Abandoned mines represent an innovative and under-exploited resource to meet current energy challenges, particularly because of their geothermal potential. Flooded open-pits, such as those located in the Thetford Mines region (Eastern Canada), provide large, thermally stable water reservoirs, ideal for the use of geothermal cooling systems. Thermal short-circuiting that can impact the system performance affected by both free and forced convective heat transfer is hard to evaluate in these large water reservoirs subject to various heat sink and sources. Thus, this study’s objective was to evaluate the impact of natural heat transfer mechanisms on the performance of an open-loop geothermal system that could be installed in a flooded open-pit mine. Energy needs of an industrial plant using water from the flooded Carey Canadian mine were considered to develop a 3D numerical finite element model to evaluate the thermal impact associated with the operation of the system considering free and forced convection in the flooded open-pit, the natural flow of water into the pit, climatic variations at the surface and the terrestrial heat flux. The results indicate that the configuration of the proposed system meets the plant cooling needs over a period of 50 years and can provide a cooling power of approximately 2.3 MW. The simulations also demonstrated the importance of understanding the hydrological and hydrogeological systems impacting the performance of the geothermal operations expected in a flooded open-pit mine. Full article

Despite the elevated heat flow known in the Western part of the South Slave Region (Northwest Territories, Canada), a continuous and equilibrium geothermal gradient was never measured in boreholes below the communities where geothermal energy could be developed. This paper aims to predict the geothermal gradient and assess the Earth’s natural heat flow below the communities of Fort Providence, Kakisa, Hay River, and Enterprise. Temperatures from drill-stem tests and bottom well logs were corrected for drilling disturbance and paleoclimate. The thermal conductivity and heat generation rate of the geological formations were determined from the literature and with new laboratory measurements. Original 1D models were developed to evaluate subsurface temperature through the sedimentary formations based on a thermostratigraphic assessment. The results indicate a geothermal gradient that varies from 44.1 ± 10.6 °C km⁻¹ to 59.1 ± 14.9 °C km⁻¹ and heat flow that varies from 105.5 mW m⁻² to 160.2 mW m⁻² below the communities. These estimates were in agreement with the equilibrium geothermal gradients measured in Cameron Hills, south of the four communities, and were used to verify our predictions. The highest geothermal gradient (59.1 ± 14.9 °C km⁻¹) was estimated at Hay River, which, therefore, has the most favorable geological conditions for geothermal development. Full article

This work presents an estimate of the slip activation potential of existing fractures in a remote northern community located on Canadian Shield rocks for geothermal purposes. To accomplish this objective, we analyzed outcrop analogues and recorded geometrical properties of fractures, namely the strike and dip. Then, we estimated the stress regime in the study area through an empirical approach and performed a probabilistic slip tendency analysis. This allowed us to determine the slip probability of the pre-existing fractures at the current state of stress, the orientation of fractures that are most likely to be activated and the fluid pressures needed for the slip activation of pre-existing fractures, which are key aspects for developing Enhanced Geothermal Systems. The results of this simple, yet effective, analysis suggest that at the current state of stress, the pre-existing natural fractures are relatively stable, and an injection pressure of about 12.5 MPa/km could be required to activate the most optimally oriented fractures to slip. An injection of water at this pressure gradient could open the optimally oriented pre-existing fractures and enhance the permeability of the reservoir for geothermal fluid extraction. The information described in this paper provides a significant contribution to the geothermal research underway in remote northern communities. Full article

Deep geothermal energy sources harvested by circulating fluids in engineered geothermal energy systems can be a solution for diesel-based northern Canadian communities. However, poor knowledge of relevant geology and thermo-hydro-mechanical data introduces significant uncertainty in numerical simulations. Here, a first-order assessment was undertaken following a “what-if” approach to help design an engineered geothermal energy system for each of the uncertain scenarios. Each possibility meets the thermal energy needs of the community, keeping the water losses, the reservoir flow impedance and the thermal drawdown within predefined targets. Additionally, the levelized cost of energy was evaluated using the Monte Carlo method to deal with the uncertainty of the inputs and assess their influence on the output response. Hydraulically stimulated geothermal reservoirs of potential commercial interest were simulated in this work. In fact, the probability of providing heating energy at a lower cost than the business-as-usual scenario with oil furnaces ranges between 8 and 92%. Although the results of this work are speculative and subject to uncertainty, geothermal energy seems a potentially viable alternative solution to help in the energy transition of remote northern communities. Full article

