This paper presents the theoretical foundation, practical implementation, and empirical evaluation of a glove for interaction with 3-D virtual environments. At the dawn of the “Spatial Computing Era”, where users continuously interact with 3-D Virtual and Augmented Reality environments, the need for a practical and intuitive interaction system that can efficiently engage 3-D elements is becoming pressing. Over the last few decades, there have been attempts to provide such an interaction mechanism using a glove. However, glove systems are currently not in widespread use due to their high cost and, we propose, due to their inability to sustain high levels of performance under certain situations. Performance deterioration has been observed due to the distortion of the local magnetic field caused by ordinary ferromagnetic objects present near the glove’s operating space. There are several areas where reliable hand-tracking gloves could provide a next generation of improved solutions, such as American Sign Language training and automatic translation to text and training and evaluation for activities that require high motor skills in the hands (e.g., playing some musical instruments, training of surgeons, etc.). While the use of a hand-tracking glove toward these goals seems intuitive, some of the currently available glove systems may not meet the accuracy and reliability levels required for those use cases. This paper describes our concept of an interaction glove instrumented with miniature magnetic, angular rate, and gravity (MARG) sensors and aided by a single camera. The camera used is an off-the-shelf red, green, and blue–depth (RGB-D) camera. We describe a proof-of-concept implementation of the system using our custom “GMVDK” orientation estimation algorithm. This paper also describes the glove’s empirical evaluation with human-subject performance tests. The results show that the prototype glove, using the GMVDK algorithm, is able to operate without performance losses, even in magnetically distorted environments. Full article

While the availability of low-cost micro electro-mechanical systems (MEMS) accelerometers, gyroscopes, and magnetometers initially seemed to promise the possibility of using them to easily track the position and orientation of virtually any object that they could be attached to, this promise has not yet been fulfilled. Navigation-grade accelerometers and gyroscopes have long been the basis for tracking ships and aircraft, but the signals from low-cost MEMS accelerometers and gyroscopes are still orders of magnitude poorer in quality (e.g., bias stability). Therefore, the applications of MEMS inertial measurement units (IMUs), containing tri-axial accelerometers and gyroscopes, are currently not as extensive as they were expected to be. Even the addition of MEMS tri-axial magnetometers, to conform magnetic, angular rate, and gravity (MARG) sensor modules, has not fully overcome the challenges involved in using these modules for long-term orientation estimation, which would be of great benefit for the tracking of human–computer hand-held controllers or tracking of Internet-Of-Things (IoT) devices. Here, we present an algorithm, GMVDμK (or simply GMVDK), that aims at taking full advantage of all the signals available from a MARG module to robustly estimate its orientation, while preventing damaging overcorrections, within the context of a human–computer interaction application. Through experimental comparison, we show that GMVDK is more robust to magnetic disturbances than three other MARG orientation estimation algorithms in representative trials. Full article

Motion capture systems have enormously benefited the research into human–computer interaction in the aerospace field. Given the high cost and susceptibility to lighting conditions of optical motion capture systems, as well as considering the drift in IMU sensors, this paper utilizes a fusion approach with low-cost wearable sensors for hybrid upper limb motion tracking. We propose a novel algorithm that combines the fourth-order Runge–Kutta (RK4) Madgwick complementary orientation filter and the Kalman filter for motion estimation through the data fusion of an inertial measurement unit (IMU) and an ultrawideband (UWB). The Madgwick RK4 orientation filter is used to compensate gyroscope drift through the optimal fusion of a magnetic, angular rate, and gravity (MARG) system, without requiring knowledge of noise distribution for implementation. Then, considering the error distribution provided by the UWB system, we employ a Kalman filter to estimate and fuse the UWB measurements to further reduce the drift error. Adopting the cube distribution of four anchors, the drift-free position obtained by the UWB localization Kalman filter is used to fuse the position calculated by IMU. The proposed algorithm has been tested by various movements and has demonstrated an average decrease in the RMSE of 1.2 cm from the IMU method to IMU/UWB fusion method. The experimental results represent the high feasibility and stability of our proposed algorithm for accurately tracking the movements of human upper limbs. Full article

