In the current context of global communications, HF (High Frequency) NVIS (Near Vertical Incidence Skywave) data networks can be of strategic importance, providing short- and medium-range communication capabilities independent of terrestrial configuration and existing conventional communications infrastructure. They are essential in critical conditions, such as natural disasters or conflicts, when terrestrial networks are unavailable. This paper investigates the development of such systems for HF NVIS data communications by introducing a customized Orthogonal Frequency Division Multiplexing (OFDM) protocol with parameters adapted to HF ionospheric propagation, implemented on Software-Defined Radio (SDR) systems, which provide extensive configurability and high adaptability to varying HF channel conditions. This work presents an innovative approach to the application of OFDM narrow-channel aggregation in the HF spectrum, a technique that significantly enhances system performance. The aggregation enables a more efficient utilization of the available spectrum and an increase in the data transmission rate, which represents a substantial advancement in NVIS communications. The implementation was realized using an SDR system, which allows flexible integration of the new OFDM protocol and dynamic adaptation of resources. The work also includes the development of a messaging application capable of using this enhanced HF communication system, taking advantage of the new features of channel aggregation and SDR flexibility. This application demonstrates the applicability of the protocol in real-world scenarios and provides a robust platform for data transmission under conditions of limited access to other means of communication. Thus, this study contributes to the technological advancement of NVIS communications and opens new research and deployment directions in HF communications. Full article

Systems for atmospheric research and wireless communication use the High Frequency (HF) radio spectrum. At these frequencies, typically up to 20 MHz, the ambient electromagnetic noise is stronger than the noise generated by the receiver itself, thereby limiting the sensitivity of the instruments. Especially in urban areas, the noise level is high. In remote rural environments, where artificial noise sources are absent, a much lower noise level is observed. It has been shown that this noise arrives via ionospheric propagation and consists of impulsive noise from lightning and a background component that resembles additive white Gaussian noise. To establish the absolute field strength of this background noise component, a direction- and polarization-agnostic antenna is realized by adding the power of two orthogonal antenna elements in the digital domain. To suppress radio signals arriving via ionospheric propagation—of which the spectral and temporal aspects are not known a priori—a novel adaptive filter is demonstrated that separates the background noise from the radio signals in the joint frequency-time domain. This method is demonstrated using measurements from a polarimetric experiment on 7 MHz in a remote rural area in Catalonia. The results are submitted to the International Telecommunication Union for the validation of ambient noise models. Full article

Emergency situations such as wildfires, water floods, or even terrorist attacks require continuous communication between the coordination centres, the several on-the-field teams, and their respective devices to properly address the adverse circumstances. From a technological point of view, this can be best seen as a live Ubiquitous Sensor Network—composed of human beings (e.g., first responders, victims) and devices (e.g., drones, environmental sensors, radios)—with stringent and special communication requirements in terms of flexibility, mobility, reliability, bandwidth, heterogeneity, and speed of deployment. However, for this specific use case, most of the already deployed and well-known communication technologies (e.g., satellite, 4G/5G) might become unusable and hard to repair due to the associated effects of the disaster itself. The purpose of this paper is (1) to review the emergency communications challenges, (2) to analyse the existing surveys on technologies for emergency situations, (3) to conduct a more updated, extensive, and systematic review of the emergency communications’ technologies, and (4) to propose a heterogeneous communication architecture able to communicate between moving agents in harsh conditions. The proposed approach is conceived to link the relocating agents that constitute a Ubiquitous Sensor Network spanning a large-scale area (i.e., hundreds of square kilometres) by combining Near Vertical Incidence Skywave technologies with Drone-Based Wireless Mesh Networks. The conclusions derived from this research aim to set up the fundamentals of a rapidly deployable Emergency Communications System inspired by the Ubiquitous Sensor Network paradigm. Full article

