Search Results (32)

Herein, an integrated system is developed based on knitted strain sensors for real-time translation of sign language into text and audio voices. To investigate how the structural characteristics of the knit affect the electrical performance, the position of the conductive yarn and the presence or absence of elastic yarn are set as experimental variables, and five distinct sensors are manufactured. A comprehensive analysis of the electrical and mechanical performance, including sensitivity, responsiveness, reliability, and repeatability, reveals that the sensor with a plain-plated-knit structure, no elastic yarn included, and the conductive yarn positioned uniformly on the back exhibits the best performance, with a gauge factor (GF) of 88. The sensor exhibited a response time of less than 0.1 s at 50 cycles per minute (cpm), demonstrating that it detects and responds promptly to finger joint bending movements. Moreover, it exhibits stable repeatability and reliability across various angles and speeds, confirming its optimization for sign language recognition applications. Based on this design, an integrated textile-based system is developed by incorporating the sensor, interconnections, snap connectors, and a microcontroller unit (MCU) with built-in Bluetooth Low Energy (BLE) technology into the knitted glove. The complete system successfully recognized 12 Korean Sign Language (KSL) gestures in real time and output them as both text and audio through a dedicated application, achieving a high recognition accuracy of 98.67%. Thus, the present study quantitatively elucidates the structure–performance relationship of a knitted sensor and proposes a wearable system that accounts for real-world usage environments, thereby demonstrating the commercialization potential of the technology. Full article

This paper proposes a control method to improve the dynamic performance of a two-phase DM (Differential Mode)-coupled boost converter designed for applications such as hybrid vehicles and railway systems. A conventional boost converter can be modified to a two-phase interleaved configuration to reduce current ripple and incorporate a differential mode (DM)-coupled inductor to reduce the volume of magnetic components, thereby achieving a decrease in cost and volume. However, when this converter is operated using a conventional PI controller, significant issues arise, particularly in the discontinuous conduction mode (DCM), where dynamic characteristics and response times are considerably slow. For a conventional boost converter, the steady-state duty cycle during DCM operation can be calculated analytically and used for feedforward compensation in a current-duty controller. In contrast, the duty cycle of a two-phase DM-coupled boost converter during DCM operation exhibits non-linear behavior depending on input/output voltages and load conditions, making analytical computation infeasible. To address this, steady-state duty cycle data is extracted through experiments and simulations, and a Look-Up Table is constructed to perform feedforward compensation. Given the multiple input and output specifications, multiple Look-Up Tables are required, leading to excessive MCU (Micro Controller Unit) computation load. The proposed correction algorithm enables feedforward compensation in the DCM region with a single Look-Up Table for all input and output specifications, achieving improvements in dynamic characteristics and reducing MCU computational load. This method achieves a reduction in settling time by up to 77 ms, with a minimum improvement of 10 ms, thereby significantly enhancing the responsiveness of the converter. Full article

The proliferation of small electronic devices has significantly increased the demand for self-powered sensors. This study introduces a triboelectric frequency sensor (TFS) that combines the frequency-responsive characteristics of triboelectric nanogenerators with a simple one-dimensional structure for sustainable vibration measurement. This sensor is specifically designed to aid in the tuning of string instruments, capable of detecting frequency responses up to 330 Hz generated by string vibrations. Structural optimization was achieved by setting a non-contact mode with a gap distance of 3 mm and utilizing perfluoroalkoxy alkane (PFA) as the contact dielectric material. The TFS exhibits dynamic response characteristics by varying the vibrating frequency and the tension of the string, facilitated by a custom-built testing setup. Frequency data captured by the sensor can be visualized on a monitor through the integration of a microcontroller unit (MCU) and dedicated coding. The practical applicability and effectiveness of this sensor in real-world scenarios are demonstrated experimentally. This innovation represents a significant step forward in the development of self-sustaining sensing technologies for precision instrument tuning. Full article

Due to their high accuracy, excellent stability, minor size, and low cost, silicon piezoresistive pressure sensors are used to monitor downhole pressure under high-temperature, high-pressure conditions. However, due to silicon’s temperature sensitivity, high and very varied downhole temperatures cause a significant bias in pressure measurement by the pressure sensor. The temperature coefficients differ from manufacturer to manufacturer and even vary from batch to batch within the same manufacturer. To ensure high accuracy and long-term stability for downhole pressure monitoring at high temperatures, this study proposes a temperature compensation method based on bilinear interpolation for piezoresistive pressure sensors under downhole high-temperature and high-pressure environments. A number of calibrations were performed with high-temperature co-calibration equipment to obtain the individual temperature characteristics of each sensor. Through the calibration, it was found that the output of the tested pressure measurement system is positively linear with pressure at the same temperatures and nearly negatively linear with temperature at the same pressures, which serves as the bias correction for the subsequent bilinear interpolation temperature compensation method. Based on this result, after least squares fitting and interpolating, a bilinear interpolation approach was introduced to compensate for temperature-induced pressure bias, which is easier to implement in a microcontroller (MCU). The test results show that the proposed method significantly improves the overall measurement accuracy of the tested sensor from 21.2% F.S. to 0.1% F.S. In addition, it reduces the MCU computational complexity of the compensation model, meeting the high accuracy demand for downhole pressure monitoring at high temperatures and pressures. Full article

