Search Results (38)

In this paper, a wideband circularly polarized folded reflectarray antenna (CPFRA) based on a transmissive linear-to-circular polarization converter is proposed. The CPFRA consists of a primary reflector and a sub-reflector. To achieve broadband performance, a metasurface-based RA element on the primary reflector surface and a transmissive linear-to-circular polarization converter on the sub-reflector surface are applied. Moreover, the transmissive linear-to-circular polarization converter on the sub-reflector surface helps convert linear polarization to circular polarization. To verify the proposed CPFRA, a prototype is designed, fabricated, and tested. The measured results exhibit that the proposed CPFRA presents a 3 dB gain bandwidth of 27.4% and a 3 dB axial ratio bandwidth of 23%. The CPFRA achieves a peak gain of 21.2 dBi with an aperture efficiency of 27.2%. The proposed CPFRA is a promising candidate for millimeter-wave (mm-W) satellite communication applications because of its advantages of high gain, low cost, low profile, and broad bandwidth. Full article

Conceptually, this paper aims to help reduce the communication blind spots originating from the design of millimeter-wave (mmW) beamforming by deploying radio units of an open radio access network (O-RAN) with free-space optics (FSOs) as the backhaul and the fiber-optic link as the fronthaul. At frequencies exceeding 24 GHz, the transmission reach of 5G/6G beamforming is limited to a few hundred meters, and the periphery area of the sector operational range of beamforming introduces a communication blind spot. Using FSOs as the backhaul and a fiber-optic link as the fronthaul, O-RAN empowers the radio unit to extend over greater distances to supplement the communication range that mmW beamforming cannot adequately cover. Notably, O-RAN is a prime example of next-generation wireless networks renowned for their adaptability and open architecture to enhance the cost-effectiveness of this integration. A 200 meter-long FSO link for backhaul and a fiber-optic link of up to 10 km for fronthaul were erected, thereby enabling the reach of communication services from urban centers to suburban and remote rural areas. Furthermore, in the context of beamforming, reinforcement learning (RL) was employed to optimize the error vector magnitude (EVM) by dynamically adjusting the beamforming phase based on the communication user’s location. In summary, the integration of RL-based mmW beamforming with the proposed O-RAN communication setup is operational. It lends scalability and cost-effectiveness to current and future communication infrastructures in urban, peri-urban, and rural areas. Full article

The stringent requirements of industrial communication, especially high reliability and real-time response, are regarded as the main bottlenecks for the widespread adoption of wireless technologies in industrial applications. The integration of 5G and Time-Sensitive Networking (TSN) protocols offers convergence of both wireless and various wired communication technologies for industrial applications. In this article, we describe our 5G and TSN integrated prototype, which achieves high reliability based on the IEEE 802.1CB Frame Replication and Elimination for Reliability (FRER) scheme. Different 5G systems have been used in various combinations to empirically study the benefits of FRER for 5G communication in real industrial environments. We evaluate the performance of our prototype and validate it for an industrial use case on Smart Sensors for Milling Processes, requiring a latency below 10 ms for 99.99% of the packets sent, which has been achieved in the measurements using FRER. This use case and the high requirements towards latency and reliability demonstrate the benefits of 5G integration with FRER for industrial production. Full article

Wireless communication plays an important role in the digitization of industries. A 5G cellular communication system enables several industrial automation use cases. Fifth-generation deployments in industrial use cases have mainly been carried out in the sub-7 GHz frequency range. In this work, we empirically study 5G system performance in the millimeter wavelength (mmW) range for industrial use cases: additive manufacturing processes and precision manufacturing robotics. We carry out an experimental performance evaluation of a commercially available non-public 5G mmW system to assess its latency, reliability and throughput for uplink and downlink data traffic in a real industrial environment. We also investigate the impact of various 5G configurations on 5G performance characteristics with insights from the baseband log information as well as unidirectional latency measurements. Our empirical results indicate that 5G mmW system can achieve low latency with high reliability in both one-way traffic directions. The throughput is observed to be high for line-of-sight (LOS) scenarios, making the use of the 5G mmW system appealing especially for data rate-intensive and time-critical industrial use cases. We also observe that industrial environments with lots of metal and reflective surfaces provide favorable propagation conditions for non-LOS transmissions. Our results indicate that static industrial use cases with low mobility can leverage the performance benefits of 5G mmW systems. Full article

