The development of hydroelectric technology and much of the “knowledge” on hydraulic phenomena derive from scale modeling and “bench” tests to improve machinery efficiency. The result of these experimental tests is mapping the so-called “hill chart”, representing the “DNA” of a turbine model. Identifying the efficiency values as a function of the specific parameters of the flow and energy coefficient (which both identify the operating point) allows us to represent the complete behavior of a turbine in hydraulic similarity with the original model developed in the laboratory. The present work carries out a “reverse engineering” operation that leads to the definition of “an innovative research model” that is relatively simple to use in every field. Thus, from the experimental survey of the degree of efficiency of several prototypes of machines deriving from the same starting model, the hill chart of the hydraulic profile used is reconstructed. The “mapping” of all the characteristic quantities of the machine, together with the physical parameters of the regulating organs of a four-blade Kaplan turbine model, also made it possible to complete the process, allowing to identify not only the iso-efficiency regions but also the curves relating to the trend of the angle of the impeller blades, the specific opening of the distributor, and the identification of critical areas of cavitation. The development of the hill chart was made possible by investigating the behavior of 33 actual prototypes and 46 characteristic curves derived from the same reference model based on practical experiments for finding the optimal blade distributor “setup curve”. To complete this, theoretical characteristic curves of “not physically realized” prototypes were also mapped, allowing us to complete the regions comprising the diagram. The study of the unified hill charts found in previous documentation of the most famous manufacturers was of great help. Finally, the validation of the “proposed procedure” was obtained through the experimental survey of the actual efficiency of the new prototype based on the theoretical values defined in the design phase on the chart obtained with the method described. Full article

This work focuses on the simulation and testing of an innovative storage system for a PHEV vehicle, investigating the possibility of replacing the car’s original storage system with a mixed-storage system with lithium-ion batteries and supercapacitors connected in direct parallel without the use of an intermediate DC/DC converter. The aim is to evaluate the behavior of the supercapacitors’ branch compared with that of the Li-ion cells, both in the discharge/charge transients and over an entire WLTP cycle (Worldwide harmonized Light vehicles Test Procedure). The analysis started with the definition of the digital models of a lithium cell and a supercapacitor. The parameters of the models were tuned through experimental characterization of the two storage cells, Li-ion and supercapacitor. Subsequently, the overall models of the branch with the lithium cells and the branch with the supercapacitors were constructed and connected. The overall storage system was sized for application to a PHEV, and a reduced-scale storage system was realized and tested. Finally, the results obtained from the simulations were validated and compared with experimental tests. Full article

The aim of this work was to develop the design of a direct liquid cooling system for a battery pack of a high-performance plug-in hybrid vehicle. The cooling system of the battery pack is of an innovative type, with the direct cooling of the power busbars and the poles of the lithium cells. In order to obtain preliminary information for the dimensioning and verification of the battery pack cooling system, a simulation model of the whole vehicle and its powertrain was developed. In this way, the current profiles to which the storage system will be subjected can be estimated and can be used to fine-tune the cooling system. The use of a simulation model of the entire vehicle was necessary because the vehicle is still at the design stage, and only experimental data on the specific consumption of the internal combustion engine and experimental characterization data of the lithium cells used, as well as data provided by the manufacturers of the electric motors and inverters, are currently available. Full article

The present work aims to provide a technical, economic, and environmental analysis on the electric accumulators used for electric mobility (pure electric, hybrid, full hybrid and/or mild hybrid) to reduce the environmental, social and economic impacts generated by private vehicles. Initially, the scenarios for the development of electric mobility and the regulatory context were assessed. Attention has been focused on the batteries used in electric vehicles and the technological aspects related to their charging operations. With regard to the economic aspects, the evolution of battery costs in relation to capacity and size has been highlighted in recent years. The advantages related to the containment of environmental impacts are highlighted considering the aspects related to the end of life of the batteries themselves. As retrofitting ICE vehicles by electric motor currently represents a potential transition solution to improve the shift towards the widespread adoption of electric vehicles, the retrofit methodology of some of the current B-segment vehicles was evaluated. In the present work, the authors wanted to demonstrate how the solution proposed here, the retrofitting of class B vehicles, can represent a medium-term way to implement the transition from MCI-based traction to electric. Full article

