Environmental Effects on the Electrical Characteristics of Back-Gated WSe2 Field-Effect Transistors
1
Physics Department “E. R. Caianiello” and Interdepartmental Centre NanoMates, University of Salerno, via Giovanni Paolo II n. 132, 84084 Fisciano, Italy
2
CNR-SPIN Salerno, via Giovanni Paolo II n. 132, 84084 Fisciano, Italy
3
AMBER & School of Chemistry, Trinity College Dublin, 2 Dublin, Ireland
*
Author to whom correspondence should be addressed.
Nanomaterials 2018, 8(11), 901; https://doi.org/10.3390/nano8110901
Received: 4 October 2018
/
Revised: 31 October 2018
/
Accepted: 1 November 2018
/
Published: 3 November 2018
(This article belongs to the Special Issue 2D Materials and Van der Waals Heterostructures: Physics and Applications)
We study the effect of polymer coating, pressure, temperature, and light on the electrical characteristics of monolayer back-gated transistors with contacts. Our investigation shows that the removal of a layer of poly(methyl methacrylate) (PMMA) or a decrease of the pressure change the device conductivity from p- to n-type. From the temperature behavior of the transistor transfer characteristics, a gate-tunable Schottky barrier at the contacts is demonstrated and a barrier height of 70 meV in the flat-band condition is measured. We also report and discuss a temperature-driven change in the mobility and the subthreshold swing that is used to estimate the trap density at the interface. Finally, from studying the spectral photoresponse of the , it is proven that the device can be used as a photodetector with a responsivity of at and optical power.
View Full-Text
Keywords:
2D materials; field effect transistors; PMMA; tungsten diselenide
▼