This work addresses a critical challenge in microscale computational electromagnetics for liquid crystal-based reconfigurable components: the inadequate capability of current software to accurately identify and simulate higher-order modes (HoMs) in complex electromagnetic structures. Specifically, commercial simulators often fail to capture modes such as Transverse Electric (TE11) beyond the fundamental transverse electromagnetic (TEM) mode in coaxial liquid crystal phase shifters operating in the terahertz (THz) regime, leading to inaccurate performance predictions and suboptimal designs for telecommunication engineering applications. To address this limitation, we propose a novel diagnostic methodology incorporating three lossless assumptions to enhance the identification and analysis of pseudo-HoMs in full-wave simulators. Our approach theoretically eliminates losses associated with metallic conductivity, dielectric dissipation, and reflection effects, enabling precise assessment of frequency-dependent HoM power propagation alongside the primary TEM mode. We validate the methodology by applying it to a coaxially filled liquid crystal variable phase shifter device structure, underscoring its effectiveness in advancing the design and characterization of THz devices. This work provides valuable insights for researchers and engineers utilizing closed-source commercial simulators in micro- and nano-electromagnetic device development. The findings are particularly relevant for microscale engineering applications, including millimeter-wave (mmW), sub-mmW, and THz systems, with potential impacts on next-generation communication technologies. Full article

Fading in communication channels presents eminently stochastic characteristics and is a significant challenge, especially at millimeter wave (mmW) frequencies, where the need for lines of sight and the high attenuation of obstacles complicate transmission. This article presents a model based on Bayesian fundamentals intended to improve the description and simulation of stochastic fading effects in these channels. It also includes the use of signal processing techniques to simulate and reconstruct the received signal, simulating the communication channel with an FIR filter. The results obtained by simulating the model show its ability to efficiently capture rapid and profound variations in the signal, typical of those that occur in urban and suburban environments and transmissions in the mmW spectrum. It also provides greater uniformity in signal reconstruction compared to the traditional models that are in use. Using Bayesian fundamentals, which allow dynamic adaptation to change in channel behavior, can improve the efficiency and reliability of networks, especially modern smart networks. Compared to traditional models, the proposed model offers improved signal reconstruction and fading mitigation accuracy, with prospects for future integration in smart communication systems. The better capacity in signal reconstruction presents itself as a differentiator of the model, suggesting greater precision in data transmission. Full article

A wide-angle scanning phased array with dual circular polarization in the Ka-band is presented in this paper. To improve the scanning capability of the phased array, the microstrip element is modified by loading many metal posts at its center and periphery. In addition, a stripline coupler is designed to achieve dual circularly polarized (CP) radiation, and the inner conductor of the subminiature micro-push-on (SSMP) connectors for feeding the coupler is extended to the top layer of the multilayer element by introducing an open stub, which simplifies the assembly process between the SSMP connector and multilayer printed circuit board (PCB) due to through-hole soldering instead of blind-hole soldering. The proposed element can cover a frequency range from 28 GHz to 30.5 GHz with a relative bandwidth of 8.5% in the Ka-band. An 8 × 8 phased array is constructed based on this proposed element, and a wide-angle scanning range from −65° to +65° is obtained for the dual circular polarization. The proposed array has a gain fluctuation of 5.1 dB and an axial ratio (AR) of less than 3.3 dB during beam-steering. The prototype is fabricated and measured, with a good agreement between the measured and simulated results. The proposed phased array can be applied in a Ka-band millimeter-wave (MMW) communication system. Full article

The deployment of wireless communication networks in the E band (60–90 GHz) requires highly flexible, real-time, and precise tunability to optimize power transmission amidst diffraction, obstacles, and scattering challenges. This paper proposes an innovative reconfigurable metasurface reflect array design capable of achieving a dynamic phase range of 312 degrees with less than 1 dB of loss. The design integrates two types of unit cells and employs piezoelectric crystal as the tuning element. Simulation results illustrate the feasibility of beam focusing and accurate beam steering within a range of ±3 degrees. Furthermore, the proposed reconfigurable metasurface reflector demonstrates an antenna gain comparable to that of a dish antenna with the same aperture size. Full article

