Soil particle size distribution is a critical parameter in geotechnical and hydraulic engineering, particularly in applications such as dam seepage monitoring, building foundation assessments, and sediment transport. This study presents a novel algorithm for estimating soil particle sizes by analyzing their falling velocities in water, combining optical flow computation with chaotic motion analysis. To address the limitations of the classical Horn and Schunck method, particularly its sensitivity to large displacements and brightness variations, we introduced a coarse-to-fine warping strategy, an image decomposition step to separate dominant structures from fine textures, and the Charbonnier penalty function. The improved model achieved competitive accuracy compared to advanced optical flow algorithms. To manage turbulence and motion noise during particle settling, we incorporated a global flow analysis framework using streaklines, streak flow, and potential functions. This enabled the segmentation of laminar, turbulent, and rebound flow regions without requiring individual particle tracking. Soil particle sizes were then back-calculated from laminar flow velocities using Stokes’ Law. Experimental results confirmed the method’s accuracy for particle sizes ranging from 20 mm to 0.7 mm, significantly extending the measurable range of Sedimaging systems. The proposed approach shows strong potential for integration into dam-related particle monitoring applications and building-related monitoring systems requiring fine-resolution analysis. Full article

The detection of moving objects in images is a crucial research objective; however, several challenges, such as low accuracy, background fixing or moving, ‘ghost’ issues, and warping, exist in its execution. The majority of approaches operate with a fixed camera. This study proposes a robust feature threshold moving object identification and segmentation method with enhanced optical flow estimation to overcome these challenges. Unlike most optical flow Otsu segmentation for fixed cameras, a background feature threshold segmentation technique based on a combination of the Horn–Schunck (HS) and Lucas–Kanade (LK) optical flow methods is presented in this paper. This approach aims to obtain the segmentation of moving objects. First, the HS and LK optical flows with the image pyramid are integrated to establish the high-precision and anti-interference optical flow estimation equation. Next, the Delaunay triangulation is used to solve the motion occlusion problem. Finally, the proposed robust feature threshold segmentation method is applied to the optical flow field to attract the moving object, which is the. extracted from the Harris feature and the image background affine transformation model. The technique uses morphological image processing to create the final moving target foreground area. Experimental results verified that this method successfully detected and segmented objects with high accuracy when the camera was either fixed or moving. Full article

Individual abnormal behaviors vary depending on crowd sizes, contexts, and scenes. Challenges such as partial occlusions, blurring, a large number of abnormal behaviors, and camera viewing occur in large-scale crowds when detecting, tracking, and recognizing individuals with abnormalities. In this paper, our contribution is two-fold. First, we introduce an annotated and labeled large-scale crowd abnormal behavior Hajj dataset, HAJJv2. Second, we propose two methods of hybrid convolutional neural networks (CNNs) and random forests (RFs) to detect and recognize spatio-temporal abnormal behaviors in small and large-scale crowd videos. In small-scale crowd videos, a ResNet-50 pre-trained CNN model is fine-tuned to verify whether every frame is normal or abnormal in the spatial domain. If anomalous behaviors are observed, a motion-based individual detection method based on the magnitudes and orientations of Horn–Schunck optical flow is proposed to locate and track individuals with abnormal behaviors. A Kalman filter is employed in large-scale crowd videos to predict and track the detected individuals in the subsequent frames. Then, means and variances as statistical features are computed and fed to the RF classifier to classify individuals with abnormal behaviors in the temporal domain. In large-scale crowds, we fine-tune the ResNet-50 model using a YOLOv2 object detection technique to detect individuals with abnormal behaviors in the spatial domain. The proposed method achieves 99.76% and 93.71% of average area under the curves (AUCs) on two public benchmark small-scale crowd datasets, UMN and UCSD, respectively, while the large-scale crowd method achieves 76.08% average AUC using the HAJJv2 dataset. Our method outperforms state-of-the-art methods using the small-scale crowd datasets with a margin of 1.66%, 6.06%, and 2.85% on UMN, UCSD Ped1, and UCSD Ped2, respectively. It also produces an acceptable result in large-scale crowds. Full article

Radargrammetry is a widely used methodology to generate the large-scale Digital Surface Model (DSM). Stereo matching is the most challenging step in radargrammetry due to the significant geometric differences and the inherent speckle noise. The speckle noise results in significant grayscale differences of the same feature points, which makes the traditional Horn–Schunck (HS) flow or multi-window zero-mean normalized cross-correlation (ZNCC) methods degrade. Therefore, this paper proposes an algorithm named Epipolar HS-NCC Flow (EHNF) for dense stereo matching, which is an improved HS flow method with normalized cross-correction constraint based on epipolar stereo images. First, the epipolar geometry is applied to resample the image to realize the coarse stereo matching. Subsequently, the EHNF method forms a global energy function to achieve fine stereo matching. The EHNF method constructs a local normalized cross-correlation constraint term to compensate for the grayscale invariance constraint, especially for the SAR stereo images. Additionally, two assessment methods are proposed to calculate the optimal cross-correlation parameter and smoothness parameter according to the refined matched point pairs. Two GaoFen-3 (GF-3) image pairs from ascending and descending orbits and the open Light Detection and Ranging (LiDAR) data are utilized to fully evaluate the proposed method. The results demonstrate that the EHNF algorithm improves the DSM elevation accuracy by 9.6% and 27.0% compared with the HS flow and multi-window ZNCC methods, respectively. Full article