We summarize the feasibility of using geothermal energy from the Western Canada Sedimentary Basin (WCSB) to support communities with populations >3000 people, including those in northeastern British Columbia, southwestern part of Northwest Territories (NWT), southern Saskatchewan, and southeastern Manitoba, along with previously studied communities in Alberta. The geothermal energy potential of the WCSB is largely determined by the basin’s geometry; the sediments start at 0 m thickness adjacent to the Canadian shield in the east and thicken to >6 km to the west, and over 3 km in the Williston sub-basin to the south. Direct heat use is most promising in the western and southern parts of the WCSB where sediment thickness exceeds 2–3 km. Geothermal potential is also dependent on the local geothermal gradient. Aquifers suitable for heating systems occur in western-northwestern Alberta, northeastern British Columbia, and southwestern Saskatchewan. Electrical power production is limited to the deepest parts of the WCSB, where aquifers >120 °C and fluid production rates >80 kg/s occur (southwestern Northwest Territories, northwestern Alberta, northeastern British Columbia, and southeastern Saskatchewan. For the western regions with the thickest sediments, the foreland basin east of the Rocky Mountains, estimates indicate that geothermal power up to 2 MW_el. (electrical), and up to 10 times higher for heating in MW_th. (thermal), are possible. Full article

The Canadian off-grid communities heavily rely on fossil fuels. This unsustainable energetic framework needs to change, and deep geothermal energy can play an important role. However, limited data availability is one of the challenges to face when evaluating such resources in remote areas. Thus, a first-order assessment of the geothermal energy source is, therefore, needed to trigger interest for further development in northern communities. This is the scope of the present work. Shallow subsurface data and outcrop samples treated as subsurface analogs were used to infer the deep geothermal potential beneath the community of Kuujjuaq (Nunavik, Canada). 2D heat conduction models with time-varying upper boundary condition reproducing climate events were used to simulate the subsurface temperature distribution. The available thermal energy was inferred with the volume method. Monte Carlo-based sensitivity analyses were carried out to determine the main geological and technical uncertainties on the deep geothermal potential and risk analysis to forecast future energy production. The results obtained, although speculative, suggest that the old Canadian Shield beneath Kuujjuaq host potential to fulfill the community’s annual average heating demand of 37 GWh. Hence, deep geothermal energy can be a promising solution to support the energy transition of remote northern communities. Full article

Remote communities that have limited or no access to the power grid commonly employ diesel generators for communal electricity provision. Nearly 65% of the overall thermal energy input of diesel generators is wasted through exhaust and other mechanical components such as water-jackets, intercoolers, aftercoolers, and friction. If recovered, this waste heat could help address the energy demands of such communities. A viable solution would be to recover this heat and use it for direct heating applications, as conversion to mechanical power comes with significant efficiency losses. Despite a few examples of waste heat recovery from water-jackets during winter, this valuable thermal energy is often discarded into the atmosphere during the summer season. However, seasonal thermal energy storage techniques can mitigate this issue with reliable performance. Storing the recovered heat from diesel generators during low heat demand periods and reusing it when the demand peaks can be a promising alternative. At this point, seasonal thermal storage in shallow geothermal reserves can be an economically feasible method. This paper proposes the novel concept of coupling the heat recovery unit of diesel generators to a borehole seasonal thermal storage system to store discarded heat during summer and provide upgraded heat when required during the winter season on a cold, remote Canadian community. The performance of the proposed ground-coupled thermal storage system is investigated by developing a Computational Fluid Dynamics and Heat Transfer model. Full article

Heat flow and geothermal gradient of the sedimentary succession of the Western Canada Sedimentary Basin (WCSB) are mapped based on a large thermal database. Heat flow in the deep part of the basin varies from 30 mW/m² in the south to high 100 mW/m² in the north. As permeable strata are required for a successful geothermal application, the most important aquifers are discussed and evaluated. Regional temperature distribution within different aquifers is mapped for the first time, enabling a delineation of the most promising areas based on thermal field and aquifer properties. Results of previous regional studies on the geothermal potential of the WCSB are newly evaluated and discussed. In parts of the WCSB temperatures as high as 100–210 °C exist at depths of 3–5 km. Fluids from deep aquifers in these “hot” regions of the WCSB could be used in geothermal power plants to produce electricity. The geothermal resources of the shallower parts of the WCSB (>2 km) could be used for warm water provision (>50 °C) or district heating (>70 °C) in urban areas. Full article