High–speed, high–power photodiodes play a key role in wireless communication systems for the generation of millimeter wave (MMW) and terahertz (THz) waves based on photonics–based techniques. Uni–traveling–photodiode (UTC–PD) is an excellent candidate, not only meeting the above–mentioned requirements of broadband (3 GHz~1 THz) and high–frequency operation, but also exhibiting the high output power over mW–level at the 300 GHz band. This paper reviews the fundamentals of high–speed, high–power photodiodes, mirror–reflected photodiodes, microstructure photodiodes, photodiode–integrated devices, the related equivalent circuits, and design considerations. Those characteristics of photodiodes and the related photonic–based devices are analyzed and reviewed with comparisons in detail, which provides a new path for these devices with applications in short–range wireless communications in 6G and beyond. Full article

This paper presents a novel approach to addressing the issue of temperature-induced instability in an optical, single-sideband transmitter based on a micro-ring resonator (MRR) suitable for millimeter-wave (mmW) radio-over-fiber (RoF) communications. We propose utilizing the drop port of the MRR to provide a feedback signal to the closed-loop control (CLC) system. The latter serves to maintain the optimal alignment between the laser’s carrier and the MRR’s resonant wavelength, thus mitigating the adverse effects of chromatic-dispersion-induced power fading at the receiving end. Since the feedback information is extracted from the otherwise-wasted resonant energy at the drop port, the control system does not compromise the delicate optical signal at the through port. A CLC was synthesized, designed, and prototyped to provide real-time wavelength tuning of the heat-pump-controlled laser based on the feedback signal. Experimental evaluations demonstrate that the wavelength of the laser could be successfully locked to the MRR’s resonance with a wavelength dither of less than 0.004 nm (~491 MHz). This allowed us to limit the power-penalty deterioration to less than 2 dB for a RoF link with a 2.5-km standard telecommunication single-mode fiber (SMF), a modulation frequency of 37.8 GHz, and a carrier wavelength of 1563.97 nm (~191.820 THz). The proposed solution offers an alternative approach for the carrier and the MRR’s resonant wavelength interlocking without the need for complex photonics like thermo-optic or electro-optic structures to control the temperature or phase velocity, respectively. Full article

We propose and demonstrate a hybrid communication architecture that combines millimeter-wave (MMW) in the radio frequency (RF) domain and free-space-optics (FSO) technologies using adaptive combining and hybrid automatic repeat request (HARQ) techniques. At the receiving end, we employed joint signal processing with an adaptive diversity combining technique (ADCT) based on a maximum ratio combining (MRC) algorithm. We derived closed-form expressions for the outage probability and throughput of the hybrid RF and FSO (RF/FSO) system, considering various characteristics of atmospheric turbulence in the FSO link. Experimental testing with 10-Gbaud quadrature phase shift keying (QPSK) data was conducted under different simulated atmospheric turbulence intensities, FSO and MMW speed-ratios, and forward error correction (FEC) overheads. Additionally, we validated improvements in terms of bit error ratio (BER), outage probability, and throughput performance. Full article

Due to increasingly strong and varied performance requirements, cooperative wireless communication systems today occupy a prominent place in both academic research and industrial development. The technological and economic challenges for future sixth-generation (6G) wireless systems are considerable, with the objectives of improving coverage, data rate, latency, reliability, mobile connectivity and energy efficiency. Over the past decade, new technologies have emerged, such as massive multiple-input multiple-output (MIMO) relay systems, intelligent reflecting surfaces (IRS), unmanned aerial vehicular (UAV)-assisted communications, dual-polarized (DP) antenna arrays, three dimensional (3D) polarized channel modeling, and millimeter-wave (mmW) communication. The objective of this paper is to provide an overview of tensor-based MIMO cooperative communication systems. Indeed, during the last two decades, tensors have been the subject of many applications in signal processing, especially for digital communications, and more broadly for big data processing. After a brief reminder of basic tensor operations and decompositions, we present the main characteristics allowing to classify cooperative systems, illustrated by means of different architectures. A review of main codings used for cooperative systems is provided before a didactic and comprehensive presentation of two-hop systems, highlighting different tensor models. In a companion paper currently in preparation, we will show how these tensor models can be exploited to develop semi-blind receivers to jointly estimate transmitted information symbols and communication channels. Full article

