A 2.53 NEF 8-bit 10 kS/s 0.5 μm CMOS Neural Recording Read-Out Circuit with High Linearity for Neuromodulation Implants
Abstract
:1. Introduction
2. Amplifier Architecture
3. ADC Architecture
3.1. Charge-Scaling DAC
3.2. Comparator
4. Measurement Results and Discussion
4.1. Amplifier Characterization
4.2. ADC Characterization
4.3. Neural Signal Amplification and Digitization
5. Conclusions