To obtain effective indoor moving target localization, a reliable and stable moving target localization method based on binocular stereo vision is proposed in this paper. A moving target recognition extraction algorithm, which integrates displacement pyramid Horn–Schunck (HS) optical flow, Delaunay triangulation and Otsu threshold segmentation, is presented to separate a moving target from a complex background, called the Otsu Delaunay HS (O-DHS) method. Additionally, a stereo matching algorithm based on deep matching and stereo vision is presented to obtain dense stereo matching points pairs, called stereo deep matching (S-DM). The stereo matching point pairs of the moving target were extracted with the moving target area and stereo deep matching point pairs, then the three dimensional coordinates of the points in the moving target area were reconstructed according to the principle of binocular vision’s parallel structure. Finally, the moving target was located by the centroid method. The experimental results showed that this method can better resist image noise and repeated texture, can effectively detect and separate moving targets, and can match stereo image points in repeated textured areas more accurately and stability. This method can effectively improve the effectiveness, accuracy and robustness of three-dimensional moving target coordinates. Full article

This article deals with the design and implementation of a prototype of an efficient Low-Cost, Low-Power, Low Complexity–hereinafter (L-CPC) an image recognition system for person detection. The developed and presented methods for processing, analyzing and recognition are designed exactly for inbuilt devices (e.g., motion sensor, identification of property and other specific applications), which will comply with the requirements of intelligent building technologies. The paper describes detection methods using a static background, where, during the search for people, the background image field being compared does not change, and a dynamic background, where the background image field is continually adjusted or complemented by objects merging into the background. The results are compared with the output of the Horn-Schunck algorithm applied using the principle of optical flow. The possible objects detected are subsequently stored and evaluated in the actual algorithm described. The detection results, using the change detection methods, are then evaluated using the Saaty method in order to determine the most successful configuration of the entire detection system. Each of the configurations used was also tested on a video sequence divided into a total of 12 story sections, in which the normal activities of people inside the intelligent building were simulated. Full article

Due to payload restrictions for micro aerial vehicles (MAVs), vision-based approaches have been widely studied with their light weight characteristics and cost effectiveness. In particular, optical flow-based obstacle avoidance has proven to be one of the most efficient methods in terms of obstacle avoidance capabilities and computational load; however, existing approaches do not consider 3-D complex environments. In addition, most approaches are unable to deal with situations where there are wall-like frontal obstacles. Although some algorithms consider wall-like frontal obstacles, they cause a jitter or unnecessary motion. To address these limitations, this paper proposes a vision-based obstacle avoidance algorithm for MAVs using the optical flow in 3-D textured environments. The image obtained from a monocular camera is first split into two horizontal and vertical half planes. The desired heading direction and climb rate are then determined by comparing the sum of optical flows between half planes horizontally and vertically, respectively, for obstacle avoidance in 3-D environments. Besides, the proposed approach is capable of avoiding wall-like frontal obstacles by considering the divergence of the optical flow at the focus of expansion and navigating to the goal position using a sigmoid weighting function. The performance of the proposed algorithm was validated through numerical simulations and indoor flight experiments in various situations. Full article

Hong Kong Observatory has been operating an in-house developed rainfall nowcasting system called “Short-range Warning of Intense Rainstorms in Localized Systems (SWIRLS)” to support rainstorm warning and rainfall nowcasting services. A crucial step in rainfall nowcasting is the tracking of radar echoes to generate motion fields for extrapolation of rainfall areas in the following few hours. SWIRLS adopted a correlation-based method in its first operational version in 1999, which was subsequently replaced by optical flow algorithm in 2010 and further enhanced in 2013. The latest optical flow algorithm employs a transformation function to enhance a selected range of reflectivity for feature tracking. It also adopts variational optical flow computation that takes advantage of the Horn–Schunck approach and the Lucas–Kanade method. This paper details the three radar echo tracking algorithms, examines their performances in several significant rainstorm cases and summaries verification results of multi-year performances. The limitations of the current approach are discussed. Developments underway along with future research areas are also presented. Full article

This article presents an efficient hardware implementation of the Horn-Schunck algorithm that can be used in an embedded optical flow sensor. An architecture is proposed, that realises the iterative Horn-Schunck algorithm in a pipelined manner. This modification allows to achieve data throughput of 175 MPixels/s and makes processing of Full HD video stream (1; 920 × 1; 080 @ 60 fps) possible. The structure of the optical flow module as well as pre- and post-filtering blocks and a flow reliability computation unit is described in details. Three versions of optical flow modules, with different numerical precision, working frequency and obtained results accuracy are proposed. The errors caused by switching from floating- to fixed-point computations are also evaluated. The described architecture was tested on popular sequences from an optical flow dataset of the Middlebury University. It achieves state-of-the-art results among hardware implementations of single scale methods. The designed fixed-point architecture achieves performance of 418 GOPS with power efficiency of 34 GOPS/W. The proposed floating-point module achieves 103 GFLOPS, with power efficiency of 24 GFLOPS/W. Moreover, a 100 times speedup compared to a modern CPU with SIMD support is reported. A complete, working vision system realized on Xilinx VC707 evaluation board is also presented. It is able to compute optical flow for Full HD video stream received from an HDMI camera in real-time. The obtained results prove that FPGA devices are an ideal platform for embedded vision systems. Full article