In poor sanitary conditions, people need to wear masks to protect the health of their respiratory system. Meanwhile, it is necessary for patients with respiratory diseases to have real-time measurement on respiratory rate when wearing masks. Thermoelectric generation provides a new approach and method for powering and sensing small low-power devices, and has good application prospects in smart masks. In view of this, a novel sensible smart mask using micro thermal-electric energy conversion elements (TECE) is proposed in this paper, which can detect and display the respiratory rate in real time. First, the temperature conversion characteristic of micro TECE represented by the thermoelectric generator module is analyzed. Second, the respiratory characteristics of the human body are studied, and the respiratory rate sensing effect based on micro TECEs is analyzed and verified. Then, a sensible smart mask, which can show respiratory rate in real time, is developed by integrating MCU and OLED module. Finally, human respiratory rate experiments are conducted, the experimental results verified the effectiveness and accuracy of the proposed sensible smart mask. Full article

Multi-motor servo systems are widely used in industrial control. However, the single-core microprocessor architecture based on the microcontroller unit (MCU) and digital signal processor (DSP) is not well suited for high-performance multi-motor servo systems due to the inherent limitations in computing performance and serial execution of code. The bus-based distributed architecture formed by interconnecting multiple unit controllers increases system communication complexity, reduces system integration, and incurs additional hardware and software costs. Field programmable gate array (FPGA) possesses the characteristics of high real-time performance, parallel processing, and modularity. A single FPGA can integrate multiple motor servo controllers. This research uses MCU + FPGA as the core to realize high-precision multi-axis real-time control, combining the powerful performance of the MCU processor and the high-speed parallelism of FPGA. The MCU serves as the central processor and facilitates data interaction with the host computer through the controller area network (CAN). After data parsing and efficient computation, MCU communicates with the FPGA through flexible static memory controller (FSMC). A motor servo controller intellectual property (IP) core is designed and packaged for easy reuse within the FPGA. A 38-axis micro direct current (DC) motor control system is constructed to test the performance of the IP core and the heterogeneous embedded platforms. The experimental results show that the designed IP core exhibits robust functionality and scalability. The system exhibits high real-time performance and reliability. Full article

Background: Continuous glucose monitoring (CGM) systems offer the advantage of noninvasive monitoring and continuous data on glucose fluctuations. This study introduces a new model that enables the generation of synthetic but realistic databases that integrate physiological variables and sensor attributes into a dataset generation model and this, in turn, enables the design of improved CGM systems. Methods: The presented approach uses a combination of physiological data and sensor characteristics to construct a model that considers the impact of these variables on the accuracy of CGM measures. A dataset of 500 sensor responses over a 15-day period is generated and analyzed using machine learning algorithms (random forest regressor and support vector regressor). Results: The random forest and support vector regression models achieved Mean Absolute Errors (MAEs) of $16.13$ mg/dL and $16.22$ mg/dL, respectively. In contrast, models trained solely on single sensor outputs recorded an average MAE of $11.01\pm 5.12$ mg/dL. These findings demonstrate the variable impact of integrating multiple data sources on the predictive accuracy of CGM systems, as well as the complexity of the dataset. Conclusions: This approach provides a foundation for developing more precise algorithms and introduces its initial application of Tiny Machine Control Units (MCUs). More research is recommended to refine these models and validate their effectiveness in clinical settings. Full article

In this paper, a temperature measurement system with NTC (Negative Temperature Coefficient) thermistors was designed. An MCU (Micro Control Unit) primarily operates by converting the voltage value collected by an ADC (Analog-to-Digital Converter) into the resistance value. The temperature value is then calculated, and a DAC (Digital-to-Analog Converter) outputs a current of 4 to 20 mA that is linearly related to the temperature value. The nonlinear characteristics of NTC thermistors pose a challenging problem. The nonlinear characteristics of NTC thermistors were to a great extent solved by using a resistance ratio model. The high precision of the NTC thermistor is obtained by fitting it with the Hoge equation. The results of actual measurements suggest that each module works properly, and the temperature measurement accuracy of 0.067 °C in the range from −40 °C to 120 °C has been achieved. The uncertainty of the output current is analyzed and calculated with the uncertainty of 0.0014 mA. This type of system has broad potential applications in industry fields such as the petrochemical industry. Full article

