Search Results (27)

Determining the active substance content in the tested product is an essential part of research for overall assessment of the quality of a medicinal substance. This role can be successfully performed by membrane electrodes that are selective for a specific drug. The novelty of the presented research is the development of the first ion-selective electrode with a polymer membrane phase with the octenidine (OCT) function. Classical ion-selective electrodes (ISE), polymer electrodes with an internal Ag/AgCl electrode, and electrode bodies with glassy carbon were used for the research. The membranes were prepared based on cation exchangers from the borate group and neutral cyclodextrin. All sensors have good parameters, e.g., the polymer electrode with KtpClPB is characterised by a wide linear range of −logc 6−3, a low limit of detection 5 × 10⁻⁷ M, and a near-Nernstian, reproducible slope of characteristics of 31.41 ± 1.14 mV/decade. It can be seen that a stable, reversible potential and a short response time were achieved for this sensor. The obtained favourable selectivity coefficients of the electrode determined in relation to excipients allowed direct determination of octenidine, e.g., in lozenges. The results obtained with the calibration curve method show a recovery of 97% and a precision of SD 2.3 mg/L, which indicates that the data are consistent with the pharmacopoeia requirements. Full article

A strong application potential for Ag/AgCl ion-selective electrodes (ISEs) used as chloride sensors in cement-based material is widely accepted, but their stability and durability have not been sufficiently addressed. This paper summarizes the research status of the stability and durability of Ag/AgCl ISEs used for the non-destructive detection of chloride in cement-based materials. Four topics including working principle and fabrication methods, the factors that influence stability, research status for stability and durability studies, and the reason for durability failure of Ag/AgCl ISEs in cement-based materials are reviewed. Meanwhile, the improving methods for Ag/AgCl ISEs are proposed based on discussions of various aspects of Ag/AgCl ISEs. Full article

A simple and easily applicable analytical method for the simultaneous determination of Cd²⁺, Pb²⁺, Zn²⁺, Cu^2+, and Cl⁻ by applying a modified carbon paste electrode with saffron-conjugated silver nanoparticles (AgNPs@Sa) is being presented. The modified CPE was then used for the simultaneous determination of Cd²⁺, Pb²⁺, Zn²⁺, and Cu²⁺ as well as chloride ions in soil and plants. The comparative analysis demonstrated a significant enhancement in the applicability of the modified electrode through the incorporation of silver nanoparticles (AgNPs) at the carbon paste electrode (CPE) surface, leading to the development of a poly-Sa-CPE. This newly proposed method offers notably superior qualitative performance compared to other metal nanoparticle-based modifications reported in the literature. The accordingly modified electrode was successfully applied in the development of a chloride ion. A novel sensor is being proposed that makes possible the determination of heavy metals and chlorides in the same solution, in soil and plant samples. The enhanced sensitivity and selectivity of the poly-Sa-CPE system highlights its potential as a more effective alternative for heavy metal and chloride analysis, further demonstrating its advantages in electrochemical applications. The LODs of Cd²⁺, Pb²⁺, Zn^2+, Cu²⁺, and Cl⁻ for their simultaneous determination are 0.38 μg·L⁻¹, 0.44 μg·L⁻¹, 0.72 μg·L⁻¹, 0.42 μg·L⁻¹, and 0.11 μg·L⁻¹, respectively, with comparably high relative standard deviations of about 8.1%, 9.4%, 8.3%, 7.6%, and 7.9%, respectively. Full article

A composite solid chloride sensor consisting of two single sensors, i.e., Ag/AgCl working electrode and Mn/MnO₂ reference electrode, was developed. The Ag/AgCl electrode was prepared by the anodic polarization method, while the Mn/MnO₂ reference electrode was prepared using the powder compaction technique. Then, the electrochemical performances such as stability, reproducibility, and sensitivity of the composite and single sensors were investigated in a saturated Ca(OH)₂ solution and mortar specimen. A current density of 0.5 mA/cm² and polarization time of 2.5 h were the optimal preparation parameters of the Ag/AgCl selective electrode. The Ag/AgCl selective electrode showed a linear potential response with the logarithm of chloride ion content in solution and had good stability, reproducibility, and anti-polarization performances. In addition, the Mn/MnO₂ electrode exhibited potential stability after being activated in an alkaline solution for 60 days. The composite sensor demonstrated exceptional sensitivity to the Cl⁻ content, boasting a slope of approximately 51.1 mV/decade, and showcased excellent stability in both solution and mortar specimens. In every measurement, the time needed for the potential of a composite sensor to become stable was less than 30 s. The sensor enables non-destructive in situ monitoring of the chloride ion content in cement mortar, thus realizing early warning of deterioration of reinforcement and guaranteeing long service life of the structure. Full article