The SHETLAND-NET research project aims to build an Internet of Things (IoT) telemetry service in Antarctica to automatize the data collection of permafrost research studies on interconnecting remote wireless sensor networks (WSNs) through near vertical incidence skywave (NVIS) long fat networks (LFN). The proposed architecture presents some properties from challenging networks that require the use of delay tolerant networking (DTN) opportunistic techniques that send the collected data during the night as a bulk data transfer whenever a link comes available. This process might result in network congestion and packet loss. This is a complex architecture that demands a thorough assessment of the solution’s viability and an analysis of the transport protocols in order to find the option which best suits the use case to achieve superior trustworthiness in network congestion situations. A heterogeneous layer-based model is used to measure and improve the trustworthiness of the service. The scenario and different transport protocols are modeled to be compared, and the system’s trustworthiness is assessed through simulations. Full article

Despite high costs and lengthy deployments, satellite communications have traditionally been used to provide coverage in remote areas. However, given the fact that there is no radio infrastructure available in these areas, Near Vertical Incidence Skywave (NVIS) technology has positioned itself as an attractive alternative to communicate with low-power nodes in remote areas. This type of communication works in the HF frequency range complying with STANAG and MIL-STD standards, which define a physical layer for scenarios that differ from NVIS and low-power communication. The purpose of this paper was to present the definition of a new communication physical layer based on single-carrier frequency-domain equalization (SC-FDE) based on these standards but adapted to the ionospheric communication channel. This physical layer was compared to an OFDM-based layer from a previous study. The experiments performed show that this new approach achieves better results than OFDM in terms of a higher signal quality with a higher specific BER probability. Finally, this layer was also used in the theoretical design of an NVIS gateway to link sensor network devices spanning large-scale remote areas in a secure manner in the context of ubiquitous sensor networks (USN). Full article

Sensor networks have become more popular in recent years, now featuring plenty of options and capabilities. Notwithstanding this, remote locations present many difficulties for their study and monitoring. High-frequency (HF) communications are presented as an alternative to satellite communications, being a low-cost and easy-to-deploy solution. Near vertical incidence skywave (NVIS) technology provides a coverage of approximately 250 km (depending on the frequency being used and the ionospheric conditions) without a line of sight using the ionosphere as a communication channel. This paper centers on the study of the ionosphere and its characteristic waves as two independent channels in order to improve any NVIS link, increasing its robustness or decreasing the size of the node antennas through the appliance of specific techniques. We studied the channel sounding of both the ordinary and extraordinary waves and their respective channels, analyzing parameters such as the delay spread and the channel’s availability for each wave. The frequency instability of the hardware used was also measured. Furthermore, the correlation coefficient of the impulse response between both signals was studied. Finally, we applied polarization diversity and two different combining techniques. These measurements were performed on a single frequency link, tuned to 5.4 MHz. An improvement on the mean bit energy-to-noise power spectral density (E_b/N₀) was received and the bit error rate (BER) was achieved. The results obtained showed that the extraordinary mode had a higher availability throughout the day (15% more availability), but a delayed spread (approximately 0.3 ms mean value), similar to those of the ordinary wave. Furthermore, an improvement of up to 4 dB was achieved with the usage of polarization diversity, thus reducing transmission errors. Full article

The number of Internet of Things (IoT) devices has experienced a large growth during the last decade, as well as the data volume gathered from remote sensors. Satellites are still a suitable communication method and may be preferable for a remote ubiquitous sensor network (USN), which sometimes are located in places without much communications infrastructure where coverage is the principal drawback. Alternatively, the proposed solution for this article aims at a near-vertical incidence skywave (NVIS) channel for high frequencies (HF) with a low-cost platform, allowing a low-power transmissions coverage area up to 250 km for USN. The HF standards are focused on generic communication channels not being robust for NVIS communications. In this article we study and test an alternative based on orthogonal frequency-division multiplexing (OFDM) modulations to make them more robust and less dependent on the channel NVIS communications. For that purpose, we test the HF standard modulations and a designed OFDM modulation to prove the robustness of each. This study has been tested between Barcelona and Tarragona, using different transmission power levels and modulation orders. Full article

