Owing to the challenge of capturing the dynamic behaviour of metal experimentally, high-precision numerical simulations have become essential for analysing dynamic characteristics. In this study, calculation accuracy was improved by analysing the impact of constitutive models using the finite element (FE) model, and the deep learning (DL) model was employed for result analysis. The results showed that FE simulations with these models effectively capture the elastic-plastic response, and the ZA model exhibits the highest accuracy, with a 26.0% accuracy improvement compared with other models at 502 m/s for Hugoniot elastic limit (HEL) stress. The different constitutive models offer diverse descriptions of stress during the elastic-plastic response because of temperature effects. Concurrently, the parameters related to the yield strength at quasi-static influence the propagation speed of elastic waves. Calculation show that the yield strength at quasi-static of 6061 Al adheres to y = ax + b for HEL stress. The R-squared (R²) and mean absolute error (MAE) values of the DL model for HEL stress predictions are 0.998 and 0.0062, respectively. This research provides a reference for selecting constitutive models for simulation under the same conditions. Full article

The present study aimed to provide new insights into the behavior of high-strength low-alloy steel under dynamic compression and to promote its use in high-stress applications. The dynamic compression response of a Cr-Ni-Mo-V steel under shock stresses ranging from 3.54 GPa to 19.76 GPa was investigated using loading technology. The free surface velocity of the specimen was measured using a displacement interferometer system with the range of 166–945 m/s. The Hugoniot elastic limit (HEL), spalling fracture, and microstructure evolution of specimens under different shock stresses were determined. The results showed that an α→ε phase transition occurred in the material at an impact stress of 15.63 GPa, leading to a change in particle velocity. The relationship between the shock wave velocity and particle velocity was found to be linear. The HEL of the steel was found to be consistent at 2.28 GPa, while the spall strength showed a more complex relationship with the increasing shock stress. Initially, the spall strength increased and then decreased with increasing shock stress before increasing again after the phase transformation. The fracture mode of the steel shifted from brittle fracture to ductile fracture with the increasing impact stresses, which is related to the previous plastic deformation under different impact loads. Full article

The shock and spalling behavior of a compositionally complex high strength low-alloy steel (HSLA) was studied using plate impact testing. The free surface velocity of the specimen in the range of 194~938 m/s was measured by a displacement interferometer system for any reflector (DISAR). The Hugoniot elastic limit (HEL), spallation fracture and microstructural evolution of the HSLA under an impact stress of 3.04~18.66 GPa were analyzed. Shock Hugoniots were obtained from the measured particle velocities and calculated shock velocities. The velocity curves show clear signs of HEL and velocity fallback, indicating a transition from elastic to plastic and spalling behavior. When the impact velocity exceeds 757 m/s, the particle velocity rises to the peak and then increases again, indicating that an α→ε phase transition occurred, with a threshold of 13.51 GPa. It was found that the impact velocity is linearly related to the particle velocity of the HSLA. As the impact stress increased, the HEL remained within the range of 1.32~1.50 GPa, while the spalling strength presented an upward trend with the increasing impact stresses. Metallographic analysis shows that the impact failure is dominated by brittle fracture at lower velocities, while more ductile fracture occurs at higher velocities. Full article

The Hugoniot elastic limit and spall strength were measured for a heat-resistant metal-matrix composite Inconel 625–5%NiTi–TiB₂ alloy additive manufactured (AM) by direct laser deposition. The strength characteristics of the alloy were obtained from the analysis of the complete wave profiles recorded with a VISAR laser Doppler velocimeter during shock-wave loading of the samples. The samples were loaded using a PP50 pneumatic gun or ad hoc explosive devices along and across the material deposition direction in order to determine the strength anisotropy of the AM alloy under study. The maximum shock compression pressure was ~7 GPa, and the strain rate under tension before spalling varied in the range of 10⁵–10⁶ s^–1. Kinetic dependencies of elastic/plastic transition and critical fracture stresses vs. loading conditions were plotted. It was shown that the Hugoniot elastic limit of the alloy under study decreases as the shock wave travels into the sample, while the spall strength increases as the material’s strain rate increases at the moment of spall fracture. A comparison of the strength characteristics of the Inconel 625–NiTi–TiB₂ composite alloy with the original Inconel 625 alloy has shown that an addition of 5% of powder based on NiTi-TiB₂ leads to a decrease in its elastic limit and critical fracture stresses upon spalling by more than 10%. The alloy under study demonstrates anisotropy of strength properties relative to the material deposition direction. Full article