As part of a project for the realization of a hybrid vehicle with an innovative power train system, the proposal presented is to disconnect the turbocharger group and study the different behavior of the compressor and turbine, so decoupled. In an actual turbocharger, when the power of the turbine exceeds that required by the compressor, the wastegate valve opens. In this way, a part of the flue gases does not evolve into a turbine and limits the power generated. In the solution proposed here (the paper considers only “compressor side”) all the flow rate of the flue gases is processed by the turbine. In this way, for each rpms of the IC engine, the turbine generates more power than that required by the compressor. This makes it possible to use this surplus of power for the auxiliaries and/or to recharge the battery pack of the considered hybrid vehicle. An additional advantage is, thanks to this surplus generated, that the battery pack can be smaller and can be recharged while driving. Therefore, the entire system operates as a “Range Extended”. As mentioned above, this work is focused on the direct compressor—innovative electric motor coupling will be sized and realized, and a subsequent series of experimental tests will confirm the feasibility of this phase of the project. Full article

In this study, an ORC plant is considered that recovers the heat source from 1800 cc Diesel Engine exhaust gases. The power recovered by the ORC system could be used, as an auxiliary system, to provide energy to the electronic parts of the car. The purpose of this study is to investigate the possibility of allocating this ORC plant into a vehicle and in the design of the condenser, with the purpose of reaching the best configurations that lead to low-pressure drop and compact dimensions. The Organic Rankine Cycle converts thermal energy from low-grade heat sources into electricity. The thermodynamic cycles to produce 5 kW were simulated using a custom software application. The basic cycle was chosen to guarantee the most compact configurations. The selected thermodynamic parameters are based on the need to cope with atmospheric conditions. The working fluid chosen is R245fa, due to its thermodynamic characteristics. Since the electrical part would be partially satisfied by this system, the entire power of the thermal engine would be dedicated to mechanical use. It could also be assumed that, as a consequence of the settings of this plant, a reduction in fuel consumption could be expected, which, although at a percentage that cannot be theoretically evaluated at the moment, is nevertheless predictable. In this first stage of the evaluation, the condenser design is presented and analyzed. Full article

This research aims to test the feasibility of a prototype of a newly designed thermal engine for a hybrid propulsion vehicle. This study consists of the implementation of an innovative supercharger for city car internal combustion engine ICE (900 cc). The preliminary proposal presented here is to mechanically disconnect the compressor/turbine device, supporting the rotation of the compressor with a dedicated electric motor and connecting a turbine to a generator. Mechanical decoupling will allow both machines to be designed for operating closer to their maximum performance point, for most of the expected real field of operation. Specifically, the turbine is likely to have a lower rotation speed than the original group and will, therefore, be slightly larger. The advantage is that, while in the current supercharger groups the surplus at high regimes is discharged through the waste-gate valve without expanding in a turbine, in the configuration proposed, all the energy of the combustible gases is used by the turbine to generate electrical power that can be used where required. Once the motorization of the vehicle (999 cc) has been fixed, the two turbomachines will have to be studied and designed, looking where possible, for commercial components. Finally, a computational fluid dynamic CFD will be needed to verify the validity of the choice, followed by careful experimentation campaigns. Full article

Within a large, state-funded, Italian National Project aimed to test the feasibility of an on-the-road prototype of a mild hybrid city vehicle, one of the tasks was to conceive, design and implement an innovative turbocharger that would allow for some energy recovery. The selected vehicle is propelled by a 3-cylinder, 998 cc turbocharged engine (the 66 kW Mitsubishi-Smart W451). The idea is to implement two types of energy recovery: one via the new turbocharger and one through a standard braking energy recovery (also known as KERS). The study of the former is the object of this paper. The proposed turbocharger configuration consists of mechanically separated, electrically coupled compressor and turbine, possibly mounting only slightly modified commercial equipment to reduce construction costs. This paper reports the results of the calculation of the behavior of the new turbocharging group across the entire engine operating range and describes the preliminary design of the unit. An accurate simulation of a mixed (urban and extra-urban) driving mission demonstrates that a net saving of about 5.6% can be attained by the installation of the novel turbocharger unit. Full article

