Raman Microspectroscopic Imaging of Binder Remnants in Historical Mortars Reveals Processing Conditions
Abstract
:1. Introduction
2. Materials and Methods
2.1. Samples
2.2. Raman Microspectroscopy
2.3. Scanning Electron Microscopy
3. Results and Discussion
3.1. Intensities of Marker Bands Provide Access to Distributions of Phases in Clinker Remnants in Early Cement Mortars
3.2. Raman Spectra Enable the Discrimination of Polymorphs of Cement Clinker Phases
3.3. Changes in Relative Band Intensities Visualise Different Crystal Orientations
3.4. Band Shifts Elucidate Stoichiometric Changes and Members of Solid Solution Series
3.5. Band Widths are Measures for Crystallinities and Provide Access to the Thermal History of Medieval Gypsum Mortars
4. Conclusions
Author Contributions
Funding
Acknowledgments
Conflicts of Interest
References
