Ensuring Global Navigation Satellite System (GNSS) integrity, which provides operational reliability via fault detection, is important for safety-critical applications using high-precision techniques like Precise Point Positioning (PPP) and Real-Time Kinematic (RTK). Ionospheric errors, from atmospheric free electrons, challenge this integrity by introducing variable uncertainties into positioning solutions. This study investigates how ionospheric error modeling spatial resolution impacts protection level (PL) calculations, a metric defining positioning error bounds with high confidence. A comparative evaluation was conducted in low-latitude (Guangdong) and mid-latitude (Shandong) regions, contrasting large-scale with small-scale grid-based ionospheric models from regional GNSS networks. Experimental results show small-scale grids improve characterization of localized ionospheric variability, reducing ionospheric residual standard deviation by approximately 30% and enhancing PL precision. Large-scale grids show limitations, especially in active low-latitude conditions, leading to conservative PLs that reduce system availability and increase missed fault detection risks. A user-side PL computation framework incorporating this high-resolution ionospheric residual uncertainty improved system availability to 94.7% and lowered misleading and hazardous outcomes by over 80%. This research indicates that refined, high-resolution ionospheric modeling improves operational reliability and safety for high-integrity GNSS applications, particularly under diverse and challenging ionospheric conditions. Full article

Extended Kalman Filter (EKF) is extensively employed in Global Navigation Satellite System (GNSS)-based real-time orbit determination (RTOD) for microsatellites due to its low complexity. However, the performance of EKF-RTOD is markedly degraded when the microsatellite deviates from a stable Earth-pointing attitude and employs a low-cost receiver. Factor graph optimization (FGO), which addresses nonlinear problems through multiple iterations and re-linearization, has demonstrated superior accuracy and robustness compared to EKF in challenging environments such as urban canyons. In this study, we introduce a novel FGO-based RTOD (FGO-RTOD) approach, which integrates state transfer factors to establish temporal connections between state nodes across multiple epochs. Real-time processing is achieved through a sliding window mechanism combined with marginalization. This paper evaluates the performance of the proposed algorithm in a regular scenario using data from GRACE-FO-A, which maintains the Earth-pointing attitude and employs a high-performance receiver. The positioning results of GRACE-FO-A indicate that FGO-RTOD marginally outperforms EKF-RTOD in accuracy. Furthermore, the performance of FGO-RTOD is assessed in challenging scenarios using simulation data and on-orbit data from Tianping-2B microsatellite, which is not in an Earth-pointing attitude and employs a low-cost receiver. The simulation results reveal that FGO-RTOD reduces the Root Mean Square (RMS) of positioning error by 79.0% relative to EKF-RTOD and exhibits significantly enhanced smoothing. In the Tianping-2B experiments, FGO-RTOD reduces the RMS of carrier-phase ionosphere-free combination residuals from 2 cm to 1 cm relative to EKF-RTOD, alongside a substantial improvement in the ratio of valid observations. These findings underscore the effectiveness of FGO-RTOD in managing outlier measurements in challenging scenarios. Full article