Injection molding is a highly nonlinear procedure that is easily influenced by various external factors, thereby affecting the stability of the product’s quality. High-speed injection molding is required for production due to the rapid cooling characteristics of thin-walled parts, leading to increased manufacturing complexity. Consequently, establishing appropriate process parameters for maintaining quality stability in long-term production is challenging. This study selected a hot runner mold with a thin wall fitted with two external sensors, a nozzle pressure sensor and a tie-bar strain gauge, to collect data regarding the nozzle peak pressure, the timing of peak pressure, the viscosity index, and the clamping force difference value. The product weight was defined as the quality indicator, and a standardized parameter optimization process was constructed, including injection speed, V/P switchover point, packing, and clamping force. Finally, the optimized process parameters were applied to the adaptive process control experiments using the developed control system operated within the micro-controller unit (MCU). The results revealed that the control system effectively stabilized the product weight variation and standard deviation of 0.677% and 0.0178 g, respectively. Full article

The Internet of Remote Things (IoRT) offers an exciting landscape for the development and deployment of remote wireless sensing nodes (WSNs) which can gather useful environmental data. Low Power Wide Area Networks (LPWANs) provide an ideal network topology for enabling the IoRT, but due to the remote location of these WSNs, the power and energy requirements for such systems must be accurately determined before deployment, as devices will be running on limited energy resources, such as long-life batteries or energy harvesting. Various sensor modules that are available on the consumer market are suitable for these applications; however, the exact power requirements and characteristics of the sensor are often not stated in datasheets, nor verified experimentally. This study details an experimental procedure where the energy requirements are measured for various sensor modules that are available for Arduino and other microcontroller units (MCUs). First, the static power consumption of continually powered sensors was measured. The impact of sensor warm-up time, associated with powering on the sensor and waiting for reliable measurements, is also explored. Finally, the opportunity to reduce power for sensors which have multiple outputs was investigated to see if there is any significant reduction in power consumption when obtaining readings from fewer outputs than all that are available. It was found that, generally, CO₂ and soil moisture sensors have a large power requirement when compared with temperature, humidity and pressure sensors. Limiting multiple sensor outputs was shown not to reduce power consumption. The warm-up time for analog sensors and digital sensors was generally negligible and in the order of 10–50 ms. However, one CO₂ sensor had a large overhead warm-up time of several seconds which added a significant energy burden. It was found that more, or as much, power could be consumed during warm-up as during the actual measurement phase. Finally, this study found disparity between power consumption values in datasheets and experimental measurements, which could have significant consequences in terms of battery life in the field. Full article

This study presents a standalone solar power system that incorporates a photovoltaic (PV) module, a boost converter, an H-bridge inverter, a low-pass filter (LPF), and a microcontroller unit (MCU). A novel cake sweetness maximum power point tracking (CS MPPT) algorithm and adjustable frequency and duty cycle (AFDC) control strategy has been proposed and efficiently applied to the solar power system for optimizing the system efficiency and output power quality. The experimental results show that the proposed CS MPPT algorithm achieves an efficiency of 99% under both the uniform irradiance conditions (UIC) and partial shading conditions (PSC). Subsequently, the AFDC control strategy is applied to the H-bridge inverter which improves the output AC voltage and AC current and thereby improving the power quality. The system ensures a stable 110 V_rms/60 Hz AC output voltage with only 2% total voltage harmonic distortion of voltage (THD_v), and produces a high-quality output voltage with reduced LPF volume and better economic benefits. The comparative analysis demonstrates that the characteristics and the performances of the CS MPPT algorithm in combination with the AFDC control strategy is better than the existing several maximum power point tracking (MPPT) techniques and inverter control strategies. The research output affirms the potential of the proposed solar power system to fulfill the actual daily needs of electricity by harnessing the maximum power from PV modules. Full article

For the next coming years, metaverse, digital twin and autonomous vehicle applications are the leading technologies for many complex applications hitherto inaccessible such as health and life sciences, smart home, smart agriculture, smart city, smart car and logistics, Industry 4.0, entertainment (video game) and social media applications, due to recent tremendous developments in process modeling, supercomputing, cloud data analytics (deep learning, etc.), communication network and AIoT/IIoT/IoT technologies. AIoT/IIoT/IoT is a crucial research field because it provides the essential data to fuel metaverse, digital twin, real-time Industry 4.0 and autonomous vehicle applications. However, the science of AIoT is inherently multidisciplinary, and therefore, it is difficult for readers to understand its evolution and impacts. Our main contribution in this article is to analyze and highlight the trends and challenges of the AIoT technology ecosystem including core hardware (MCU, MEMS/NEMS sensors and wireless access medium), core software (operating system and protocol communication stack) and middleware (deep learning on a microcontroller: TinyML). Two low-powered AI technologies emerge: TinyML and neuromorphic computing, but only one AIoT/IIoT/IoT device implementation using TinyML dedicated to strawberry disease detection as a case study. So far, despite the very rapid progress of AIoT/IIoT/IoT technologies, several challenges remain to be overcome such as safety, security, latency, interoperability and reliability of sensor data, which are essential characteristics to meet the requirements of metaverse, digital twin, autonomous vehicle and Industry 4.0. applications. Full article

