In this paper, we introduce a novel method for calculating the electromagnetic (EM) field below a flat interface between two lossless media when a radiating vertical Hertzian dipole (VHD) is located far from the interface. The method uses a Geometrical Optics (GOs) approach based on the concept of ‘equal optical lengths’, in the framework of which the location of the ‘virtual image’ of the original source is calculated. Using the well-known formulae for the far EM field of a vertical Hertzian dipole, the EM field at a point below the flat interface is calculated in a closed mathematical form. Full article

Non-invasive concealed object detection, identification, and discrimination have been of interest to the research community for decades due to the needs to preserve infrastructures and artifacts, guarantee safe conditions for the detection and location of landmines, etc. A modern approach is based on the use of an unmanned aerial vehicle equipped with ground-penetrating radar, which has the advantage of not requiring direct contact with the ground. Moreover, high-resolution underground images are obtained by coherently combining measurements by using a synthetic aperture radar algorithm. Due to the complexity of the real scenario, numerical analyses have always been welcomed to provide almost real-time information to make the best use of the potential of such kinds of techniques. This paper proposes an analysis of the scattering from a zero-thickness perfectly electrically conducting disk buried in a lossy half-space surrounded by air and illuminated by a field generated by a Hertzian dipole located in the air. It is carried out by means of a generalized form of the analytically regularizing Helmholtz–Galerkin technique, introduced and successfully applied by the authors to analyze the plane-wave scattering from a disk and a holed plane in a homogeneous medium. As clearly shown in the numerical results, the proposed method is very effective and drastically outperforms the commercial software CST Microwave Studio 2023. Full article

It is still difficult to accurately evaluate the reactive electromagnetic energy and the radiative electromagnetic energy of a radiator, because there are no explicit expressions for them. This paper proposes to borrow the energy concept in the charged particle theory and separate the total electromagnetic energy of a radiator into three parts: a Coulomb–velocity energy, a radiative energy and a macroscopic Schott energy. Consequently, the Poynting vector is considered to include a real radiative power flow by the radiative energy and a pseudo power flow caused by the fluctuation of the reactive energy. The energies involved in the electromagnetic mutual coupling are separated in a similar way. All energies are defined with explicit expressions in which the vector potential plays an important role. The time domain formulation and the frequency domain formulation of the theory are consistent with each other. The theory is verified with the Hertzian dipole. Numerical examples demonstrate that this theory may provide proper interpretations for electromagnetic radiation and mutual coupling problems. Full article

The creation of electromagnetic energy may be realised by engineering a device with a method of transduction, which allows an external energy source, such as mechanical, chemical, nuclear, etc., to be impressed into the electromagnetic system through a mechanism that enables the separation of opposite polarity charges. For example, a voltage generator, such as a triboelectric nanogenerator, enables the separation of charges through the transduction of mechanical energy, creating an active physical dipole in the static case, or an active Hertzian dipole in the time-dependent case. The net result is the creation of a static or time-dependent permanent polarisation, respectively, without an applied electric field and with a non-zero vector curl. This system is the dual of a magnetic solenoid or permanent magnet excited by a circulating electrical current or fictitious bound current, respectively, which supplies a magnetomotive force described by a magnetic vector potential and a magnetic geometric phase proportional to the enclosed magnetic flux. Thus, the active electric dipole voltage generator has been described macroscopically by a circulating fictitious magnetic current boundary source and exhibits an electric vector potential with an electric geometric phase proportional to the enclosed electric flux density. This macroscopic description of an active dipole is a semi-classical average description of some underlying microscopic physics, which exhibits emergent nonconservative behaviour not found in classical closed-system laws of electrodynamics. We show that the electromotive force produced by an active dipole in general has both electric scalar and vector potential components to account for the magnitude of the electromotive force it produces. Independent of the electromagnetic gauge, we show that Faraday’s and Ampere’s law may be derived from the time rate of change of the magnetic and dual electric geometric phases. Finally, we analyse an active cylindrical dipole in terms of scalar and vector potential and confirm that the electromotive force produced, and hence potential difference across the terminals is a combination of vector and scalar potential difference depending on the aspect ratio (AR) of the dipole. For long thin active dipoles (AR approaches 0), the electric field is suppressed inside, and the voltage is determined mainly by the electric vector potential. For large flat active dipoles (AR approaches infinity), the electric flux density is suppressed inside, and the voltage is mainly determined by the scalar potential. Full article