Every year, the number of ubiquitous sensor networks (USN) is increasing and the need for remote USN communications is emerging in some scenarios. As an alternative to satellite communications, more interests are focused on high frequencies (HF) communications as a low-cost option to reach links of more than 250 km without a line of sight. The HF standards are designed for generic communication channels being not robust for near vertical incidence skywave (NVIS) USN. In this article, we propose a new protocol for USN in remote places based on NVIS communications. For that purpose, we study the main characteristics of the NVIS channel with the presence of groundwaves, particularly in Antarctica. We analyze the availability of the channel, the height of the layers, the delay spread, and the Doppler spread. On the basis of the results obtained, we propose two protocols based on an OFDM (orthogonal frequency division multiplexing) modulation depending on the presence of the groundwave at the receiver. Finally, we make a simulation of the two OFDM configurations and we compare it with real tested standard modulations. The results show a better performance of the new protocol compared to the current HF standards. Full article

Every year more interest is focused on high frequencies (HF) communications for remote sensing platforms due to their capacity to establish links of more than 250 km without a line of sight and due to them being a low-cost alternative to satellite communications. In this article, we study the ionospheric ordinary and extraordinary waves to improve the applications of near vertical incidence skywave (NVIS) on a single input multiple output (SIMO) configuration. To obtain the results, we established a link of 95 km to test the diversity combining of ordinary and extraordinary waves by using selection combining (SC) and equal-gain combining (EGC) on a remote sensing platform. The testbench is based on digital modulation transmissions with power transmission between 3 and 100 W. The results show us the main energy per bit to noise spectral density ratio (E_b/N₀) and the bit error rate (BER) differences between ordinary and extraordinary waves, SC, and EGC. To conclude, diversity techniques show us a decrease of the power transmission need, allowing for the use of compact antennas and increasing battery autonomy. Furthermore, we present three different improvement options for NVIS SIMO remote sensing platforms depending on the requirements of bitrate, power consumption, and efficiency of communication. Full article

In communications, channel models are useful approximations to the performance of a real channel, which most of the time is not available for repeated tests. In this work we present the problem of the real Near Vertical Incidence Skywave (NVIS) ionospheric scenario channel sounding, and evaluate the channel propagation characteristics in terms of frequency and time spread, with the final goal of designing a channel model. An NVIS channel model can be obtained from the evaluated channel parameters; however, on one hand, there is the problem of missing data due to bad channel performance in some frequencies, and, on the other hand, the measured parameters have strong dependencies between them that cannot be evinced directly. In this work, we conduct a first set of analyses of the measured parameters of the soundings to determine the dependencies in terms of quality of the channel propagation but refer mainly to the Doppler spread and the delay spread in the sensor. This classification approach allows us to face the second part of the research focusing on the design of the channel model for the ionospheric communication of remote sensors. Full article

This article describes the design and validation of deployable low-power probes and sensors to investigate the influence of the ionosphere and the Earth’s magnetic field on radio wave propagation below the plasma frequency of the ionosphere, known as Near Vertical Incidence Skywave (NVIS) propagation. The propagation of waves that are bent downward by the ionosphere is dominated by a bi-refractive mechanism called ‘magneto-ionic propagation’. The polarization of both downward waves depends on the spatial angle between the Earth’s magnetic field and the direction of propagation of the radio wave. The probes and sensors described in this article are needed to simultaneously investigate signal fading and polarization dynamics on six radio wave propagation paths. The 1-Watt probes realize a 57 dB signal-to-noise ratio. The probe polarization is controlled using direct digital synthesis and the cross-polarization is 25–35 dB. The intermodulation-free dynamic range of the sensor exceeds 100 dB. Measurement speed is 3000 samples/second. This publication covers design, practical realization and deployment issues. Research performed with these devices will be shared in subsequent publications. Full article