The influence of the heat treatment regime and the initial temperature on the strength characteristics of the cast heat-resistant superalloy Inconel 718 under shock loading has been studied. For samples of four types: in the as-received state, in the as-received state with subsequent heat treatment, in the as-received state after annealing and in the as-received state after annealing and subsequent heat treatment, measurements of the Hugoniot elastic limit and spall strength were carried out, based on the registration and subsequent analysis of the wave profiles in the samples under study. Shock-wave load pulses with an amplitude of ~6.5 GPa were generated using a light-gas gun. Measurement of the evolution of the shock-wave during loading—registration of the velocity profiles of the free surface of all types of samples of different thicknesses was carried out using a laser Doppler velocimeter VISAR. The measurements were carried out at a temperature of 20 °C and 650 °C. The analysis of the results revealed a noticeable effect of heat treatment and temperature on the characteristics of the elastic-plastic transition and the resistance to spalling of the Inconel 718 superalloy. Full article

By recording and analyzing complete wave profiles using the VISAR laser interferometer, measurements of the Hugoniot elastic limit and critical fracture stresses were carried out under the spalling conditions of the heat-resistant Inconel 718 alloy, additively manufactured by direct laser deposition, at shockwave loading up to ~6.5 GPa using a light-gas gun. For comparison, similar experiments were performed with the Inconel 718 alloy made by the traditional method of vacuum induction melting. The process of the delay of an elastic compression wave during its propagation through the sample and the dependence of the spall strength on the strain before fracture in the range 10⁵–10⁶ s⁻¹ were investigated. To identify the anisotropy of the strength properties of the material under study, two series of experiments were carried out on loading additively manufactured samples along and perpendicular to the direction of the deposition. The measurements performed showed that the additively manufactured Inconel 718 alloy demonstrates weak anisotropy of strength properties for both the initial and thermal-treated samples. The thermal treatment leads to a noticeable increase in the Hugoniot elastic limit and the spall strength of the samples at low strain rates. For all types of samples, there is an increase in the spall strength with an increase in the strain rate. The spall strength measured for the cast alloy practically coincides with the strength of the as-received additive alloy and is noticeably lower than the strength of the thermal-treated additive alloy over the entire range of the strain rates. The process of the decay of the elastic precursor in the cast alloy occurs much faster than in the additive one, and the minimum values of the Hugoniot elastic limit are measured for thick samples in the cast alloy. Full article

Additive manufacturing is a rapidly developing manufacturing technology of great potential for applications. One of the merits of AM is that the microstructure of manufactured materials can be actively controlled to meet engineering requirements. In this work, three types of Ti-6Al-4V (TC4) materials with different porosities are manufactured using selective laser melting using different printing parameters. Their dynamic behaviors are then studied by planar impact experiments based on the free-surface velocity measurements and shock-recovery characterizations. Experimental results indicate that the porosity significantly affects their dynamic response, including not only the yield, but also spall behaviors. With the increasing porosity, the Hugoniot elastic limit and spall strength decrease monotonically. In the case of TC4 of a large porosity, it behaves similar to energy-absorbing materials, in which the voids collapse under shock compression and then the spallation takes place. Full article

In this research, a finite element (FE) technique was used to predict the residual stresses in laser-peened aluminum 5083 at different power densities. A dynamic pressure profile was used to create the pressure wave in an explicit model, and the stress results were extracted once the solution was stabilized. It is shown that as power density increases from 0.5 to 4 GW/cm², the induced residual stresses develop monotonically deeper from 0.42 to 1.40 mm. However, with an increase in the power density, the maximum magnitude of the sub-surface stresses increases only up to a certain threshold (1 GW/cm² for aluminum 5083). Above this threshold, a complex interaction of the elastic and plastic waves occurring at peak pressures above ≈2.5 Hugoniot Elastic Limit (HEL) results in decreased surface stresses. The FE results are corroborated with physical experiments and observations. Full article

