Search Results (260)

The output energy of Laser Active Optical Systems (LAOSs), in which image brightness is amplified within the laser-active medium, is always higher than the input energy. This contrasts with conventional optical systems (OSs). As a result, a LAOS enables the creation of laser beams with tailored energy distribution across the aperture, making them ideal for material processing applications. This concept was first successfully implemented using metal vapor lasers as the gain medium. In these systems, material processing was achieved by using a laser beam that either carried the required energy profile or the image of the object itself. Later, other laser media were utilized for LAOSs, including barium vapor, strontium vapor, excimer XeCl lasers, and solid-state media. Additionally, during the development of these systems, several modifications were introduced. For example, Space-Time Light Modulators (STLMs) and CCD cameras were incorporated, along with the use of multipass amplifiers, disk-shaped or thin-disk (TD) solid-state laser amplifiers, and other advancements. These techniques have significantly expanded the range of power, energy, pulse durations, and operating wavelengths. Currently, TD laser amplifiers and STLMs based on Digital Light Processor (DLP) technology or Digital Micromirror Devices (DMDs) enhance the potential to develop LAOS devices for Subtractive and Additive Technologies (ST, AT), applicable in both macromachining (cutting, welding, drilling) and micro-nano processing. This review presents comparable characteristics and requirements for these various LAOS applications. Full article

A novel reusable silicon foil dosimeter based on the new emerging optically stimulated luminescence (OSL) material MgB₄O₇:Ce,Li (MBO) is developed and characterized for dosimetric verification of spatially resolved radiotherapy doses. Direct comparison of the spatial (two-2D towards three-3D) proton dose mapping can be achieved with an appropriately designed optical detection setup equipped with a light source (e.g., LEDs) that illuminates the dosimeter and a highly sensitive CCD camera that simultaneously acquires the 2D OSL light from the foil. The newly designed (2nd generation) optical setup allows the registration of high-resolution 2D proton doses (below 0.1 mm resolution) and reconstruction of the 2D proton dose distribution with an accuracy comparable to that of the Gafchromic^TM foils, the current standard of passive 2D dosimetry in radiotherapy. This article outlines the technology’s potential application with respect to the commercially available Gafchromic^TM EBT3 films in measurements of the clinically relevant, spatial proton dose mapping. The obtained comparison of the proton radial dose profiles (for EBT3 films vs MBO foils) agrees within 5%. The resulting image resolution (0.074 mm/px for MBO foil) corresponded well with the tested EBT3 films (0.085 mm/px), indicating excellent properties for future 3D proton dose verifications of modern radiotherapy techniques (e.g., proton radiotherapy). Full article

With the development of chip technology, the demand for device reliability in various electronic chip industries continues to grow. In recent years, with the advancement of quantum sensors, the solid-state spin (nitrogen-vacancy) NV center temperature measurement system has garnered attention due to its high sensitivity and spatial range. However, NV centers are not only affected by temperature but also by magnetic fields. This article analyzes the impact of magnetic fields on temperature detection. By combining the wide-field imaging platform of optically detected magnetic resonance (ODMR) with a temperature-sensitive structure of thin ensemble diamond overlaid on a quartz substrate, high-sensitivity temperature detection has been achieved. And obtains a sensitivity of approximately 10 mK/Hz^1/2. By combining a CCD camera imaging system, it realizes a wide field of view of 500 μm², a high spatial resolution of 1.3 μm. Ultimately, this study demonstrates the two-dimensional actual temperature distribution on the chip surface under different currents, achieving wide-field, non-contact, high-speed temperature imaging of the chip surface. Full article

Ultrafast diagnostic technology has caused breakthroughs in fields such as inertial confinement fusion, particle accelerator research, and laser-induced phenomena. As the most widely used tool for ultrafast diagnostic technology, investigating the characteristics of streak cameras in the imaging process and streak tubes’ complex physical processes is significant for its overall development. In this work, the imaging process of a streak camera is modeled and simulated using Geant4-based Monte Carlo simulations. Based on the selected phosphor screen P43 (Gd₂O₂S: Tb) and charged coupled device (CCD) sensor parameters, Monte Carlo simulation models of phosphor screens and CCD sensors (We refer to the sensor parameters of the US company onsemi’s KAF-50100 sensor, but some adjustments are made during the simulation), implemented with the toolkit Geant4, are used to study the electron beam to generate fluorescence on phosphor and photoelectrons on CCD sensors. The physical process of a high-energy electron beam hitting a phosphor screen and imaging on the CCD camera is studied. Meanwhile, merits such as the luminous efficiency of the selected phosphor, spatial resolution of the phosphor screen, and spatial resolution of the selected CCD sensor are analyzed. The simulation results show that the phosphor screen and CCD sensor simulation models can accurately simulate the selected components’ performance parameters with the imaging process’ simulation results precisely reflecting the distribution of output electrons in the streak image tube. References for simulation and device selection in the subsequent research on streak cameras can be provided. Full article

