This study presents an innovative hybrid geothermal air conditioning system that combines conventional air-based heat exchange with ground heat exchange technology. The system features a ground heat exchanger placed downstream from the outdoor unit heat exchanger, requiring minimal modifications to conventional air conditioners through the addition of bypass flow paths and a four-way valve. This design ensures that the ground heat exchanger consistently operates after the outdoor unit heat exchanger in both cooling and heating modes. The researchers evaluated the proposed system’s performance through both computational simulation (1D-CAE) and experimental testing. Simulation results demonstrated significant efficiency improvements, with the hybrid system achieving a coefficient of performance (COP) of 4.51 compared to just 1.24 for conventional air conditioners under extreme temperature conditions (38 °C). The experimental validation with a shallow-buried (20 cm) ground heat exchanger confirmed an approximately 20% COP improvement across various ambient temperatures. The main advantages of this hybrid system over conventional geothermal systems include reduced installation costs due to shorter borehole lengths, separate air conditioning units and underground piping, and compatibility with existing control systems. The design addresses skilled labor shortages while enabling large-scale demonstration operations with minimal initial investment. Future work will focus on optimizing the burial depth and conducting long-term durability testing to advance practical implementation. Full article

Effective thermal management of electronic modules is crucial to the reliable operation of variable frequency air conditioners. For this reason, two types of plate-finned heat sinks of electronic modules were selected. The experiments utilized ceramic heating plates to simulate chip heating, conducted in an enthalpy difference laboratory with controlled environments. Four installation cases were analyzed to evaluate the impact of heat sink orientation, airflow direction, and structural layout. The results showed that when multiple chips were arranged on the same heat dissipation substrate, the heat dissipation process of the chips would be coupled with each other, and the rational layout of the chips played an important role in heat dissipation. In the case of cooling air impacting the jet, the heat dissipation performance of the heat sink was significantly improved, and the heat transfer coefficient of the heat sink was as high as 316.5 W·m⁻²·°C⁻¹, representing a 6.9% improvement over conventional designs (case I: 296.1 W·m⁻²·°C⁻¹). The maximum temperature of the chips could be reduced by 11.1%, which is 10.1 °C lower. This study will provide a reference for the optimization design of the heat sink of the electric control module in inverter air conditioners. Full article

Outdoor ozone (O₃) is elevated on hot, sunny days when residential air conditioning is used most. We evaluated the impact of direct evaporative coolers (ECs) and vapor-compression air conditioners (ACs) on indoor O₃ concentrations in homes (N = 31) in Utah County, Utah, United States of America. Indoor and outdoor O₃ concentrations were measured for 24 h at each home using nitrite-impregnated glass-fiber filters. AC homes (n = 16) provided a protective envelope from outdoor O₃ pollution. Only one AC home had O₃ levels above the limit of detection (LOD). Conversely, EC homes (n = 15) provided minimal protection from outdoor O₃. Only one EC home had O₃ levels below the LOD. The average indoor O₃ concentration in EC homes was 23 ppb (95% CI 20, 25). The indoor-to-outdoor (I/O) ratio for O₃ in EC homes was 0.65 (95% CI 0.58, 0.72), while the upper bound for the I/O ratio for AC homes was 0.13 (p < 0.001). Indoor exposure to O₃ for residents in EC homes is approximately five times greater than for residents of AC homes. Although ECs offer energy and cost-saving advantages, public health awareness campaigns in O₃-prone areas are needed, as well as research into O₃ pollution controls for direct ECs such as activated carbon filtration. Full article

The heat rejected by outdoor units of split A/C conditioners can impact the ambient outdoor environment of mixed-mode buildings. Nevertheless, how this environmental impact may affect the space-conditioning energy use and indoor air pollution is poorly understood. By coupling EnergyPlus and Fluent, this study examines the effects of outdoor units’ heat rejection on the building surroundings, building cooling load, and indoor PM_2.5 exposure of a six-storey mixed-mode building. The building had an open-plan room on each floor, with the outdoor unit positioned below the window. The coupled model was run for a selected day when the building was cooled by air conditioning and natural ventilation. Five mixed-mode cooling strategies were simulated, reflecting different window-opening schedules, airflow rates of outdoor units, and cooling set-points. The results indicate that compared with the always-air-conditioned mode, the mixed-mode operation could significantly mitigate the negative impact of heat rejection on space-cooling energy consumption. Increasing the airflow rate of outdoor units led to a lower increase in demand for space cooling and lower indoor PM_2.5 exposure. If one of the six rooms needs to be cooled to a lower temperature than the others; choosing the bottom-floor room helped achieve more energy savings and better indoor air quality. Full article

