In the seismic design of steel moment-resisting frames (MRFs), the panel zone region can significantly affect overall ductility and energy-dissipation capacity. This study investigates the influence of panel zone flexibility on the seismic response of steel MRFs by comparing two modeling approaches: one with a detailed panel zone representation and the other considering fixed beam-column connections. A total of 30 2D steel MRFs (15 frames incorporating panel zone modeling and 15 frames without panel zone modeling) are subjected to nonlinear time–history analyses using four suites of ground motions compatible with Eurocode 8 (EC8) soil types (A, B, C, and D). Structural performance is evaluated at three distinct performance levels, namely, damage limitation (DL), life safety (LS), and collapse prevention (CP), to capture a wide range of potential damage scenarios. Based on these analyses, the study provides information about the seismic response of these frames. Also, lower-bound, upper-bound, and mean values of behavior factor (q) for each soil type and performance level are displayed, offering insight into how panel zone flexibility can alter a frame’s inelastic response under seismic loading. The results indicate that neglecting panel zone action leads to an artificial increase in frame stiffness, resulting in higher base shear estimates and an overestimation of the seismic behavior factor. This unrealistically increased behavior factor can compromise the accuracy of the seismic design, even though it appears conservative. In contrast, including panel zone flexibility provides a more realistic depiction of how forces and deformations develop across the structure. Consequently, proper modeling of the panel zone supports both safety and cost-effectiveness under strong earthquake events. Full article

Split reinforced concrete column (SRCC), recognized for their exceptional ductility as seismic members, have faced developmental challenges due to the complexities of on-site casting. This study presents an innovative steel sleeve dry connection assembled SRCC, which is highly modular and simplifies construction, aiming to promote the engineering application of this innovative ductile seismic structural system. This study used a validated 3D finite element (FE) method to analyze internal joint forces. Key parameters influencing joint performance, such as the axial compression ratio (u) and cross-sectional equal division ratio (n), were analyzed in detail. Subsequently, a comparative of dynamic analysis of SRCC and normal reinforced concrete column (NRCC) frames was conducted, leading to recommendations for structural strengthening. The analysis revealed that the sleeve can provide effective protection for the core area of the joint. The ductility of SRCC is 2–3 times higher than that of NRCC. A detailed formula for calculating the shear-bearing capacity of SRCC joints was derived, showing strong agreement with numerical simulations. At a high seismic intensity of 9°, the acceleration response of the SRCC frame is significantly reduced compared to the NRCC frame, with the maximum base shear (MBS) decreasing by approximately 4 times, which significantly enhances its seismic performance. However, due to the larger inter-story displacements, it is necessary to incorporate energy-dissipating braces to comply with code requirements. Collectively, these findings underscored that the proposed SRCC system significantly enhances seismic performance by improving ductility and energy dissipation, providing a robust foundation for future studies and practical applications in seismic design. Full article

In recent years, numerous studies highlighted the crucial role of the soil–structure interaction (SSI) in the seismic performance of basement structures. However, there remains a limited understanding of how this interaction affects buildings with basement structures under varying site conditions. Based on the three-dimensional (3D) numerical analysis method, the influence of the SSI on the seismic response of high-rise steel frame–core wall (SFCW) structures situated on shallow-box foundations were investigated in this study. To further investigate the effects of the SSI and site conditions, three types of soil profiles—soft, medium, and hard—were considered, along with a fixed-foundation model. The results were compared in terms of the maximum lateral displacement, inter-story drift ratio (IDR), acceleration amplification coefficient, and tensile damage for the SFCW structure under different site conditions, with both fixed-base and shallow-box foundation configurations. The findings highlight that the site conditions significantly affected the seismic performance of the SFCW structure, particularly in the soft soil, which increased the lateral deflection and inter-story drift. Moreover, compared with non-pulse-like ground motion, pulse-like ground motion resulted in a higher acceleration amplification coefficient and greater structural response in the SFCW structure. The RC core wall–basement slab junction was a critical region of stress concentration that exhibited a high sensitivity to the site conditions. Additionally, the maximum IDRs showed a more significant variation at incidence angles between 20 and 30 degrees, with a more pronounced effect at a seismic input intensity of 0.3 g than at 0.2 g. Full article