The Earth rotation parameters (ERP) play a crucial role in defining the global reference frame and the Global Navigation Satellite System (GNSS) is one of the important tools used to obtain ERP, including polar motion (PM), its rates, and length of day (LOD). The latest IGS Repro3 ERP products, which provided the IGS contribution to the latest ITRF2020, were generated without consideration of the Beidou Navigation Satellite System (BDS) observations. The global BDS, namely the BDS-3 constellation, has been completely constructed from July 2020 and the observing stations are evenly distributed globally now. Two couple dual-frequency combinations, including the B1I/B3I and B1C/B2a combinations, are commonly used for BDS-3 ionosphere-free combination usage. With the goal of identifying the optimal dual-frequency combination for BDS-3 ERP estimates for the future ITRF definition with a consideration of BDS-3, this research evaluated the performance of ERP estimation using B1I/B3I and B1C/B2a combinations. Firstly, we conducted a comparison of the ambiguity resolutions. The mean percentage of successfully resolved ambiguities for the BDS-3 B1C/B2a combination is 86.5%, surpassing that of B1I/B3I. The GNSS satellite orbits and ERP were estimated simultaneously, thus the accuracy of orbits could also reflect the performance of the ERP estimates. Subsequently, we validated the orbits of 22 BDS-3 Medium Earth Orbit (MEO) satellites using Satellite Laser Ranging (SLR), and the root mean square error (RMS) of the SLR residuals for the 3-day arc orbit with B1C/B2a signals was 5.72 cm, indicating superior accuracy compared with the B1I/B3I combination. Finally, we compared the performance of ERP estimation, considering both internal and external accuracy. For the internal accuracy, B1C/B2a-based solutions demonstrated a reduction in mean formal errors of approximately 17% for PM, 22% for LOD, and 21% for PM rates compared with B1I/B3I-based solutions. In terms of external accuracy, we compared BDS-3-derived ERP estimates with the IERS 20C04 products. The B1C/B2a combination exhibited a slightly better standard deviation performance and a significant reduction in mean bias by 56%, 54%, 39%, 64%, and 23% for X, Y polar motion, X, Y polar motion rates, and LOD, respectively, compared with B1I/B3I solutions. In conclusion, the results highlight the excellent signal quality for BDS-3 B1C/B2a and its superiority in ERP estimation when compared with the B1I/B3I combination. Full article

Currently, there are two main methods for single-epoch decimeter-level precise point positioning (PPP); one is a model based on ambiguity-fixed ionosphere-free (AFIF) observations, and the other is based on uncombined (UC) PPP. The implementation of these two models requires both extra-wide-lane (EWL) and wide-lane (WL) ambiguity fixing. Different from the existing methods, this paper proposes a multi-frequency ionosphere-reduced (IR) PPP model suitable for single-epoch decimeter-level positioning. Based on Galileo five-frequency data, the optimal selection strategy of IR combinations is first studied with ionosphere, noise level and wavelength factors considered. Then, based on the selected IR combination, two IR PPP models, namely IR(EST) and IR(IGN), are established according to whether ionosphere parameters are estimated or ignored. Finally, the proposed models are verified with real tracked data from globally distributed stations, and further compared with the existing AFIF/UC models in terms of positioning performance and time consumption. The relationship between the ionosphere equivalent ranging error and satellite elevation in the IR models is analyzed. The lower the elevation is, the larger the residual ranging error is, and its impact on positioning is weakened by downweighting its observations and adjusting the cut-off elevation during the partial ambiguity fixing (PAF) process. The results show that the performance of the two IR models is basically the same, and both can achieve horizontal and vertical accuracies better than 20 cm and 40 cm, respectively. Compared with the existing AFIF/UC models, the proposed IR models can achieve similar decimeter-level accuracy with only one step of EWL ambiguity fixing, and at the same time, the IR models have varying degrees of improvement in time consumption: 38% shorter than the AFIF model and 97% shorter than the UC model. Full article

BeiDou Global Navigation Satellite System (BDS-3) broadcasts multifrequency signals that offer more choices of frequencies and more signal combinations for positioning. This paper analyzes the effect of timing group delay (TGD) and differential code bias (DCB) of BDS-3 on the corresponding triple-frequency positioning. The triple-frequency observation models of BDS-3 are summarized and the DCB correction models are derived for the four different frequency combinations of triple-frequency ionospheric-free (IF) combination (IF123), two dual-frequency IF combinations (IF1213) and triple-frequency uncombined (UC123) positioning modes. Standard point positioning (SPP) and precise point positioning (PPP) experiments were conducted using 30 days of observations from 25 multi-GNSS experiment (MGEX) stations. The results show that the TGD/DCB correction has a significant impact on the accuracy of SPP. The positioning accuracy using IF123 and IF1213 models improved by about 73~90% after TGD correction, in comparison to a 27~30% improvement achieved using the UC123 model. In addition, the correction effect of DCB is slightly better than TGD. The DCB correction significantly improves accuracy in the initial epoch of the PPP, which helps the convergence of the filtering and reduces the convergence time. The average convergence times of IF123, IF1213 and UC123 are 26.1, 26.9 and 38.3 min, respectively, which are reduced by 6.79, 2.54 and 8.59% with DCB correction. The pseudorange residuals are closer to zero-mean random noise after DCB correction. Furthermore, the DCB affects the evaluation of the inter-frequency bias (IFB), ionospheric delay and floating ambiguity parameters. However, the tropospheric delay is almost unaffected by DCB. Full article

