Conditions of In Vitro Biofilm Formation by Serogroups of Listeria monocytogenes Isolated from Hass Avocados Sold at Markets in Mexico

by
María Guadalupe Avila-Novoa
1,
Velia Navarrete-Sahagún
1,
Jean Pierre González-Gómez
2,
Carolina Novoa-Valdovinos
1,
Pedro Javier Guerrero-Medina
1,
Ramón García-Frutos
3,
Liliana Martínez-Chávez
3,
Nanci Edid Martínez-Gonzáles
3 and
Melesio Gutiérrez-Lomelí
1,*
1
Centro de Investigación en Biotecnología Microbiana y Alimentaria, Departamento de Ciencias Básicas, División de Desarrollo Biotecnológico, Centro Universitario de la Ciénega, Universidad de Guadalajara, Av. Universidad 1115, Ocotlán 47810, Jalisco, Mexico
2
Laboratorio Nacional para la Investigación en Inocuidad Alimentaria (LANIIA), Centro de Investigación en Alimentación y Desarrollo A.C. (CIAD), Carretera a Eldorado Km. 5.5, Culiacán 80110, Sinaloa, Mexico
3
Departamentos de Farmacobiología y Matemáticas, CUCEI, Universidad de Guadalajara, Marcelino García Barragán 1451, Guadalajara 44430, Jalisco, Mexico
*
Author to whom correspondence should be addressed.
Foods 2021, 10(9), 2097; https://doi.org/10.3390/foods10092097
Submission received: 16 August 2021 / Revised: 31 August 2021 / Accepted: 3 September 2021 / Published: 5 September 2021
(This article belongs to the Special Issue Food Safety: Persistence of Listeria monocytogenes in Food Production Environments)
Browse Figures
Versions Notes

Abstract

:
Listeria monocytogenes is an important pathogen that has been implicated in foodborne illnesses and the recall of products such as fruit and vegetables. This study determines the prevalence of virulence-associated genes and serogroups and evaluates the effects of different growth media and environmental conditions on biofilm formation by L. monocytogenes. Eighteen L. monocytogenes isolates from Hass avocados sold at markets in Guadalajara, Mexico, were characterized by virulence-associated genes and serogroup detection with PCR. All isolates harbored 88.8% actA, 88.8% plcA, 83.3% mpl, 77.7% inlB, 77.7% hly, 66.6% prfA, 55.5% plcB, and 33.3% inlA. The results showed that 38.8% of isolates harbored virulence genes belonging to Listeria pathogenicity island 1 (LIPI-1). PCR revealed that the most prevalent serogroup was serogroup III (1/2b, 3b, and 7 (n = 18, 66.65%)), followed by serogroup IV (4b, 4d–4e (n = 5, 27.7%)) and serogroup I (1/2a–3a (n = 1, 5.5%)). The assessment of the ability to develop biofilms using a crystal violet staining method revealed that L. monocytogenes responded to supplement medium TSBA, 1/10 diluted TSBA, and TSB in comparison with 1/10 diluted TSB (p < 0.05) on polystyrene at 240 h (p < 0.05). In particular, the biofilm formation by L. monocytogenes (7.78 ± 0.03–8.82 ± 0.03 log10 CFU/cm2) was significantly different in terms of TSBA on polypropylene type B (PP) (p < 0.05). In addition, visualization by epifluorescence microscopy, scanning electron microscopy (SEM), and treatment (DNase I and proteinase K) revealed the metabolically active cells and extracellular polymeric substances of biofilms on PP. L. monocytogenes has the ability to develop biofilms that harbor virulence-associated genes, which represent a serious threat to human health and food safety.

Graphical Abstract

1. Introduction

Listeria monocytogenes is a bacterium ubiquitous in the environment and is the causative agent of listeriosis, leading to septicemia, encephalitis, endocarditis, meningitis, abortions, and stillbirths [1,2]. The severity of the pathology is associated with several at-risk groups, such as those with a weak immune system, adults >65 years, pregnant women, and newborn babies [3,4]. Listeria, Salmonella, and Shiga toxin-producing Escherichia coli (STEC) are the most common causes of hospitalizations (82%) and deaths (825) reported in outbreaks with a single confirmed etiology [5].
According to the Interagency Food Safety Analytics Collaboration (IFSAC) in 2018, foodborne L. monocytogenes illnesses are mostly attributed to fruit (32.5%) and vegetable row crops (11.6%) [6]. In particular, the FDA (2020–2021) issues recalls of vegetable products and fruits when they are associated with a potential risk of L. monocytogenes [7]. A recent sampling (May 2014 to November 2015) by the FDA demonstrated the prevalence of L. monocytogenes in samples of avocado fruit pulp (0.24%) and skin (17.33%) [8]. Clearly, avocados have a high lipid (saturated, polyunsaturated, and monounsaturated fatty acids) and moisture content, a non-acidic pH level, and low carbohydrates, which can make them a favorable growth medium for L. monocytogenes. In addition, the fresh produce supply chain is complex, with increasing potential sources of L. monocytogenes contamination. For example, contamination from irrigation water, fertilization with contaminated manure and contaminated soil (agricultural practices), cross-contamination from surfaces contaminated with pathogens, food spoilage, improper manipulation by food handlers, or processing fresh produce into fresh-cut products increases the risk of bacterial growth by breaking the fruit’s skin and allowing for the spread and potential growth of any pathogens that may be present [3,8,9,10,11,12].
Determining the virulence potential of L. monocytogenes is important in terms of public health, as is risk identification in ready-to-eat (RTE) fruits and vegetables because they provide critical information regarding food sources of listeriosis [13]. Currently, L. monocytogenes consists of four major evolutionary lineages (I, II, III, and rare lineage IV), including 14 recognized serotypes of L. monocytogenes that are grouped into four PCR serogroups [13,14,15,16]. In addition, L. monocytogenes has the ability to develop a biofilm and is thus persistent in food-processing environments and can be a subsequent source of contamination, representing a serious concern for human health and food safety [1,11,17,18,19,20,21]. Biofilm confers advantages to pathogens and food spoilage, such as desiccation resistance, as well as UV and chemical protection [18,22,23].
Previous research has demonstrated the persistence of L. monocytogenes associated with biofilm formation; however, it is a complex system regulated by environmental and genetic factors of the strains. In fact, extracellular polymeric substances (EPS), apart from contributing to adhesion to the surface and for cohesion in the biofilm, have the function of protecting individual cells from environmental stress [20].
Therefore, it is important to know the behavior of L. monocytogenes in the environment and in components of the biofilm matrix and to generate new strategies for the prevention or removal of biofilm from fresh produce. It is also critical to determine the prevalence of serogroups of L. monocytogenes and their virulence potential, which is necessary to understand their diversity. Hence, the objectives of this research were (i) to determine the prevalence of virulence-associated genes and serogroups of L. monocytogenes from Hass avocados, (ii) to evaluate the effects of different growth media and environmental conditions on biofilm formation by L. monocytogenes, and (iii) to determine the components of the extracellular matrix in L. monocytogenes biofilm.

2. Materials and Methods

2.1. L. monocytogenes Isolates

In total, 18 L. monocytogenes isolates were evaluated in this study, which were previously obtained from Hass avocados sold at retail markets in Guadalajara, Mexico [12]. Stocks of L. monocytogenes were stored using the protocol described by Avila-Novoa et al. [24]. Working cultures of L. monocytogenes were maintained in tryptic soy broth (TSB; Becton Dickinson Bioxon, Le Pont de Claix, France) with 0.6% yeast extract (TSBYE) (Sigma-Aldrich, St. Louis, MO, USA) and confirmed by PCR.

