Search Results (69)

The green octopus, Octopus hubbsorum, is a merobenthic species that inhabits warm-temperate waters in the eastern Pacific. However, its similarity to some morphological characteristics of and its slight genetic divergence from Octopus mimus has led to the proposal that both species are conspecific. The objective of this study was the morphological and molecular identification of eggs and paralarvae of the green octopus, O. hubbsorum, to provide information contributing to clarifying its taxonomy and relationship with O. mimus. The results obtained show that although O. hubbsorum has similarities with O. mimus in terms of egg size, chromatophore pattern, number of suckers, and presence of Kölliker’s organs, the O. hubbsorum paralarvae observed in this study are smaller (1.6 mm) and have a thin layer of loose skin, not described for O. mimus. Likewise, the morphology of the beak, radula, and suckers of O. hubbsorum is described for the first time and there are no studies of these structures for O. mimus. The phylogenetic analysis (mitochondrial cytochrome C oxidase subunit I and III genes) showed that both species form a monophyletic clade but belong to separate subclades. In conclusion, although the slight genetic divergence between these two species suggests conspecificity, their disjoint geographic distribution (O. hubbsorum is found in warm-temperate waters and O. mimus in cold-temperate waters) suggests the hypothesis of being two separate species with a close phylogenetic relationship. However, further research (morphological and population analyses) is required to solve taxonomic uncertainty. Full article

The influence of the mounting position of a magnetic-inertial measurement unit (MIMU) on the accuracy of posture estimation for a shank has not been extensively studied and remains unknown. In this study, we conducted comparative experiments using three MIMU positions: the lateral and frontal positions, which are commonly used, and the medial tibial position, which is less affected by muscle protuberance, considering the anatomical structure of the body. To determine the optimal MIMU mounting position on the shank, we repeatedly performed plantar–dorsiflexion and relaxation of the ankle joint in a chair-sitting position and examined the effect of muscle contraction on the posture of the MIMU (Experiment 1). We also performed posture estimation during gait and compared the three-dimensional shank posture measured by the MIMU and optical motion capture to evaluate the estimation accuracy for each mounting position (Experiment 2). In Experiment 1, the orientation change at the medial tibia was significantly smaller than that at the other positions, showing an 80% reduction compared with the anterior tibia during dorsiflexion. In Experiment 2, the medial tibia achieved the highest estimation accuracy, showing a 13% lower RMSE than that of the anterior position. The results of these two experiments suggest that the medial tibia is the optimal position on the shank, as the posture estimation accuracy was the highest when the MIMU was mounted on the medial tibia, where there was no muscle under the mounting surface. Moreover, the posture estimation accuracy was less affected by muscle protuberance under these conditions. Full article

The ocean represents the cradle of life on Earth, making it essential to comprehend the complex interactions between marine animal behaviors and the physical microstructure of their environments in order to study their behavioral ecology. Due to the vastness of the ocean, traditional observational techniques are constrained by distance, which poses significant challenges for conducting extended and continuous research on marine animal behavior and ecology. To overcome these challenges, this paper introduces a behavior recording tag system incorporating temperature, pressure, and miniature inertial measurement unit (MIMU) sensors as data collection modules. These sensors are integrated with a main control module and a data storage module to gather and archive behavioral and environmental information. A combined positioning recovery method is proposed, developed, and validated to address the issue of retrieving the tag system post data collection. The behavior recording tag system’s performance was assessed through laboratory and pool tests. The findings show that the accuracy of temperature sensor is about 0.01 °C, the accuracy of pressure sensor is approximately 0.5% of full scale, the continuous data collection duration can extend to 3 days, and the recovery window time after surfacing exceeds 7 days, underscoring its viability as a marine animal behavior recorder. Full article