This paper presents a novel technique to estimate DCBs from GPS transmitters and receivers on-board Low Earth Orbit (LEO) satellites. The technique consists of obtaining the DCBs as residuals from the difference between the ionospheric combination of the code and the associated ionospheric delay. The ionospheric delay is computed with TOMION, a background-model-free ionospheric tomographic technique based on dual-frequency GPS carrier phase data only, and solved with a Kalman filter. Thus, DCBs are also estimated epoch-wise from the LEO Precise Orbit Determination (POD) GPS receiver as a secondary product. The results for GPS satellite DCBs, obtained exclusively from the three MetOp LEO POD GPS receivers over four consecutive weeks, are in full agreement (i.e., at the level of a few tenths of ns) with those reported independently with other techniques from hundreds of ground-based receivers exclusively, by JPL and CODE analysis centers. Full article

For long baseline in a network, the traditional combined ionosphere-free (IF) + wide-lane (WL) strategy is commonly used, but the residual tropospheric delays and larger noise hamper the basic ambiguity resolution (AR). With the completion of the BeiDou global navigation satellite system (BDS-3) and the quad-frequency signals provided by BDS-3 satellites, we can construct more combinations that are conducive to ambiguity resolution. Compared with ionosphere-free linear combinations, we estimated ionospheric delay using three independent WL observations, and formed an ionosphere-weighted model using uncombined code and phase observations, which proved to be quite effective. Based on the real quad-frequency BDS-3 observations of two CORS (Continuously Operating Reference Stations) and two user stations, we processed eight days of data to study the formal and empirical ambiguity success rates and user positioning errors. The rounding success rate of WL ambiguity was significantly improved with ionospheric correction. The success rate of the basic ambiguity increased from 94.4 and 96.1% to 98.0% using the quad-frequency ionosphere-weighted (QFIW) model compared with the double-frequency ionosphere-free (DFIF) model and the triple-frequency geometry-based (TFGB) model. Furthermore, the user E/N/U positioning accuracy improved by 20.6/31.5/13.1% and 6.3/22.9/5.8%, respectively. Full article

Low Earth Orbit (LEO) satellites can be used for remote sensing and gravity field recovery, while precise orbit determination (POD) is vital for LEO satellite applications. However, there are some systematic errors when using the LEO satellite orbits released by different agencies in multi-satellite-based applications, e.g., Swarm and Gravity Recovery and Climate Experiment-Follow-On (GRACE-FO), as different GNSS precise orbit and clock products are used as well as processing strategies and software. In this paper, we performed undifferenced kinematic PODs for Swarm and GRACE-FO satellites simultaneously over a total of 14 days by using consistent International Global Navigation Satellite System (GNSS) Service (IGS) precise orbit and clock products. The processing strategy based on an undifferenced ionosphere-free combination and a least squares method was applied for Swarm and GRACE-FO satellites. Furthermore, the quality control for the kinematic orbits was adopted to mitigate abrupt position offsets. Moreover, the accuracy of the kinematic orbits solution was evaluated by carrier phase residual analysis and Satellite Laser Ranging (SLR) observations, as well as comparison with official orbits. The results show that the kinematic orbits solution is better than 4 cm, according to the SLR validation. With quality control, the accuracy of the kinematic orbit solution is improved by 2.49 % for the Swarm-C satellite and 6.98 % for the GRACE-D satellite when compared with their precise orbits. By analyzing the accuracy of the undifferenced kinematic orbit solution, the reliability of the LEO orbit determination is presented in terms of processing strategies and quality control procedures. Full article

