Subsurface exploration of Mars is essential for understanding its geological evolution and potential water ice distribution. Subsurface radar sounding is an effective technique for detecting layered structure and physical parameters beneath the Martian surface. However, existing methods often neglect the influence of loss tangent and rely on data-driven approaches without physical constraints, limiting their accuracy in high-lossy environments and reducing their physical interpretability. To overcome these limitations, this paper proposes a dual-branch physics-informed network (DBPINet) for the joint inversion of layer thickness, permittivity, and loss tangent of Martian layered media. This method introduces a dual signal loss tangent branch (DSLT-Branch) to extract frequency-dependent attenuation features from dual-frequency radar signals and incorporates a physics-informed loss function based on the electromagnetic transmission-line model to embed physical laws into the learning process. Multiple numerical and measured experiments demonstrate the effectiveness of DBPINet. Compared with the MLP-based baseline and the more advanced LMPINet, DBPINet achieves significant improvements in different layered subsurface models. Specifically, on the three-layer models, the mean absolute percentage error (MAPE) for layer thickness, permittivity, and loss tangent is reduced by 4.793%, 3.600% and 4.559%, respectively. Meanwhile, DBPINet exhibits enhanced robustness under noisy conditions. When applied to real Mars Advanced Radar for Subsurface and Ionosphere Sounding (MARSIS) data acquired over the Medusae Fossae Formation (MFF) region, the inversion results reveal a three-layer subsurface structure (a volcanic ash surface layer, an ice-mixed basaltic middle layer, and a basaltic basement) that is consistent with existing geological interpretations. Full article

As the most similar planet to Earth in the solar system, Mars’ surface and subsurface water ice provide important clues for studying extraterrestrial life and planetary evolution. Since the 1960s, the exploration of Martian water ice has gradually become a focus of scientific research. This article reviews the evolution of Mars water-ice detection technology from 1990 to 2024 through bibliometric analysis, with a focus on the application of key technologies such as radar detection, image analysis, in situ analysis, thermal infrared imaging, and neutron spectroscopy. The analysis results indicate that research in the field of Mars water-ice exploration has been increasing year by year, with major research institutions including National Aeronautics and Space Administration (NASA) and the California Institute of Technology (CIT), and key researchers such as Professor James W. Head making significant contributions. Keyword analysis shows that current research is focused on the distribution and status of water ice and its relationship with the Martian climate, and the application of modern exploration technology has also become a hot topic. However, despite continuous technological advancements, issues such as detection depth and data analysis accuracy remain challenges. The complex terrain and extreme climate conditions make water-ice detection difficult. This article also points out that future research should focus on integrating multiple high-precision detection techniques for consistent results and the application of new technologies such as time-varying gravity. Moreover, combined with the application of artificial intelligence, this will provide new directions for the precise detection and data-processing of Martian water ice. Full article

The polar regions of Mars, including the South and North Poles, are crucial for studying Martian climate and geological history, as they contain the largest reservoir of subsurface water ice. This study introduces a new approach for reflector detection, which includes radargram denoising to effectively enhance the signal of underground reflectors, peak detection to extract the positions of subsurface stratification from the radar echoes, and peak points connection to form continuous layers. The mapped enhancement denoising process involves a linear brightness adjustment and a fourth-order diffusion equation to enhance the signal of the subsurface layers for effective detection. The subsurface detection extracts the surface and subsurface peak points based on a peak detection algorithm, while using locally window-enhanced peak filtering and Kullback–Leibler (KL) divergence mapping to filter out non-stratified peak points. Finally, the layered connection process uses the proximity parameter to connect peak points in the same layer. Applied to multiple SHARAD (Shallow Radar) images at the Martian poles, this algorithm demonstrated a false detection rate below 5%. Compared to other methods, this method has a missed detection rate of less than 5% and, additionally, exhibits fewer discontinuities in layer connectivity. Therefore, this algorithm shows exceptional proficiency and applicability in analyzing the complex subsurface structures of the Martian polar regions. Full article