Ammonium thiosulfate leaching is a promising alternative to the conventional cyanide method for extracting gold from ores. However, strategies for recovering gold from the leachate are less commercially used due to its low affinity to gold. The present study investigated the recovery of gold from the leachate using iron oxides (hematite, Fe₂O₃ or magnetite, Fe₃O₄). Cementation experiments were conducted by mixing 0.15 g of aluminum powder as an electron donor and 0.15 g of an electron mediator (activated carbon, hematite, or magnetite) in 10 mL of ammonium thiosulfate leachate containing 100 mg/L gold ions and 10 mM cupric ions for 24 h at 25 °C. The results of the solution analysis showed that when activated carbon (AC) was used, the gold was recovered together with copper (recoveries were 99.99% for gold and copper). However, selective gold recovery was observed when iron oxides were used, where the gold and copper recoveries were 89.7% and 21% for hematite and 85.9% and 15.4% for magnetite, respectively. An electrochemical experiment was also conducted to determine the galvanic interaction between the electron donor and electron mediator in a conventional electrochemical setup (hematite/magnetite–Al as the working electrode, Pt as the counter electrode, Ag/AgCl as the reference electrode) in a gold–thiosulfate medium. Cyclic voltammetry showed a gold reduction “shoulder-like” peak at −1.0 V using hematite/Al and magnetite/Al electrodes. Chronoamperometry was conducted and operated at a constant voltage (−1.0 V) determined during cyclic voltammetry and further analyzed using SEM-EDX. The results of the SEM-EDX analysis for the cementation products and electrochemical experiments confirmed that the gold was selectively deposited on the iron oxide surface as an electron mediator. Full article

Continuous in vivo monitoring (CIVM) of pH value is essential for personalized medicine, as many diseases are closely related to acid–base imbalances. However, conventional pH meters are limited in their ability to perform CIVM due to excessive blood consumption, large device volume, frequent calibration, and inadequate real-time monitoring. There is thus an urgent need for a portable method for CIVM of pH value. To address this need, we propose a minimally invasive, continuous monitoring solution in the form of an implantable pH microneedle sensor (MNS) in this study. The MNS is based on the integration of an acupuncture needle (AN) and a Ag/AgCl reference electrode. We fabricate the sensor by electrochemically depositing platinum black and gold nanoparticles onto the AN and further modifying it with polyaniline to increase its sensitivity to hydrogen ions. The pH value is obtained by calculating the open circuit voltage between the modified AN and the reference electrode. The resulting MNS demonstrates excellent selectivity and a high nernstian response to pH (−57.4 mV per pH) over a broad range (pH = 4.0 to pH = 9.0). Both in vitro and in vivo experiments have verified the performance of the sensor, showcasing its potential for biomedical research and clinical practice. The MNS provides an alternative to conventional pH meters, offering a less invasive and more convenient way to perform CIVM of pH value. Moreover, this electrochemical implantable sensor based on AN and silver wires provides a simple and sensitive method for continuous in vivo detection of other biomarkers. Full article

A flexible pH sensor based on using iridium oxide (IrO_x) as the sensing film was developed by the roll-to-roll (R2R) process. The inert and biocompatible properties of IrO_x make it a desired metal oxide for pH-sensing applications. The flexible substrates being continuously processed by the R2R technique provides the advantages of scalability, reconfigurability, resiliency, on-demand manufacturing, and high throughput, without the need for vacuum systems. Potential sweeps by cyclic voltammetry across the IrO_x film against commercial and planar Ag/AgCl electrodes validated the reversible electrochemical mechanisms. Multiple IrO_x electrodes showed similar output potentials when continuously tested in the pH range of 2–13, indicating good fabrication uniformity. For practical applications, planar IrO_x/Ag-AgCl pairs developed on polyimide substrates were tested, with a good linear fit within pH 2–13, achieving Nernstian responses of around −60.6 mV/pH. The pH sensors showed good repeatability when analyzed with hysteresis, drift, fluctuation, and deviation as the stability factors. The selectivity of the interference ions and the effect of temperature were studied and compared with the reported values. The electrodes were further laminated in a process compatible with the R2R technique for packaging. The flexible sensors were tested under flat and curved surface conditions. Tests in artificial sweat and viscous solutions were analyzed in the Clarke error grid, showing reliable pH-sensing performance. The materials used during the manufacturing processes were sustainable, as the active materials were in small amounts and there was no waste during processing. No toxic chemicals were needed in the fabrication processes. The cost-effective and efficient materials and the fabrication process allow for rapid production that is necessary for disposable and point-of-care devices. Flexible electronics provide a platform for device and sensor integration and packaging, which enables Internet-of-things (IoT) network applications. Full article

