This article presents the design and analysis of a low profile double-negative (DNG) metamaterial unit structure for 5G mmWave (millimeter wave) applications. The structure, comprised of double-slotted rectangular ring patches, experiences the peak current value near the magnetic resonance, causing the metamaterial to resonate at 28 GHz where it exhibits negative effective permittivity and permeability. The 3.05 mm × 2.85 mm compact structure is designed over a substrate Rogers RT/Duroid 5880 to attain better effective medium ratio (EMR) in the 5G frequency range (27.1–29.2 GHz). A rigorous parametric study is conducted to obtain the proposed design. Full-wave electromagnetic simulation software tools CST and HFSS are used to generate the scattering parameters for the analysis. The Nicolson–Ross–Wier method is used to observe the negative effective permittivity and permeability. In addition, different output quantities, e.g., surface current and electric and magnetic field distribution, are investigated. The structure is further tested with 1 × 2, 2 × 2, and 4 × 4 arrays, where the results show adequate agreement to be considered for 5G mmWave applications. Full article

A symmetric engineered high polarization-insensitive double negative (DNG) metamaterial (MM) reflector with frequency tunable features for fifth-generation (5G) antenna gain and directivity enhancement is proposed in this paper. Four identical unique quartiles connected by a metal strip are introduced in this symmetric resonator that substantially tunes the resonance frequency. The proposed design is distinguished by its unique symmetric architecture, high polarization insensitivity, DNG, and frequency tunable features while retaining a high effective medium ratio (EMR). Moreover, the suggested patch offers excellent reflectance in the antenna system for enhancing the antenna gain and directivity. The MM is designed on a Rogers RO3010 low loss substrate, covering the 5G sub-6GHz band with near-zero permeability and refractive index. The performance of the proposed MM is investigated using Computer Simulation Technology (CST), Advanced Design Software (ADS), and measurements. Furthermore, polarization insensitivity is investigated up to 180° angles of incidence, confirming the identical response. The 4 × 4 array of the MM has been utilized on the backside of the 5G antenna as a reflector, generating additional resonances that enhance the antenna gain and directivity by 1.5 and 1.84 dBi, respectively. Thus, the proposed prototype outperforms recent relevant studies, demonstrating its suitability for enhancing antenna gain and directivity in the 5G network. Full article

This paper introduces the tunability performance, concept, and analysis of a unique and miniaturized metamaterial (MTM) unit cell covering the upcoming 6G applications. The proposed metamaterial consists of two metallic star-shaped split-ring resonators (SRR). It has a line segment placed in the middle of the structure, which can feature tunable characteristics. The proposed design provides dual resonances of transmission coefficient S21 at 0.248 and 0.383 THz with a significant operating frequency span of 0.207–0.277 and 0.382–0.390 THz, respectively. Moreover, wide-range achievement, negative permittivity, double-negative (DNG) refractive index, and near-zero permeability characteristics have been exhibited in two (z and y) principal wave propagation axes. The resonance frequencies are selective and modified by adjusting the central slotted-strip line length. Furthermore, the metamaterial is constituted on a polyimide substrate while the overall dimensions are 160 × 160 μm². A numerical simulation of the proposed design is executed in CST microwave studio and has been compared with advanced design software (ADS) to generate the proposed MTM’s equivalent circuit, which exhibits a similar transmission coefficient (S21). Full article

The development and improvement of the dual-band 802.11ac standard Wi-Fi and wide bandwidth satellite communication devices are currently research subjects that have garnered significant interest. In this paper, double C-shaped two split-ring resonator (SRR) bounded unit cells were developed, which are applicable for S, C, and X band applications, including dual-band Wi-Fi communication devices and satellite communication applications for its effective medium ratio (EMR) of 15.6, which results in a 2.4 GHz resonance frequency and wide bandwidth (S21 < −10 dB) of 1650 MHz at an 11.5 GHz resonance frequency. A copper resonator and the popular substrate material Rogers RT 5880 (thickness of 1.575 mm) were adopted for analyzing the characteristics of this unit cell. The $8\times 8 {\mathrm{mm}}^2$ structure was designed and simulated using a commercially available electromagnetic simulator CST (Computer Simulation Technology) Studio Suite 2019, which was utilized at four resonance frequencies: 2.4 GHz, 5.6 GHz, 8.93 GHz, and 11.5 GHz. The electric field, magnetic field, and surface current distribution were examined by modifying the metamaterial unit cell design structure, showing effective results. To confirm the CST simulation results, the newly designed double C-shaped double-negative metamaterial (DNG) was also simulated with the Ansys High-Frequency Structure Simulator (HFSS) and compared with the extracted results. The suggested metamaterial is advised for usage in Wi-Fi and satellite communication applications for superior long-distance communication performance and efficiency with the compactness of the structure. Full article