Axial-flow fans are widely used as cooling fans in the outdoor units of split-type air conditioners. The design of an axial-flow fan blade involves stacking several airfoils that can be differently designed for each spanwise section. However, the complex flow field around the fan blade, including circumferential and axial flows, presents challenges when applying the single airfoil theory. This study proposed a systematic performance-based design method for axial-flow fans using a cascade of airfoils based on the blade strip theory. The theory characterized the complex three-dimensional flow field driven by an axial-flow fan in terms of a two-dimensional cascade of airfoil flows. Computational fluid dynamics based on finite volume methods were used to predict the flow field and aerodynamic sound sources of an existing low-pressure axial-flow fan partially covered by a fan shroud, and the results were validated against experimental measurements. Three radial locations in the spanwise region from the hub to the blade tip that have a significant impact on aerodynamic performance were selected, and the two-dimensional flow field on a cylindrical surface with a constant radius was extracted from the three-dimensional flow field to characterize the performance of an axial fan. Then, the airfoils at the targeted span locations were optimized for a higher flow rate and greater efficiency via two-dimensional simulations using the cascades of the airfoil, and the selected optimized airfoils were applied to existing fan blades. The effectiveness of the proposed performance-based design method for low-pressure axial-flow fans was validated by the results, which showed that the redesigned fan blades with cascades of airfoils performed as predicted, increasing the intended higher flow rate by about 1%, improving power consumption by 8%, and lowering the overall sound pressure level by 1.5 dBA. Full article

To improve the performance of the aerodynamic properties and reduce the aerodynamic noise of an axial flow fan in the outdoor unit of an air conditioner, this study proposed a bionic forked trailing-edge structure inspired by the forked fish caudal fin and implemented by modifying the trailing edge of the prototype fan. The effect of the bionic forked trailing edge on the aerodynamic and aeroacoustic performance was investigated experimentally, and detailed analyses of the blade load and internal vortex structures were performed based on large-eddy simulations (LES). It is shown that the bionic forked trailing edge could effectively adjust the blade load distribution, reduce the pressure difference between the pressure side and suction side near the trailing edge of the blade tip region, and weaken the intensity and influence range of the inlet vortex (IV) and the tip leakage vortex (TLV). The discrete noise caused by the vortices in the rotor tip area was also reduced, particularly at the blade passing frequency (BPF) and its harmonic frequency. The experimental results confirmed the existence of an optimal bionic forked trailing-edge structure, resulting in the maximum power-saving rate γ of 7.5% and the reduction of 0.3 ~ 0.8 dB of aerodynamic noise, with an included angle θ_t of 13.5°. The detailed analysis of the internal vortex structures provides a good reference for the efficiency improvement and noise reduction of axial flow fans. Full article

Sustainable architecture is a key approach for creating sustainable cities and reducing the impact of climate change. In hot, arid regions, the passive design traditional architecture is known for its ability to provide comfortable indoor environments and outdoor shaded areas, in contrast to the use of energy-intensive air conditioners in a great deal of modern architecture. Thus, this research used a qualitative methodology based on ENVI-met software to study, investigate, and compare the thermal performance of two urban fabrics as case studies (traditional and modern districts) in the hot, arid climate of the United Arab Emirates. The thermal performance of the old urban districts was better than the new ones, with a lower maximum potential air temperature and an improvement in the level of thermal comfort, measured by a predicted mean vote. Moreover, it was found that enhancing the shade in the outdoor open areas in the modern district, mimicking the traditional passive design solutions, resulted in lower air temperature and PMVs. This research is expected to be one step among many towards creating sustainable, innovative modern architecture. Full article