A novel, portable chemiluminescence (CL) sensing platform powered by deep learning and smartphone integration has been developed for cost-effective and selective glucose detection. This platform features low-cost, wax-printed micro-pads (WPµ-pads) on paper-based substrates used to construct a miniaturized CL sensor. A 3D-printed black box serves as a compact WPµ-pad sensing chamber, replacing traditional bulky equipment, such as charge coupled device (CCD) cameras and optical sensors. Smartphone integration enables a seamless and user-friendly diagnostic experience, making this platform highly suitable for point-of-care (PoC) applications. Deep learning models significantly enhance the platform’s performance, offering superior accuracy and efficiency in CL image analysis. A dataset of 600 experimental CL images was utilized, out of which 80% were used for model training, with 20% of the images reserved for testing. Comparative analysis was conducted using multiple deep learning models, including Random Forest, the Support Vector Machine (SVM), InceptionV3, VGG16, and ResNet-50, to identify the optimal architecture for accurate glucose detection. The CL sensor demonstrates a linear detection range of 10–1000 µM, with a low detection limit of 8.68 µM. Extensive evaluations confirmed its stability, repeatability, and reliability under real-world conditions. This deep learning-powered platform not only improves the accuracy of analyte detection, but also democratizes access to advanced diagnostics through cost-effective and portable technology. This work paves the way for next-generation biosensing, offering transformative potential in healthcare and other domains requiring rapid and reliable analyte detection. Full article

To improve the performance of Radio Frequency Identification (RFID) multi-label systems, the multi-label network structure needs to be quickly located and optimized. A multi-label location measurement method based on the NLM–Harris algorithm is proposed in this paper. Firstly, multi-label geometric distribution images are obtained through a label image acquisition system of a multi-label semi-physical simulation platform with two vertical Charge-Coupled Device (CCD) cameras, and Gaussian noise is added to the image to simulate thermoelectric interference. Then, a fast NLM algorithm that optimizes the kernel coefficient acquisition speed is used for image denoising. Finally, the Harris corner algorithm is used to obtain the corner points of the images. After screening the diagonal points, the pixel coordinates of the preset origin and the four corners of the labels are obtained. Furthermore, the actual coordinates of the labels are obtained according to the pixel relationship. The results show that the average absolute errors of x, y, and z coordinates are 0.773 mm, 0.782 mm, and 0.807 mm, respectively. In addition, the relative errors are 1.659%, 2.260%, and 0.258%, which shows the high location accuracy of the multi-label network. It is of great significance to measure and optimize the performance of multi-label systems. Full article

This work aimed to understand how the energy released by short laser pulses can produce different effects in carbon targets with different allotropic states. The IR pulse laser ablation, operating at 1064 nm wavelength, 3 ns pulse duration, and 100 mJ pulse energy, has been used to irradiate different types of carbon targets in a high vacuum. Graphite, highly oriented pyrolytic graphite, glassy carbon, active carbon, and vegetable carbon have exhibited different mass densities and have been laser irradiated. Time-of-flight (TOF) measurements have permitted the evince of the maximum carbon ion acceleration in the generated plasma (of about 200 eV per charge state) and the maximum yield emission (96 μg/pulse in the case of vegetal carbon) along the direction normal to the irradiated surface. The ion energy analyzer measured the carbon charge states (four) and their energy distributions. Further plasma investigations have been performed using a fast CCD camera image and surface profiles of the generated craters to calculate the angular emission and the ablation yield for each type of target. The effects as a function of the target carbon density and binding energy have been highlighted. Possible applications for the generation of thin films and carbon nanoparticles are discussed. Full article

In conventional camera or monochromator-based spectroscopy, different wavelengths, spanning from short ultraviolet region to long infrared region, are calculated under steady-state conditions due to the temporally multiplexed nature of conventional CMOS/CCD-equipped spectrometers, which limit the refresh rates to the order of milliseconds for most tools available on the market. These refresh rates might not be suitable for most temporally dynamic effects that govern the behavior of disparate effects, such as phase transition in phase-change materials, conformal changes in molecules, and microbial community evolution, among others. Pump-probe methods are often presented as a solution to the capture speed limitation, but in themselves are not applicable universally and are not truly “real-time”. In this work, we present an evolution to the conventional spectrometers, increasing its speed by over 4 orders of magnitude while maintaining reasonable spectral resolution. We additionally present a path that combines our technique with supercontinuum light sources for even more ambitious future applications. Full article