Satellite navigation spoofing is a major challenge in the field of satellite/inertial integrated navigation security. To effectively enhance the anti-spoofing capability of a low-cost GNSS/MEMS-SINS integrated navigation system, this paper proposes a method integrating a dual-antenna global navigation satellite system (GNSS) and a micro-inertial measurement unit (MIMU) to determine the two-dimensional directions of spoofing signal sources. The proposed method evaluates whether the single-difference carrier-phase measurements conform to the corresponding directions given in ephemeris files and employs micro-inertial navigation technology to determine the two-dimensional directions of the signal source. Based on a set of short-baseline dual-station measurements, the accuracy of the proposed method in determining the two-dimensional azimuths of satellites in synchronous orbits is verified, and the deviation from the real value is evaluated. The experimental results show that the proposed method can effectively identify the spoofed satellite signals while providing high-precision direction information at three different distances: 100 m, 10 km, and 36,000 km. The two-dimensional angle errors do not exceed 0.2 rad, 0.05 rad, and 0.01 rad, respectively. Full article

The inertial measurement method of pipelines utilizes a Micro-Electro-Mechanical Systems Inertial Measurement Unit (MIMU) to get the three-dimensional trajectory of underground pipelines. The initial attitude is significant for the inertial measurement method of pipelines. The traditional method to obtain the initial attitude uses three-axis magnetometers to measure the Earth’s magnetic field. However, the magnetic field in urban underground pipelines is intricate, which leads to the initial attitude being inaccurate. To overcome this challenge, a novel multi-position initial alignment method based on data backtracking for a single-axis FOG and a three-axis Micro-Electro-Mechanical Inertial Measurement Unit (MIMU) is proposed. Firstly, the configuration of the sensors is determined. Secondly, according to the three-point support structure of the pipeline measuring instrument, a three-position alignment scheme is designed. Additionally, an initial alignment algorithm using the data backtracking method is developed. In this algorithm, a rough initial alignment is conducted by the data from single-axis FOG, and a fine initial alignment is conducted by the data from FOG/MIMU. Finally, an experiment was conducted to validate this method. The experiment results indicate that the pitch and roll angle errors are less than 0.05°, and the azimuth angle errors are less than 0.2°. This improved the precision of the 3-D trajectory of underground pipelines. Full article

In the field of unmanned aerial vehicle (UAV) control, high-precision navigation algorithms are a research hotspot. To address the problem of poor localization caused by non-line-of-sight (NLOS) errors in ultra-wideband (UWB) systems, an UWB/MIMU integrated navigation method was developed, and a particle filter (PF) algorithm for data fusion was improved upon. The extended Kalman filter (EKF) was used to improve the method of constructing the importance density function (IDF) in the traditional PF, so that the particle sampling process fully considers the real-time measurement information, increases the sampling efficiency, weakens the particle degradation phenomenon, and reduces the UAV positioning error. We compared the positioning accuracy of the proposed extended Kalman particle filter (EKPF) algorithm with that of the EKF and unscented Kalman filter (UKF) algorithm used in traditional UWB/MIMU data fusion through simulation, and the results proved the effectiveness of the proposed algorithm through outdoor experiments. We found that, in NLOS environments, compared with pure UWB positioning, the accuracy of the EKPF algorithm in the X- and Y-directions was increased by 35% and 39%, respectively, and the positioning error in the Z-direction was considerably reduced, which proved the practicability of the proposed algorithm. Full article

Violin is one of the most complex musical instruments to learn. The learning process requires constant training and many hours of exercise and is primarily based on a student–teacher interaction where the latter guides the beginner through verbal instructions, visual demonstrations, and physical guidance. The teacher’s instruction and practice allow the student to learn gradually how to perform the correct gesture autonomously. Unfortunately, these traditional teaching methods require the constant supervision of a teacher and the interpretation of non-real-time feedback provided after the performance. To address these limitations, this work presents a novel interface (Visual Interface for Bowing Evaluation—VIBE) to facilitate student’s progression throughout the learning process, even in the absence of direct teacher intervention. The proposed interface allows two key parameters of bowing movements to be monitored, namely, the angle between the bow and the string (i.e., α angle) and the bow tilt (i.e., β angle), providing real-time visual feedback on how to correctly move the bow. Results collected on 24 beginners (12 exposed to visual feedback, 12 in a control group) showed a positive effect of the real-time visual feedback on the improvement of bow control. Moreover, the subjects exposed to visual feedback judged the latter as useful to correct their movement and clear in terms of the presentation of data. Although the task was rated as harder when performed with the additional feedback, the subjects did not perceive the presence of a violin teacher as essential to interpret the feedback. Full article