The planet Mars is the most probable among the terrestrial planets in our solar system to support human settlement or colonization in the future. The detection of water ice or liquid water on the shallow subsurface of Mars is a crucial scientific objective for both the Chinese Tianwen-1 and United States Mars 2020 missions, which were launched in 2020. Both missions were equipped with Rover-mounted ground-penetrating radar (GPR) instruments, specifically the RoPeR on the Zhurong rover and the RIMFAX radar on the Perseverance rover. The in situ radar provides unprecedented opportunities to study the distribution of shallow subsurface water ice on Mars with its unique penetrating capability. The presence of water ice on the shallow surface layers of Mars is one of the most significant indicators of habitability on the extraterrestrial planet. A considerable amount of evidence pointing to the existence of water ice on Mars has been gathered by previous researchers through remote sensing photography, radar, measurements by gamma ray spectroscopy and neutron spectrometers, soil analysis, etc. This paper aims to review the various approaches utilized in detecting shallow subsurface water ice on Mars to date and to sort out the past and current evidence for its presence. This paper also provides a comprehensive overview of the possible clues of shallow subsurface water ice in the landing area of the Perseverance rover, serving as a reference for the RIMFAX radar to detect water ice on Mars in the future. Finally, this paper proposes the future emphasis and direction of rover-mounted radar for water ice exploration on the Martian shallow subsurface. Full article

In recent decades, extensive research has led to the understanding that Mars once hosted substantial liquid-water reserves. While the current Martian landscape boasts significant water-ice deposits at its North and South poles, the elusive presence of liquid-water bodies has remained undetected. A breakthrough occurred with the identification of radar-echo reflections at the base of the Martian South Pole, using MARSIS (Mars Advanced Radar for Subsurface and Ionospheric Sounding) in 2018. These radar echoes strongly suggest the presence of a highly concentrated liquid-water body. However, a counter-narrative has emerged, contending that the subterranean conditions beneath the ice cap, encompassing factors like temperature and pressure, may be inhospitable to liquid water. Consequently, alternative hypotheses posit that the observed bright echoes could be attributed to conductive minerals or water-absorbing clay-like materials. The ongoing discourse regarding the presence of liquid water beneath the southern polar ice cap is a hot topic in the realm of Martian exploration. The primary focus of this paper is to provide a comprehensive overview of Martian radar detection, the recent controversies regarding liquid water’s existence in the Martian South Pole, and the implications regarding the potential existence of Martian life forms in the water on Mars. The revelation of liquid water on Mars fundamentally suggests an environment conducive to the viability of Martian life, consequently furnishing invaluable insights for future exploratory endeavors in the pursuit of Martian biospheres. In addition, this paper anticipates the forthcoming research dedicated to Martian liquid water and potential life forms, while also underscoring the profound significance of identifying liquid water on Mars in propelling the field of astrobiology forward. Full article

The Rover-mounted Subsurface Penetrating Radar (RoSPR) is one of the scientific payloads onboard China’s first independent Mars exploration mission, Tianwen-1. The radar aims to characterize the thickness of the upper Martian soil and investigate the subsurface stratigraphy by collecting and processing the data. This article is mainly divided into two parts, the introduction of data pre-processing and analysis of pre-processed radar signals, aiming at helping scientists make more effective use of radar data. The first part describes the operating principle of the RoSPR and the procedure of radar data pre-processing at all levels. Data pre-processing is mainly designed to transfer the raw data format to a common PDS (Planetary Data System) and eliminate the influence of the instrument. In the signal analysis part, the performances of both self-check signals and echo signals of low- and high-frequency channels are analyzed, which indicate a stable radar system and are useful for background removal. Phase and time calibration is of great importance for improving data quality and making the radar data more accurate. Moreover, further processing is required to obtain clear radar images, such as filtering, background removal and gain setting. Full article