Fourier ptychography (FP) can break through the limitations of existing optical systems with a single aperture and realize large field-of-view (FOV) and high-resolution (HR) imaging simultaneously by aperture synthesis in the frequency domain. The method has potential applications for remote sensing and space-based imaging. However, the aperture stop of the imaging system was generally set to be much smaller than the system with an adjustable diaphragm, so it failed to make full use of the imaging capability of the system. In this paper, a reflective remote FP with full aperture is proposed, and the optical aperture of the camera is set to be the maximum according to the sample-matching condition, which can further improve the imaging resolution by exploring the whole capability of the system. Firstly, the physical model of the remote FP is established using oblique illumination of a convergent spherical wave. Then, the sampling characteristics of the low-resolution (LR) intensity image are analyzed. Assuming diffraction-limited imaging, the size of the aperture of the optical system needs to match the sampling of the detector. An experimental setup with an imaging distance of 2.4 m is built, and a series of LR images is collected by moving the camera for the diffused samples, including the USAF resolution test target and the banknote, where the diameter of the single aperture is set to the maximum to match the size of the CCD pixel under the practical minimum F^# of the camera of 2.8. The high-resolution image is reconstructed by applying the iterative phase retrieval algorithm. The experimental results show that the reconstructed resolution is improved to 2.5×. This verifies that remote FP with full aperture can effectively improve the imaging resolution using only the present single-aperture optical system. Full article

This article delineates the enhancement of an autonomous navigation and obstacle avoidance system for a quadruped robot dog. Part one of this paper presents the integration of a sophisticated multi-level dynamic control framework, utilizing Model Predictive Control (MPC) and Whole-Body Control (WBC) from MIT Cheetah. The system employs an Intel RealSense D435i depth camera for depth vision-based navigation, which enables high-fidelity 3D environmental mapping and real-time path planning. A significant innovation is the customization of the EGO-Planner to optimize trajectory planning in dynamically changing terrains, coupled with the implementation of a multi-body dynamics model that significantly improves the robot’s stability and maneuverability across various surfaces. The experimental results show that the RGB-D system exhibits superior velocity stability and trajectory accuracy to the SLAM system, with a 20% reduction in the cumulative velocity error and a 10% improvement in path tracking precision. The experimental results also show that the RGB-D system achieves smoother navigation, requiring 15% fewer iterations for path planning, and a 30% faster success rate recovery in challenging environments. The successful application of these technologies in simulated urban disaster scenarios suggests promising future applications in emergency response and complex urban environments. Part two of this paper presents the development of a robust path planning algorithm for a robot dog on a rough terrain based on attached binocular vision navigation. We use a commercial-of-the-shelf (COTS) robot dog. An optical CCD binocular vision dynamic tracking system is used to provide environment information. Likewise, the pose and posture of the robot dog are obtained from the robot’s own sensors, and a kinematics model is established. Then, a binocular vision tracking method is developed to determine the optimal path, provide a proposal (commands to actuators) of the position and posture of the bionic robot, and achieve stable motion on tough terrains. The terrain is assumed to be a gentle uneven terrain to begin with and subsequently proceeds to a more rough surface. This work consists of four steps: (1) pose and position data are acquired from the robot dog’s own inertial sensors, (2) terrain and environment information is input from onboard cameras, (3) information is fused (integrated), and (4) path planning and motion control proposals are made. Ultimately, this work provides a robust framework for future developments in the vision-based navigation and control of quadruped robots, offering potential solutions for navigating complex and dynamic terrains. Full article

In order to evaluate the tracking capability of optoelectric tracking for an orbital target, the limit magnitude detection performance calculation model and its calculation method are studied. Combining the optical signal characteristics of the tracked orbital target, the background, and the CCD noise, the framework of the limit magnitude calculation model of the system for dynamic target detection is constructed. The relationships between the limit magnitude and the signal-to-noise ratio threshold of the optical signal characteristics, the exposure time of the CCD camera, and the dark current of the CCD imaging are studied and analyzed while considering the sunlight illumination condition, so that the calculation function and its change curve are given. The limit magnitude detection capability of the system is verified by the simulated experiment and the synchronized tracking test, and the detection distance maximum error of the model calculation is 3.6 m. The results show that under certain illumination conditions, when the exposure time of the CCD camera is longer and the SNR threshold is lower, the limit magnitude detection performance of the system is better, and the tracking performance of the system is more stable. Full article