2.2. PCR-Serogroup Analysis and Virulence Genes

Bacterial DNA was extracted from 24 h/30 °C cultures in TBSYE using the protocol described by Avila-Novoa et al. [24]. All L. monocytogenes strains were investigated for the detection of prfA, plcA, hly, mpl, actA, plcB, inlA, and inlB genes by PCR using the protocol by Montero et al. [25]. The amplification conditions used were as follows: 5 min at 94 °C; 35 cycles of 40 s at 94 °C, 75 s at different temperatures for different genes, and 75 s at 72 °C; followed by a final extension of 10 min at 72 °C (Table 1). Alternatively, the serogroups of L. monocytogenes isolates were determined by Doumith et al. [14] for the detection of the four PCR serogroups of L. monocytogenes, as described: I (1/2a and 3a), II (1/2c and 3c), III (1/2b, 3b, and 7), and IV (4b, 4d, and 4e). L. monocytogenes ATCC 19111 was used as the positive control.

2.3. Biofilm Formation Assay

The ability of the strains to form biofilms was assessed in four culture media (TSB, 1/10 diluted TSB, TSBA (TSB + 1% Hass avocado residues), 1/10 diluted TSBA (1/10 TSB + 1% Hass Avocado residues)) in polystyrene microtiter plates (Corning® 96-Well Assay Microplate, Lowell, MA, USA) using crystal violet (CV) staining as described by Stepanović et al. [26] and Lee et al. [27], with some modifications. For each of the strains, 230 μL of each of the culture media (TSB, 1/10 diluted TSB, TSBA, 1/10 diluted TSBA) + 20 μL bacterial suspension (~108 CFU/mL) were incorporated; this was done in triplicate. Wells filled with broth medium (TSB, 1/10 diluted TSB, TSBA, 1/10 diluted TSBA) were used as negative controls, and L. monocytogenes ATCC 19111 was used as the positive control. Then, the plates were incubated at 30 °C for 48 h and 240 h. Afterwards, the planktonic bacteria were removed with phosphate-buffered saline (PBS; 7 mM Na2HPO4, 3 mM NaH2PO4 and 130 mM NaCl, pH 7.4) and the biofilm was fixed with methanol for 5 min and stained with 100 µL of 0.1% crystal violet solution for 15 min. The excess stain was rinsed off with sterile water and resolubilized with 33% (v/v) glacial acetic acid. Absorbance was measured at 570 nm (OD570), using a Multiskan FC (Thermo Fisher Scientific, Inc., Madison, WI, USA). The cutoff OD (ODc) was defined using the protocol described by Stepanović et al. [26].

2.4. Conditions and Quantification of Mono-Species Biofilms

Biofilms were developed on PP coupons (polypropylene type B (2 × 0.7 × 0.2 cm; Plásticos Tarkus, Jalisco, Mexico)), using the protocol described by Avila-Novoa et al. [24] for 240 h at 30 °C in 10 mL of 4 different media: TSB, 1/10 diluted TSB, TSBA, and 1/10 diluted TSBA, and inoculated with 100 μL of the corresponding strain of L. monocytogenes (~108 CFU/mL). The quantification was carried out as described by Avila-Novoa et al. [24]. L. monocytogenes ATCC 19111 was used as the positive control.

2.5. Epifluorescence Microscopy and Scanning Electron Microscopy (SEM)

After incubation at 30 °C for 240 h, the PP coupons were removed and processed using the protocol described by Avila-Novoa et al. [24]. Alternatively, SEM was performed using the methodology described by Borucki et al. [22] and Fratesi et al. [28]. Biofilms were observed using a TESCAN Mira3 LMU scanning electron microscope (Brno-Kohoutovice; Czech Republic). L. monocytogenes ATCC 19111 was used as the positive control and a PP coupon without inoculum was included in all assays.

2.6. Determination of Biofilm Components

2.6.1. Matrix Characterization

Biofilm detachment assays were carried out as described by Fredheim et al. [29] and Avila-Novoa et al. [30]. Previously mature biofilms cultivated in TSB at 30 °C for 240 h in polystyrene microtiter plates were washed with 0.9% NaCl. The major components of L. monocytogenes biofilms were treated with (i) proteinase K (Promega, Madison, WI, USA) and (ii) 0.5 mg/mL DNase I (Roche, Mannheim, Germany) using the protocol described by Avila-Novoa et al. [24].

2.6.2. Phenotype Analysis of Biofilm Production

All L. monocytogenes strains were characterized phenotypically by culture on Congo red agar (CRA) plates according to the protocol described by Arciola et al. [31], with some modifications. Briefly, CRA was prepared with TSBYE, 30 g/L of glucose (Sigma-Aldrich, St. Louis, MO, USA), 15 g/L of bacteriological agar (Becton Dickinson Bioxon, Le Pont de Claix, France), and 40 mg/L of Congo red (Sigma-Aldrich, Steinheim, Germany). According to the macroscopic characteristics developed by L. monocytogenes in the CRA, they were interpreted as (a) biofilm producers: black colonies with a dry filamentous, or (b) nonproducers: smooth pink colonies.

2.7. Statistical Analysis

All the experiments were performed in triplicate, and the data were evaluated using analysis of variance (ANOVA), followed by a Fisher’s least significant difference (LDS) test, using the Statgraphics Centurion XVI software program (StatPoint Technologies, Inc., Warrenton, VA, USA).

3. Results

3.1. Prevalence of Virulence Genes and Distribution of L. monocytogenes Serogroups Based on PCR Analysis

All isolates harbored 88.8% actA, 88.8% plcA, 83.3% mpl, 77.7% inlB, 77.7% hly, 66.6% prfA, 55.5% plcB, and 33.3% inlA. Additionally, 38.8% of L. monocytogenes isolates were positive for the prfA, plcA, hly, mpl, actA, and plcB genes associated with Listeria pathogenicity island 1 (LIPI-1) (Table 2). Based on variable gene content, 18 isolates were divided into serogroup I (1/2a–3a (n = 1, 5.5%)), serogroup III (1/2b, 3b, and 7 (n = 18, 66.65%)), and serogroup IV (4b, 4d–4e (n = 5, 27.7%)).

3.2. Ability to Form Biofilms

All isolates of L. monocytogenes had a higher biomass biofilm in TSBA (OD570 = 0.071–0.350, respectively) and 1/10 diluted TSBA (OD570 = 0.070–0.291) in comparison with 1/10 diluted TSB (OD570 = 0.066–0.135) (p < 0.05) at 48 h. Furthermore, there was no significant difference between TSBA and 1/10 diluted TSBA (p > 0.05), TSB and 1/10 diluted TSB (p > 0.05), and TSBA and TSB (p > 0.05) at 48 h. Clearly, the development of the biofilm of L. monocytogenes was favored at 240 h (p < 0.05). In general, L. monocytogenes had a higher biomass biofilm in TSBA (OD570 = 0.161–0.447) in comparison with TSB (OD570 = 0.155–0.302; p < 0.05) and 1/10 diluted TSB (OD570 = 0.141–0.262; p < 0.05) at 240 h; there was no difference between TSBA and 1/10 diluted TSBA (OD570 = 0.173–0.441; p > 0.05). In addition, L. monocytogenes had a higher biomass biofilm in 1/10 diluted TSBA in comparison with 1/10 diluted TSB p < 0.05); there was no significant difference between 1/10 diluted TSBA and TSB (p > 0.05) at 240 h.
Finally, L. monocytogenes strains were classified as strong biofilm producers (22%), moderate biofilm producers (5.5–22%), or weak biofilm producers (38.8–77.7%) depending on the composition of the medium culture at 48 h. The mean OD570 values obtained by the quantitative biofilm production of L. monocytogenes strains in the different medium culture are shown in Table 3. However, L. monocytogenes strains were classified only as strong (5.5–61.1%) or moderate biofilm producers (38.8–94.4%) at 240 h (Table 3).
Alternatively, four strains of L. monocytogenes (Lm-303, Lm-320, Lm-352, and Lm-356) were selected depending on the serogroup type, strong biofilm producers, and genetic profile (Table 2 and Table 3). Table 4 describes the development of mono-species models considering strains and culture media. All the tested microorganisms showed a strong ability to develop biofilms on PP serogroup III (serotype 1/2b, 3b, and 7) (Lm-352 (7.78 ± 0.03 log10 CFU/cm2) and Lm-356 (7.84 ± 0.30 log10 CFU/cm2)) and serogroup IV (serotype 4b, 4d, and 4e) (Lm-303 (8.36 ± 0.01 log10 CFU/cm2) and Lm-320 (8.82 ± 0.03 log10 CFU/cm2)) in TSBA (p < 0.05). In addition, biofilms developed by Lm-303 were present in lower amounts than Lm-320 (p < 0.05).
Furthermore, L. monocytogenes biofilms on PP were observed as cells irreversibly attached and microcolonies of metabolically active cells examined by an epifluorescence microscope (Figure 1). Mono-species L. monocytogenes showed that cells were linked and embedded in dense EPS (Figure 2).