In this paper, we present the FIU MARG Dataset (FIUMARGDB) of signals from the tri-axial accelerometer, gyroscope, and magnetometer contained in a low-cost miniature magnetic–angular rate–gravity (MARG) sensor module (also known as magnetic inertial measurement unit, MIMU) for the evaluation of MARG orientation estimation algorithms. The dataset contains 30 files resulting from different volunteer subjects executing manipulations of the MARG in areas with and without magnetic distortion. Each file also contains reference (“ground truth”) MARG orientations (as quaternions) determined by an optical motion capture system during the recording of the MARG signals. The creation of FIUMARGDB responds to the increasing need for the objective comparison of the performance of MARG orientation estimation algorithms, using the same inputs (accelerometer, gyroscope, and magnetometer signals) recorded under varied circumstances, as MARG modules hold great promise for human motion tracking applications. This dataset specifically addresses the need to study and manage the degradation of orientation estimates that occur when MARGs operate in regions with known magnetic field distortions. To our knowledge, no other dataset with these characteristics is currently available. FIUMARGDB can be accessed through the URL indicated in the conclusions section. It is our hope that the availability of this dataset will lead to the development of orientation estimation algorithms that are more resilient to magnetic distortions, for the benefit of fields as diverse as human–computer interaction, kinesiology, motor rehabilitation, etc. Full article

Precise pedestrian positioning based on smartphone-grade sensors has been a research hotspot for several years. Due to the poor performance of the mass-market Micro-Electro-Mechanical Systems (MEMS) Magnetic, Angular Rate, and Gravity (MARG) sensors, the standalone pedestrian dead reckoning (PDR) module cannot avoid long-time heading drift, which leads to the failure of the entire positioning system. In outdoor scenes, the Global Navigation Satellite System (GNSS) is one of the most popular positioning systems, and smartphone users can use it to acquire absolute coordinates. However, the smartphone’s ultra-low-cost GNSS module is limited by some components such as the antenna, and so it is susceptible to serious interference from the multipath effect, which is a main error source of smartphone-based GNSS positioning. In this paper, we propose a multi-phase GNSS/PDR fusion framework to overcome the limitations of standalone modules. The first phase is to build a pseudorange double-difference based on smartphone and reference stations, the second phase proposes a novel multipath mitigation method based on multipath partial parameters estimation (MPPE) and a Double-Difference Code-Minus-Carrier (DDCMC) filter, and the third phase is to propose the joint stride lengths and heading estimations of the two standalone modules, to reduce the long-time drift and noise. The experimental results demonstrate that the proposed multipath error estimation can effectively suppress the double-difference multipath error exceeding 4 m, and compared to other methods, our fusion method achieves a minimum error RMSE of 1.63 m in positioning accuracy, and a minimum error RMSE of 4.71 m in long-time robustness for 20 min of continuous walking. Full article

Background: This article presents the system architecture and validation of the NeuroSuitUp body–machine interface (BMI). The platform consists of wearable robotics jacket and gloves in combination with a serious game application for self-paced neurorehabilitation in spinal cord injury and chronic stroke. Methods: The wearable robotics implement a sensor layer, to approximate kinematic chain segment orientation, and an actuation layer. Sensors consist of commercial magnetic, angular rate and gravity (MARG), surface electromyography (sEMG), and flex sensors, while actuation is achieved through electrical muscle stimulation (EMS) and pneumatic actuators. On-board electronics connect to a Robot Operating System environment-based parser/controller and to a Unity-based live avatar representation game. BMI subsystems validation was performed using exercises through a Stereoscopic camera Computer Vision approach for the jacket and through multiple grip activities for the glove. Ten healthy subjects participated in system validation trials, performing three arm and three hand exercises (each 10 motor task trials) and completing user experience questionnaires. Results: Acceptable correlation was observed in 23/30 arm exercises performed with the jacket. No significant differences in glove sensor data during actuation state were observed. No difficulty to use, discomfort, or negative robotics perception were reported. Conclusions: Subsequent design improvements will implement additional absolute orientation sensors, MARG/EMG based biofeedback to the game, improved immersion through Augmented Reality and improvements towards system robustness. Full article