To characterize the electromagnetic compatibility (EMC) of integrated circuits (ICs), especially the radiated emissions in the near field, transversal electromagnetic cell (TEM cell) or IC-stripline measurements (IEC 61967) are utilized. Due to the ongoing miniaturization and the increasing operating frequencies, accurate EMC characterization of ICs is becoming more important to achieve first-time-right designs. In order to avoid expensive redesigns, the prediction of these measurements in terms of a simulation workflow would be of high interest. Because of the high computational burden needed to conduct 3D full-wave finite element (FEM) simulations of both the device under test (DUT) and the measurement system, an equivalent representation of the DUT by means of analytical incident fields, such as Hertzian dipole moments, can be considered. In order to develop an order-reduced model of this kind, it is essential to have a solid understanding of the coupling and wave propagation effects inside the measurement systems. In the present paper, a fundamental investigation of the coupling paths between an IC-stripline and electric or magnetic dipole moments is presented and the results are compared to the existing analytical models. The results show that these analytical models, originally developed for TEM cells, are only partially valid for IC-striplines. It has also been shown that even for simple test structures, such as loop and monopole antennas, the representation in terms of one single dipole moment is insufficient. Full article

A key part of every space science mission, in the system-level approach, is the detailed study and modeling of the emissions from transmission lines. Harnesses usually emit electromagnetic fields due to the currents (of common and/or differential modes) that flow on their shields. These fields can be identified via conducted emissions measurements. Relying on the operating frequency, any cable can be considered as a dipole or a traveling-wave antenna. Limited work can be found in the literature regarding modeling methodologies for cable topologies, especially in the low frequency (ELF, SLF, VLF, LF) domain. This work intends to provide perceptions for the precise estimation of harness radiated emissions, consider a mission-specific measurement point (where the sensors are placed), and follow ESA’s recent science mission studies for electromagnetic cleanliness applications. For the low frequencies considered herein, any linear cable path is considered as a point source (infinitesimal dipole) and we evaluate its effect on the calculated electric field extremely close to the source. For such distances, it is shown that the dipole representation is not accurate. To remedy this phenomenon, this article proposes a methodology, which can be easily expanded to complex cable geometry cases. Full article

In this paper, a modified finite-difference time-domain (FDTD) method is proposed for the rapid analysis of a Hertzian dipole source in the low-frequency band. The FDTD technique is one of the most widely used methods for interpreting high-resolution problems such as those associated with the human body. However, this method has been difficult to use in the low-frequency band as the required number of iterations has increased significantly in such cases. To avoid this problem, FDTD techniques using quasi-static assumptions in low-frequency bands were used. However, this method was applied only to plane wave excitation, making it difficult to apply to near-field problems. Therefore, a modified approach is proposed, involving the application of the FDTD technique with a quasi-static approximation to an electric and magnetic dipole problem. The results when using the proposed method are in good agreement with those from a theoretical solution. An example of comparison with the standard FDTD method is shown for illustrating the proposed method’s performance. Full article

