This work deals with the performance gap between prognostic models of the energy needed for heating and actual energy consumption based on measurements. An in-depth case study is presented for a real single-family building, taking into account physical calculation models (monthly and simple hourly method according to the Polish methodology based on standard EN ISO 13790) and relevant input data. The hypothesis is confirmed in that it is possible to achieve high convergence between actual energy consumption and the calculated energy need when taking into account the high-quality input data obtained using relatively simple measurement methods. The results indicate the impact of key input data on the computational energy needed for heating. For the case study considered, the greatest influence is caused by the introduction of actual internal heat gains. Entering only some of the actual data may yield a result that is farther from the actual value than a result based only on standard data. This article provides knowledge that leads to the development of a “new consumption method” using physical models in combination with available high-quality input data, which helps change regulations and increase the significance of energy performance certificates in Poland. Full article

This paper presents an application of the Simulink stvmgain S-function for the thermal modelling of a building zone based on the resistance–capacitance scheme of EN ISO 13790. That model in the form of the state-space matrix with time-varying elements was used in simulations of a building with hourly and, suggested in that standard, daily averaged ventilation airflow in five European cities. The following two ventilation schedules were used: occupancy-based; and wind-dependent. Comparative simulations were conducted in EnergyPlus. In general, the results obtained for the annual heating and cooling demand were better for hourly than daily averaged ventilation with an error below 10%. However, in several cases of cooling, the error was above 30%. When considering hourly indoor air temperatures, the proposed method provided very good results with MAE of up to 0.52 °C and 0.46 °C, RMSE < 0.69 °C and 0.62 °C, and CV(RMSE) < 3.09% and 2.75% for the daily averaged and hourly ventilation flow, respectively. For wind-driven ventilation, the temperatures were as follows: MAE < 0.49 °C and 0.48 °C; RMSE < 0.69 °C and 0.68 °C; and CV(RMSE) < 3.01% and 2.97%. Full article

Multifamily buildings account for about half of all residential buildings in Poland and about 70% of the urban population live in them. Most of them require thermal refurbishment. Evaluation of a building’s energy performance with the use of correlation models has been very rarely used in relation to buildings in Poland. This method is simple, fast and can improve the decision process on thermal modernisation. It is especially important at the pre-design stage of planned investments. This paper presents an attempt to develop correlations that could be used in the energy assessment of multifamily buildings. For this purpose a dataset containing of 29 audits of multifamily buildings was used. The statistical analysis was performed for buildings before and after planned refurbishment. Obtained relationships showed strong correlation between thermal demand for space heating or domestic hot water and ventilation airflow and thermal transmittance of windows (R² > 0.6). After designed modernisation the number of strong correlations decreased. Energy for domestic hot water was correlated with the number of inhabitants (R² = 0.6). Energy for space heating was correlated with the number of users and heated volume of a building. Full article

Natural ventilation dominates in Polish residential buildings. It is a simple and low-cost system but its performance is affected by varying environmental conditions. Hence, setting up constant ventilation airflow results in errors when calculating heating and cooling energy. In this paper, an attempt to integrate the buoyancy effect in natural ventilation of a residential building at hourly resolution with the hourly simulation method of EN ISO 13790 to obtain energy use for space heating and cooling is presented. The ping-pong coupling algorithm was proposed and applied. Hourly variation of ventilation airflow rate was from −26.8 m³/h (flow from outdoor to the interior of the building) to 87.2 m³/h with 55 m³/h on average. The lack of a cooling system resulted in overheating during summer and indicated the necessity of its application or use of other techniques to reduce solar gains. Application of the cooling system resulted in an hourly ventilation rate from −38.0 m³/h to 87.2 m³/h. Detailed simulation in EnergyPlus and statistical analysis proved the applicability of the proposed method in stack-induced ventilation assessment. The coefficient of determination R² = 0.936, mean squared error MAE = 5.72 m³/h and root mean square error RMSE = 7.86 m³/h. Full article

Costs of cooling installations cause them to be very rarely used in residential buildings in countries located in heating-dominated climates, like Poland. Hence, there arises the need to assess indoor thermal comfort during summer and to indicate ways to reduce possible overheating. This paper presents an attempt to use the thermal network model of the building zone of EN ISO 13790 to assess indoor operative temperature during four warm months from June to September. The model of the naturally ventilated single-family residential building located in central Poland was used. Performed calculations for the base case resulted in 38 and 63 days within the comfort zone at 80% acceptance level in a total of 122 days in the analyzed period for EN 15251 and ASHRAE standards, respectively. Use of external shading on windows and the roof with lower solar absorptance resulted in 46 and 70 days with acceptable conditions, respectively. Further application of night ventilation resulted in the 38 and 63 days, respectively. From the considered solutions in Polish climate conditions, windows shading seems to be the most efficient solution when controlling indoor comfort in residential buildings with no cooling system. A comparison of hourly operative temperature from that model with the detailed simulation in EnergyPlus showed a strong correlation with R² = 0.934. Full article