3.3. Quantification and Components of the Matrix Biofilm Formation

DNase I and proteinase K were used to determine the components that make up the matrix of the L. monocytogenes biofilm; we found eDNA (9.44–47.69%) and protein (16.90–46.82%) (p < 0.05). In turn, there was a difference between each of the L. monocytogenes strains that made up the groups (p < 0.05) (Table 5). It was determined that 100% of L. monocytogenes strains were biofilm producers on CRA (Figure 3).

4. Discussion

In recent years, the consumption of fruit and vegetables has increased; consequently, there have been L. monocytogenes outbreaks associated with foods such as enoki mushrooms, cantaloupe, frozen vegetables, and packaged salads [7]. In addition, L. monocytogenes has the ability to develop biofilms in a food environment [21]. Sixty percent of outbreaks are caused by biofilm-associated infections by pathogens and antimicrobial resistance, which have a significant impact on the food industry [32,33].
In our study, the analysis of serogroups by PCR revealed that 66.6% of the L. monocytogenes isolates from Hass avocado were identified as serogroup III (1/2b, 3b, and 7), 27.7% as IV (4b, 4d, and 4e), and 5.5% as serogroup I (1/2a and 3a). Other investigators have demonstrated a higher prevalence of some serotypes (1/2b, 3b, 1/2a, 1/2c, and 4b) in food or processing environments [20,25,34,35]. According to the CDC (2011), serotypes 1/2a and 1/2b were associated with 147 cantaloupe-associated listeriosis cases in 28 U.S. states in 2011 [36]. This could be relevant for food safety and public health, as it shows the diversity of serogroups of L. monocytogenes in Hass avocados. It is essential to confirm the serotype with the incorporation of techniques used for subtyping L. monocytogenes such as random amplification of polymorphic DNA-polymerase chain reaction (RAPD-PCR), repetitive extragenic palindromes-PCR (REP-PCR), and pulsed field gel electrophoresis (PFGE), which allow for the sources and mechanisms of contamination during food processing to be determined and fresh food produce to be commercialized, at the same time identifying serotypes related to disease outbreaks. Likewise, Roche et al. [37] argued that the virulence of L. monocytogenes is related to its serotype and lineage (I–IV).
Additionally, 38.8% of L. monocytogenes isolates had virulence-associated genes (LIPI-1) (Table 2). Montero et al. [25] and Vilchis-Rangel et al. [38] reported similar percentages (20–40%) for LIPI-1 in L. monocytogenes isolates from orange juice, vegetables, and frozen vegetables. Moreover, several studies have reported LIPI-1 in 100% of L. monocytogenes isolates from duck, beef, pork, chicken, vegetables, fried rice, fish, goat meat, pasteurized milk, and yogurt [13,39,40]. The wide range of virulence-associated L. monocytogenes genes found in this study could be associated with food type, sources, mechanisms of contamination during food processing and marketing, epidemiological factors, countries, geographical differences, the genetic diversity of strains, and methodologies for the serotyping of L. monocytogenes in food. Overall, 55.5% of L. monocytogenes isolates carried genes corresponding to LIPI-1. However, 5.5% of L. monocytogenes did not carry LIPI-1 in this study (Table 2). These results agree with those of Montero et al. [25] and Vilchis-Rangel et al. [38], who reported that virulence-associated genes (LIPI-1) were not detected in L. monocytogenes isolates collected from frozen vegetables, orange juice, and fresh vegetables. Montero et al. [25] argued that the absence of one of these genes did not imply that a strain was not virulent. L. monocytogenes strains are known to differ in virulence [20]. For example, multiple distinct genetic mechanisms (mutations in the inlA and prfA genes) could be responsible for natural virulence attenuation in L. monocytogenes [41].
Biofilm formation-associated genes including prfA, actA, inlA, and plcA that play a significant role in the survival and persistence of L. monocytogenes were analyzed in this study (n = 12, 66.6%; n = 16, 88.8%; n = 6, 33.3%; n = 16, 88.8%). Likewise, Kumar et al. [42] showed that the presence of hly, prfA, and LIPI-1 genes is required to develop biofilm by L. monocytogenes. However, non-detection of prfA is associated with an L. monocytogenes prfA* mutant, which has decreased virulence [43].
In this study, L. monocytogenes isolates from Hass avocados had a high capacity for biofilm formation in supplement medium (TSBA, 1/10 diluted TSBA) and TSB in comparison with 1/10 diluted TSB (p < 0.05) at 48–240 h. Similarly, other studies have reported a high capacity for biofilm formation on polystyrene by L. monocytogenes isolated from cheese-processing plants, cheeses, and milk samples [26,27,44]. In contrast to our results, Kadam et al. [45] demonstrated that L. monocytogenes biofilm production was higher in a minimal medium compared to a nutrient-rich medium. This could be due to the organic matter or food residues that favored preconditioning and irreversible adhesion for the formation of biofilm. In fact, several studies have reported that the adherence and formation of biofilm by L. monocytogenes on surfaces is affected by factors such as temperature, pH, medium, incubation time, strain, serotype, and certain fatty acids (iso-C14:0, anteiso-C15:0, and iso-C16:0) [46,47].
Accordingly, the development of the biofilm of L. monocytogenes was favored at 240 h (p < 0.05) in this study. The difference was associated with several factors. First, consider that in 48 h at 30 °C, it is possible that L. monocytogenes isolates are developing an irreversible adhesion phase or the formation of microcolonies is occurring, compared to at 240 h, where the cell density has increased and bacteria would be in the stage of maturation or dispersal. Researchers argue that the biofilm formation capacity of L. monocytogenes increases after 72 h and the biofilm maturation stage occurs at 240 h [48,49]. Several studies have argued for a possible correlation between the serotype or phylogenetic division and biofilm-forming ability [22,50,51]. In addition, a CV staining assay is used for biofilm biomass quantification, but does not reveal the number of viable cells within the biofilm matrix [52,53].
In this study, L. monocytogenes in mono-species biofilms (Lm-303, Lm-320, Lm-352, and Lm-356) had a higher cellular density in TSBA (7.78 ± 0.03–8.82 ± 0.03 log10 CFU cm−2; p < 0.05) in comparison with TSB, 1/10 diluted TSB, and 1/10 diluted TSBA at 240 h onto polypropylene type B (Table 4). In particular, Lm-133 had a lower cellular density in TSB, 1/10 diluted TSB, and TSBA in comparison with Lm-320 (p < 0.05). This may be associated with the biofilm formation capacity of this particular serotype, even though it is serogroup III (1/2b, 3b, and 7), and with intrinsic factors like the nutrient level in the culture medium. In addition, this agrees with previous studies demonstrating the biofilm-forming ability of L. monocytogenes on materials encountered in the food-processing industry, such as stainless steel, aluminum, polycarbonate, polypropylene, polyurethane, polyvinylchloride, silicone rubber, natural white rubber, PETG, PTFE, Lexan, Nitryl rubber, and glass [17,54].
However, Pan et al. [55] and Nilsson et al. [56] revealed that the serotype or strain origin can have an effect on the biofilm-forming behavior of L. monocytogenes. Hence, a biofilm is a complex system where the different stages of biofilm formation alternate, depending on many factors such the composition of the medium or different levels of nutrients, which can influence the cell–cell communication; this drives the physiological and metabolic processes within the biofilm and affects biofilm development [50,57]. In addition, the biofilm matrix contains one or more extracellular polymeric substances (EPS) such as polysaccharides, proteins, extracellular DNA (eDNA), lipids, polyglutamate, teichoic acids, humic substances, etc. [33,58,59].
Our epifluorescence microscopy results revealed the metabolically active cells in the microcolonies formed (Figure 1), and SEM was used to assess the biofilm architecture (EPS and embedded bacterial cells) (Figure 2) onto polypropylene type B. In particular, treatment with DNase I and proteinase K revealed the presence of proteins (16.90–46.82%) and eDNA (9.44–47.69%). In addition, on CRA, 100% of the L. monocytogenes isolates were biofilm producers, because the extracellular polysaccharides combine with the Congo red dye, demonstrating exopolysaccharides of L. monocytogenes (Figure 3).
These results agree with those of Jiao et al. [60] and Muthukrishnan et al. [61], who showed that extracellular proteins are a major EPS components of the biofilm dry mass. Likewise, Kadam et al. [45] showed the presence of eDNA after DNase I was added to the microtiter plates during biofilm formation by L. monocytogenes (strains 18 and 55). Recently, studies have reported the structural components of L. monocytogenes within the EPS, such as eDNA, proteins (InlA, BapL, PlcA, FlaA, PBP, and ActA), polysaccharides (poly-β-(1-4)-N-acetylmannosamine (poly-NAM), and teichoic acids (WTA and LTA)); moreover, their roles in bacterial adhesion and aggregation, and as a structural component within the biofilm that provides stability to the entire structure and horizontal gene transfer, have been revealed [18,62,63,64,65].
Additionally, EPS strengthen the survival of microorganisms embedded on a substratum; moreover, they decrease the effectiveness of disinfectants, having a similar effect as organic matter or food residues present on the surface, resulting in less disinfectant coming into contact with the microorganism and reducing the effectiveness of the disinfectant or antimicrobial agent [66,67,68,69,70]. Our results emphasize the importance of incorporating other types of materials into the food industry so that they do not allow for the adherence and formation of biofilms in fresh produce. However, the design of strategies for the prevention and/or removal of biofilms of L. monocytogenes will also be necessary. In addition, techniques such as confocal laser scanning microscopy (CLSM) to reveal the structural components that make up the biofilm matrix and serotyping of L. monocytogenes can be used to determine the sources and mechanisms of contamination during the processing and marketing of fresh food products.