This paper suggests a heat recovery concept that is based on preheating/precooling the cold/hot fresh outside air by means of the relatively hot/cold exhaust air in winter/summer weather conditions. To investigate the feasibility of such a concept, an experimental setup is established to simulate conditions similar to an All-Air HVAC system. The prototype consists of a 6.7-m³ air-conditioned chamber by means of a split unit of 5.3-kW capacity. The heat recovery module consists of a duct system that is used to reroute the exhaust air from a conditioned chamber to flow through the fin side of a fin-and-tube heat exchanger of crossflow type. At the same time, outside, fresh air is flowing through the tube side of the fin-and-tube heat exchanger. A parametric study is performed to assess the amount of heat that can be recovered by varying the mass flow rates on both the duct and heat exchanger sides. The results show that up to 200 W of power can be saved for an exhaust flow rate of 0.1 kg/s and a fresh, outdoor air flow rate of 0.05 kg/s. Environmentally speaking, this leads to a reduction in production of about 1 tons of CO₂ per year when the system operates 24 h/day. From an economic point of view, the system is able to return its price after 1.5 years when it is used 24 h per day during hot days at 196-W thermal recovery, whereas it requires at least 6.3 years when it is used during cold days at a 60-W thermal recovery rate, which, in both cases, represents a duration less than the lifespan of an air conditioner. Full article

In this work, an atmospheric water generator (AWG) system called the medium-scale AWG (MSAWG) was designed, fabricated, and tested in Universiti Sains Malaysia (USM) under the outdoor tropical climate conditions of Malaysia to investigate the amount of fresh water production in successive periods of 24 h. The MSAWG consisted of 18 thermoelectric cooler (TEC) units, 18 internal finned heat sinks, 18 external finned heat sinks, 18 direct current (DC) cooling fans, an air-conditioner mesh air filter, and an axial ventilation fan. It was found from the results that the hourly values of water production of MSAWG were proportional to the hourly rates of relative humidity, but they were inversely affected by the corresponding hourly values of the ambient temperature. Night-time and early morning were the most effective times to produce the highest amount of fresh water from Malaysia’s atmosphere using MSAWG, as the increase in the rates of relative humidity and the decrease in the values of ambient temperature occurred over these periods. Based on the varied hourly rates of relative humidity with the ranges between the minimum rate of 55% and maximum rate of 85%, an equation of Y = 0.2285X + 36.675 with R² of 0.9404 was achieved from the 48 h experimental work to estimate the water production of MSAWG in Malaysia, where Y and X were indicated as the rate of relative humidity and the value of water production, respectively, in this equation. In conclusion, the MSAWG produced a consecutive cumulative water volume of 3.432 and 6.997 L experimentally in the periods of 24 and 48 h, respectively. The estimated cost per liter for MSAWG was USD 0.466. Some water quality parameters of the fresh water produced by MSAWG were analysed in the laboratory, which showed that they met the World Health Organization (WHO) drinking water standards. Therefore, MSAWG can be employed as a sustainable alternative to generate annual daily fresh water from Malaysia’s tropical atmosphere and aid in mitigating the problem of unpredicted water shortage in the country. Full article

Demand for air conditioners is steadily increasing due to global warming and improved living standards. The noise, as well as the performance of air conditioners, are recognized as one of the crucial factors that determine the air conditioners’ values. The performance and noise of the air conditioner are mostly determined by those of its outdoor unit, which in turn depend on those of the cooling fan unit. Therefore, a cooling fan unit of high-performance and low noise is essential for air-conditioner manufacturers and developers. In this paper, the flow performance and flow noise of the entire outdoor unit with an axial cooling fan in a split-type air-conditioner were investigated. First, a virtual fan tester constructed by using about 18 million grids is developed for highly resolved flow simulation. The unsteady Reynolds-Averaged Navier–Stokes equations are numerically solved by using finite-volume computational fluid dynamics techniques. To verify the validity of the numerical analysis, the predicted P–Q curve of the cooling fan in a full outdoor unit is compared with the measured one. There was an excellent agreement between the two curves. The further detailed analysis identifies the coherent vortex structures between the fan blade tip and fan orifice, which adversely affect the flow performance and causes flow noise. Based on this analysis, the optimization of fan orifice was carried out using the response surface method with three geometric parameters: inlet radius, neck length, and outlet angel of the orifice. The optimum layout for the high flow rate is proposed under the understanding that the increased flow rate can be converted to noise reduction. The additional computation using the proposed optimum orifice shows that the flow rate is increased by 4.6% at the operating point. Finally, the engineering sample was manufactured by using the optimum design, and the measured data confirmed that the flow rate were increased by 2.1%, the noise reduction was made by 2.8 dBA, and the power consumption is reduced by 4.0% at the operating rotational speed. Full article