An electrically tunable, textile-based metamaterial (MTM) is presented in this work. The proposed MTM unit cell consists of a decagonal-shaped split-ring resonator and a slotted ground plane integrated with RF varactor diodes. The characteristics of the proposed MTM were first studied independently using a single unit cell, prior to different array combinations consisting of 1 × 2, 2 × 1, and 2 × 2 unit cells. Experimental validation was conducted for the fabricated 2 × 2 unit cell array format. The proposed tunable MTM array exhibits tunable left-handed characteristics for both simulation and measurement from 2.71 to 5.51 GHz and provides a tunable transmission coefficient of the MTM. Besides the left-handed properties within the frequency of interest (from 1 to 15 GHz), the proposed MTM also exhibits negative permittivity and permeability from 8.54 to 10.82 GHz and from 10.6 to 13.78 GHz, respectively. The proposed tunable MTM could operate in a dynamic mode using a feedback system for different microwave wearable applications. Full article

A low-profile high-directivity, and double-negative (DNG) metamaterial-loaded antenna with a slotted patch is proposed for the 5G application. The radiated slotted arm as a V shape has been extended to provide a low-profile feature with a two-isometric view square patch structure, which accelerates the electromagnetic (EM) resonance. Besides, the tapered patch with two vertically split parabolic horns and the unit cell metamaterial expedite achieve more directive radiation. Two adjacent splits with meta units enhance the surface current to modify the actual electric current, which is induced by a substrate-isolated EM field. As a result, the slotted antenna shows a 7.14 dBi realized gain with 80% radiation efficiency, which is quite significant. The operation bandwidth is 4.27–4.40 GHz, and characteristic impedance approximately remains the same (50 Ω) to give a VSWR (voltage Standing wave ratio) of less than 2, which is ideal for the expected application field. The overall size of the antenna is 60 × 40 × 1.52 mm. Hence, it has potential for future 5G applications, like Internet of Things (IoT), healthcare systems, smart homes, etc. Full article

A multiband coplanar waveguide (CPW)-fed antenna loaded with metamaterial unit cell for GSM900, WLAN, LTE-A, and 5G Wi-Fi applications is presented in this paper. The proposed metamaterial structure is a combination of various symmetric split-ring resonators (SSRR) and its characteristics were investigated for two major axes directions at (x and y-axis) wave propagation through the material. For x-axis wave propagation, it indicates a wide range of negative refractive index in the frequency span of 2–8.5 GHz. For y-axis wave propagation, it shows more than 2 GHz bandwidth of near-zero refractive index (NZRI) property. Two categories of the proposed metamaterial plane were applied to enhance the bandwidth and gain. The measured reflection coefficient (S11) demonstrated significant bandwidths increase at the upper bands by 4.92–6.49 GHz and 3.251–4.324 GHz, considered as a rise of 71.4% and 168%, respectively, against the proposed antenna without using metamaterial. Besides being high bandwidth achieving, the proposed antenna radiates bi-directionally with 95% as the maximum radiation efficiency. Moreover, the maximum measured gain reaches 6.74 dBi by a 92.57% improvement compared with the antenna without using metamaterial. The simulation and measurement results of the proposed antenna show good agreement. Full article