5. Conclusions

L. monocytogenes has the ability to develop a biofilm that harbors virulence-associated genes (LIPI-1) of L. monocytogenes isolates from Hass avocados. This could be a relevant food safety and public health consideration. However, serotyping is required to determine the prevalence, severity, and association of serotypes of L. monocytogenes with the ability to develop biofilm. Our study showed that the development of biofilms of L. monocytogenes is affected by 1/10 diluted TSB at 48–240 h using a CV staining assay. However, the development of biofilms of L. monocytogenes had a higher cellular density in TSBA onto PP. Additionally, future research should consider the detection of genes involved in other islands of pathogenicity (LIPI-2, LIPI-3, and LIPI-4) of L. monocytogenes isolates from Hass avocados.

Author Contributions

Conceptualization, methodology, validation, formal analysis, investigation, data curation, writing—original draft preparation, and visualization, M.G.A.-N.; methodology and investigation, V.N.-S., J.P.G.-G., C.N.-V. and R.G.-F.; validation and formal analysis, P.J.G.-M., L.M.-C. and N.E.M.-G.; writing—review and editing, supervision, resources, project administration, and funding acquisition, M.G.-L. All authors have read and agreed to the published version of the manuscript.

Funding

This research received no external funding.

Institutional Review Board Statement

Not applicable.

Informed Consent Statement

Not applicable.

Data Availability Statement

The data used to support the findings of this study are available from the corresponding author upon request.

Conflicts of Interest

The authors declare no conflict of interest.

