Terahertz Broadband Adjustable Absorber Based on VO2 Multiple Ring Structure
Abstract
1. Introduction
2. Structure Design and Simulation
3. Simulation Results
4. Discussion
5. Conclusions
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Conflicts of Interest
References