Aiming at the problem of the weak dynamic performance of the gradient descent method in the attitude and heading reference system, the susceptibility to the interference of accelerometers and magnetometers, and the complex calculation of the nonlinear Kalman Filter method, an extended Kalman filter suitable for a low-cost magnetic, angular rate, and gravity (MARG) sensor system is proposed. The method proposed in this paper is a combination of a two-stage gradient descent algorithm and the extended Kalman filter (GDEKF). First, the accelerometer and magnetometer are used to correct the attitude angle according to the two-stage gradient descent algorithm. The obtained attitude quaternion is combined with the gyroscope measurement value as the observation vector of EKF and the calculated attitude of the gyroscope and the bias of the gyroscope are corrected. The elimination of the bias of the gyroscope can further improve the stability of the attitude observation results. Finally, the MARG sensor system was designed for mathematical model simulation and hardware-in-the-loop simulation to verify the performance of the filter. The results show that compared with the gradient descent method, it has better anti-interference performance and dynamic performance, and better measurement accuracy than the extended Kalman filter. Full article

Indoor localization based on pedestrian dead reckoning (PDR) is drawing more and more attention of researchers in location-based services (LBS). The demand for indoor localization has grown rapidly using a smartphone. This paper proposes a 3D indoor positioning method based on the micro-electro-mechanical systems (MEMS) sensors of the smartphone. A quaternion-based robust adaptive cubature Kalman filter (RACKF) algorithm is proposed to estimate the heading of pedestrians based on magnetic, angular rate, and gravity (MARG) sensors. Then, the pedestrian behavior patterns are distinguished by detecting the changes of pitch angle, total accelerometer and barometer values of the smartphone in the duration of effective step frequency. According to the geometric information of the building stairs, the step length of pedestrians and the height difference of each step can be obtained when pedestrians go up and downstairs. Combined with the differential barometric altimetry method, the optimal height can be computed by the robust adaptive Kalman filter (RAKF) algorithm. Moreover, the heading and step length of each step are optimized by the Kalman filter to reduce positioning error. In addition, based on the indoor map vector information, this paper proposes a heading calculation strategy of the 16-wind rose map to improve the pedestrian positioning accuracy and reduce the accumulation error. Pedestrian plane coordinates can be solved based on the Pedestrian Dead-Reckoning (PDR). Finally, combining pedestrian plane coordinates and height, the three-dimensional positioning coordinates of indoor pedestrians are obtained. The proposed algorithm is verified by actual measurement examples. The experimental verification was carried out in a multi-story indoor environment. The results show that the Root Mean Squared Error (RMSE) of location errors is 1.04–1.65 m by using the proposed algorithm for three participants. Furthermore, the RMSE of height estimation errors is 0.17–0.27 m for three participants, which meets the demand of personal intelligent user terminal for location service. Moreover, the height parameter enables users to perceive the floor information. Full article

The orientation of a magneto-inertial measurement unit can be estimated using a sensor fusion algorithm (SFA). However, orientation accuracy is greatly affected by the choice of the SFA parameter values which represents one of the most critical steps. A commonly adopted approach is to fine-tune parameter values to minimize the difference between estimated and true orientation. However, this can only be implemented within the laboratory setting by requiring the use of a concurrent gold-standard technology. To overcome this limitation, a Rigid-Constraint Method (RCM) was proposed to estimate suboptimal parameter values without relying on any orientation reference. The RCM method effectiveness was successfully tested on a single-parameter SFA, with an average error increase with respect to the optimal of 1.5 deg. In this work, the applicability of the RCM was evaluated on 10 popular SFAs with multiple parameters under different experimental scenarios. The average residual between the optimal and suboptimal errors amounted to 0.6 deg with a maximum of 3.7 deg. These encouraging results suggest the possibility to properly tune a generic SFA on different scenarios without using any reference. The synchronized dataset also including the optical data and the SFA codes are available online. Full article