This paper presents the results of measurements of the spall strength and elastic-plastic proper-ties, under dynamic and static loads, of the high-strength heat-resistant nickel-chromium alloy Inconel 625, obtained by the direct laser deposition method. The structural parameters of the obtained samples and the mechanical properties during static tests were studied. According to our information, anisotropy in the structural parameters operates primarily at the level of plastic deformation of alloys. Shock compression of the additive alloy Inconel 625 samples in the range of 6–18 GPa was carried out using a light-gas gun, both along and perpendicular to the direction of the deposition. The strength characteristics were determined from the analysis of the shock wave profiles, which were recorded using the VISAR laser velocimeter during the loading of samples. It was found that the value of the spall strength of additive samples does not depend on the direction of deposition, and the Hugoniot elastic limit of samples loaded perpendicular to the deposition direction is about ~10% higher. With an increase in the maximum compression stress, the material’s spall strength increases slightly, but for both types of samples, a slight decrease in the Hugoniot elastic limit was observed as the compression stresses increase. On the basis of the measured wave profiles, shock Hugoniots of the samples of the alloy Inconel 625, loaded both along and perpendicular to the direction of deposition, are constructed in this pressure range. Full article

In this work, the critical fracture stresses during spalling of high-strength steel 09CrNi2MoCu samples obtained by direct laser deposition (DLD) were measured under shock compression of up to ~5.5 GPa. The microstructure and mechanical properties of DLD steel samples in the initial state and after heat treatment were studied and compared to traditional hot rolled one. The microstructural features of steel before and after heat treatment were revealed. The heat treatment modes of the deposit specimens on their strength properties under both static and dynamic loads have been investigated. The spall strength of the deposited specimens is somewhat lower than the strength of steel specimens after hot rolling regardless of their heat treatment. The minimum elastic limit of elasticity is exhibited by the deposit specimens. After heat treatment of the deposit samples, the elastic limit increases and approximately doubles. Subsequent heat treatment in the form of hardening and tempering allows obtaining strength properties under Hugoniot loads in traditional hot-rolled products. Full article

Boron carbide is an extremely hard and lightweight material used in armor systems. Upon impact above the Hugoniot elastic limit (HEL), boron carbide loses strength and suddenly fails. Atomistic models suggest that boron-rich boron carbides could mitigate amorphization. Such samples were processed, and indentation-induced amorphous zones were created throughout the boron-rich samples of varying degrees and were mapped with Raman spectroscopy to assess changes in the amorphization intensity. Boron-rich samples with a B/C ratio of 6.3 showed a large reduction in amorphization intensity compared to commonly used stoichiometric B₄ C, in agreement with recent TEM results. Additionally, hardness trends were also noted as boron content is varied. This offers another pathway in which doping boron carbide can reduce amorphization. Full article

The Johnson–Holmquist-II(JH-2) model is introduced as the constitutive model for rock materials in tunnel smooth blasting. However, complicated and/or high-cost experiments need to be carried out to obtain the parameters of the JH-2 constitutive model. This study chooses Barre granite as an example to propose a quick and convenient determination method for the parameters of the JH-2 model using a series of computational and extrapolated methods. The validity of the parameters is verified via comparing the results of 3D numerical simulations with laboratory blast-loading experiments. Subsequently, the verified parameter determination method, together with the JH-2 damage constitutive model, is applied in the numerical simulation of smooth blasting in Zigaojian tunnel, Hangzhou–Huangshan high-speed railway. The overbreak/underbreak induced by rock blasting and joints/discontinuities is well estimated through comparing the damage contours resulting from the numerical study with the tunnel profiles measured from the tunnel site. The peak particle velocities (PPVs) of the near field are extracted to estimate the damage scope and damage degree for the surrounding rock mass of the tunnel on the basis of PPV damage criteria. This method can be used in the excavation of rock tunnels subjected to large strains, high strain rates, and high pressures, thereby reducing safety risk and economic losses. Full article