Optical Motion Capture Systems (OMCSs) are considered the gold standard for kinematic measurement of human movements. However, in situations such as measuring wrist kinematics during a hairdressing activity, markers can be obscured, resulting in a loss of data. Other measurement methods based on non-optical data can be considered, such as magneto-inertial measurement units (MIMUs). Their accuracy is generally lower than that of an OMCS. In this context, it may be worth considering a hybrid system [MIMU + OMCS] to take advantage of OMCS accuracy while limiting occultation problems. The aim of this work was (1) to propose a methodology for coupling a low-cost MIMU (BNO055) to an OMCS in order to evaluate wrist kinematics, and then (2) to evaluate the accuracy of this hybrid system [MIMU + OMCS] during a simple hairdressing gesture. During hair cutting gestures, the root mean square error compared with the OMCS was 4.53° (1.45°) for flexion/extension, 5.07° (1.30°) for adduction/abduction, and 3.65° (1.19°) for pronation/supination. During combing gestures, they were significantly higher, but remained below 10°. In conclusion, this system allows for maintaining wrist kinematics in case of the loss of hand markers while preserving an acceptable level of precision (<10°) for ergonomic measurement or entertainment purposes. Full article

Pedestrian navigation methods based on inertial sensors are commonly used to solve navigation and positioning problems when satellite signals are unavailable. To address the issue of heading angle errors accumulating over time in pedestrian navigation systems that rely solely on the Zero Velocity Update (ZUPT) algorithm, it is feasible to use the pedestrian’s motion constraints to constrain the errors. Firstly, a human step length model is built using human kinematic data collected by the motion capture system. Secondly, we propose the bipedal constraint algorithm based on the established human step length model. Real field experiments demonstrate that, by introducing the bipedal constraint algorithm, the mean biped radial errors of the experiments are reduced by 68.16% and 50.61%, respectively. The experimental results show that the proposed algorithm effectively reduces the radial error of the navigation results and improves the accuracy of the navigation. Full article

This paper proposes a new methodology for the automatic detection of magnetic disturbances from magnetic inertial measurement unit (MIMU) sensors based on deep learning. The proposed approach considers magnetometer data as input to a long short-term memory (LSTM) neural network and obtains a labeled time series output with the posterior probabilities of magnetic disturbance. We trained our algorithm on a data set that reproduces a wide range of magnetic perturbations and MIMU motions in a repeatable and reproducible way. The model was trained and tested using 15 folds, which considered independence in sensor, disturbance direction, and signal type. On average, the network can adequately detect the disturbances in $98\%$ of the cases, which represents a significant improvement over current threshold-based detection algorithms. Full article

Scapulothoracic movements are altered after stroke, with resulting shoulder dysfunction. The scapulohumeral rhythm (SHR) is complex and poorly studied. Magnetic inertial measurement units (MIMUs) allow a rapid and accurate analysis of shoulder kinematics. MIMUs were used to assess the SHR during active shoulder flexion and abduction of over 60°. SHR values obtained from the hemiplegic shoulders of stroke patients (n = 7) were compared with those from healthy controls (n = 25) and correlated with clinical–functional measurements. The impairment of paretic arms was assessed using the Fugl-Meyer Assessment (FMA). We found that in paretic shoulders, the scapular tilt was significantly lower at maximal arm flexion and at 60° and 90° of arm abduction. On the paretic side, the SHR was also consistently lower for all measured arm movements. The FMA was correlated with the scapular anterior–posterior tilt at 60° and 90° of shoulder abduction (Rho = 0.847, p = 0.016, and Rho = 0.757, p = 0.049, respectively). This pilot study demonstrates the feasibility of MIMUs in assessing SHR in stroke patients and confirms previous findings on scapular dysfunction in stroke patients. Full article