This research aims to test the feasibility of a prototype of a newly designed thermal engine for a hybrid propulsion vehicle. This study consists of the implementation of an innovative supercharger for city car ICE (900 cc). The preliminary proposal presented here is to mechanically disconnect the compressor/turbine device, supporting the rotation of the compressor with a dedicated electric motor and connecting a turbine to a generator. Mechanical decoupling will allow both machines to be designed for operating closer to their maximum performance point, for most of the expected real field of operation. Specifically, the turbine is likely to have a slightly lower rotation speed than the original group and will, therefore, be slightly larger. The advantage is that, while in the current supercharger groups the surplus at high regimes is discharged through the waste-gate valve without expanding in a turbine, in the configuration proposed, all the energy of the combustible gases is used by the turbine to generate electrical power that can be used where required. Once the motorization of the vehicle (999 cc) has been fixed, the two turbomachines will have to be studied and designed, looking, where possible, for commercial components. Finally, a CFD will be needed to verify the validity of the choice, followed by careful experimentation campaigns. Full article

Hybrid vehicles currently represent a compromise between the maturity of conventional vehicles and the low consumption and attention to environmental issues of electric vehicles. This article analyzes the feasibility of a hybrid series vehicle where the heat engine is replaced by a micro gas turbine. In the continuous generation of electric current, it has numerous advantages compared to an internal combustion engine and the purpose of the article is to verify whether these advantages also apply to traction in a hybrid vehicle. The model will be a city car as problems in urban environments of pollution and optimization of consumption are more revealing. After defining performance requirements, the main components are sized and then selected from the catalog, paying attention in the search for a compromise between performance, space constraints, and costs. The Advisor software will then be used to simulate the configuration in both urban and suburban cycles, paying attention to performance, the state of charge of the battery, the operating points of the microturbine, the input and output energy for each element, and fuel consumption. Then, we analyze the level of pollutant emissions to verify that they are lower than the values set by European legislation, specifically the EURO 6 standard. Finally, the total life cycle costs of the car are analyzed as the sum of the purchase cost, operating costs, and maintenance costs to verify the competitiveness of the configuration in the current market. The car was then compared with the Toyota Yaris Hybrid in terms of performance, fuel consumption, emissions, and costs to highlight advantages and disadvantages. Full article

Pollution derived from transportation systems is a worldwide, timelier issue than ever. The abatement actions of harmful substances in the air are on the agenda and they are necessary today to safeguard our welfare and that of the planet. Environmental pollution in large cities is approximately 20% due to the transportation system. In addition, private traffic contributes greatly to city pollution. Further, “vehicle operating life” is most often exceeded and vehicle emissions do not comply with European antipollution standards. It becomes mandatory to find a solution that respects the environment and, realize an appropriate transportation service to the customers. New technologies related to hybrid–electric engines are making great strides in reducing emissions, and the funds allocated by public authorities should be addressed. In addition, the use (implementation) of new technologies is also convenient from an economic point of view. In fact, by implementing the use of hybrid vehicles, fuel consumption can be reduced. The different hybrid configurations presented refer to such a series architecture, developed by the researchers and Research and Development groups. Regarding energy flows, different strategy logic or vehicle management units have been illustrated. Various configurations and vehicles were studied by simulating different driving cycles, both European approval and homologation and customer ones (typically municipal and university). The simulations have provided guidance on the optimal proposed configuration and information on the component to be used. Full article