The level of hydrogen ions in sweat is one of the most important physiological indexes for the health state of the human body. As a type of two-dimensional (2D) material, MXene has the advantages of superior electrical conductivity, a large surface area, and rich functional groups on the surface. Herein, we report a type of Ti₃C₂T_x-based potentiometric pH sensor for wearable sweat pH analysis. The Ti₃C₂T_x was prepared by two etching methods, including a mild LiF/HCl mixture and HF solution, which was directly used as the pH-sensitive materials. Both etched Ti₃C₂T_x showed a typical lamellar structure and exhibited enhanced potentiometric pH responses compared with a pristine precursor of Ti₃AlC₂. The HF-Ti₃C₂T_x disclosed the sensitivities of −43.51 ± 0.53 mV pH^–1 (pH 1–11) and −42.73 ± 0.61 mV pH^–1 (pH 11–1). A series of electrochemical tests demonstrated that HF-Ti₃C₂T_x exhibited better analytical performances, including sensitivity, selectivity, and reversibility, owing to deep etching. The HF-Ti₃C₂T_x was thus further fabricated as a flexible potentiometric pH sensor by virtue of its 2D characteristic. Upon integrating with a solid-contact Ag/AgCl reference electrode, the flexible sensor realized real-time monitoring of pH level in human sweat. The result disclosed a relatively stable pH value of ~6.5 after perspiration, which was consistent with the ex situ sweat pH test. This work offers a type of MXene-based potentiometric pH sensor for wearable sweat pH monitoring. Full article

In this work, the stability, electrical conductivity, and versatility of graphite-based inks were taken advantage of to fabricate a nitrate potentiometric sensor. One other key property that was exploited for the design of an ion-selective electrode was the hydrophobicity of graphite. This prevented the formation of a water layer between the solid contact and the polymeric selective membrane. Moreover, given the use of printing technologies for electrode fabrication, it was possible to easily miniaturize the sensors and achieve lower fabrication costs. In this article, a printed sensor, composed of a graphite working electrode and a Ag/AgCl reference electrode, is presented and thoroughly characterized. The working electrode was modified with a well-known PVC-ionophore membrane, and the reference electrode was protected with a PVB-NaCl saturated membrane. It showed almost-Nernstian sensitivity of −(55.4 ± 0.7) mV/dec to NO₃⁻, stability of up to 25 days of operation, limit of detection of 0.204 ± 0.009 mM, and repeatability of 99.02 % (N = 3). Coupled with its high selectivity compared with other anions, this low-cost, mass-producible sensor is a great alternative for environmental and industrial applications. Full article

We built an integrated solid-contact ion-selective electrode (SCISE) system with the functionality of self-calibration. A multiplexed SCISE sensor (K⁺ and NO₃⁻ vs. Ag/AgCl) was fabricated on printed-circuit board (PCB) substrates and was subsequently embedded into a microfluidic flow cell for self-calibration and flow-through analysis. A PCB circuit that includes modules for both sensor readout and fluid control was developed. The sensors showed a fast and near-Nernstian response (56.6 for the K⁺ electrode and −57.4 mV/dec for the NO₃⁻ electrode) and maintained their performance for at least three weeks. The sensors also showed a highly reproducible response in an automated two-point calibration, demonstrating the potential for in situ monitoring. Lastly, the sensor system was successfully applied to measure mineral nutrients in plant sap samples. Full article

Chalcogenide glasses are widely used as sensitive membranes in the chemical sensors for heavy metal ions detection. The lack of research work on sodium ion-selective electrodes (Na⁺-ISEs) based on chalcogenide glasses is due to the high hygroscopicity of alkali dopes chalcogenides. However, sodium halide doped Ga₂S₃-GeS₂ glasses are more chemically stable in water and could be used as Na⁺-sensitive membranes for the ISEs. In this work we have studied the physico-chemical properties of mixed cation (AgI)_x(NaI)_30-x(Ga₂S₃)₂₆(GeS₂)₄₄ chalcogenide glasses (where x = 0, 7.5, 15, 22.5 and 30 mol.% AgI) using density, DSC, and conductivity measurements. The mixed cation effect with shallow conductivity and glass transition temperature minimum was found for silver fraction r = Ag/(Na + Ag) ≈ 0.5. Silver addition decreases the moisture resistance of the glasses. Only (AgI)_22.5(NaI)_7.5(Ga₂S₃)₂₆(GeS₂)₄₄ composition was suitable for chemical sensors application, contrary to the single cation sodium halide doped Ga₂S₃-GeS₂ glasses, where 15 mol.% sodium-halide-containing vitreous alloys are stable in water solutions. The analytical parameters of (NaCl)₁₅(Ga₂S₃)₂₃(GeS₂)₆₂; (NaI)₁₅(Ga₂S₃)₂₃(GeS₂)₆₂ and (AgI)_22.5(NaI)_7.5(Ga₂S₃)₂₆(GeS₂)₄₄ glass compositions as active membranes in Na⁺-ISEs were investigated, including detection limit, sensitivity, linearity, ionic selectivity (in the presence of K⁺, Mg²⁺, Ca²⁺, Ba²⁺, and Zn²⁺ interfering cations), reproducibility and optimal pH-range. Full article