In the process of construction, pouring and vibrating concrete on existing reinforced structures is a necessary process. This paper presents an automatic vibration position detecting method based on the feature extraction of 3D lidar point clouds. Compared with the image-based method, this method has better anti-interference performance to light with reduced computational consumption. First, lidar scans are used to capture multiple frames of local steel bar point clouds. Then, the clouds are stitched by Normal Distribution Transform (NDT) for preliminary matching and Iterative Closest Point (ICP) for fine-matching. The Graph-Based Optimization (g2o) method further refines the precision of the 3D registration. Afterwards, the 3D point clouds are projected into a 2D image. Finally, the locations of concrete vibration points and concrete casting points are discerned through point cloud and image processing technologies. Experiments demonstrate that the proposed automatic method outperforms ICP and NDT algorithms, reducing the mean square error (MSE) by 11.5% and 11.37%, respectively. The maximum discrepancies in identifying concrete vibration points and concrete casting points are 0.059 ± 0.031 m and 0.089 ± 0.0493 m, respectively, fulfilling the requirement for concrete vibration detection. Full article

Laser scanning has become a popular technology for monitoring structural deformation due to its ability to rapidly obtain 3D point clouds that provide detailed information about structures. In this study, the deformation of a complex steel frame structure is estimated by comparing the associated point clouds captured at two epochs. To measure its deformations, it is essential to extract the bottom flanges of the steel beams in the captured point clouds. However, manual extraction of numerous bottom flanges is laborious and the separation of beam bottom flanges and webs is especially challenging. This study presents an algorithm-driven approach for extracting all beams’ bottom flanges of a complex steel frame. RANdom SAmple Consensus (RANSAC), Euclidean clustering, and an originally defined point feature is sequentially used to extract the beam bottom flanges. The beam bottom flanges extracted by the proposed method are used to estimate the deformation of the steel frame structure before and after the removal of temporary supports to beams. Compared to manual extraction, the proposed method achieved an accuracy of 0.89 in extracting the beam bottom flanges while saving hours of time. The maximum observed deformation of the steel beams is 100 mm at a location where the temporal support was unloaded. The proposed method significantly improves the efficiency of the deformation measurement of steel frame structures using laser scanning. Full article

To address the issue of inconsistencies between the 3D structural models built on Building Information Modeling (BIM) platforms and the original structural designs, thereby ensuring structural safety and reliability, this paper proposes an integrated design approach for prefabricated steel frame structures based on BIM technology with a primary focus on structural safety. The application of the integrated design methodology for prefabricated steel frame structures, leveraging BIM technology, is concretely demonstrated through case studies. These illustrations focus on pivotal aspects: assessing the overall safety performance of the structure, conducting meticulous analyses of beam-to-column connection nodes, and harnessing the outcomes of these evaluations to inform and direct the optimization of the structural design. The research findings presented herein offer insights and methodologies for applying BIM in safety assessments of prefabricated steel frame structures, thereby further refining the comprehensive framework of BIM engagement throughout the entire life cycle of prefabricated steel frame construction projects. Full article

The arrangement of eccentric bracing has a significant impact on the seismic performance of structures. However, there is no further stipulation on different forms of eccentric bracing in the current Chinese code. At the same time, there is a lack of research on the seismic loss of eccentrically braced structures by Chinese domestic scholars. Therefore, this paper designs different forms of eccentrically braced frames and analyzes them according to the concept of seismic engineering based on performance, which provides some reference for the selection of the eccentrically braced steel frame structure layout in future engineering practice. In this paper, K-shaped, V-shaped, and D-shaped eccentrically braced steel frame structures with 3, 5, and 8 floors are designed, and the finite element analysis model is used for static napping and dynamic time history analysis. The results show that the K-shaped eccentrically braced structure has the best performance in bearing capacity and stiffness and has good seismic and collapse resistance performance. In the FEMA P-58 seismic assessment and vulnerability assessment, it is found that the V-shaped eccentrically braced structure has the smallest loss. However, it is necessary to fully consider the acceleration sensitivity of the non-structural components in the design. In general, the seismic performance of the eccentrically braced structure is improved by the energy dissipation beam yielding to consume energy, which provides a useful reference for structural design. Full article

