Simultaneous Biarticular Growth Modulation for Ipsilateral Concomitant Valgus Deformities of the Knee and Ankle: Short-Term Results of a Case Series
Highlights
- Simultaneous biarticular HED achieved physiological alignment in nearly all patients within a mean modulation period of 14.3 months.
- A two-stage termination strategy seems to prevent overcorrection in cases where joint correction rates of the knee and ankle joints diverged.
- For children with symptomatic CKAVD, simultaneous ipsilateral biarticular hemiepiphysiodesis (HED) may be considered as a treatment option, presented as feasible with promising short-term outcomes and a low complication rate.
- The possibility of a two-stage treatment termination by hardware removal should be considered.
Abstract
1. Introduction
2. Materials and Methods
2.1. Ethical Approval and Consent
2.2. Subjects
2.3. Intervention
2.4. Statistical Analysis
3. Results
3.1. Patients and Clinical Parameters
3.2. Interobserver Reliability
3.3. Radiological Outcomes
3.4. Complications
4. Discussion
5. Conclusions
Supplementary Materials
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Conflicts of Interest
Abbreviations
| aFTA | anatomic femorotibial angle |
| aLDFA | anatomic lateral distal femoral angle |
| MPTA | medial proximal tibial angle |
| CKAVD | concomitant knee and ankle valgus deformities |
| HED | hemiepiphysiodesis |
| LDTA | lateral distal tibial angle |
| ROC | rate of correction |
References
- Zajonz, D.; Schumann, E.; Wojan, M.; Kübler, F.B.; Josten, C.; Bühligen, U.; Heyde, C.E. Treatment of genu valgum in children by means of temporary hemiepiphysiodesis using eight-plates: Short-term findings. BMC Musculoskelet. Disord. 2017, 18, 456. [Google Scholar] [CrossRef] [PubMed]
- Burghardt, R.D.; Herzenberg, J.E. Temporary hemiepiphysiodesis with the eight-plate for angular deformities: Mid-term results. J. Orthop. Sci. 2010, 15, 699–704. [Google Scholar] [CrossRef] [PubMed]
- Stevens, P.M. Guided growth for angular correction: A preliminary series using a tension band plate. J. Pediatr. Orthop. 2007, 27, 253–259. [Google Scholar] [CrossRef] [PubMed]
- Rupprecht, M.; Spiro, A.S.; Breyer, S.; Vettorazzi, E.; Ridderbusch, K.; Stücker, R. Growth modulation with a medial malleolar screw for ankle valgus deformity. 79 children with 125 affected ankles followed until correction or physeal closure. Acta Orthop. 2015, 86, 611–615. [Google Scholar] [CrossRef] [PubMed]
- Driscoll, M.D.; Linton, J.; Sullivan, E.; Scott, A. Medial Malleolar Screw Versus Tension-band Plate Hemiepiphysiodesis for Ankle Valgus in the Skeletally Immature. J. Pediatr. Orthop. 2014, 34, 441–446. [Google Scholar] [CrossRef] [PubMed]
- Van Oosterbos, M.; Van Der Zwan, A.L.; Van Der Woude, H.J.; Ham, S.J. Correction of ankle valgus by hemiepiphysiodesis using the tension band principle in patients with multiple hereditary exostosis. J. Child. Orthop. 2016, 10, 267–273. [Google Scholar] [CrossRef] [PubMed]
- Noonan, K.J.; Feinberg, J.R.; Levenda, A.; Snead, J.; Wurtz, L.D. Natural history of multiple hereditary osteochondromatosis of the lower extremity and ankle. J. Pediatr. Orthop. 2002, 22, 120–124. [Google Scholar] [CrossRef]
- Stevens, P.M.; Kennedy, J.M.; Hung, M. Guided Growth for Ankle Valgus. J. Pediatr. Orthop. 2011, 31, 878–883. [Google Scholar] [CrossRef]
- Masquijo, J.J.; Artigas, C.; De Pablos, J. Growth modulation with tension-band plates for the correction of paediatric lower limb angular deformity: Current concepts and indications for a rational use. EFORT Open Rev. 2021, 6, 658–668. [Google Scholar] [CrossRef] [PubMed]
- Phemister, D.B. Operative arrestment of longitudinal growth of bones in the treatment of deformities. J. Bone Jt. Surg. Am. 1933, 15, 1–15. [Google Scholar]
- Lamm, B.M.; Paley, D. Deformity correction planning for hindfoot, ankle, and lower limb. Clin. Podiatr. Med. Surg. 2004, 21, 305–326. [Google Scholar] [CrossRef] [PubMed]
- Paley, D. Six-Axis Deformity Analysis and Correction. In Principles of Deformity Correction; Springer: Berlin/Heidelberg, Germany, 2002; pp. 411–436. [Google Scholar]
- Dimeglio, A. Growth in pediatric orthopaedics. J. Pediatr. Orthop. 2001, 21, 549–555. [Google Scholar] [CrossRef] [PubMed]