The SHAllow RADar (SHARAD) onboard Mars Reconnaissance Orbiter (MRO) is a 20 MHz Synthetic Aperture Radar (SAR) that probes the first hundreds of meters of the Martian subsurface. In order to interpret the detection of subsurface interfaces with ground penetrating radars, simulations using Digital Terrain Models (DTM) are necessary. This methodology paper focuses on the analysis of the first tens of meters of the Martian subsurface with SHARAD, comparing the use of different high-resolution DTMs for radar simulation, namely, from the High-Resolution Stereo Camera (HRSC) onboard the Mars Express and from the Context Camera (CTX) onboard MRO. The region of Terra Cimmeria was chosen as a demonstration area. It is a highly cratered southern midlatitude region, where, as will be discussed, the higher resolution of the aforementioned terrain models is mandatory to describe the surface at an acceptable level of detail for shallow subsurface radar interpretation. With a DTM corrected by photoclinometry using CTX imagery, we show that a reflector that was visible on SHARAD data but not on the simulation made with an HRSC DTM is, in fact, a surface echo that was not reproduced by the HRSC surface model. We also show that, unlike laser altimetry DTMs, optical DTMs are prone to artifacts that can make radar analysis more complicated for some scenarios. Reciprocally, we show that the comparison between radar and its corresponding simulated data is a way of assessing a DTM’s quality, which is especially useful in missions where ground control points are lacking, unlike Martian observations. Full article

The Martian ionosphere was actively detected by Mars Advanced Radar for Subsurface and Ionosphere Sounding (MARSIS) aboard the Mars Express. The detected echo signal of the MARSIS at an epoch is presented as a function of frequency and time delay to form an ionogram. Some MARSIS ionograms have been processed to obtain the electron density profiles of the Martian topside ionosphere. Unfortunately, more than half of the records cannot be processed with current methods due to the lack of local plasma density information at spacecraft altitude. In this work, we employ a piece-wise exponent to describe the electron density profile of the Martian topside ionosphere. The piece-wise exponent used in our method can reasonably capture the altitude structure of the Martian topside ionosphere, which has been validated with the MGS and MAVEN data. In an altitude regime of lower than 200 km, the average absolute height error of the same electron density between MGS data and fitted profiles is 0.006 km, and the average relative error is 0.008%. In an altitude regime of higher than 200 km, the average absolute height error of the same electron density between MGS data and fitted profiles is 0.55 km, and the average relative error is −0.1%. Based on the altitude structure knowledge of the Martian topside ionosphere, we put forward a new method to invert electron density profiles from MARSIS ionograms with/without local plasma density information. Compared with the previous results, the average absolute difference in the peak height of the retrieved profile is 7.38 km, within the margin of the MARSIS height resolution of 13.8 km. The average relative difference is only 3%. The application of the new method can greatly improve the utilization rate of MARSIS ionogram records. Full article

Mars’s polar regions are covered by kilometers-thick layered deposits which carry a record of the planet’s climate history. The deposition and volatilization of the shallow CO₂ deposits in the south pole have a large impact on the planet’s atmosphere and environment. This research focuses on the timing variation of the thickness of the shallow deposits based on the SHARAD data collected from the past 11 terrestrial years, and analysis of the contributing factors based on the volatilization and deposition mechanisms of surface and subsurface materials. In this work, we selected more than four thousand data points, covering several seasons and Martian years, to extract radar echoes and calculate the thickness changes in the subsurface layer over time. We found that the thickness of the CO₂ layer becomes thinner in the summer, with seasonal variation in the range of ~16–45 m. The thickness variations have a Gaussian-like distribution and do not increase with the distance between the compared node pair, implying that the phenomenon is not caused by regional differences. The overall thickness within the 11 terrestrial years does not show a clear trend of thickening or thinning, indicating a moderate vertical change of the southern deposits. Full article

