheme for a Rayleigh fading channel is proposed. For the NB LDPC-coded PS scheme in Rayleigh fading channel, the rotation angle of 16 quadrature amplitude modulation (QAM) constellations, 64QAM constellations and 256QAM constellations are optimized by the exhaustive search. The simulation results verify the information–theoretical analysis. Compared with the binary LDPC-coded PS scheme for Rayleigh fading channel, the proposed NB LDPC-coded PS scheme can improve error performance. In summary, the proposed NB LDPC-coded PS scheme for Rayleigh fading channel is reliable and thus suitable for future communication systems. Full article

In this paper, we propose an Extended Kalman Filtering with phase noise reconstruction (EKF-PC) scheme to enhance the carrier recovery capability for probabilistic shaping of coherent optical communication systems with various shaping factors. We first investigate the weights of the shaping factor and the noise rejection window length of EKF-PC for PS-64QAM at a fixed signal-to-noise ratio (SNR). After that, we jointly optimize the shaping factor and the noise rejection window length to obtain the maximum achievable information rate at a variety of SNRs. Then, we numerically analyze the carrier recovery performance of the EKF-PC for different linewidths and SF conditions. Finally, we conduct simulation experiments to compare EKF-PC, PCPE, and other currently available Kalman CPE algorithms with the SFs of 0.02, 0.025, 0.03, and 0.035 under back-to-back (B2B) scenarios. The experimental results show that EKF-PC obtains an average SNR improvement of 0.13–0.5 dB compared to PCPE and an average performance improvement of 0.5–1 dB compared to other Kalman algorithms. Full article

Faster-than-Nyquist (FTN) coherent optical transmission technology is considered to be an outstanding solution to achieve higher spectral efficiency (SE), larger capacity, and greater achievable transmission by using advanced modulation formats in concert with highly efficient digital signal processing (DSP) to estimate and compensate various impairments. However, severe inter-symbol interference (ISI) caused by tight FTN pulse shaping will lead to intractable chromatic dispersion (CD) estimation problems, as existing conventional methods are completely ineffective or exhibit unaffordable computational complexity (CC). In this paper, we propose a low-complexity and highly robust scheme that could realize accurate and reliable CD estimation (CDE) based on a designed training sequence (TS) in the first stage and an optimized fractional Fourier transform (FrFT) in the second stage. The training sequence with the designed structure helps us to estimate CD roughly but reliably, and it further facilitates the FrFT in the second stage to achieve accurate CDE within a narrowed searching range; it thereby results in very low CC. Comprehensive simulation results of triple-carrier 64-GBaud FTN dual-polarization 16-ary quadrature amplitude modulation (DP-16QAM) systems demonstrate that, with only overall 3% computational complexity compared with conventional blind CDE methods, the proposed scheme exhibits a CDE accuracy better than 65 ps/nm even under an acceleration factor as low as 0.85. In addition, 60-GBaud FTN DP quadrature phase shift keying (DP-QPSK)/16QAM transmission experiments are carried out, and the results show that the CDE error is less than 70 ps/nm. The advantages of the proposed scheme make it a preferable candidate for CDE in practical FTN coherent optical systems. Full article

As a typical high-order modulation format optimization technology, constellation probability shaping enhances generalized mutual information (GMI) by optimizing the probability distribution of each constellation point of the signal. It can improve the transmission capacity of the same order M Quadrature Amplitude Modulation (QAM) signal under the condition of limited average transmission power, and further narrow the gap with the Shannon limit capacity. The distribution matcher is a key part of constellation probability shaping since it not only ensures the one-to-one mapping of input and output sequences but also realizes the function of probability shaping. The constant composition distribution matcher (CCDM) structure is a widely utilized distribution matcher in the current probability shaping technology. Based on CCDM, a parallel distribution matcher scheme is proposed in this paper. It has a lower rate loss than CCDM for short output lengths (n is less than 100). Block lengths can be reduced by up to 30% with the same rate loss. When the GMI is the same as for the probability shaping (PS) 64QAM signal using CCDM, the OSNR required by the PS-64QAM signal using this scheme can be enhanced by 0.12dB, the block length can be reduced by 40%, and the transmission distance in a standard single-mode fiber can be slightly extended. Full article