References

  1. Vázquez-Boland, J.A.; Kuhn, M.; Berche, P.; Chakraborty, T.; Domínguez-Bernal, G.; Goebel, W.; González-Zorn, B.; Wehland, J.; Kreft, J. Listeria pathogenesis and molecular virulence determinants. Clin. Microbiol. Rev. 2001, 14, 584–640. [Google Scholar] [CrossRef] [Green Version]
  2. Charlier, C.; Perrodeau, É.; Leclercq, A.; Cazenave, B.; Pilmis, B.; Henry, B.; Lopes, A.; Maury, M.; Moura, A.; Goffinet, F.; et al. Clinical features and prognostic factors of listeriosis: The MONALISA national prospective cohort study. Lancet Infect. Dis. 2017, 17, 510–519. [Google Scholar] [CrossRef]
  3. Smith, A.; Hearn, J.; Taylor, C.; Wheelhouse, N.; Kaczmarek, M.; Moorhouse, E.; Singleton, I. Listeria monocytogenes isolates from ready to eat plant produce are diverse and have virulence potential. Int. J. Food Microbiol. 2019, 299, 23–32. [Google Scholar] [CrossRef] [Green Version]
  4. CDC (Center for Disease Control and Prevention). Listeria Outbreak Linked to Fully Cooked Chicken. 2021. Available online: https://www.cdc.gov/listeria/outbreaks/precooked-chicken-07-21/index.html (accessed on 31 July 2021).
  5. Dewey-Mattia, D.; Manikonda, K.; Hall, A.J.; Wise, M.E.; Crowe, S.J. Surveillance for Foodborne Disease Outbreaks—United States, 2009–2015. MMWR Surveill. Summ. 2018, 67, 1–11. [Google Scholar] [CrossRef]
  6. IFSAC (Interagency Food Safety Analytics Collaboration). Foodborne Illness Source Attribution Estimates for 2018 Salmonella, Escherichia coli, Listeria monocytogenes, and Campylobacter Using Multi-Year Outbreak Surveillance Date, United States. Atlanta, Georgia and Washington, District of Columbia: U.S. Department of Health and Human Services, CDC, FDA, USDA/FSIS. 2000. Available online: https://www.cdc.gov/foodsafety/ifsac/pdf/P19-2018-report-TriAgency-508.pdf (accessed on 2 August 2021).
  7. CDC (Center for Disease Control and Prevention). List of Selected Multistate Foodborne Outbreak Investigations. 2021. Available online: https://www.cdc.gov/foodsafety/outbreaks/multistate-outbreaks/outbreaks-list.html (accessed on 2 August 2021).
  8. FDA (Food Drugs and Administration). Microbiological Surveillance Sampling: FY18-21 Fresh Herbs (Cilantro, Basil & Parsley) and Processed Avocado and Guacamole Assignments. 2021. Available online: https://www.fda.gov/food/sampling-protect-food-supply/microbiological-surveillance-sampling-fy18-19-fresh-herbs-cilantro-basil-parsley-and-processed (accessed on 2 August 2021).
  9. Hoelzer, K.; Oliver, H.F.; Kohl, L.R.; Hollingsworth, J.; Wells, M.T.; Wiedmann, M. Structured expert elicitation about Listeria monocytogenes scross-contamination in the environment of retail deli operations in the United States. Risk Anal. 2012, 32, 1139–1156. [Google Scholar] [CrossRef]
  10. Scollon, A.M.; Wang, H.; Ryser, E.T. Transfer of Listeria monocytogenes during mechanical slicing of onions. Food Control 2016, 65, 160–167. [Google Scholar] [CrossRef] [Green Version]
  11. Smith, A.; Moorhouse, E.; Monaghan, J.; Taylor, C.; Singleton, I. Sources and survival of Listeria monocytogenes on fresh, leafy produce. J. Appl. Microbiol. 2018, 125, 930–942. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  12. García-Frutos, R.; Martínez-Chávez, L.; Cabrera-Díaz, E.; Gutiérrez-González, P.; Montañez-Soto, J.L.; Varela-Hernández, J.J.; Martínez-Gonzáles, N.E. Salmonella, Listeria monocytogenes, and indicator microorganisms on hass avocados sold at retail markets in Guadalajara, Mexico. J. Food Prot. 2020, 83, 75–81. [Google Scholar] [CrossRef] [PubMed]
  13. Chen, Y.; Chen, M.; Wang, J.; Wu, Q.; Cheng, J.; Zhang, J.; Sun, Q.; Xue, L.; Zeng, H.; Lei, T.; et al. Heterogeneity, characteristics, and public health implications of Listeria monocytogenes in ready-to-eat foods and pasteurized milk in China. Front. Microbiol. 2020, 11, 642. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  14. Doumith, M.; Buchrieser, C.; Glaser, P.; Jacquet, C.; Martin, P. Differentiation of the major Listeria monocytogenes serovars by multiplex PCR. J. Clin. Microbiol. 2004, 42, 3819–3822. [Google Scholar] [CrossRef] [Green Version]
  15. Vázquez-Sánchez, D.; Galvão, J.A.; Oetterer, M. Contamination sources, serogroups, biofilm-forming ability and biocide resistance of Listeria monocytogenes persistent in tilapia-processing facilities. J. Food Sci. Technol. 2017, 54, 3867–3879. [Google Scholar] [CrossRef]
  16. Yin, Y.; Yao, H.; Doijad, S.; Kong, S.; Shen, Y.; Cai, X.; Tan, W.; Wang, Y.; Feng, Y.; Ling, Z.; et al. A hybrid sub-lineage of Listeria monocytogenes comprising hypervirulent isolates. Nature 2019, 10, 4283. [Google Scholar] [CrossRef] [Green Version]
  17. Beresford, M.R.; Andrew, P.W.; Shama, G. Listeria monocytogenes adheres to many materials found in food-processing environments. J. Appl. Microbiol. 2001, 90, 1000–1005. [Google Scholar] [CrossRef] [PubMed]
  18. Colagiorgi, A.; Di Ciccio, P.; Zanardi, E.; Ghidini, S.; Ianieri, A. A Look inside the Listeria monocytogenes Biofilms Extracellular Matrix. Microorganisms 2016, 4, 22. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  19. Piercey, M.J.; Hingston, P.A.; Truelstrup, H.L. Genes involved in Listeria monocytogenes biofilm formation at a simulated food processing plant temperature of 15 °C. Int. J. Food Microbiol. 2016, 223, 63–74. [Google Scholar] [CrossRef] [PubMed]
  20. Buchanan, R.L.; Gorris, L.G.M.; Hayman, M.M.; Jackson, T.C.; Whiting, R.C. A review of Listeria monocytogenes: An update on outbreaks, virulence, dose-response, ecology, and risk assessments. Food Control 2017, 75, 1–13. [Google Scholar] [CrossRef]
  21. Sadekuzzaman, M.; Yang, S.; Mizan, M.F.R.; Kim, H.S.; Ha, S.D. Effectiveness of a phage cocktail as a biocontrol agent against L. monocytogenes biofilms. Food Control 2017, 78, 256–263. [Google Scholar] [CrossRef]
  22. Borucki, M.K.; Peppin, J.D.; White, D.; Loge, F.; Call, D.R. Variation in Biofilm Formation among Strains of Listeria monocytogenes. Appl. Environ. Microbiol. 2003, 69, 7336–7342. [Google Scholar] [CrossRef] [Green Version]
  23. Flemming, H.C.; Wingender, J.; Szewzyk, U.; Steinberg, P.; Rice, S.A.; Kjelleberg, S. Biofilms: An emergent form of bacterial life. Nat. Rev. Microbiol. 2016, 14, 563–575. [Google Scholar] [CrossRef]
  24. Avila-Novoa, M.G.; Guerrero-Medina, P.J.; Navarrete-Sahagún, V.; Gómez-Olmos, I.; Velázquez-Suárez, N.Y.; De la Cruz-Color, L.; Gutiérrez-Lomelí, M. Biofilm formation by multidrug-resistant serotypes of Salmonella isolated from fresh products: Effects of nutritional and environmental conditions. Appl. Sci. 2021, 11, 3581. [Google Scholar] [CrossRef]
  25. Montero, D.; Bodero, M.; Riveros, G.; Lapierre, L.; Gaggero, A.; Vidal, R.M.; Vidal, M. Molecular epidemiology and genetic diversity of Listeria monocytogenes isolates from a wide variety of ready-to-eat foods and their relationship to clinical strains from listeriosis outbreaks in Chile. Front. Microbiol. 2015, 6, 384. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  26. Stepanović, S.; Ćirković, I.; Ranin, L.; Švabić-Vlahović, M. Biofilm formation by Salmonella spp. and Listeria monocytogenes on plastic surface. Lett. Appl. Microbiol. 2004, 38, 428–432. [Google Scholar] [CrossRef]
  27. In Lee, S.H.; Barancelli, G.V.; de Camargo, T.M.; Corassin, C.H.; Rosim, R.E.; Gomes, A.C.; Pereira, C.L.; Fernandes, C.A.O. Biofilm-producing ability of Listeria monocytogenes isolates from Brazilian cheese processing plants. Food Res. Int. 2017, 91, 88–91. [Google Scholar] [CrossRef] [PubMed]
  28. Fratesi, S.E.; Lynch, F.L.; Kirkland, B.L.; Brown, L.R. Effects of SEM Preparation Techniques on the Appearance of Bacteria and Biofilms in the Carter Sandstone. J. Sediment. Res. 2004, 74, 858–867. [Google Scholar] [CrossRef]
  29. Fredheim, E.G.A.; Klingenberg, C.; Rohde, H.; Frankenberger, S.; Gaustad, P.; Flægstad, T.; Sollid, J.E. Biofilm formation by Staphylococcus haemolyticus. J. Clin. Microbiol. 2009, 47, 1172–1180. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  30. Avila-Novoa, M.G.; González-Gómez, J.P.; Guerrero-Medina, P.J.; Cardona-López, M.A.; Ibarra-Velazquez, L.M.; Velazquez-Suarez, N.Y.; Morales-Del Río, J.A.; Gutiérrez-Lomelí, M. Staphylococcus aureus and methicillin-resistant S. aureus (MRSA) strains isolated from dairy products: Relationship of ica-dependent/independent and components of biofilms produced in vitro. Int. Dairy J. 2021, 119, 105066. [Google Scholar] [CrossRef]
  31. Arciola, C.R.; Baldassarri, L.; Montanaro, L. Presence of icaA and icaD genes and slime production in a collection of staphylococcal strains from catheter-associated infections. J. Clin. Microbiol. 2001, 39, 2151–2156. [Google Scholar] [CrossRef] [Green Version]