Due to different designs of receiver correlators and front ends, receiver-related pseudorange biases, called signal distortion biases (SDBs), exist. Ignoring SDBs that can reach up to 0.66 cycles and 10 ns in Melbourne-Wübbena (MW) and ionosphere-free (IF) combinations can negatively affect phase bias estimation. In this contribution, we investigate the SDBs and evaluate the impacts on wide-lane (WL) and narrow-lane (NL) phase bias estimations, and further propose an approach to eliminating these SDBs to improve phase bias estimation. Based on a large data set of 302 multi-global navigation satellite system (GNSS) experiment (MGEX) stations, including 5 receiver brands, we analyze the characteristics of these SDBs The SDB characteristics of different receiver types for different GNSS systems differ from each other. Compared to the global positioning system (GPS) and BeiDou navigation satellite system (BDS), SDBs of Galileo are not significant; those of BDS-3 are significantly superior to BDS-2; Septentrio (SEPT) receivers show the most excellent consistency among all receiver types. Then, we apply the corresponding corrections to phase bias estimation for GPS, Galileo and BDS. The experimental results reveal that the calibration can greatly improve the performance of phase bias estimation. For WL phase biases estimation, the consistencies of WL phase biases among different networks for GPS, Galileo, BDS-2 and BDS-3 improve by 89%, 77%, 76% and 78%, respectively. There are scarcely any improvements of the fixing rates for Galileo due to its significantly small SDBs, while for GPS, BDS-2 and BDS-3, the WL ambiguity fixing rates can improve greatly by 13%, 27% and 14% after SDB calibrations with improvements of WL ambiguity fixing rates, the corresponding NL ambiguity fixing rates can further increase greatly, which can reach approximately 16%, 27% and 22%, respectively. Additionally, after the calibration, both WL and NL phase bias series become more stable. The standard deviations (STDs) of WL phase bias series for GPS and BDS can improve by more than 46%, while those of NL phase bias series can yield improvements of more than 13%. Ultimately, the calibration can make more WL and NL ambiguity residuals concentrated in ranges within ±0.02 cycles. All these results demonstrate that SDBs for phase bias estimation cannot be ignored and must be considered when inhomogeneous receivers are used. Full article

Precise knowledge of the phase center location of the global navigation satellite system (GNSS) antenna is a prerequisite for precise orbit determination (POD) of the low Earth orbit (LEO) satellite. The phase center offset (PCO) and phase center variation (PCV) values for the LEO antenna obtained from ground calibration cannot reflect the error sources encountered in the actual spacecraft environment. PCV corrections are estimated by ionosphere free (IF) carrier phase post-fit residuals of reduced dynamic orbit determination. Ambiguity resolution (AR) plays a crucial role in achieving the best orbit accuracy. The single receiver AR concept is realized using wide-lane (WL) and narrow-lane (NL) bias products. Single difference (SD) observations between satellites are applied to remove the receiver dependent phase bias. SD AR and traditional double difference (DD) AR methods are applied to fix the ambiguities. The recovered SD and DD IF ambiguities are taken as pseudo-observations to constrain the undifferenced IF ambiguity parameters in the POD process. The LEO orbits based on float ambiguity (FA), SD, AR, and DD AR are investigated. One year’s data collected by the Gravity Recovery And Climate Experiment Follow-On (GRACE-FO) mission and GPS precise products provided by the Center for Orbit Determination in Europe (CODE) were analyzed. Precise orbit generated by the Jet Propulsion Laboratory (JPL), independent satellite laser ranging (SLR), and K-band ranging (KBR) measurements were utilized to assess the orbit accuracy. More than 98% of SD WL and 95% of SD NL ambiguities are fixed, which confirms the good quality of the bias products and correctness of the SD AR method. With PCV corrections, the average phase residuals of DD and SD AR solutions are 0.13 and 0.41 mm, which indicates improved consistency between applied models and observations. Compared with JPL’s orbit, the SD AR orbits achieve the accuracy of 6.0, 6.2, and 5.1 mm in along-track, cross-track, and radial directions. The SD AR solutions show an average improvement of 18.3% related to the FA orbits while 6.3% is gained by the DD AR approach. The root mean squares (RMSs) of SLR residuals for FA, DD AR, and SD AR solutions are 11.5, 10.2, and 9.6 mm, which validate the positive effect of AR on POD. Standard deviation (STD) of KBR residuals for SD AR orbits is 1.8 mm while 0.9 mm is achieved by the DD AR method. The explanation is that the phase bias products used for SD AR are not free of errors and the errors may degrade the KBR validation. In-flight PCV calibration and ambiguity resolution improve the LEO orbit accuracy effectively. Full article