A recently developed high-frequency asymptotic solution for the famous “Sommerfeld radiation problem” is revisited. The solution is based on an analysis performed in the spectral domain, through which a compact asymptotic formula describes the behavior of the EM field, which emanates from a vertical Hertzian radiating dipole, located above flat, lossy ground. The paper is divided into two parts. We first demonstrate an efficient technique for the accurate numerical calculation of the well-known Sommerfeld integrals. The results are compared against alternative calculation approaches and validated with the corresponding Norton figures for the surface wave. In the second part, we introduce the asymptotic solution and investigate its performance; we compare the solution with the accurate numerical evaluation for the received EM field and with a more basic asymptotic solution to the given problem, obtained via the application of the Stationary Phase Method. Simulations for various frequencies, distances, altitudes, and ground characteristics are illustrated and inferences for the applicability of the solution are made. Finally, special cases leading to analytical field expressions close as well as far from the interface are examined. Full article

We proposed an IR absorber hybrid nanoantenna comprise of two overlapping gold nanoparticles residing over larger a silica nanoparticle. A wet chemical route was employed to prepare the hybrid structure of nanoantenna. High-resolution transmission electron microscope was used to measure the size and morphology of the nanoantenna. The Hybrid nanoantenna was excited by electron beam to investigate the optical response over a large wavelength range using Electron Energy Loss Spectroscopy. The beam of the electron was focused and we measured the electron energy loss spectra at different point of interest, which confirmed the of Low Energy Surface Plasmon Politron resonances in the IR region. The optical response of the nanoantenna was simulated numerically by employing Electric Hertzian dipole using finite element method with frequency domain solver in CST Microwave Studio. We used the Electric Hertzian dipole approach for the first time to model the Electron Energy Loss Spectroscopy experiment. The Electron Energy Loss Spectroscopy experimental results with their numerically simulated values confirmed the plasmonic resonance at the interface of the two overlapped gold nanoparticles. Full article

The paper probes slip differential heat of magnetorheological fluids (MRFs) subjected to shear mode operation and its effect on the structure. To begin, we present a novel model for measurement of slip differential heat to describe temperature rise of MRFs mainly caused by friction between magnetorheological particles. It includes two stages: (1) The micro-macro analysis of slip differential heat of MRFs including force, movement and heat between neighboring particles based on magnetic dipole and Hertzian contact theories, and (2) the further application to two basic disc-type and cylinder-type magnetorheological clutches combined with finite element simulations involving electromagnetic field and thermal analysis. The model takes into account the effect of each of the main influencing factors, such as the input current of excitation coil, the rotational speed difference of the clutches, the size and volume fraction of particles, the saturation magnetization of particles, and the structural size of the clutches, etc., on the slip differential heat of MRFs. Then the thermal structure analysis of MRFs comprising thermal deformation and equivalent thermal stress is carried out. Moreover, the effect of typical governing parameters on the slip power of MRFs and the influence of slip differential heat on the structure of MRFs are investigated individually. We show that such a model is effective in reflecting the temperature-slip time relation of MRFs. It is shown that the input current and the rotational speed difference have great effect on the slip power, and the slip differential heat has a certain influence on the micro-structure of MRFs. Full article

The paper describes the net momentum transported by the transient electromagnetic radiation field of a long transient dipole in free space. In the dipole a current is initiated at one end and propagates towards the other end where it is absorbed. The results show that the net momentum transported by the radiation is directed along the axis of the dipole where the currents are propagating. In general, the net momentum $P$ transported by the electromagnetic radiation of the dipole is less than the quantity $U/c$ , where $U$ is the total energy radiated by the dipole and c is the speed of light in free space. In the case of a Hertzian dipole, the net momentum transported by the radiation field is zero because of the spatial symmetry of the radiation field. As the effective wavelength of the current decreases with respect to the length of the dipole (or the duration of the current decreases with respect to the travel time of the current along the dipole), the net momentum transported by the radiation field becomes closer and closer to $U/c$ , and for effective wavelengths which are much shorter than the length of the dipole, $P\approx U/c$ . The results show that when the condition $P\approx U/c$ is satisfied, the radiated fields satisfy the condition $\Delta t\Delta U\ge h/4\pi$ where $\Delta t$ is the duration of the radiation, $\Delta U$ is the uncertainty in the dissipated energy and $h$ is the Plank constant. Full article