The frequency band in the millimeter-wave (MMW) and sub-terahertz (sub-THz) range has shown great potential in mobile communication technology due to the advantages of ultra-large bandwidth and ultra-high data rates. Based on the increasing research activities on MMW/sub-THz waves, biological safety at relevant frequencies must be explored, especially when high-power illumination occurs. Here, its non-ionizing nature plays a vital role, which makes it safe for humans at low illumination powers. However, under high power, the biothermal heating on the skin surface is still a main concern, and lots of research has been conducted in a laboratory. In this article, we analyze the thermal heating effect of human skin in outdoor environments, where atmospheric conditions can significantly impact the propagation of MMW/sub-THz waves. Our analysis is based on rat skin, which has a similar structure to human skin. A theoretical model combining Pennes’ bioheat transfer equation (BHTE), the ITU model, and the Mie scattering theory is developed. Good agreement between calculation results and measured data confirms the efficiency of this model. The influence of rainfall rate, humidity, operating frequency, illumination time, power density, and propagation distance is presented and discussed. Full article

This study introduces a new design for an ultra-compact shared-aperture antenna utilizing a quarter-mode substrate integrated waveguide (QMSIW) cavity. The proposed antenna operates as a 4 × 4 multi-input multi-output (MIMO) system in three 5G/6G millimeter-wave (MMw) bands, while functioning as a single element antenna for a 5.5 GHz wireless fidelity Microwave (Mw) band. The antenna comprises four QMSIW cavity resonators; each QMSIW is loaded with dual slots to produce tri-band MMw operation at 28 GHz, 38 GHz, and 0.13 THz. The four cavities are arranged to reuse the entire aperture by creating a conventional open-loop antenna that operates at a frequency of 5.5 GHz. Simulation, measurement, and co-simulation results show that the proposed antenna has a quad-band operation and exhibits favorable characteristics. The measured scattering parameters validate the simulated ones over the four bands under consideration. The lowest values of the measured total radiation efficiencies are 80%, 73%, 62%, and 72% (co-simulation) within the four covered bands, respectively. The antenna peak gains are 1.8 to 1.85 dBi, 4.0 to 4.5 dBi, 4.3 to 4.5 dBi, and 6.5 to 6.6 dBi within the covered bands. Furthermore, the design satisfies MIMO and diversity conditions (envelope correlation coefficient and branch power ratio) over frequency bands of operation. All excellent results are achieved from an ultra-compact size in terms of footprint area (0.018${\lambda }_0^2$), where λ₀ represents the free space wavelength at 5.5 GHz. The antenna boasts an excellent reuse aperture utilization efficiency (RAU) of 92% and a large ratio frequency of 23, making it an ideal candidate for compact devices. With its superior performance, the proposed design is well-suited for a range ofs wireless communication systems, including mobile devices and the Internet of Things. Full article

Recently, the coding metasurface has gained significant attention due to its exceptional potential in controlling electromagnetic (EM) waves with the rapid development of wireless communication systems. Meanwhile, graphene shows tremendous promise for the implementation of reconfigurable antennas due to its high tunable conductivity and its unique property that makes it a very suitable material for realizing steerable coded states. In this paper, we first propose a simple structured beam reconfigurable millimeter wave (MMW) antenna using a novel graphene-based coding metasurface (GBCM). Different from the previous method, its coding state can be manipulated by altering the sheet impedance of graphene instead of bias voltage. Then, we design and simulate several most popular coding sequences, including dual-, quad-and single-beam-generated implement, 30° beam deflection, as well as a random coding sequence for radar cross-section (RCS) reduction. The theoretical and simulation results show that graphene has great potential for MMW manipulation applications, which lay a foundation for the subsequent development and fabrication of GBCM. Full article