Skewed supports complicate load paths in continuous steel I-girder bridges, causing secondary stresses and differential deformations. For a continuous bridge where tensile stresses are developed in the top flange of the steel girders over the intermediate supports, these effects may exacerbate potential fatigue issues for the top flanges. There is a gap in knowledge regarding the level of stress one can expect at these locations, and the stress level can render the problem either serious or trivial. This paper has been successful in providing this information, which was not available before. The study examines the fatigue performance of the top flange in girders over skewed supports. Results are presented from a detailed investigation consisting of 3D finite element modeling to evaluate 26 skewed bridges in the State of Florida that represent the wide range of geometries found in practice. The analysis focused on stress ranges in the top flanges and axial demands on end cross-frame members under fatigue truck loading. A preliminary analysis helped to select the appropriate element type and support conditions. The maximum factored stress range of 3.63 ksi obtained for the selected group of bridges remains below the 10 ksi fatigue threshold for an AASHTO Category C connection, alleviating the concerns about the fatigue performance of the continuous girder top flange over the intermediate pier. Hence, fatigue is unlikely to be a concern in the flanges at this location. Statistics on computed stress ranges and cross-frame forces that provide an understanding of the expected values and guidance for detailing practices are also presented. A limited comparative refined FE analysis on two different types of end cross-frame to girder connections also provided useful insight into the fatigue sensitivities of the skew connections. Half-Round Bearing Stiffener (HRBS) connections performed better than the customary bent plate connections. The HRBS connection reduces girder flange stress concentration range by at least 18% compared to the bent plate connection. The maximum stress concentration range in bent plate components is significantly higher than in the HRBS connection components. The work documented in this paper is important for understanding the fatigue performance of the cross-frames and girders in support regions in the upcoming 10th edition of the AASHTO Bridge Design Specifications that may include plate stiffeners oriented either normally or skewed to the girder web, or Half-Round Bearing Stiffeners. Full article

The efficient extraction, storage, and visualization of geometric and semantic information is a key foundation for the operation of the building information modeling (BIM) platform. This study aims to develop a lightweight BIM system and optimize the system’s performance according to the specific characteristics of steel structures. This study proposes several novel techniques for extracting and decoupling the geometric and semantic information of components from industry foundation class (IFC) files. A redundancy removal approach combining the principal content analysis (PCA) algorithm and the Hausdorff-based comparison algorithm is proposed to identify standardized steel components, and a lightweight visualization method on Web3D for redundant instances is also presented. A loading mechanism of the level of detail (LOD) model based on a mesh simplification algorithm is presented to optimize the display efficiency. The developed system is evaluated by three steel structural models. Using the redundancy removal approach, the number of instances is decreased by 96.46% in less than 30 s and over 30 FPS (frame per second) is kept when rendering. Using the LOD loading mechanism, 95.38% of vertices and 98.46% of patches are eliminated under 50 mm precision. The experiment results indicate that users can quickly load large BIM models and fetch sufficient information from the website. Full article