This paper presents a multiband metamaterial (MM) absorber based on a novel spiral resonator with continuous, dual, and opposite P-shape. The full wave analysis shows 80.06% to 99.95% absorption at frequencies range for Ku and K bands for several substrate materials of 100 mm² area. The results indicate that the absorption rate remains similar for different polarizing angles in TEM mode with different substrates. With FR4 (Flame Retardant 4) substrate and 64 mm² ground plane, the design acts as single negative (SNG) MM absorber in K band resonance frequencies (19.75–21.37 GHz) and acts as double negative (DNG) absorber in Ku band resonance frequencies (15.28–17.07 GHz). However, for Rogers 3035 substrate and 36 mm² ground plane, it acts as an SNG absorber for Ku band resonance frequency 14.64 GHz with 83.25% absorption and as a DNG absorber for K band frequencies (18.24–16.15 GHz) with 83.69% to 94.43% absorption. With Rogers 4300 substrate and 36 mm² ground plane, it acts as an SNG absorber for Ku band at 15.04 GHz with 89.77% absorption and as DNG absorber for K band frequencies (22.17–26.88 GHz) with 92.87% to 93.72% absorption. The design was fabricated with all three substrates and showed quite similar results as simulation. In comparison with other broadband absorbers, this proposed MM absorber illustrated broad incidence angles in TEM mode. Full article

This paper presents an oval-shaped sensor design for the measurement of glucose concentration in aqueous solution. This unit cell sensing device is inspired by metamaterial properties and is analytically described for better parametric study. The mechanism of the sensor is a sensing layer with varying permittivity placed between two nozzle-shaped microstrip lines. Glucose aqueous solutions were characterized considering the water dielectric constant, from 55 to 87, and were identified with a transmission coefficient at 3.914 GHz optimal frequency with double negative (DNG) metamaterial properties. Consequently, the sensitivity of the sensor was estimated at 0.037 GHz/(30 mg/dL) glucose solution. The design and analysis of this sensor was performed using the finite integration technique (FIT)-based Computer Simulation Technology (CST) microwave studio simulation software. Additionally, parametric analysis of the sensing characteristics was conducted using experimental verification for the justification. The performance of the proposed sensor demonstrates the potential application scope for glucose level identification in aqueous solutions regarding qualitative analysis. Full article

The aim of this paper is to introduce a compact double-negative (DNG) metamaterial that exhibits a negative refractive index (NRI) bandwidth of more than 3.6 GHz considering the frequency from 2 to 14 GHz. In this framework, two arms of the designed unit cell are split in a way that forms a Modified-Z-shape structure of the FR-4 substrate material. The finite integration technique (FIT)-based Computer Simulation Technology (CST) Microwave Studio is applied for computation, and the experimental setup for measuring the performance is performed inside two waveguide ports. Therefore, the measured data complies well with the simulated data of the unit cell at 0-degree and 90-degree rotation angles. The designed unit cell shows a negative refractive index from 3.482 to 7.096 GHz (bandwidth of 3.61 GHz), 7.876 to 10.047 GHz (bandwidth of 2.171 GHz), and 11.594 to 14 GHz (bandwidth of 2.406 GHz) in the microwave spectra. The design also exhibits almost the same wide negative refractive index bandwidth in the major region of the C-band and X-band if it is rotated 90 degrees. However, the novelty of the proposed structure lies in its effective medium ratio of more than 4, wide bandwidth, and compact size. Full article

A new design and analysis of a wide-band double-negative metamaterial, considering a frequency range of 0.5 to 7 GHz, is presented in this paper. Four different unit cells with varying design parameters are analyzed to evaluate the effects of the unit-cell size on the resonance frequencies of the metamaterial. Moreover, open and interconnected 2 × 2 array structures of unit cells are analyzed. The finite-difference time-domain (FDTD) method, based on the Computer Simulation Technology (CST) Microwave Studio, is utilized in the majority of this investigation. The experimental portion of the study was performed in a semi-anechoic chamber. Good agreement is observed between the simulated and measured S parameters of the developed unit cell and array. The designed unit cell exhibits negative permittivity and permeability simultaneously at S-band (2.95 GHz to 4.00 GHz) microwave frequencies. In addition, the designed unit cell can also operate as a double-negative medium throughout the C band (4.00 GHz to 4.95 GHz and 5.00 GHz to 5.57 GHz). At a number of other frequencies, it exhibits a single negative value. The two array configurations cause a slight shift in the resonance frequencies of the metamaterial and hence lead to a slight shift of the single- and double-negative frequency ranges of the metamaterial. Full article
