Over the past two decades, several add-on modules for computational fluid dynamics (CFD) software focusing on modelling electrochemical processes and two-phase effects within fuel cells have been described in the literature. Most of these models are based on custom-written code that is not openly accessible to everyone. Furthermore, several commercial CFD codes offer specific modules for modelling fuel cells. Here, code modification is difficult to achieve. This work analyses and further develops the PEMFC toolbox of Kone et al. for use in OpenFOAM to simulate low temperature (LT-)PEM fuel cells. This model is freely available under the GNU GPLv3 licence. The present work focuses on enhanced physical and electrochemical modelling and improved user-friendliness. The major improvements compared to the original toolbox will be detailed in the article, together with the first results obtained. The improved PEMFC toolbox is validated using experimental data from an automotive fuel cell stack design. Furthermore, these results are compared to the original Kone model, and a commercially available CFD model. The improved toolbox reproduces both the experimentally measured polarisation curve and the current density distribution quite accurately, producing results that are fairly comparable to the more sophisticated commercial model. Full article

The offshore jack-up production platform operates in extreme and unpredictable marine environments. Therefore, its structural strength must be designed to withstand harsh conditions, particularly hydrodynamic loads from waves and ocean currents. This study aims to numerically analyze the interaction of marine hydrodynamic forces with a jack-up production platform using OpenFOAM v1606, a Computational Fluid Dynamics (CFD) software. Specifically, the research evaluates a buoyancy-modified k−ω SST turbulence model based on the Standard Gradient Diffusion Hypothesis (SGDH) on a 3D jack-up platform model. The analysis is conducted using a Stokes 5th-order wave model within the waves2Foam toolbox, considering four variations in wave height and period. The results demonstrate that the modified turbulence model provides more accurate predictions. Additionally, they reveal that the forces acting on the platform’s walls are directly proportional to wave height and period, with the highest recorded load reaching 4000 N in Case A, where the wave height and period are 5.4 m and 5.9 s, respectively. Furthermore, it is observed that most of the forces exerted on the platform hull are vertical, primarily due to the negative pressure on the platform’s bottom side. Full article

No alternatives are currently available to operate industrial furnaces, except for hydrocarbon fuels. Plant managers, therefore, face at least two challenges. First, environmental legislation demands emission reduction. Second, changes in the origin of the fuel might cause unforeseen changes in the heat release. This paper develops the hypothesis for the detailed control of the combustion process using computational fluid dynamic models. A full-scale mock-up of a rotary cement kiln is selected as a case study. The kiln is fired by the non-premixed combustion of Dutch natural gas. The gas is injected at Mach $0.6$ via a multi-nozzle burner located at the outlet of an axially mounted fuel pipe. The preheated combustion air is fed in (co-flow) through a rectangular inlet situated above the attachment of the fuel pipe. The multi-jet nozzle burner enhances the entrainment of the air in the fuel jet. A diffusion flame is formed by thin reaction zones where the fuel and oxidizer meet. The heat formed is transported through the freeboard, mainly via radiation in a participating medium. This turbulent combustion process is modeled using unsteady Favre-averaged compressible Navier–Stokes equations. The standard k-$ϵ$ equations and standard wall functions close the turbulent flow description. The eddy dissipation concept model is used to describe the combustion process. Here, only the presence of methane in the composition of the fuel is accounted for. Furthermore, the single-step reaction mechanism is chosen. The heat released radiates throughout the freeboard space. This process is described using a P1-radiation model with a constant thermal absorption coefficient. The flow, combustion, and radiative heat transfer are solved numerically using the OpenFoam simulation software. The equations for flow, combustion, and radiant heat transfer are discretized on a mesh locally refined near the burner outlet and solved numerically using the OpenFoam simulation software. The main results are as follows. The meticulously crafted mesh combined with the outlet condition that avoids pressure reflections cause the solver to converge in a stable manner. Predictions for velocity, pressure, temperature, and species distribution are now closer to manufacturing conditions. Computed temperate and species values are key to deducing the flame length and shape. The radiative heat flux to the wall peaks at the tip of the flame. This should allow us to measure the flame length indirectly from exterior wall temperature values. The amount of thermal nitric oxide formed in the flame is quantified. The main implication of this study is that the numerical model developed in this paper reveals valuable information on the combustion process in the kiln that otherwise would not be available. This information can be used to increase fuel efficiency, reduce spurious peak temperatures, and reduce pollutant emissions. The impact of the unsteady nature of the flow on the chemical species concentration and temperature distribution is illustrated in an accompanying video. Full article