(1) Background: Data mining has turned essential when exploring a large amount of information in performance analysis in sports. This study aimed to select the most relevant variables influencing the external and internal load in top-elite 5-a-side soccer (Sa5) using a data mining model considering some contextual indicators as match result, body mass index (BMI), scoring rate and age. (2) Methods: A total of 50 top-elite visually impaired soccer players (age 30.86 ± 11.2 years, weight 77.64 ± 9.78 kg, height 178.48 ± 7.9 cm) were monitored using magnetic, angular and rate gyroscope (MARG) sensors during an international Sa5 congested fixture tournament.; (3) Results: Fifteen external and internal load variables were extracted from a total of 49 time-related and peak variables derived from the MARG sensors using a principal component analysis as the most used data mining technique. The principal component analysis (PCA) model explained 80% of total variance using seven principal components. In contrast, the first principal component of the match was defined by jumps, take off by 24.8% of the total variance. Blind players usually performed a higher number of accelerations per min when losing a match. Scoring players execute higher Distance_Explosive and Distance_{21–24 km/h}. And the younger players presented higher HR_AVG and Acc_Max. (4) Conclusions: The influence of some contextual variables on external and internal load during top elite Sa5 official matches should be addressed by coaches, athletes, and medical staff. The PCA seems to be a useful statistical technique to select those relevant variables representing the team’s external and internal load. Besides, as a data reduction method, PCA allows administrating individualized training loads considering those relevant variables defining team load behavior. Full article

This paper presents a lightweight, infrastructureless head-worn interface for robust and real-time robot control in Cartesian space using head- and eye-gaze. The interface comes at a total weight of just 162 g. It combines a state-of-the-art visual simultaneous localization and mapping algorithm (ORB-SLAM 2) for RGB-D cameras with a Magnetic Angular rate Gravity (MARG)-sensor filter. The data fusion process is designed to dynamically switch between magnetic, inertial and visual heading sources to enable robust orientation estimation under various disturbances, e.g., magnetic disturbances or degraded visual sensor data. The interface furthermore delivers accurate eye- and head-gaze vectors to enable precise robot end effector (EFF) positioning and employs a head motion mapping technique to effectively control the robots end effector orientation. An experimental proof of concept demonstrates that the proposed interface and its data fusion process generate reliable and robust pose estimation. The three-dimensional head- and eye-gaze position estimation pipeline delivers a mean Euclidean error of $19.0\pm 15.7$ mm for head-gaze and $27.4\pm 21.8$ mm for eye-gaze at a distance of 0.3–1.1 m to the user. This indicates that the proposed interface offers a precise control mechanism for hands-free and full six degree of freedom (DoF) robot teleoperation in Cartesian space by head- or eye-gaze and head motion. Full article

This paper presents an open-source environment for development, tuning, and performance evaluation of magnetic, angular rate, and gravity-based (MARG-based) filters, such as pose estimators and classification algorithms. The environment is available in both ROS/Gazebo and MATLAB/Simulink, and it contains a six-degrees of freedom (6 DOF) test bench, which simultaneously moves and rotates an MARG unit in the three-dimensional (3D) space. As the quality of MARG-based estimation becomes crucial in dynamic situations, the proposed test platform intends to simulate different accelerating and vibrating circumstances, along with realistic magnetic perturbation events. Moreover, the simultaneous acquisition of both the real pose states (ground truth) and raw sensor data is supported during these simulated system behaviors. As a result, the test environment executes the desired mixture of static and dynamic system conditions, and the provided database fosters the effective analysis of sensor fusion algorithms. The paper systematically describes the structure of the proposed test platform, from mechanical properties, over mathematical modeling and joint controller synthesis, to implementation results. Additionally, a case study is presented of the tuning of popular attitude estimation algorithms to highlight the advantages of the developed open-source environment. Full article