- Koo, T.K.; Li, M.Y. A Guideline of Selecting and Reporting Intraclass Correlation Coefficients for Reliability Research. J. Chiropr. Med. 2016, 15, 155–163, Erratum in J. Chiropr. Med. 2017, 16, 346. https://doi.org/10.1016/j.jcm.2017.10.001. [Google Scholar] [CrossRef] [PubMed] [PubMed Central]
- Danino, B.; Rödl, R.; Herzenberg, J.E.; Shabtai, L.; Grill, F.; Narayanan, U.; Segev, E.; Wientroub, S. Growth modulation in idiopathic angular knee deformities: Is it predictable? J. Child. Orthop. 2019, 13, 318–323. [Google Scholar] [CrossRef] [PubMed]
- Wiemann, J.M.; Tryon, C.; Szalay, E.A. Physeal Stapling Versus 8-plate Hemiepiphysiodesis for Guided Correction of Angular Deformity about the Knee. J. Pediatr. Orthop. 2009, 29, 481–485. [Google Scholar] [CrossRef] [PubMed]
- Rupprecht, M.; Spiro, A.S.; Rueger, J.M.; Stücker, R. Temporary Screw Epiphyseodesis of the Distal Tibia: A Therapeutic Option for Ankle Valgus in Patients with Hereditary Multiple Exostosis. J. Pediatr. Orthop. 2011, 31, 89–94. [Google Scholar] [CrossRef] [PubMed]
- Macneille, R.; Chen, J.; Segal, L.; Hennrikus, W. Hemiepiphysiodesis Using a Transphyseal Screw at the Medial Malleolus for the Treatment of Ankle Valgus Deformity. Foot Ankle Orthop. 2021, 6, 24730114211061494. [Google Scholar] [CrossRef] [PubMed]
- Shin, Y.-W.; Trehan, S.K.; Uppstrom, T.J.; Widmann, R.F.; Green, D.W. Radiographic Results and Complications of 3 Guided Growth Implants. J. Pediatr. Orthop. 2018, 38, 360–364. [Google Scholar] [CrossRef] [PubMed]
- Kumar, S.; Sonanis, S.V. Growth modulation for coronal deformity correction by using Eight Plates—Systematic review. J. Orthop. 2018, 15, 168–172. [Google Scholar] [CrossRef] [PubMed]


| Parameter | All | Female | Male | p-Value |
|---|---|---|---|---|
| Patients (n) | 21 | 7 | 14 | |
| unilateral [n (%)] bilateral [n (%)] | 4 (19%) 17 (81%) | 2 5 | 2 12 | 0.26 |
| underlying cause primary secondary | 12 9 | 3 4 | 9 5 | 0.32 |
| Body height (SD) in cm before growth modulation Range | 154 (14.7) 122–175 | 149.0 (16.5) 122–174 | 157.1 (13.6) 130–175 | 0.25 |
| Increase in body height (SD) in cm Range | 7 (4.08) 1.0–18.0 | 7.0 (4.55) 1.0–16.0 | 7.1 (4.01) 2.0–18.0 | 0.86 |
| Mean age at implantation (SD) in years Range | 11.5 (1.1) 9.3–14.0 | 10.8 (0.95) 9.3–12.0 | 11.9 (0.98) 10.8–14.0 | <0.05 |
| Modulation period (SD) in months Range | 14.3 (4.3) 8.1–24.2 | 13.8 (4.7) 9.7–23.3 | 14.5 (4.2) 8.1–24.2 | 0.71 |
| Mean age at termination (SD) in years Range | 12.7 (1.0) 11.2–14.9 | 11.92 (0.74) 11.2–13.2 | 13.09 (0.89) 12.0–14.9 | <0.05 |
| Parameter | All | p-Value 1 | Female | Male | p-Value 2 |
|---|---|---|---|---|---|
| Patients (n) | 21 | 7 | 14 | ||
| Legs (n) Left Right | 21 7 14 | 7 1 6 | 14 6 8 | 0.21 | |
| aFTA (n = 21) in degrees pre-operative (SD) post-correction (SD) Magnitude of correction ROC in degree/month (SD) | 168.0 (2.92) 175.0 (2.29) 6.9 (2.6) 0.46 (0.24) | <0.05 | 166.4 (2.2) 174.5 (0.8) 6.7 (1.3) 0.52 (0.15) | 168.9 (2.9) 175.2 (2.7) 5.6 (3.2) 0.43 (0.28) | 0.06 0.51 0.28 0.17 |
| LDTA (n = 21) in degrees pre-operative (SD) post-correction (SD) Magnitude of correction (SD) ROC in degree/month (SD) | 80.4 (3.2) 87.6 (2.8) 7.1 (3.0) 0.51 (0.22) | <0.05 | 79.9 (3.4) 87.3 (3.3) 7.4 (3.5) 0.53 (0.35) | 80.7 (3.3) 87.7 (2.7) 7.0 (2.9) 0.51 (0.21) | 0.63 0.74 0.82 0.81 |
| aLDFA (n = 13) in degree pre-operative (SD) post-correction (SD) Magnitude of correction (SD) ROC in degree/month (SD) | 76.4 (2.3) 83.1 (3.4) 6.7 (2.7) 0.34 (0.33) | <0.05 | 75.6 (2.9) 83.1 (4.1) 7.5 (2.1) 0.44 (0.35) | 76.8 (2.0) 81.7 (3.6) 4.9 (2.7) 0.30 (0.32) | 0.41 0.43 0.15 0.37 |
| MPTA (n = 7) in degree pre-operative (SD) post-correction (SD) Magnitude of correction (SD) ROC in degree/month (SD) | 93.4 (2.6) 86.1 (2.6) 7.2 (2.3) 0.46 (0.2) | <0.05 | 95.8 (2.1) 88.2 (1.0) 7.6 (1.3) 0.53 (0.15) | 92.0 (1.8) 85.0 (2.2) 7.0 (2.8) 0.42 (0.24) | 0.04 0.06 0.74 0.52 |
| Pre-Operative | Post-Correction | |||||||
|---|---|---|---|---|---|---|---|---|
| Parameter | aFTA | aLDFA | MPTA | LDTA | aFTA | aLDFA | MPTA | LDTA |
| ICC | 0.967 | 0.946 | 0.962 | 0.885 | 0.970 | 0.884 | 0.764 | 0.864 |