  32. Han, Q.; Song, X.; Zhang, Z.; Fu, J.; Wang, X.; Malakar, P.K.; Lui, H.; Pan, Y.; Zhao, Y. Removal of foodborne pathogen biofilms by acidic electrolyzed water. Front. Microbiol. 2017, 8, 988. [Google Scholar] [CrossRef] [Green Version]
  33. Zhao, X.; Zhao, F.; Wang, J.; Zhong, N. Biofilm formation and control strategies of foodborne pathogens: Food safety perspectives. RSC Adv. 2017, 7, 36670–36683. [Google Scholar] [CrossRef] [Green Version]
  34. Korsak, D.; Borek, A.; Daniluk, S.; Grabowska, A.; Pappelbaum, K. Antimicrobial susceptibilities of Listeria monocytogenes strains isolated from food and food processing environment in Poland. Int. J. Food Microbiol. 2012, 158, 203–208. [Google Scholar] [CrossRef]
  35. Laksanalamai, P.; Huang, B.; Sabo, J.; Burall, L.S.; Zhao, S.; Bates, J.; Datta, A.R. Genomic characterization of novel Listeria monocytogenes serotype 4b variant strains. PLoS ONE 2014, 9, 89024. [Google Scholar] [CrossRef] [Green Version]
  36. Lomonaco, S.; Verghese, B.; Gerner-Smidt, P.; Tarr, C.; Gladney, L.; Joseph, L.; Katz, L.; Turnsek, M.; Frace, M.; Chen, Y.; et al. Novel Epidemic Clones of Listeria United States. Emerg. Infect. Dis. 2013, 19, 147–150. [Google Scholar] [CrossRef]
  37. Roche, S.M.; Grépinet, O.; Kerouanton, A.; Ragon, M.; Leclercq, A.; Témoin, S.; Schaeffer, B.; Skorski, G.; Mereghetti, L.; Le Monnier, A.; et al. Polyphasic characterization and genetic relatedness of low-virulence and virulent Listeria monocytogenes isolates. BMC Microbiol. 2012, 12, 304. [Google Scholar] [CrossRef] [Green Version]
  38. Vilchis-Rangel, R.E.; Espinoza-Mellado, M.R.; Salinas-Jaramillo, I.J.; Martinez-Peña, M.D.; Rodas-Suárez, O.R. Association of Listeria monocytogenes LIPI-1 and LIPI-3 marker llsX with invasiveness. Curr. Microbiol. 2019, 76, 637–643. [Google Scholar] [CrossRef]
  39. Su, X.; Zhang, J.; Shi, W.; Yang, X.; Li, Y.; Pan, H.; Kuang, D.; Xu, X.; Shi, X.; Meng, J. Molecular characterization and antimicrobial susceptibility of Listeria monocytogenes isolated from foods and humans. Food Control 2016, 70, 96–102. [Google Scholar] [CrossRef]
  40. Osman, K.M.; Kappell, A.D.; Fox, E.M.; Orabi, A.; Samir, A. Prevalence, pathogenicity, virulence, antibiotic resistance, and phylogenetic analysis of biofilm producing Listeria monocytogenes isolated from different ecological niches in Egypt: Food, humans, animals, and environment. Pathogens 2019, 9, 5. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  41. López, V.; Navas, J.; Martínez-Suárez, J.V. Low potential virulence associated with mutations in the inla and prfa genes in Listeria monocytogenes isolated from raw retail poultry meat. J. Food Prot. 2013, 76, 129–132. [Google Scholar] [CrossRef]
  42. Kumar, S.; Parvathi, A.; George, J.; Krohne, G.; Karunasagar, I.; Karunasagar, I. A study on the effects of some laboratory-derived genetic mutations on biofilm formation by Listeria monocytogenes. World J. Microbiol. Biotechnol. 2009, 25, 527–531. [Google Scholar] [CrossRef]
  43. Scortti, M.; Monzó, H.J.; Lacharme-Lora, L.; Lewis, D.A.; Vázquez-Boland, J.A. The PrfA virulence regulon. Microbes Infect. 2007, 9, 1196–1207. [Google Scholar] [CrossRef] [PubMed]
  44. Osman, K.M.; Samir, A.; Abo-Shama, U.H.; Mohamed, E.H.; Orabi, A.; Zolnikov, T. Determination of virulence and antibiotic resistance pattern of biofilm producing Listeria species isolated from retail raw milk. BMC Microbiol. 2016, 16, 1–13. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  45. Kadam, S.R.; den Besten, H.M.W.; van der Veen, S.; Zwietering, M.H.; Moezelaar, R.; Abee, T. Diversity assessment of Listeria monocytogenes biofilm formation: Impact of growth condition, serotype and strain origin. Int. J. Food Microbiol. 2013, 165, 259–264. [Google Scholar] [CrossRef] [PubMed]
  46. Chao, J.; Wolfaardt, G.M.; Arts, M.T. Characterization of pseudomonas aeruginosa fatty acid profiles in biofilms and batch planktonic cultures. Can. J. Microbiol. 2010, 56, 1028–1039. [Google Scholar] [CrossRef] [Green Version]
  47. Perez, L.J.; Ng, W.L.; Marano, P.; Brook, K.; Bassler, B.L.; Semmelhack, M.F. Role of the CAI-1 fatty acid tail in the Vibrio cholerae quorum sensing response. J. Med. Chem. 2012, 55, 9669–9681. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  48. Keeney, K.; Trmcic, A.; Zhu, Z.; Delaquis, P.; Wang, S. Stress survival islet 1 contributes to serotype-specific differences in biofilm formation in Listeria monocytogenes. Lett. Appl. Microbiol. 2018, 67, 530–536. [Google Scholar] [CrossRef]
  49. De Oliveira, M.M.; Brugnera, D.F.; Alves, E.; Piccoli, R.H. Biofilm formation by Listeria monocytogenes on stainless steel surface and biotransfer potential. Braz. J. Microbiol. 2010, 41, 97–106. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  50. Djordjevic, D.; Wiedmann, M.; McLandsborough, L.A. Microtiter plate assay for assessment of Listeria monocytogenes biofilm formation. Appl. Environ. Microbiol. 2002, 68, 2950–2958. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  51. Takahashi, H.; Miya, S.; Igarashi, K.; Suda, T.; Kuramoto, S.; Kimura, B. Biofilm formation ability of Listeria monocytogenes isolates from raw ready-to-eat seafood. J. Food Prot. 2009, 72, 1476–1480. [Google Scholar] [CrossRef]
  52. Pantanella, F.; Valenti, P.; Natalizi, T.; Passeri, D.; Berlutti, F. Analytical techniques to study microbial biofilm on abiotic surfaces: Pros and cons of the main techniques currently in use. Ann Ig 2013, 25, 31–42. [Google Scholar]
  53. Azeredo, J.; Azevedo, N.F.; Briandet, R.; Cerca, N.; Coenye, T.; Costa, A.R.; Desvaux, M.; Di Bonaventura, G.D.; Hébraud, M.; Jaglic, Z.; et al. Critical review on biofilm methods. Crit. Rev. Microbiol. 2017, 43, 313–351. [Google Scholar] [CrossRef] [Green Version]
  54. Di Bonaventura, G.; Piccolomini, R.; Paludi, D.; D’Orio, V.; Vergara, A.; Conter, M.; Ianieri, A. Influence of temperature on biofilm formation by Listeria monocytogenes on various food-contact surfaces: Relationship with motility and cell surface hydrophobicity. J. Appl. Microbiol. 2008, 104, 1552–1561. [Google Scholar] [CrossRef]
  55. Pan, Y.; Breidt, F.; Kathariou, S. Competition of Listeria monocytogenes serotype 1/2a and 4b strains in mixed-culture biofilms. Appl. Environ. Microbiol. 2009, 75, 5846–5852. [Google Scholar] [CrossRef] [Green Version]
  56. Nilsson, R.E.; Ross, T.; Bowman, J.P. Variability in biofilm production by Listeria monocytogenes correlated to strain origin and growth conditions. Int. J. Food Microbiol. 2011, 150, 14–24. [Google Scholar] [CrossRef]
  57. Kocot, A.M.; Olszewska, M.A. Biofilm formation and microscopic analysis of biofilms formed by Listeria monocytogenes in a food processing context. LWT 2017, 84, 47–57. [Google Scholar] [CrossRef]
  58. Flemming, H.-C.; Wingender, J. The biofilm matrix. Nat. Rev. 2010, 8, 623–633. [Google Scholar] [CrossRef] [PubMed]
  59. Renier, S.; Hébraud, M.; Desvaux, M. Molecular biology of surface colonization by Listeria monocytogenes: An additional facet of an opportunistic Gram-positive foodborne pathogen. Environ. Microbiol. 2011, 13, 835–850. [Google Scholar] [CrossRef] [PubMed]
  60. Jiao, Y.; Cody, G.D.; Harding, A.K.; Wilmes, P.; Schrenk, M.; Wheeler, K.E.; Banfield, J.F.; Thelen, M.P. Characterization of extracellular polymeric substances from acidophilic microbial biofilms. Appl. Environ. Microbiol. 2010, 76, 2916–2922. [Google Scholar] [CrossRef] [Green Version]
  61. Muthukrishnan, G.; Quinn, G.A.; Lamers, R.P.; Diaz, C.; Cole, L.; Chen, S.; Cole, A.M. Exoproteome of Staphylococcus aureus reveals putative determinants of nasal carriage. J. Proteome Res. 2011, 10, 2064–2078. [Google Scholar] [CrossRef] [Green Version]
  62. Harmsen, M.; Lappann, M.; Knøchel, S.; Molin, S. Role of extracellular DNA during biofilm formation by Listeria monocytogenes. Appl. Environ. Microbiol. 2010, 76, 2271–2279. [Google Scholar] [CrossRef] [Green Version]
  63. Okshevsky, M.; Meyer, R.L. The role of extracellular DNA in the establishment, maintenance and perpetuation of bacterial biofilms. Crit. Rev. Microbiol. 2015, 41, 341–352. [Google Scholar] [CrossRef]
  64. Alhede, M.; Bjarnsholt, T.; Givskov, M.; Alhede, M. Pseudomonas aeruginosa biofilms. Mechanisms of immune evasion. Adv. Appl. Microbiol. 2014, 86, 1–40. [Google Scholar]
  65. Ibáñez de Aldecoa, A.L.; Zafra, O.; González-Pastor, J.E. Mechanisms and regulation of extracellular DNA release and its biological roles in microbial communities. Front. Microbiol. 2017, 8, 1390. [Google Scholar] [CrossRef] [Green Version]
  66. Thévenot, D.; Dernburg, A.; Vernozy-Rozand, C. An updated review of Listeria monocytogenes in the pork meat industry and its products. J. Appl. Microbiol. 2006, 101, 7–17. [Google Scholar] [CrossRef]