In this work, quad-frequency precise point positioning (PPP) time and frequency transfer methods using Galileo E1/E5a/E5b/E5 and BDS-3 B1I/B3I/B1C/B2a observations were proposed with corresponding mathematical models. In addition, the traditional dual-frequency (BDS-3 B1I/B3I and Galileo E1/E5a) ionospheric-free (IF) model was also described and tested for comparison. To assess the proposed method for time transfer, datasets selected from timing labs were utilized and tested. Moreover, the number of Galileo or BDS-3 satellites, pseudorange residuals, positioning accuracy and tropospheric delay at receiver end were all analyzed. The results showed that the proposed quad-frequency BDS-3 or Galileo PPP models could be used to time transfer, due to stability and accuracy identical to that of dual-frequency IF model. Furthermore, the quad-frequency models can provide potential for enhancing the reliability and redundancy compared to the dual-frequency time transfer method. Full article

The reparameterization of the geometry-free and geometry-based approaches to derive single-site ionospheric delays using Global Navigation Satellite System (GNSS) measurements is described. Kalman filtering is used to compute the geometry-free and geometry-based ionospheric delays in a forward computation procedure, aiming for a real-time application case. The numerical similarity and differences between the geometry-free and geometry-based ionospheric delays are assessed in terms of both formal and experimental errors (precision). The differences between geometry-free and geometry-based ionospheric delays are derived using two types of precise orbit and clock products. The effects of the precise orbit and clock residual errors are analyzed. The correlation coefficients between the L1 and L2 wide-lane ambiguities with the ionospheric delay are derived and analyzed. It is discovered that the geometry-based ionospheric delay is negatively correlated with geometry-based wide-lane ambiguities, while the geometry-free ionospheric delay and wide-lane ambiguities are much less correlated. A simulation analysis indicates that the impacts on geometry-based ionospheric delay estimates are partly coincided with the actual time-variant errors of the used orbit and clock in the line-of-sight direction. Full article

Real-time cycle slip detection and repair is one of the key issues in global positioning system (GPS) high precision data processing and application. In particular, when GPS stations are in special environments, such as strong ionospheric disturbance, sea, and high-voltage transmission line interference, cycle slip detection and repair in low elevation GPS observation data are more complicated than those in normal environments. For low elevation GPS undifferenced carrier phase data in different environments, a combined cycle slip detection algorithm is proposed. This method uses the first-order Gauss–Markov stochastic process to model the pseudorange multipath in the wide-lane phase minus narrow-lane pseudorange observation equation, and establishes the state equation of the wide-lane ambiguity with the pseudorange multipath as a parameter, and it uses the Kalman filter for real-time estimation and detects cycle slips based on statistical hypothesis testing with a predicted residual sequence. Meanwhile, considering there are certain correlations among low elevation, observation epoch interval, and ionospheric delay error, a second-order difference geometry-free combination cycle slip test is constructed that takes into account the elevation. By combining the two methods, real-time cycle slip detection for GPS low elevation satellite undifferenced data is achieved. A cycle slip repair method based on spatial search and objective function minimization criterion is further proposed to determine the correct solution of the cycle slips after they are detected. The whole algorithm is experimentally verified using the static and kinematic measured data of low elevation satellites under four different environments: normal condition, high-voltage transmission lines, dynamic condition in the sea, and ionospheric disturbances. The experimental results show that the algorithm can detect and repair cycle slips accurately for low elevation GPS undifferenced data, the difference between the float solution and the true value for the cycle slip does not exceed 0.5 cycle, and the differences obey the normal distribution overall. At the same time, the wide-lane ambiguity and second-order difference GF combination sequence calculated by the algorithm is smoother, which give further evidence that the algorithm for cycle slip detection and repair is feasible and effective, and has the advantage of being immune to the special observation environments. Full article