The color stability of resin cements plays a key role in the achievement of esthetically-pleasant restorations. Resin luting materials can be mainly divided into two main classes: adhesive (relying on previous application of adhesive systems) or self-adhesive (also known as one-step cements). The different chemical compositions determine their physio-mechanical characteristics which, in turns, influence their color stability. To evaluate the color variations of different dual-cured resin cements after water aging, 80 disc-shaped specimens (15 mm in diameter and 1.2 mm thick) were obtained from the following resin cements (n = 10): (1) Maxcem Elite Universal, MCU (Kerr); (2) RelyX Universal, RXU (3M); (3) Calibra Ceram, CAL (Dentsply); (4) Multilink, MUL (Ivoclar-Vivadent); (5) Panavia V5, PAN (Kuraray); (6) Calibra Universal, CUN (Dentsply); (7) SpeedCEM Plus, SCP (Ivoclar); and (8) Panavia SA, PSA (Kuraray). After light-polymerization, the specimens were measured with a spectrophotometer and CIELab* values were recorded. The specimens were then placed in a digitally controlled thermostatic water bath at 60° for 30 days and afterwards the color measurements were repeated. Color differences were calculated for each specimen before and after water-aging procedures with ΔEab formula and the data were statistically analyzed (p < 0.05). The type of cement statistically influenced the ΔEab (p < 0.05), with MCU showing the lowest color variations (4.3 ± 0.7) whereas RXU and PSA the highest (16.9 ± 1.6 and 16.8 ± 1.2, respectively). No differences were observed between CAL, CUN and SCP (p = 0.05). Color stability is related to the chemical composition of the resinous luting materials, thus material dependent. Full article

Field deployment is critical to developing numerous sensitive impedance transducers. Precise, cost-effective, and real-time readout units are being sought to interface these sensitive impedance transducers for various clinical or environmental applications. This paper presents a general readout method with a detailed design procedure for interfacing impedance transducers that generate small fractional changes in the impedance characteristics after detection. The emphasis of the design is obtaining a target response resolution considering the accuracy in real-time. An entire readout unit with amplification/filtering and real-time data acquisition and processing using a single microcontroller is proposed. Most important design parameters, such as the signal-to-noise ratio (SNR), common-mode-to-differential conversion, digitization configuration/speed, and the data processing method are discussed here. The studied process can be used as a general guideline to design custom readout units to interface with various developed transducers in the laboratory and verify the performance for field deployment and commercialization. A single frequency readout unit with a target 8-bit resolution to interface differentially placed transducers (e.g., bridge configuration) is designed and implemented. A single MCU is programmed for real-time data acquisition and sine fitting. The 8-bit resolution is achieved even at low SNR levels of roughly 7 dB by setting the component values and fitting algorithm parameters with the given methods. Full article

In this paper, a detailed review of microcontroller unit (MCU)-based wireless sensor node platforms from recently published research articles is presented. Despite numerous research efforts in the fast-growing field of wireless sensor devices, energy consumption remains a challenge that limits the lifetime of wireless sensor networks (WSNs). The Internet-of-Things (IoT) technology utilizes WSNs for providing an efficient sensing and communication infrastructure. Thus, a comparison of the existing wireless sensor nodes is crucial. Of particular interest are the advances in the recent MCU-based wireless sensor node platforms, which have become diverse and fairly advanced in relation to the currently available commercial WSN platforms. The recent wireless sensor nodes are compared with commercially available motes. The commercially available motes are selected based on a number of criteria including popularity, published results, interesting characteristics and features. Of particular interest is to understand the trajectory of development of these devices and the technologies so as to inform the research and application directions. The comparison is mainly based on processing and memory specifications, communication capabilities, power supply and consumption, sensor support, potential applications, node programming and hardware security. This paper attempts to provide a clear picture of the progress being made towards the design of autonomous wireless sensor nodes to avoid redundancy in research by industry and academia. This paper is expected to assist developers of wireless sensor nodes to produce improved designs that outperform the existing motes. Besides, this paper will guide researchers and potential users to easily make the best choice of a mote that best suits their specific application scenarios. A discussion on the wireless sensor node platforms is provided, and challenges and future research directions are also outlined. Full article