Introduction: The study of facial profiles in the dental field is very important for the diagnosis and the dental and orthodontic treatment plan. The aim of this study is to analyze the three-dimensional morphology of the faces of 269 growing patients with Class I and II occlusions, focusing on children aged between 6 and 9 years old. The analysis was conducted using a non-invasive computerized system, which allowed for the automatic collection of facial landmarks and the subsequent reconstruction of three-dimensional coordinates. Materials and methods: The sample comprised 269 children within the specified age range. Each child’s facial features were captured using the non-invasive computerized system, which utilized two infrared CCD cameras, real-time hardware for label recognition, and software for three-dimensional landmark reconstruction. Sixteen cutaneous facial landmarks were automatically collected for each participant. From these landmarks, 10 angular and 15 linear measurements, as well as five direct distance rates, were derived. The mean values for each age class were calculated separately for children with bilateral Angle Class I occlusion and compared with those for children with bilateral Class II occlusion. In all children, the left and right occlusal classes were measured as suggested by Katz. Results: The analysis revealed notable differences, primarily in the three-dimensional angular measurements between children with Class I and II occlusions. Specifically, Class II children exhibited more convex faces in the sagittal plane and a less prominent lower jaw compared to Class I children. However, no significant differences were observed in linear measurements, except for the lower facial height rate, which varied inconsistently across age groups between the two occlusion types. Discussion and Conclusions: the findings of this research highlight distinct three-dimensional facial morphological differences between children with Class I and II occlusions. While Class II children tended to have more convex facial profiles and less prominent lower jaws, linear measurements showed minimal variation between the two occlusion types. These results underscore the importance of three-dimensional analysis in understanding facial morphology in growing patients with different occlusal patterns. Full article

Long-term observation of single-cell oscillations within tissue networks is now possible by combining bioluminescence reporters with stable tissue explant culture techniques. This method is particularly effective in revealing the network dynamics in systems with slow oscillations, such as circadian clocks. However, the low intensity of luciferase-based bioluminescence requires signal amplification using specialized cameras (e.g., I-CCDs and EM-CCDs) and prolonged exposure times, increasing baseline noise and reducing temporal resolution. To address this limitation, we implemented a cost-effective optical enhancement technique called telecompression, first used in astrophotography and now commonly used in digital photography. By combining a high numerical aperture objective lens with a magnification-reducing relay lens, we significantly increased the collection efficiency of the bioluminescence signal without raising the baseline CCD noise. This method allows for shorter exposure times in time-lapse imaging, enhancing temporal resolution and enabling more precise period estimations. Our implementation demonstrates the feasibility of telecompression for enhancing bioluminescence imaging for the tissue-level network observation of circadian clocks. Full article

In the process of laser-based direct energy deposition (DED-LB), the quality of the deposited layer will be affected by the process parameters and the external environment, and there are problems such as poor stability and low accuracy. A molten pool monitoring method based on coaxial vision is proposed. Firstly, the molten pool image is captured by a coaxial CCD camera, and the geometric features of the molten pool are accurately extracted by image processing techniques such as grayscale, median filtering noise reduction, and K-means clustering combined with threshold segmentation. The molten pool width is accurately extracted by the Canny operator combined with the minimum boundary rectangle method, and it is used as the feedback of weld pool control. The influence of process parameters on the molten pool was further analyzed. The results show that with an increase in laser power, the width and area of the molten pool increase monotonously, but exceeding the material limit will cause distortion. Increasing the scanning speed will reduce the size of the molten pool. By comparing the molten pool under constant power mode and width control mode, it is found that in width control mode, the melt pool width fluctuates less, and the machining accuracy is improved, validating the effectiveness of the real-time control system. Full article

This paper presents the theoretical fundamentals, prerequisites for creation, and peculiarities of modeling a new method for determining the refractive index of biological tissues. The method uses a mirror ellipsoid of revolution as an optical element to ensure total internal reflection phenomena. This paper thoroughly analyzes the differences in the refractive index of healthy and pathological tissues on a biometric diagnostic basis. The analysis is used to model the measurement setup’s parameters. This paper also considers various methods of determining the refractive index of biological tissues based on different principles of physical optics, such as interferometry, refractometry, ellipsometry, and goniophotometry. It systematizes typical optical elements of total internal reflection that can be used in goniophotometry. It justifies the selection of the element base for the goniometric installation based on the ellipsoidal reflector method. A simulation of the installation operation was carried out for various parameters of the ellipsoidal reflector, ensuring the measurement of the biological tissue refractive index from 1.33 to 1.7. This paper also proposes a constructive solution for manufacturing an ellipsoidal reflector of the required configuration. Full article
