This paper proposes a full-automatic high-efficiency Mueller matrix microscopic imaging (MMMI) system based on the tissue microarray (TMA) for cancer inspection for the first time. By performing a polar decomposition on the sample’s Mueller matrix (MM) obtained by a transmissive MMMI system we established, the linear phase retardance equivalent waveplate fast-axis azimuth and the linear phase retardance are obtained for distinguishing the cancerous tissues from the normal ones based on the differences in their polarization characteristics, where three analyses methods including statistical analysis, the gray-level co-occurrence matrix analysis (GLCM) and the Tamura image processing method (TIPM) are used. Previous MMMI medical diagnostics typically utilized discrete slices for inspection under a high-magnification objective (20×–50×) with a small field of view, while we use the TMA under a low-magnification objective (5×) with a large field of view. Experimental results indicate that MMMI based on TMA can effectively analyze the pathological variations in biological tissues, inspect cancerous cervical tissues, and thus contribute to the diagnosis of postoperative cancer biopsies. Such an inspection method, using a large number of samples within a TMA, is beneficial for obtaining consistent findings and good reproducibility. Full article

Polarization characteristics are significantly crucial for tasks in various fields, including the remote sensing of oceans and atmosphere, as well as the polarization LIDAR and polarimetric imaging in scattering media. Many polarimetric metrics (such as the degree of polarization, polarization angle diattenuation, and depolarization) have been proposed to enrich the characterization and improve the task performance in scattering media; yet, their related efficacy is limited, especially in high turbidity conditions. The indices of polarimetric purity (IPPs), including three different depolarization metrics, have been successfully applied to biomedical diagnosis. However, it is still debatable whether IPPs also are excellent metrics for identifying or distinguishing objects in scattering media. In this work, we seek to provide physical insights into the application of distinguishing and identifying different objects via IPPs. Imaging experiments are devised and performed on different objects, e.g., metals and plastics, under different turbidity levels, demonstrating the superiority of IPPs as excellent metrics for object identification in scattering conditions. The experimental results show that the IPPs images can enhance image contrast and improve discriminability, as well as break the limitation of traditional intensity-model imaging techniques when further combined with dehazing or enhancing algorithms. Importantly, as the used Mueller matrix (MM) and the related IPPs can also be obtained via other types of MM polarimeters (e.g., PolSAR and MM microscopy), the proposed solution and idea have potential for such applications as biomedical imaging, photogrammetry, and remote sensing. Full article

Pharmacokinetic/pharmacodynamic (PKPD) studies of anti-infectives are frequently performed in in vitro infection models where accurate quantification of antibiotic concentrations in bacterial growth media is crucial to establish PK/PD relationships. Here, a sensitive and rapid high-performance liquid chromatography (HPLC) method was developed to quantify tedizolid (TDZ) in the bacterial growth medium Mueller-Hinton broth (MHB). Matrix components were separated by direct protein precipitation with methanol (1:1). The chromatographic separation was carried out in a Dionex Ultimate 3000 HPLC system using an Accucore^® C-18 RPMS HPLC column (2.6 µm, 100 × 2.1 mm) using isocratic elution with 25% acetonitrile and 75% of 0.1% formic acid. The lower limit of quantification was 0.03 mg/L when measured at 300 nm. Following relevant European Medicine Agency guidelines, the method was successfully validated for linearity, selectivity, recovery, inter- and intra-day precision, and accuracy and stability. When applied to in vitro PKPD studies, the method successfully quantified a range of TDZ concentration (Cmin, 0.09-Cmax, 0.65 mg/L) in MHB. The analyzed concentrations were in line with the planned PK profiles. The application of the developed method to quantify TDZ in MHB in in vitro PKPD studies is warranted. Full article