The reduction of emissions from large industrial furnaces critically relies on insights gained from numerical models of turbulent non-premixed combustion. In the article Mitigating Thermal NOx by Changing the Secondary Air Injection Channel: A Case Study in the Cement Industry, the authors present the use of the open-source OpenFoam software environment for the modeling of the combustion of Dutch natural gas in a cement kiln operated by our industrial partner. In this paper, various model enhancements are discussed. The steady-state Reynolds-Averaged Navier-Stokes formulation is replaced by an unsteady variant to capture the time variation of the averaged quantities. The infinitely fast eddy-dissipation combustion model is exchanged with the eddy-dissipation concept for combustion to account for the finite-rate chemistry of the combustion reactions. The injection of the gaseous fuel through the nozzles occurs at such a high velocity that a comprehensive flow formulation is required. Unlike in Mitigating Thermal NOx by Changing the Secondary Air Injection Channel: A Case Study in the Cement Industry, wave transmissive boundary conditions are imposed to avoid spurious reflections from the outlet patch. These model enhancements result in stable convergence of the time-stepping iteration. This in turn increases the resolution of the flow, combustion, and radiative heat transfer in the kiln. This resolution allows for a more accurate assessment of the thermal NO-formation in the kiln. Results of a test case of academic interest are presented. In this test case, the combustion air is injected at a low-mass flow rate. Numerical results show that the flow in the vicinity of the hot end of the kiln is unsteady. A vortex intermittently transports a fraction of methane into the air stream and a spurious reaction front is formed. This front causes a transient peak in the top wall temperature. The simulated combustion process is fuel-rich. All the oxygen is depleted after traveling a few diameters into the kiln. The thermal nitric oxide is formed near the burner and diluted before reaching the outlet. At the outlet, the simulated thermal NO concentration is equal to 1 ppm. The model is shown to be sufficiently mature to capture a more realistic mass inflow rate in the next stage of the work. Full article

Metallic flow field plates, also called bipolar plates, are an important component of fuel cell stacks, electrolyzers, hydrogen purification and compression stacks. The manufacturing of these plates by means of stamping or hydroforming is highly suitable for mass production. In this work, a toolbox is created that is suitable for a screening process of different flow field design variants. For this purpose, the geometry and computational mesh are generated in an automated manner. Basic building blocks are combined using the open source software SALOME, and these allow for the construction of a large variant of serpentine-like flow field structures. These geometric variants are evaluated through computational fluid dynamics (CFD) simulations with the open source software OpenFOAM. The overall procedure allows for the screening of more than 100 variants within one week using a standard desktop computer. The performance of the flow fields is evaluated on the basis of two parameters: the overall pressure difference across the plate and the relative difference of the hydrogen concentration at the outlet of the channels. The results of such a screening first provide information about optimum channel geometry and the best choice of the general flow field layout. Such results are important at the beginning of the design process, as the channel geometry has an influence on the selection of the metal for deep drawing or hydroforming processes. Full article

Simulating the steam dumping process of a pressurized relief tank is a challenging engineering problem, due to the massive computing resource requirements and its complex physical models. This study gave a comprehensive 3D numerical study for the transient dumping process from the PRT (Pressurizer Relief Tank) to the room containing the tank. The physical model, geometry design and meshing strategy, along with the numerical techniques, have been described in detail. Through parallel simulations based on the open source CFD toolbox OpenFOAM, numerical results for the temperature, pressure, and the velocity distribution are presented. The results show that the maximum velocity throughout the whole domain is 967 m/s over Mach 2 and the maximum pressure on the roof of the room is 2.8 atm. It could provide the guidance information for the safety design of the reactor coolant system. Additionally, comparison cases between OpenFOAM and CFX are tested, and it turns out that OpenFOAM could produce comparable accuracy with commercial CFD software and scale to much more computing cores in parallel simulations. Full article

The reactive process of reinforced thermoset injection molding significantly influences the mechanical properties of the final composite structure. Therefore, reliable process simulation is crucial to predict the process behavior and relevant process effects. Virtual process design is thus highly important for the composite manufacturing industry for creating high quality parts. Although thermoset injection molding shows a more complex flow behavior, state of the art molding simulation software typically focusses on thermoplastic injection molding. To overcome this gap in virtual process prediction, the present work proposes a finite volume (FV) based simulation method, which models the multiphase flow with phase-dependent boundary conditions. Compared to state-of-the-art Finite-Element-based approaches, Finite-Volume-Method (FVM) provides more adequate multiphase flow modeling by calculating the flow at the cell surfaces with an Eulerian approach. The new method also enables the description of a flow region with partial wall contact. Furthermore, fiber orientation, curing and viscosity models are used to simulate the reinforced reactive injection molding process. The open source Computational-Fluid-Dynamics (CFD) toolbox OpenFOAM is used for implementation. The solver is validated with experimental pressure data recorded during mold filling. Additionally, the simulation results are compared to commercial Finite-Element-Method software. The simulation results of the new FV-based CFD method fit well with the experimental data, showing that FVM has a high potential for modeling reinforced reactive injection molding. Full article
