Preparation of Remote Plasma Atomic Layer-Deposited HfO2 Thin Films with High Charge Trapping Densities and Their Application in Nonvolatile Memory Devices
Abstract
1. Introduction
2. Materials and Methods
2.1. Fabrication of Devices
2.2. Evaluation of Device Characteristics
3. Results and Discussion
4. Conclusions