The design innovation of high-strength steel frames paired with D-eccentric bracing exhibits remarkable resistance to plastic deformation during seismic events. This method strategically combines regular steel connections (with yield strengths below 345 MPa) and high-strength steel beams and columns (such as Q460 or Q690, with yield strengths over 460 MPa), effectively reducing cross-sectional sizes while preserving the elasticity of non-energy-dissipating members. This configuration results in substantial ductility and superior energy dissipation capabilities. The response modification factor (R) is vital for achieving both effective and economical seismic resilience, particularly in the development of efficient and cost-effective seismic designs. However, the 2016 edition of the Code for Seismic Design of Buildings (GB50011-2010) fails to incorporate the concept of R, opting instead to apply a uniform value to all structural systems. This oversight is fundamentally flawed, necessitating a comprehensive investigation into the R value specifically for the high-strength steel frame with a D-eccentric brace. This research primarily aims to improve structural performance design, provide guidance for future projects, and encourage the adoption of this advanced seismic performance structure in earthquake-prone areas. To achieve these objectives, a performance-based seismic design approach is employed. This method involves designing structures with varying numbers of stories (4, 8, and 12), different link lengths (900, 1000, and 1100 mm), and various steel strengths (Q460 and Q690). This study uses the Incremental Dynamic Analysis (IDA) method to determine the R values for each prototype. The derived performance coefficients act as crucial references for the development of future innovative structural designs. This research greatly enhances seismic design practices and facilitates the wider adoption of high-strength steel frames with D-eccentric braces due to their outstanding seismic performance. Full article

The accurate evaluation of the thermal performance of building envelope components (e.g., facade walls) is crucial for the reliable evaluation of their energy efficiency. There are several methods available to quantify their thermal resistance, such as analytical formulations (e.g., ISO 6946 simplified calculation method), numerical simulations (e.g., using finite element method), experimental measurements under lab-controlled conditions or in situ. Regarding measurements, when using the heat flow meter (HFM) method, very often, the measured value is based on surface conditions (e.g., temperature and heat flux), achieving in this way the so-called surface-to-surface or conductive thermal resistance ($R_{cond}$). When the building components are made of homogeneous layers, their $R_{cond}$ values are constant, regardless of their internal and external surface boundary conditions. However, whenever this element is composed of inhomogeneous layers, such as in lightweight steel-framed (LSF) walls, their $R_{cond}$ values are no longer constant, depending on their thermal surface resistance. In the literature, such systematic research into how these $R_{cond}$ values vary is not available. In this study, the values of four LSF walls were computed, with different levels of thermal conductivity inhomogeneity, making use of four finite elements’ numerical simulation tools. Six external thermal surface resistances ($R_{\mathrm{s}\mathrm{e}}$) were modelled, ranging from 0.00 up to 0.20 m²·K/W. The average temperature of the partition LSF walls is 15 °C, while for the facade LSF walls it is 10 °C. It was found that the accuracy values of all evaluated numerical software are very high and similar, the $R_{cond}$ values being nearly constant for walls with homogeneous layers, as expected. However, the variation in the $R_{cond}$ value depends on the level of inhomogeneity in the LSF wall layers, increasing up to 8%, i.e., +0.123 m²·K/W, for the evaluated $R_{\mathrm{s}\mathrm{e}}$ values. Full article

The construction industry in New Zealand is significantly impacted by the importance of housing, particularly as urbanisation continues to grow in major cities. Modern construction methods, such as offsite construction and building automation, evolving into digital manufacturing and construction in the industry, have become prominent. Despite the global recognition of 3D printing technology, its adoption in the construction industry in New Zealand is still relatively limited. This study aims to examine the feasibility of 3D printing construction in response to current market challenges, innovation, and the 2050 net-zero carbon goal. Utilising Building Information Modelling (BIM) and Life Cycle Assessment (LCA) approaches, this study investigated the environmental impacts of three housing types: 3D printing (3DP), light steel framed (LSF), and timber. This study used cradle-to-cradle as the system boundary. The results indicate that the 3DP house emits 20% fewer carbon emissions than the traditional timber house and 25% less than the LSF house. Additionally, the 3DP house exhibits a 19% lower annual electric energy consumption than the timber house. Therefore, in response to the growing housing demand in New Zealand, the construction industry must innovate and embrace digital and advanced construction methods, including the adoption of 3D printing. Full article