Integrated Ultra-wideband (UWB) and Magnetic Inertial Measurement Unit (MIMU) sensor systems have been gaining popularity for pedestrian tracking and indoor localization applications, mainly due to their complementary error characteristics that can be exploited to achieve higher accuracies via a data fusion approach. These integrated sensor systems have the potential for improving the ambulatory 3D analysis of human movement (estimating 3D kinematics of body segments and joints) over systems using only on-body MIMUs. For this, high accuracy is required in the estimation of the relative positions of all on-body integrated UWB/MIMU sensor modules. So far, these integrated UWB/MIMU sensors have not been reported to have been applied for full-body ambulatory 3D analysis of human movement. Also, no review articles have been found that have analyzed and summarized the methods integrating UWB and MIMU sensors for on-body applications. Therefore, a comprehensive analysis of this technology is essential to identify its potential for application in 3D analysis of human movement. This article thus aims to provide such a comprehensive analysis through a structured technical review of the methods integrating UWB and MIMU sensors for accurate position estimation in the context of the application for 3D analysis of human movement. The methods used for integration are all summarized along with the accuracies that are reported in the reviewed articles. In addition, the gaps that are required to be addressed for making this system applicable for the 3D analysis of human movement are discussed. Full article

Monitoring shoulder kinematics, including the scapular segment, is of great relevance in the orthopaedic field. Among wearable systems, magneto-inertial measurement units (M-IMUs) represent a valid alternative for applications in unstructured environments. The aim of this systematic literature review is to report and describe the existing methods to estimate 3D scapular movements through wearable systems integrating M-IMUs. A comprehensive search of PubMed, IEEE Xplore, and Web of Science was performed, and results were included up to May 2023. A total of 14 articles was included. The results showed high heterogeneity among studies regarding calibration procedures, tasks executed, and the population. Two different techniques were described, i.e., with the x-axis aligned with the cranial edge of the scapular spine or positioned on the flat surface of the acromion with the x-axis perpendicular to the scapular spine. Sensor placement affected the scapular motion and, also, the kinematic output. Further studies should be conducted to establish a universal protocol that reduces the variability among studies. Establishing a protocol that can be carried out without difficulty or pain by patients with shoulder musculoskeletal disorders could be of great clinical relevance for patients and clinicians to monitor 3D scapular kinematics in unstructured settings or during common clinical practice. Full article

The importance of performance excellence and operator’s safety is fundamental not only when operators perform repetitive and controlled industrial tasks, but also in case of abrupt gestures due to inattention and unexpected circumstances. Since optical systems work at frequencies that are too low and they are not able to detect gestures as early as possible, combining the use of wearable magneto-inertial measurement units (MIMUs) with the adoption of deep learning techniques can be useful to instruct the machine about human motion. To improve the initial training phase of neural networks for high classification performance, gesture repeatability over time has to be verified. Since the test–retest approach has been poorly applied based on MIMUs signals in a context of human–machine interaction, the aim of this work was to evaluate the repeatability of pick-and-place gestures composed of both normal and abrupt movements. Overall, results demonstrated an excellent test–retest repeatability for normal movements and a fair-to-good test–retest repeatability for abrupt movements. In addition, results suggested important information about the application of deep learning to identify the types of movements: the test showed how to improve reinforcement learning for the identification of onset gestures, whereas the retest allowed for defining the time necessary to retrain the network. Full article

In this paper, we present the FIU MARG Dataset (FIUMARGDB) of signals from the tri-axial accelerometer, gyroscope, and magnetometer contained in a low-cost miniature magnetic–angular rate–gravity (MARG) sensor module (also known as magnetic inertial measurement unit, MIMU) for the evaluation of MARG orientation estimation algorithms. The dataset contains 30 files resulting from different volunteer subjects executing manipulations of the MARG in areas with and without magnetic distortion. Each file also contains reference (“ground truth”) MARG orientations (as quaternions) determined by an optical motion capture system during the recording of the MARG signals. The creation of FIUMARGDB responds to the increasing need for the objective comparison of the performance of MARG orientation estimation algorithms, using the same inputs (accelerometer, gyroscope, and magnetometer signals) recorded under varied circumstances, as MARG modules hold great promise for human motion tracking applications. This dataset specifically addresses the need to study and manage the degradation of orientation estimates that occur when MARGs operate in regions with known magnetic field distortions. To our knowledge, no other dataset with these characteristics is currently available. FIUMARGDB can be accessed through the URL indicated in the conclusions section. It is our hope that the availability of this dataset will lead to the development of orientation estimation algorithms that are more resilient to magnetic distortions, for the benefit of fields as diverse as human–computer interaction, kinesiology, motor rehabilitation, etc. Full article