Due to their simple design and reliable operation, earth-to-air heat exchangers (EAHE) are used in modern buildings to reduce ventilation heat losses. EAHE operation in atmospheric conditions results in variation in ambient air temperature and pressure affecting air density. The paper presents the study on the impact of ambient air density variation on the calculated hourly air temperature at the EAHE outlet and the resulting energy use for space heating and cooling of an exemplary residential building. The ground temperature was computed from the model given in EN 16798-5-1. Then, air density was obtained using five various methods. Energy use for space heating and cooling of the building was computed using the 5R1C thermal network model of EN ISO 13790. Depending on the chosen method and concerning the base case without EAHE, a reduction in annual heating and cooling needs was obtained from 7.5% to 8.8% in heating and from 15.3% to 19% in cooling. Annual heating and cooling gain from EAHE were 600.9 kWh and 628.3 kWh for heating and 616.9 kWh and 603.5 kWh for cooling for the Typical Meteorological Years (TMY) and International Weather for Energy Calculation (IWEC) files, respectively. Unit heating and cooling gains per heat exchanger area were from 34.9 kWh/m² to 36.8 kWh/m² and from −35.1 kWh/m² to −36.3 kWh/m². Density variation with temperature from the relevant typical Polish meteorological year at constant pressure, in comparison to the method of EN 16798-5-1, resulted in an hourly difference of that unit gain up to 4.3 W/m² and 2.0 W/m² for heating and cooling, respectively. The same was true inthe case of IWEC files that resulted in differences of 5.5 W/m² and 1.1 W/m². Full article

The earth-to-air heat exchanger (EAHE) is a well-founded and verified solution used in modern buildings both for heating and cooling purposes around the world. However, there is a lack of studies on operation of such devices cooperating with ventilation systems of buildings in hourly time step. In this study, the 5R1C thermal network model of a building from EN ISO 13790 was coupled with the EAHE model from EN 16798-5-1 to calculate hourly outlet air temperature. To improve the effectiveness of the considered solution, an additional algorithm was developed to choose between the EAHE outlet and ambient air as the source of ventilation air. Simulations were conducted in a spreadsheet for a low-energy single-family building. Ground temperature was compared with measurements taken in the considered location. The application of the EAHE with the proposed bypass resulted in a decrease in annual energy use for space heating and cooling from 14.82 GJ and 1.67 GJ to 12.74 GJ and 0.93 GJ, i.e., by 14% and 44%, respectively. Peak hourly heating and cooling thermal power decreased from 2.73 kW and 3.06 kW to 2.21 kW and 2.34 kW. Introduction of a bypass and switching between the EAHE and ambient air as the source of ventilation for the building resulted in annual energy savings of 123 kWh. Full article

Nowadays it is possible to employ several software packages to evaluate building’s energy performance, each of them based on a different calculation code, with different boundary conditions in terms of environmental temperature, solar radiation, wind velocity and relative humidity. In this contribution, a comparison between two calculation codes, taking into account different types of buildings, has been carried out. In particular, a semi-stationary calculation code and a dynamic one have been employed to determine energy demands of three different building’s types: an old building, a house and a flat. Analyzing semi-stationary conditions (consequently simplified environmental conditions), a software which applies the UNI TS 11300 standard has been considered. This standard defines the procedures for the national implementation of the UNI EN ISO 13790. Furthermore, in order to consider the environmental conditions variation, a well-known dynamic software has been used. Full article

This study aims to highlight the importance of thermal inertia in buildings. Nowadays, it is possible to use energy analysis software to simulate the building energy performance. Considering Italian standards, these analyses are based on the UNI TS 11300 that defines the procedures for the national implementation of the UNI EN ISO 13790. These standards require an energy analysis under steady-state condition, underestimating the thermal inertia of the building. In order to understand the inertial behavior of walls, a cubic Test-Cell was modelled through the dynamic calculation code TRNSYS and three different wall types were tested. Different stratigraphies, characterized by the same thermal transmittance value, composed by massive elements and insulating layers in different order, were simulated. Through TRNSYS, it was possible to define maximum surface temperatures and to calculate thermal lag between maximum values, both external and internal. Moreover, the attenuation between external surface temperatures and internal ones during summer (July) was calculated. Finally, the comparison between Test-Cell’s annual energy demands, performed by using a commercial code based on the Italian standard UNITS 11300 and the dynamic code, TRNSYS, was carried out. Full article

Among solar passive systems integrated in buildings, sunspaces or solar greenhouses represent a very interesting solution. A sunspace is a closed, southbound volume, constituted by transparent surfaces, adjacent to a building, which reduces winter energy demand thanks to the use of solar gains. The effect of a typical solar greenhouse on the energy balance of a building was evaluated during the heating period with two stationary procedures (Method 5000 and EN ISO 13790) and with a dynamic tool (TRNSYS). After the analysis of the greenhouse alone, the behavior of an entire house was simulated; a flat equipped with a sunspace, recently built thanks to public contributions provided by the Umbria Region in Italy to widespread bio-climatic architecture, was used as case-study. Simulations were carried out for the examined flat, both with a steady-state tool and with a dynamic one; the contribution of the sunspace was estimated thanks to the various methods previously mentioned. Finally, the simulated data were satisfactorily compared with the real energy consumptions (natural gas for heating) of the flat; the sunspace allows a reduction of winter energy demand of the flat of about 20%. Full article