Due to its significance in astrobiology, assessing the amount and state of liquid water present on Mars today has become one of the drivers of its exploration. Subglacial water was identified by the Mars Advanced Radar for Subsurface and Ionosphere Sounding (MARSIS) aboard the European Space Agency spacecraft Mars Express through the analysis of echoes, coming from a depth of about 1.5 km, which were stronger than surface echoes. The cause of this anomalous characteristic is the high relative permittivity of water-bearing materials, resulting in a high reflection coefficient. A determining factor in the occurrence of such strong echoes is the low attenuation of the MARSIS radar pulse in cold water ice, the main constituent of the Martian polar caps. The present analysis clarifies that the conditions causing exceptionally strong subsurface echoes occur solely in the Martian polar caps, and that the detection of subsurface water under a predominantly rocky surface layer using radar sounding will require thorough electromagnetic modeling, complicated by the lack of knowledge of many subsurface physical parameters. Higher-frequency radar sounders such as SHARAD cannot penetrate deep enough to detect basal echoes over the thickest part of the polar caps. Alternative methods such as rover-borne Ground Penetrating Radar and time-domain electromagnetic sounding are not capable of providing global coverage. MARSIS observations over the Martian polar caps have been limited by the need to downlink data before on-board processing, but their number will increase in coming years. The Chinese mission to Mars that is to be launched in 2020, Tianwen-1, will carry a subsurface sounding radar operating at frequencies that are close to those of MARSIS, and the expected signal-to-noise ratio of subsurface detection will likely be sufficient for identifying anomalously bright subsurface reflectors. The search for subsurface water through radar sounding is thus far from being concluded. Full article

Machine learning (ML) algorithmic developments and improvements in Earth and planetary science are expected to bring enormous benefits for areas such as geospatial database construction, automated geological feature reconstruction, and surface dating. In this study, we aim to develop a deep learning (DL) approach to reconstruct the subsurface discontinuities in the subsurface environment of Mars employing the echoes of the Shallow Subsurface Radar (SHARAD), a sounding radar equipped on the Mars Reconnaissance Orbiter (MRO). Although SHARAD has produced highly valuable information about the Martian subsurface, the interpretation of the radar echo of SHARAD is a challenging task considering the vast stocks of datasets and the noisy signal. Therefore, we introduced a 3D subsurface mapping strategy consisting of radar echo pre-processors and a DL algorithm to automatically detect subsurface discontinuities. The developed components the of DL algorithm were synthesized into a subsurface mapping scheme and applied over a few target areas such as mid-latitude lobate debris aprons (LDAs), polar deposits and shallow icy bodies around the Phoenix landing site. The outcomes of the subsurface discontinuity detection scheme were rigorously validated by computing several quality metrics such as accuracy, recall, Jaccard index, etc. In the context of undergoing development and its output, we expect to automatically trace the shapes of Martian subsurface icy structures with further improvements in the DL algorithm. Full article

Liquid water was present on the surface of Mars in the distant past; part of that water is now in the ground in the form of permafrost and heat from the molten interior of the planet could cause it to melt at depth. MARSIS (Mars Advanced Radar for Subsurface and Ionosphere Sounding) has surveyed the Martian subsurface for more than fifteen years in search for evidence of such water buried at depth. Radar detection of liquid water can be stated as an inverse electromagnetic scattering problem, starting from the echo intensity collected by the antenna. In principle, the electromagnetic problem can be modelled as a normal plane wave that propagates through a three-layered medium made of air, ice and basal material, with the final goal of determining the dielectric permittivity of the basal material. In practice, however, two fundamental aspects make the inversion procedure of this apparent simple model rather challenging: (i) the impossibility to use the absolute value of the echo intensity in the inversion procedure; (ii) the impossibility to use a deterministic approach to retrieve the basal permittivity. In this paper, these issues are faced by assuming a priori information on the ice electromagnetic properties and adopting an inversion probabilistic approach. All the aspects that can affect the estimation of the basal permittivity below the Martian South polar cap are discussed and how detection of the presence of basal liquid water was done is described. Full article