  67. Araújo, P.A.; Lemos, M.; Mergulhão, F.; Melo, L.; Simões, M. The influence of interfering substances on the antimicrobial activity of selected quaternary ammonium compounds. Int. J. Food Sci. 2013, 2013, 237581. [Google Scholar] [CrossRef] [Green Version]
  68. Chiang, W.C.; Nilsson, M.; Jensen, P.Ø.; Høiby, N.; Nielsen, T.E.; Givskov, M.; Tolker-Nielsen, T. Extracellular DNA shields against aminoglycosides in Pseudomonas aeruginosa biofilms. Antimicrob. Agents Chemother. 2013, 57, 2352–2361. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  69. Chaitiemwong, N.; Hazeleger, W.C.; Beumer, R.R. Inactivation of Listeria monocytogenes by disinfectants and bacteriophages in suspension and stainless steel carrier tests. J. Food Prot. 2014, 77, 2012–2020. [Google Scholar] [CrossRef] [PubMed]
  70. Lutskiy, M.Y.; Avneri-Katz, S.; Zhu, N.; Itsko, M.; Ronen, Z.; Arnusch, C.J.; Kasher, R. A microbiology-based assay for quantification of bacterial early stage biofilm formation on reverse-osmosis and nanofiltration membranes. Sep. Purif. Technol. 2015, 141, 214–220. [Google Scholar] [CrossRef]
Foods 10 02097 g001 550
Figure 1. Micrographs of biofilm of L. monocytogenes development on polypropylene type B (PP) by epifluorescence microscopy. The biofilms were developed at 30 °C for 240 h. (A) Lm-303 TSB; (B) Lm-320 in 1/10 diluted TSB; (C) Lm-356 in TSBA. The white bar scale indicates 5 µm.
Figure 1. Micrographs of biofilm of L. monocytogenes development on polypropylene type B (PP) by epifluorescence microscopy. The biofilms were developed at 30 °C for 240 h. (A) Lm-303 TSB; (B) Lm-320 in 1/10 diluted TSB; (C) Lm-356 in TSBA. The white bar scale indicates 5 µm.
Foods 10 02097 g001
Foods 10 02097 g002 550
Figure 2. Micrographs of biofilm of L. monocytogenes development on polypropylene type B (PP) by scanning electron microscopy (SEM). The biofilms were developed at 30 °C for 240 h. (A) Lm-303 TSB; (B) Lm-320 in 1/10 diluted TSB; (C) Lm-356 in TSBA.
Figure 2. Micrographs of biofilm of L. monocytogenes development on polypropylene type B (PP) by scanning electron microscopy (SEM). The biofilms were developed at 30 °C for 240 h. (A) Lm-303 TSB; (B) Lm-320 in 1/10 diluted TSB; (C) Lm-356 in TSBA.
Foods 10 02097 g002
Foods 10 02097 g003 550
Figure 3. Black colonies of the slime-producing L. monocytogenes: (A) Lm-352; (B) Lm-303; (C) Lm-356.
Figure 3. Black colonies of the slime-producing L. monocytogenes: (A) Lm-352; (B) Lm-303; (C) Lm-356.
Foods 10 02097 g003
Table
Table 1. Primers used in this study.
Table 1. Primers used in this study.
PrimersLength (bp)Sequence 5′—3′Tm (°C)
plcB723Forward5′-CAG CTC CGC ATG ATA TTG AC-3′58
Reverse5′-CTG CCA AAG TTT GCT GTG AA-3′
Inl 1A629Forward5′-GGC TGG GCA TAA CCA AAT TA-3′60
Reverse5′-CTT TTG GTG CCG TAG GT-3′
Inl 1B293Forward5′-CCT AAA CCT CCG ACC AAA CA-3′60
Reverse5′-CCA TTT CGC GCT TCT CTA TC-3′
prfA330Forward5′-ACC AAT GGG ATC CAC AAG AA-3′58
Reverse5′-GCT TCC CGT TAA TCG AAA AAT-3′
icA840Forward5′-TCC CAT TAG GTG GAA AAG CA-3′57
plcAReverse5′-CGG GGA AGT CCA TGA TTA GA-3′
Hly1100Forward5′-GTC TAC CAA TTG CGC AAC AA-3′57
Reverse5′-TGG TGT TTC CCG GTT AAA AG-3′
Mpl450Forward5′-AAA GGT GGA GAA ATT GAT TCG-3′62
Reverse5′-AGT GAT CGT ATT GTA GGC TGC TT-3′
actA571Forward5′-AAA CAG AAG AGC CAA GC-3′58
Reverse5′-TTC ACT TCG GGA TTT TCG TC-3′
Table
Table 2. Serogroups and genetic determinants of virulence of Listeria monocytogenes.
Table 2. Serogroups and genetic determinants of virulence of Listeria monocytogenes.
PCR-SerogroupsStrain IDGenetic Determinants of Virulence No. of Isolates (%)
prfAplcAhlymplactAplcBinlBinlA
ILm-334+−+++−−+
IIILm-132−−−−−−+−
Lm-237−+−++−+−
Lm-249+++++−+−
Lm-252−++++−++
Lm-253+++++−+−
Lm-304 *+++++++−
Lm-333 *+++++++−
Lm-335++−+++−−
Lm-336 *++++++++
Lm-352 *++++++−+
Lm-356 *+++++++−
Lm-357+++−+++−
IVLm-142−+−−−−−−
Lm-251−++++-++
Lm-303 *+++++++−
Lm-320 *+++++++−
Lm-332−+++++++
Total18 (100%)12 (66.6%)16 (88.88%)14 (77.7%)15 (83.3%)16 (88.8%)10 (55.5%)14 (77.7%)6 (33.3%)
* Positive isolates of all genes present in the Listeria pathogenicity island 1 (LIPI-1); Lm, Listeria monocytogenes. +, presence; – absence.
Table
Table 3. Biofilm formation by Listeria monocytogenes in different medium cultures and temperatures.
Table 3. Biofilm formation by Listeria monocytogenes in different medium cultures and temperatures.
TimeMedium CultureNo. of Strains (%) Polystyrene Microtiter Plates Biofilm Formation
Strong BiofilmModerate BiofilmWeak BiofilmNon-Biofilm
ProducersProducersProducersProducers
48 hTSBAa4 (22.2)07 (38.8)7 (38.8)
OD570 mean = 0.346 ± 0.007OD570 mean = 0.091 ± 0.007OD570 mean = 0.075 ± 0.000
1/10 diluted TSBAb4 (22.2)014 (77.7)0
OD570 mean = 0.289 ± 0.002OD570 mean = 0.076 ± 0.004
TSBc01 (5.5)17 (94.4)0
OD570 mean = 0.210 ± 0.014OD570 mean = 0.093 ± 0.018
1/10 diluted TSBd04 (22.2)14 (77.7)0
OD570 mean = 0.125 ± 0.006OD570 mean = 0.072 ± 0.002
240 hTSBAa6 (33.3)12 (66.6)00
OD570 mean = 0.402 ± 0.078OD570 mean = 0.218 ± 0.082
1/10 diluted TSBAb11 (61.1)7 (38.8)00
OD570 mean = 0.317 ± 0.013OD570 mean = 0.183 ± 0.018
TSBc1 (5.5)17 (94.4)00
OD570 mean = 0.302 ± 0.007OD570 mean = 0.226 ± 0.046
1/10 diluted TSBd3 (16.6)15 (83.3)00
OD570 mean = 0.275 ± 0.004OD570 mean = 0.183 ± 0.011
TSB: tryptic soy broth; 1/10 diluted TSB; TSBA (TSB with 1% Hass avocado residues); 1/10 diluted TSBA (1/10 TSB + 1% Hass avocado residues); OD570 values ± SDs obtained by polystyrene biofilm formation assays in the corresponding culture medium. The cutoff OD (ODc): TSBAa OD570 ≤ ODc570 0.078 = non-biofilm producers; 0.078 < OD570 ≤ 0.156 = weak biofilm; 0.156 < OD570 ≤ 0.312 = moderate biofilm producers; and 0.312 < OD570 = strong biofilm; 1/10 diluted TSBAb OD570 ≤ ODc570 0.059 = non-biofilm producers; 0.059 < OD570 ≤ 0.118 = weak biofilm; 0.118 < OD570 ≤ 0.236 = moderate biofilm producers; and 0.236 < OD570 = strong biofilm; TSBc OD570 ≤ ODc570 0.07 = non-biofilm producers; 0.07 < OD570 ≤ 0.14 = weak biofilm; 0.14 < OD570 ≤ 0.28 = moderate biofilm producers; and 0.28 < OD570 = strong biofilm; 1/10 diluted TSBd OD570 ≤ ODc570 0.057 = non-biofilm producers; 0.057 < OD570 ≤ 0.114 = weak biofilm; 0.114 < OD570 ≤ 0.228 = moderate biofilm producers; and 0.228 < OD570 = strong biofilm.
Table
Table 4. Cellular density of L. monocytogenes in mono-species biofilms.
Table 4. Cellular density of L. monocytogenes in mono-species biofilms.
Mono-Species BiofilmsCulture MediaLog10 CFU/cm2 ± SD A
Polypropylene Type B
Lm-303TSB7.54 ± 0.08 g
1/10 diluted TSB7.52 ± 0.06 g
TSBA8.36 ± 0.01 b
1/10 diluted TSBA7.54 ± 0.05 fg
Lm-320TSB7.60 ± 0.08 efg
1/10 diluted TSB7.59 ± 0.14 efg
TSBA8.82 ± 0.03 a
1/10 diluted TSBA7.49 ± 0.07 g
Lm-352TSB7.61 ± 0.12 defg
1/10 diluted TSB7.56 ± 0.09 efg
TSBA7.78 ± 0.03 cdefg
1/10 diluted TSBA7.66 ± 0.06 defg
Lm-356TSB7.67 ± 0.10 defg
1/10 diluted TSB7.61 ± 0.12 defg
TSBA7.84 ± 0.30 cdef
1/10 diluted TSBA7.61 ± 0.11 efg
Listeria monocytogenes ATCC 19111TSB7.66 ± 0.30 defg
1/10 diluted TSB7.92 ± 0.59 cd
TSBA8.01 ± 0.09 c
1/10 diluted TSBA7.85 ± 0.18 cde
A Values are the means of three tests ± standard deviation. B Values in the same column followed different lowercase letters are significantly different (p < 0.05). TSB: tryptic soy broth; TSBA: TSB with 1% avocado residues; 1/10 diluted TSBA: 1/10 diluted TSB with 1% avocado residues.
Table
Table 5. Biomass reduction of mono-species biofilms of Listeria monocytogenes isolates of Hass avocados.
Table 5. Biomass reduction of mono-species biofilms of Listeria monocytogenes isolates of Hass avocados.
SerogroupsMono-Species BiofilmsBiomass Reduction (%)
Proteinase KDNase I
ILm-33436.80 ± 0.10 e47.69 ± 0.04 a
IIILm-13238.98 ± 0.03 d7.86 ± 0.06 p
Lm-23732.67 ± 0.07 h28.96 ± 0.01 e
Lm-24919.80 ± 0.07 m6.67 ± 0.00 r
Lm-25218.38 ± 0.04 o11.91 ± 0.00 m
Lm-25312.48 ± 0.02 q13.35 ± 0.17 k
Lm-30416.90 ± 0.11 p14.59 ± 0.02 j
Lm-33334.79 ± 0.03 g9.75 ± 0.04 n
Lm-33525.33 ± 0.01 j44.54 ± 0.21 c
Lm-33626.18 ± 0.02 i44.87 ± 0.06 b
Lm-35240.82 ± 0.07 b18.85 ± 0.03 g
Lm-35635.36 ± 0.01 f9.46 ± 0.00 o
Lm-35746.82 ± 0.06 a16.95 ± 0.03 h
IVLm-14239.55 ± 0.06 c33.08 ± 0.00 d
Lm-25119.23 ± 0.07 n7.56 ± 0.03 q
Lm-30320.92 ± 0.03 l23.72 ± 0.00 f
Lm-32023.60 ± 0.11 k9.44 ± 0.0287 o
Lm-33216.92 ± 0.01 p12.83 ± 0.06 l
Listeria monocytogenes ATCC 1911146.80 ± 0.01 a15.87 ± 0.01 i
Values are expressed as the means of three tests ± standard deviation. Values in the same column followed by different lowercase letters are significantly different (p < 0.05).
Publisher’s Note: MDPI stays neutral with regard to jurisdictional claims in published maps and institutional affiliations.