The bismuth film electrode (BiFE), which was first introduced in 2000 for electrochemical stripping analysis, is now widely used in electroanalytical laboratories worldwide. Numerous scientists have been inspired to conduct more research and broaden the understanding of the BiFE’s favourable electroanalytical performance, which is comparable to, or in some cases even exceeds, that of its mercury counterparts for the detection of heavy metal ions and selected organic compounds. Various types of bismuth-based paste electrodes, as well as in-situ and ex-situ prepared BiFE, have been presented in combination with potentiometric and voltammetric (stripping) protocols. Whereas the ex situ prepared electrodes must be moved from the modification solution to the measuring cell device and often need to display improved stability for several measurements, the ex-situ-prepared bismuth films require acceptable physical and chemical stability. In this study, we provided insight into the commencement of the formation of the bismuth film on a glassy carbon substrate electrode (GCE) when using a very low concentration of bismuth ions. We used our home-constructed AFM cell to fit in commercial working GCE, a platinum wire as the counter electrode, and an Ag/AgCl/NaCl (3 M) as the reference electrode. Full article

Methylmercury (MeHg) is one of the most toxic organic mercury compounds found in the environment. The continuous exposure of human beings to this highly toxic compound may damage their nervous system. The present work reports the development and application of a novel electrochemical sensing technique for the quantification of MeHg using a modified carbon paste electrode with multi-walled carbon nanotubes (MWCNTs) combined with ion imprinted polymer, which is highly selective toward MeHg (CPE/MWCNTs/IIP-MeHg) detection. The ion imprinted polymer was synthesized using 2-mercaptobenzothiazole (MBT), acrylic acid (AA) and MeHg employed as ligand, functional monomer and template ion, respectively, and the synthesized material was characterized by Raman spectroscopy and SEM-EDX. Both the proposed and control sensors were characterized by cyclic voltammetry (CV) and electrochemical impedance spectroscopy (EIS). The electrochemical measurements were carried out using differential pulse stripping voltammetry (DPSV), and a well-defined anodic peak observed at about +0.138 V (vs. Ag/AgCl) was recorded for MeHg. The application of the CPE/MWCNTs/IIP-MeHg sensor (which increased the charge transfer on the electrode surface) under the DPSV-based electrochemical method (which enhanced the signal intensity) made the detection technique highly sensitive and selective for the quantification of methylmercury. Under optimum experimental conditions, the proposed sensor exhibited a linear response range of 560–610 µg L⁻¹ and a detection limit of 0.538 µg L⁻¹, with acceptable relative error values ≤1% when applied for the detection of MeHg in real water samples. Full article

Recently, the new updates in legislation about drinking water control and human health have increased the demand for novel electrochemical low-cost sensors, such as potentiometric ones. Nowadays, the determination of chloride ion in aqueous solutions has attracted great attention in several fields, from industrial processes to drinking water control. Indeed, chloride plays a crucial role in corrosion, also influencing the final taste of beverages, especially coffee. The main goal is to obtain devices suitable for continuous and real-time analysis. For these reasons, we investigated the possibility to develop an easy, low-cost potentiometric chloride sensor, able to perform analysis in aqueous mediums for long immersion time and reducing the need of periodic calibration. We realized a chloride ion selective electrode made of Ag/AgCl sintered pellet and we tested its response in model solutions compatible with drinking water. The sensor was able to produce a stable, reproducible, and accurate quantification of chloride in 900 s, without the need for a preliminary calibration test. This opens the route to potential applications of this sensor in continuous, in situ, and real time measurement of chloride ions in industrial processes, with a reduced need for periodic maintenance. Full article

Current solid potentiometric ion sensors mostly rely on polymeric-membrane-based, solid-contact, ion-selective electrodes (SC-ISEs). However, anion sensing has been a challenge with respect to cations due to the rareness of anion ionophores. Classic metal/metal insoluble salt electrodes (such as Ag/AgCl) without an ion-selective membrane (ISM) offer an alternative. In this work, we first compared the two types of SC-ISEs of Cl⁻ with/without the ISM. It is found that the ISM-free Ag/AgCl electrode discloses a comparable selectivity regarding organic chloride ionophores. Additionally, the electrode exhibits better comprehensive performances (stability, reproducibility, and anti-interference ability) than the ISM-based SC-ISE. In addition to Cl⁻, other Ag/AgX electrodes also work toward single and multi-valent anions sensing. Finally, a flexible Cl⁻ sensor was fabricated for on-body monitoring the concentration of sweat Cl⁻ to illustrate a proof-of-concept application in wearable anion sensors. This work re-emphasizes the ISM-free SC-ISEs for solid anion sensing. Full article