In advance of precise positioning with phase data, cycle slip detection (CSD) is a basic work that should be implemented in phase data possessing. When the cycle slip occurred, cycle slip repair (CSR) can be taken to rebuild the continuity of phase data. Unfortunately, the large pseudorange errors can contaminate the combinations with the pseudoranges and phases such as the Hatch–Melbourne–Wubbena combination (HMW) and cause false CSD or wrong CSR results. On the other hand, the severe ionospheric time variation can deteriorate the epoch-difference geometry-free phase (GF), and tremendously interfere with the performances of CSD and CSR. To handle the aforementioned limitations, a global position system (GPS) triple-frequency CSR method (GTCSR) is proposed with two efficient treatments: (1) the significant ionospheric variations are corrected, and the influences from the residual ionospheric effects are minimized along with the observational noises; and (2) the impacts of large pseudorange errors are refrained by designing a discrimination function with a geometry-free and ionosphere-free phase to identify the correct cycle slip values. Consequently, CSR tests were conducted with three monitoring stations at different regions. First, during a strong geomagnetic storm, without correcting the ionospheric variation of CSR (WICSR) displayed obvious failures, and many epochs of cycle slip values from WICSR deviated from the known values. However, the results of the GTCSR were correct, and GTCSR presented a higher success rate than that of WICSR. Furthermore, for the real triple-frequency data, by adding gross errors of 2.5 m on all epoch-difference pseudoranges epoch by epoch, the conventional triple-frequency CSR with the optimized combinations (CTCSR) and the CSD with HMW (HMWCSD) showed many mistakes, where the results of CTCSR and HMWCSD on numerous epochs were inconsistent with the actual situations, but the success rate of GTCSR was significantly higher than those of CTCSR and HMWCSD. In summary, in the condition of the cutoff elevation being larger than 10 degrees, improved performances and higher success rates were achieved from GTCSR under environments of large pseudorange errors and severe ionospheric variations. Full article

Recently, some smartphone manufacturers have subsequently released dual-frequency GNSS smartphones. With dual-frequency observations, the positioning performance is expected to be significantly improved. Cycle-slip detection and correction play an important role in high-precision GNSS positioning, such as precise point positioning (PPP) and real-time kinematic (RTK) positioning. The TurboEdit method utilizes Melbourne–Wübbena (MW) and phase ionospheric residual (PIR) combinations to detect cycle-slips, and it is widely used in the data processing applications for geodetic GNSS receivers. The smartphone pseudorange observations are proved to be much noisier than those collected with geodetic GNSS receivers. Due to the poor pseudorange observation, the MW combination would be difficult to detect small cycle-slips. In addition, some specific cycle-slip combinations, where the ratio of cycle-slip values at different carrier frequencies is close to the frequency ratio, are also difficult to be detected by PIR combination. As a consequence, the traditional TurboEdit method may fail to detect specific small cycle-slip combinations. In this contribution, we develop a modified TurboEdit cycle-slip detection and correction method for dual-frequency smartphone GNSS observations. At first, MW and PIR combinations are adopted to detect cycle-slips by comparing these two combinations with moving-window average values. Then, the epoch-differenced wide-lane combinations are used to estimate the changes of smartphone position and clock bias, and the cycle-slip is identified by checking the largest normalized residual whether it exceeds a predefined threshold value. The process of estimation and cycle-slip identification is implemented in an iterative way until there is no over-limit residual or there is no redundant measurement. At last, the cycle-slip values at each frequency are estimated with the epoch-differenced wide-lane and ionosphere-free combinations, and the least-square ambiguity decorrelation adjustment (LAMBDA) method is adopted to further obtain an integer solution. The proposed method has been verified with 1 Hz dual-frequency smartphone GNSS data. The results show that the modified TurboEdit method can effectively detect and correct even for specific small cycle-slip combinations, e.g., (4, 3), which is difficult to be detected with the traditional TurboEdit method. Full article