Traditionally, strain gauge, extensometer, and reflection tracking markers have been used to measure the deformation of materials under loading. However, the anisotropy and inhomogeneity of most biological materials restricted the accessibility of the real strain field. Compared to the video extensometer, digital image correlation has the advantage of providing full-field displacement as well as strain information. In this study, a digital image correlation method (DIC) measurement system was employed for chicken breast bio-tissue deformation measurement. To increase the contrast for better correlation, a mixture of ground black pepper and white sesame was sprayed on the surface of samples. The first step was to correct the distorted image caused by the lens using the inverse distorted calibration method and then the influence of subset size and correlation criteria, sum of squared differences (SSD), and zero-normalized sum of squared differences (ZNSSD) were investigated experimentally for accurate measurement. Test results of the sample was translated along the horizontal direction from 0 mm to 3 mm, with an increment of 0.1 mm and the measurement result was compared, and the displacement set on the translation stage. The result shows that the error is less than 3%, and accurate measurement can be achieved with proper surface preparation, subset size, correlation criterion, and image correction. Detailed examination of the strain values show that the strain ε_x is proportional to the displacement of crosshead, but the strain ε_y indicates the viscoelastic behavior of tested bio-tissue. In addition, the tested bio-tissue’s linear birefringence extracted by a Mueller matrix polarimetry is for comparison and is in good agreement. As noted above, the integration of the optical parameter measurement system and the digital image correlation method is proposed in this paper to analyze the relationship between the strain changes and optical parameters of biological tissue, and thus the relative optic-stress coefficient can be significantly characterized if Young’s modulus of biological tissue is known. Full article

We constructed an active imaging model within 10 km of the atmosphere from the satellite to the ground based on Monte Carlo (MC) algorithm, and, because of the inhomogeneous distributions of the scattering particles in atmosphere environment, 10 km atmosphere layer was divided into ten layers in our model. The MC algorithm was used to simulate the transmission process of photons through the atmosphere. By launching lasers of linear polarization states from satellites to ground, the intensity, degree of polarization (DoP), polarization difference (PD), and polarization retrieve (PR) images can be obtained. The contrast of the image, peak signal to noise ratio (PSNR), and structural similarity index (SSI) were used to evaluate the imaging quality. The simulated results demonstrate that the contrast of images is degraded as the atmosphere becomes worse. However, PR imaging have a better contrast and better visibility in different atmospheric conditions. Meanwhile, we found that Mueller matrix (MM) can retrieve the original images very well in a certain range of atmospheric conditions. Finally, the simulation also shows that different wavelengths of light sources have different penetration characteristics, and, in general, infrared light shows better performances than visible light for imaging. Full article

Electrospun polycaprolactone:gelatin (PCL:GT) fibre scaffolds are widely employed in the field of tissue implants. Here, the orientation of fibres plays an important role in regard to implantation due to the impact on the mechanical properties. Likewise, the orientation of collagen fibres in skin tissue is relevant for dermatology. State-of-the-art fibre orientation measurement methods like electron microscopy are time consuming and destructive. In this work, we demonstrate polarimetry as a non-invasive approach and evaluate its potential by measuring the Mueller matrix (MM) of gelatin and collagen containing samples as simple skin tissue phantoms. We demonstrate that it is possible to determine the orientation of PCL:GT fibre scaffolds within one MM measurement. Furthermore, we determine the structural orientation in collagen film samples. Currently, the diagnosis of skin diseases is often performed by image analysis or histopathology respectively, which are either subjective or invasive. The method presented, here, provides an interesting alternative approach for such investigations. Our findings indicate that the orientation of collagen fibres within skin lesions might be detectable by MM measurements in the future, which is of interest for skin diagnostics, and will be further investigated during the next step. Full article

Electrospun fiber scaffolds are gaining in importance in the area of tissue engineering. They can be used, for example, to fabricate graded implants to mimic the tendon bone junction. For the grading of the tensile strength of the fiber scaffolds, the orientation of the fibers plays a major role. This is currently measured by hand in scanning electron microscope (SEM) images. In this work, a correlation between polarimetric information generated by measuring the Mueller matrix (MM) and the orientation of the fibers of electrospun fiber scaffolds is reported. For this, the MM of fiber scaffolds, which were manufactured with different production parameters, was measured and analyzed. These data were correlated with fiber orientation and mechanical properties, which were evaluated in an established manner. We found that by measurement of the MM the production parameters as well as the relative orientation of the fibers in space can be determined. Thus, the MM measurement is suitable as an alternative tool for non-contact, non-destructive determination of the production parameters and, thus, the degree of alignment of electrospun fiber scaffolds. Full article