Share and Cite

MDPI and ACS Style

Avila-Novoa, M.G.; Navarrete-Sahagún, V.; González-Gómez, J.P.; Novoa-Valdovinos, C.; Guerrero-Medina, P.J.; García-Frutos, R.; Martínez-Chávez, L.; Martínez-Gonzáles, N.E.; Gutiérrez-Lomelí, M. Conditions of In Vitro Biofilm Formation by Serogroups of Listeria monocytogenes Isolated from Hass Avocados Sold at Markets in Mexico. Foods 2021, 10, 2097. https://doi.org/10.3390/foods10092097

AMA Style

Avila-Novoa MG, Navarrete-Sahagún V, González-Gómez JP, Novoa-Valdovinos C, Guerrero-Medina PJ, García-Frutos R, Martínez-Chávez L, Martínez-Gonzáles NE, Gutiérrez-Lomelí M. Conditions of In Vitro Biofilm Formation by Serogroups of Listeria monocytogenes Isolated from Hass Avocados Sold at Markets in Mexico. Foods. 2021; 10(9):2097. https://doi.org/10.3390/foods10092097

Chicago/Turabian Style

Avila-Novoa, María Guadalupe, Velia Navarrete-Sahagún, Jean Pierre González-Gómez, Carolina Novoa-Valdovinos, Pedro Javier Guerrero-Medina, Ramón García-Frutos, Liliana Martínez-Chávez, Nanci Edid Martínez-Gonzáles, and Melesio Gutiérrez-Lomelí. 2021. "Conditions of In Vitro Biofilm Formation by Serogroups of Listeria monocytogenes Isolated from Hass Avocados Sold at Markets in Mexico" Foods 10, no. 9: 2097. https://doi.org/10.3390/foods10092097

Note that from the first issue of 2016, this journal uses article numbers instead of page numbers. See further details here.

Article Metrics

Back to TopTop
