Generation of Multiple Vector Optical Bottle Beams

Khonina, Svetlana N.; Porfirev, Alexey P.; Volotovskiy, Sergey G.; Ustinov, Andrey V.; Fomchenkov, Sergey A.; Pavelyev, Vladimir S.; Schröter, Siegmund; Duparré, Michael

doi:10.3390/photonics8060218

Open AccessArticle

Generation of Multiple Vector Optical Bottle Beams

by

Svetlana N. Khonina

^1,2,*

,

Alexey P. Porfirev

¹,

Sergey G. Volotovskiy

¹,

Andrey V. Ustinov

¹,

Sergey A. Fomchenkov

^1,2,

Vladimir S. Pavelyev

^1,2,

Siegmund Schröter

³ and

Michael Duparré

³

¹

Image Processing Systems Institute—Branch of the Federal Scientific Research Centre, “Crystallography and Photonics” of Russian Academy of Sciences, 443001 Samara, Russia

²

Samara National Research University, 443086 Samara, Russia

³

Leibniz Institute of Photonic Technology (IPHT), 07745 Jena, Germany

^*

Author to whom correspondence should be addressed.

Photonics 2021, 8(6), 218; https://doi.org/10.3390/photonics8060218

Submission received: 12 May 2021 / Revised: 9 June 2021 / Accepted: 10 June 2021 / Published: 12 June 2021

(This article belongs to the Special Issue Polarized Light and Optical Systems)

Download

Browse Figures

Review Reports Versions Notes

Abstract

We propose binary diffractive optical elements, combining several axicons of different types (axis-symmetrical and spiral), for the generation of a 3D intensity distribution in the form of multiple vector optical ‘bottle’ beams, which can be tailored by a change in the polarization state of the illumination radiation. The spatial dynamics of the obtained intensity distribution with different polarization states (circular and cylindrical of various orders) were investigated in paraxial mode numerically and experimentally. The designed binary axicons were manufactured using the e-beam lithography technique. The proposed combinations of optical elements can be used for the generation of vector optical traps in the field of laser trapping and manipulation, as well as for performing the spatial transformation of the polarization state of laser radiation, which is crucial in the field of laser-matter interaction for the generation of special morphologies of laser-induced periodic surface structures.

Keywords: cylindrical vector beams; vector optical bottle; diffractive optical elements; axicon; polarization