The demands for indoor positioning in location-based services (LBS) and applications grow rapidly. It is beneficial for indoor positioning to combine attitude and heading information. Accurate attitude and heading estimation based on magnetic, angular rate, and gravity (MARG) sensors of micro-electro-mechanical systems (MEMS) has received increasing attention due to its high availability and independence. This paper proposes a quaternion-based adaptive cubature Kalman filter (ACKF) algorithm to estimate the attitude and heading based on smart phone-embedded MARG sensors. In this algorithm, the fading memory weighted method and the limited memory weighted method are used to adaptively correct the statistical characteristics of the nonlinear system and reduce the estimation bias of the filter. The latest step data is used as the memory window data of the limited memory weighted method. Moreover, for restraining the divergence, the filter innovation sequence is used to rectify the noise covariance measurements and system. Besides, an adaptive factor based on prediction residual construction is used to overcome the filter model error and the influence of abnormal disturbance. In the static test, compared with the Sage-Husa cubature Kalman filter (SHCKF), cubature Kalman filter (CKF), and extended Kalman filter (EKF), the mean absolute errors (MAE) of the heading pitch and roll calculated by the proposed algorithm decreased by 4–18%, 14–29%, and 61–77% respectively. In the dynamic test, compared with the above three filters, the MAE of the heading reduced by 1–8%, 2–18%, and 2–21%, and the mean of location errors decreased by 9–22%, 19–31%, and 32–54% respectively by using the proposed algorithm for three participants. Generally, the proposed algorithm can effectively improve the accuracy of heading. Moreover, it can also improve the accuracy of attitude under quasistatic conditions. Full article

(1) Background: This study aimed to explore wearable sensors′ potential use to assess cumulative mechanical kidney trauma during endurance off-road running. (2) Methods: 18 participants (38.78 ± 10.38 years, 73.24 ± 12.6 kg, 172.17 ± 9.48 cm) ran 36 k off-road race wearing a Magnetic, Angular Rate and Gravity (MARG) sensor attached to their lower back. Impacts in g forces were recorded throughout the race using the MARG sensor. Two blood samples were collected immediately pre- and post-race: serum creatinine (sCr) and albumin (sALB). (3) Results: Sixteen impact variables were grouped using principal component analysis in four different principal components (PC) that explained 90% of the total variance. The 4th PC predicted 24% of the percentage of change (∆%) of sCr and the 3rd PC predicted the ∆% of sALB by 23%. There were pre- and post-race large changes in sCr and sALB (p ≤ 0.01) and 33% of participants met acute kidney injury diagnosis criteria. (4) Conclusions: The data related to impacts could better explain the cumulative mechanical kidney trauma during mountain running, opening a new range of possibilities using technology to better understand how the number and magnitude of the g-forces involved in off-road running could potentially affect kidney function. Full article

Assistive robots support people with limited mobility in their everyday life activities and work. However, most of the assistive systems and technologies for supporting eating and drinking require a residual mobility in arms or hands. For people without residual mobility, different hands-free controls have been developed. For hands-free control, the combination of different modalities can lead to great advantages and improved control. The novelty of this work is a new concept to control a robot using a combination of head and eye motions. The control unit is a mobile, compact and low-cost multimodal sensor system. A Magnetic Angular Rate Gravity (MARG)-sensor is used to detect head motion and an eye tracker enables the system to capture the user’s gaze. To analyze the performance of the two modalities, an experimental evaluation with ten able-bodied subjects and one subject with tetraplegia was performed. To assess discrete control (event-based control), a button activation task was performed. To assess two-dimensional continuous cursor control, a Fitts’s Law task was performed. The usability study was related to a use-case scenario with a collaborative robot assisting a drinking action. The results of the able-bodied subjects show no significant difference between eye motions and head motions for the activation time of the buttons and the throughput, while, using the eye tracker in the Fitts’s Law task, the error rate was significantly higher. The subject with tetraplegia showed slightly better performance for button activation when using the eye tracker. In the use-case, all subjects were able to use the control unit successfully to support the drinking action. Due to the limited head motion of the subject with tetraplegia, button activation with the eye tracker was slightly faster than with the MARG-sensor. A further study with more subjects with tetraplegia is planned, in order to verify these results. Full article