The present article deals with the design of a micro turbogas turbine suitable for on board applications, e.g., as a power generator on hybrid transit bus, characterized by a simple constructive approach. Deriving the machine layout from an existing KJ-66 aircraft model engine, the authors propose a theoretical design of a compact, lightweight turbogas turbine, by investigating the technical possibility and limits of the proposed design. In particular, a different combustion chamber layout has been proposed, and fuel adduction channels for different swirler designs have been simulated via ANSYS Fluent in order to identify a satisfactory fuel spreading. As a result, the complete characterization of the design parameters and geometries has been performed, and a series of RANS simulations has been used in order to identify an optimal swirler configuration. Full article

The increasing demand for miniaturized radio-controlled vehicles inspired the following research. The uses of these unmanned miniaturized/micro vehicles range from aero-modeling to drones for urban control and military applications too. The common characteristic of these vehicles is the need for a light and compact propulsion system. The radio-controlled (RC) turbines for modeling are ideally suited for this purpose, guaranteeing the necessary thrust with compactness and lightness. This device is a miniaturized turbojet, and it is generally composed of three basic elements: compressor, combustion chamber and turbine. The main goal of the paper is to evaluate the turbojet performance for considering the possibility of its use as a range extender in a hybrid vehicle. Considering the total volume constraints, it will be important to evaluate the specific fuel consumption. Also from the environmental point of view, the possibility of feeding the device with gas has been considered and, consequently, the needed device modifications performed. The test bench has been realized and assembled at the University Department Laboratory. Several different experimental configurations are reproduced and reported here, to obtain performance maps. The experiments results have been compared to previous tests results, as well as numerical simulations. Therefore, it has been possible to make a comparison between the two different fuels. The results show that this device can be used as a range extender for a hybrid vehicle. Moreover, the various tests have shown that, acting on the control unit, it is possible to feed the device with gas (mixture of propane and butane), obtaining a further benefit from the economic point of view. Surely, an in-depth study of the turbine management logic would produce a further advantage in terms of fuel consumption. Full article

Although tissue and cell manipulation nowadays is a common task in biomedical analysis, there are still many different ways to accomplish it, most of which are still not sufficiently general, inexpensive, accurate, efficient or effective. Several problems arise both for in vivo or in vitro analysis, such as the maximum overall size of the device and the gripper jaws (like in minimally-invasive open biopsy) or very limited manipulating capability, degrees of freedom or dexterity (like in tissues or cell-handling operations). This paper presents a new approach to tissue and cell manipulation, which employs a conceptually new conjugate surfaces flexure hinge (CSFH) silicon MEMS-based technology micro-gripper that solves most of the above-mentioned problems. The article describes all of the phases of the development, including topology conception, structural design, simulation, construction, actuation testing and in vitro observation. The latter phase deals with the assessment of the function capability, which consists of taking a series of in vitro images by optical microscopy. They offer a direct morphological comparison between the gripper and a variety of tissues. Full article

With the increasing popularity enjoyed by ultra-micro scale turbomachinery, designers are often faced with severe challenges due to the substantial phenomenological difference between the low-Reynolds fluid-dynamics in rotating or strongly curved flows and the established knowledge acquired through decades of theoretical and experimental studies on medium and large-scale machines. The problem is complicated by the absence of an extended and reliable database that might be used for preliminary design and provide indications for scale-up or scale-down. As a result, custom-designed experimental campaigns are necessary that make the development of any new machine exceedingly costly. The situation has seen some improvement in recent years, after the publication of a sufficient number of experimental results and numerical simulations that pave the way towards a development of semi-empirical correlations. The purpose of this work is to present and discuss a preliminary and simple method to extend the currently available design maps into the small scale range (Re < 10⁵) by introducing in the Balje charts an efficiency correction that depends on the specific speed n_s. The method results in a Stodola-like formula which originates a lower-than-standard Cordier curve on the classical Balje charts. A validation with some experimental results is also presented and discussed. Though the agreement is more than satisfactory, it must be stressed that the method provides only approximate results, and thus it must be considered as an evolving temporary solution, that needs to be updated as long as larger series of (numerical or physical) experimental results become available. Full article