Modular timber construction embodies a pioneering and eco-friendly methodology within the building sector. With the notable progress made in manufacturing technologies and the advent of engineered wood products, timber has evolved into a promising substitute for conventional materials such as concrete, masonry, and steel. Beyond its structural attributes, timber brings environmental advantages, including its inherent capacity for carbon sequestration and a reduced carbon footprint compared to conventional materials. Timber’s lightweight nature, coupled with its versatility and efficiency in factory-based production, accelerates modular construction processes, providing a sustainable solution to the growing demands of the building industry. This work thoroughly explores contemporary modular construction using wood as the primary material. The investigation spans various aspects, from the fundamentals of modularity and the classification of modular timber solutions to considerations of layout design, structural systems, and stability at both the building and module levels. Moreover, inter-module joining techniques, MEP (mechanical, electrical, and plumbing) integration, and designs for disassembly are scrutinized. The investigation led to the conclusion that timber modular construction, drawing inspiration from the steel modular concept, consistently utilizes a structural approach based on linear members (timber frame, post-and-beam, etc.), incorporating stability configurations and diverse joint techniques. Despite the emphasis on modularization and prefabrication for adaptability, a significant portion of solutions still concentrate on the on-site linear assembly process of those linear members. Regarding modularity trends, the initial prevalence of 2D and 3D systems has given way to a recent surge in the utilization of post-and-beam structures, congruent with the ascending verticality of buildings. In contrast to avant-garde and bold trends, timber structures typically manifest as rectilinear, symmetric plans, characterized by regular and repetitive extrusions, demonstrating a proclivity for centrally located cores. This work aims to offer valuable insights into the current utilization of modular timber construction while identifying pivotal gaps for exploration. The delineation of these unexplored areas seeks to enable the advancement of modular timber projects and systems, fully leveraging the benefits provided by prefabrication and modularity. Full article

In recent years, mixed reality (MR) technology has gained popularity in construction management due to its real-time visualisation capability to facilitate on-site decision-making tasks. The semantic segmentation of building components provides an attractive solution towards digital construction monitoring, reducing workloads through automation techniques. Nevertheless, data shortages remain an issue in maximizing the performance potential of deep learning segmentation methods. The primary aim of this study is to address this issue through synthetic data generation using Building Information Modelling (BIM) models. This study presents a point-cloud-based deep learning segmentation approach to a 3D light steel framing (LSF) system through synthetic BIM models and as-built data captured using MR headsets. A standardisation workflow between BIM and MR models was introduced to enable seamless data exchange across both domains. A total of five different experiments were set up to identify the benefits of synthetic BIM data in supplementing actual as-built data for model training. The results showed that the average testing accuracy using solely as-built data stood at 82.88%. Meanwhile, the introduction of synthetic BIM data into the training dataset led to an improved testing accuracy of 86.15%. A hybrid dataset also enabled the model to segment both the BIM and as-built data captured using an MR headset at an average accuracy of 79.55%. These findings indicate that synthetic BIM data have the potential to supplement actual data, reducing the costs associated with data acquisition. In addition, this study demonstrates that deep learning has the potential to automate construction monitoring tasks, aiding in the digitization of the construction industry. Full article

After the excavation and unloading of deep-buried soft rock tunnels, support structures often experience deformation-related disasters such as concrete cracking, steel frame bending and twisting, and primary support instability under different forms of load. Accurately calculating the load borne by the primary support structure is the key to ensuring design rationality and construction safety. Especially in layered soft surrounding rock formations, the magnitude and distribution of the loads are different from those of conventional rock and soil masses, resulting in limited applicability of existing load calculation methods to similar formations. Therefore, based on the measured deformation of the tunnel structure, while considering the different geometric forms of the primary support structure during partial excavation, this paper proposes a deformation-structure (D-S) load calculation method. By comparing the calculation results of this method and a large number of sample data for typical deep-buried layered soft rock tunnels, the reliability of the D-S load calculation method is verified. In addition, the variation law of the loads during the tunnel construction period is enunciated, and the magnitude and distribution of the loads acting on the primary support are clarified. The D-S load calculation method provides a theoretical basis for load calculation in deep-buried layered soft rock tunnels. Full article
